Pelonis PTH21S4BRB Manual de usuario
INFRARED QUARTZ
HEATER
PTH21S4BRB
pelonis.com
USER MANUAL
en
PTH21S4BRB
Warning Notice: Before using
this product, please read this
manual carefully and keep it for
future reference. For additional
support, please call customer
service at 866-646-4332.
The design and specifications are
subject to change without prior
notice for product improvement.
Consult with your dealer or
the manufacturer for details.
When using electrical appliances,basic precautions should
always be followed to reduce the risk of fire,electric shock,
and injury to persons,including the following:
1. Read all instructions before using heater.
2. This heater is hot when in use. To avoid burns, do not let
bare skin touch hot surface. If provided, always use handles
when moving this heater. Keep combustible materials such as
furniture, pillows, bedding, papers, clothes and curtains at
least 3 feet (0.9m) from the front of the heater and keep them
away from the sides and rear.
3. Extreme caution is necessary when any heater is used by
or near children or invalids and whenever the heater is left
operating and unattended.
4. Always unplug the heater when not in use.
5. Do not operate any heater with a damaged cord or plug or
after the heater malfunctions, has been dropped or damaged
in any manner. Discard heater or return heater to authorized
service facility for examination, electrical or mechanical
adjustment, or repair.
6. Do not use the heater outdoors.
7. This heater is not intended for use in bathroom, laundry
areas and similar moist indoor locations. Never locate heater
where it may fall into a bathtub or other water container.
8. Do not run cord under carpeting. Do not cover cord with
throw rugs, runners, or similar coverings. Do not route cord
under furniture or appliances. Arrange cord away from traffic
area and where it will not be tripped over.
9. CAUTION: This appliance has a polarized plug (one blade
is wider than the other). To reduce the risk of shock, this plug
is intended to fit only one way in a polarized outlet. If the plug
PLEASE READ AND SAVE THESE IMPORTANT SAFETY
INSTRUCTIONS
SAFETY INSTRUCTIONS
1
2
does not fit fully in the outlet, reverse the plug. If it still does not
fit, contact a qualified electrician. DO NOT attempt to defeat this
safety feature. To do so could result in an electric shock hazard.
10. This heater draws 3.3 amps during operation. To prevent
overloading a circuit, do not plug the heater into a circuit that
already has other appliances working.
11. CAUTION: It is normal for the plug to feel warm to the
touch; however, a loose fit between the AC outlet and plug may
cause overheating and distortion of the plug. Contact a qualified
electrician to replace loose or worn outlet.
12. To disconnect the heater, first turn controls to off, then
remove plug from outlet. Never pull by the cord.
13. Do not insert or allow foreign objects to enter any ventilation
or exhaust opening as this may cause electric shock, fire, or
damage the heater.
14. CAUTION: Always plug heaters directly into a wall outlet.
Never use with an extension cord or relocatable power tap
(outlet/power strip).
15. A heater has hot and arcing or sparking parts inside. Do
not use it in the areas where gasoline, paint, or
flammable liquids are used or stored.
16. Use this heater only as described in this manual. Any
other use not recommended by the manufacturer may
cause fire, electric shock, or injury to persons.
17. The output of this heater may vary and its temperature may
become intense enough to burn exposed skin. Use of this
heater is not recommended for persons with reduced sensitivity
to heat or an inability to react to avoid burns.
18. Don't leave the heater on unattended.
19. To prevent a possible fire, do not block air intakes or
exhaust in any manner. Do not use on soft surfaces, like a bed,
where openings may become blocked.
ASSEMBLY
The heater is packed with body and base enclosure
separately. The whole machine is assembled by the follow
instructions.
ELECTRICAL RATINGS
This product is rated 3.3 amps (400W) at 120V, 60Hz.
PARTS AND FEATURES
B. Power and Setting Control
C. Safety Protect Bar
D. Front Cover
A. Carry Handle
E. Base Enclosure
F. Indicator light
BC
D
E
A
F
OPERATION INSTRUCTIONS
1. Place the heater on a firm,level surface free from obstruc-
tions,and at least 3 ft. (0.9m) away from any wall or combusti-
ble material.
2. With the Power and Setting Control in the OFF position,
plug the heater into a 120V outlet. Always operate the heater
in the upright position.
3. To tum the heater on,while turming the Power and Setting
Control to the desired position(LO for 180W,HI for 400W).
3
Aim in the direction when
two arrows coincide
Put the base enclosure
on the body
Rotate to the right to lock the
base enclosure
handle in the Front Cover when moving the heater.You may
notice vibration/noise coming from the grill and the Carbon
fiber heating tube when the heater tumed on. PLEASE NOTE
THAT THIS IS A NORMAL AND SAFE OPERATION. Once
the Carbon fiber heating element has warmed, the vibra-
tion/noise will go away.
5. As soon as the product is powered on, the indicator light
will go on, and will not go off until the product is dumped.
SAFETY FEATURES
Safety off Switch: This heater is equipped with an automatic
Safety Shut off Switch for overheat protection, which is acti-
vated when the internal temperature exceeds normal operat-
ing temperatures. If this occurs, turn the heater to “ OFF ”.
Unplug the heater and allow it to cool. Inspect and carefully
remove any objects on or adjacent to the heater. Plug the
heater back in and resume normal operation.
Tip Over Switch: This heater includes a Safety Tip-Over Pro-
tection Feature which will shut the heater off in case it is
tipped over. If, at any time, the heater does tip over, put the
heater back in the upright position. The heater will resume its
normal operation.
RESET INSTRUCTIONS
If the unit shuts down please operate as follows.
1.Turn the unit off
2.Unplug unit wait 10 minutes
3.Plug in and turn on
4
4. Turn the Power and Setting Control to OFF and unplug the
heater when you finish using it.
Note:The Safety Protect Bar will be hot while the heater is in
use. Do not use it as a carrying handle.Please use the carry
If you still notice the same defect above mentioned,remove
the plug from the socket and have the appliance serviced by
authorized service personnel only.
CARE AND MAINTENANCE
We recommend that the heater be cleaned at least once a
month and before off-season storage.
Turn the heater OFF and unplug it. Allow it to cool.
Use a dry cloth to clean the external surfaces of the heater.
DO NOT USE WATER, WAX, POLISH OR ANY CHEMICAL
SOLUTION.
Clean your heater using the above-mentioned steps, then
pack the heater in its original container and store it in a cool
dry place.
This heater does not disassemble.
SPECIFICATIONS
PTH21S4BRB
5
•
•
•
•
Model No.
Current
Power
Tolerances on all specifications
Voltage 120V 60Hz
LO=180W HI=400W
Not exceed than 105%
Maximum continuous draw: 3.3 Amps
Check for any obstruction,If you find an obstruction turm the
heater OFF. Unplug the heater and wait at least ten minutes
for it to cool.Carefully remove the obstruction. Plug the heater
back in and restart it as described under OPERATION.
IF YOUR HEATER FAILS TO OPERATE
Be sure it is plugged in and that the electrical outlet is work-
ing.
SERVICE AND SUPPORT
In the event of a warranty claim or if service is required for this product,
please contact us at the following:
Toll Free: 866-646-4332
For questions or comments, please write to:
Midea America Corp
759 Bloomfield Ave., # 386
West Caldwell, NJ 07006-6701
Email: customersupport@pelonis.com
For your records, staple your sales receipt to this manual and record the
following:
DATE OF PURCHASE: _____________________________________________
PLACE OF PURCHASE: ____________________________________________
(STAPLE SALES RECEIPT HERE)
NOTE: PROOF OF PURCHASE IS REQUIRED FOR ALL
WARRANTY CLAIMS
PRINTED IN CHINA
6
1 YEAR LIMITED WARRANTY
This is the only express warranty for this product and is in lieu of any
other warranty or condition.
This product is warranted to be free from defects in material and workmanship
for a period of one (1) year from the date of original purchase. During this
period, your exclusive remedy is repair or replacement of this product or any
component found to be defective, at our option; however, you are responsible
for all costs associated with returning the product to us and our returning the
product or component under this warranty to you. If the product or component
is no longer available, we will replace with a similar one of equal or greater
value.
This warranty does not cover wear from normal use, and operation doesn't
conformity with the instruction manuals, or damages to the product resulting
from accident, alteration, abuse, or misuse. This warranty extends only to the
original consumer purchaser or gift recipient. Keep the original sales receipt, as
proof of purchase is required to make a warranty claim. This warranty is void if
products is used for other than single-family household use or subjected to any
voltage and waveform other than as specified on the label.
We exclude all claims for special, incidental, and consequential damages by
breach of express or implied warranty. All liability is limited to amount of the
purchase price. Every implied warranty, including any statutory warranty or
condition of merchant-ability or fitness for particular purpose, is disclaimed
except to the extent prohibited by law, in which case such warranty or condition
is limited to the duration of this written warranty.
This warranty gives you specific legal rights. You may have other legal rights
that vary depending on where you live. Some states or provinces do not allow
limitations on implied warranties or special, incidental consequential damages,
so the foregoing limitations may not apply to you.
Please note that failure to complete and submit this form does not diminish your
warranty rights.
Customer Service:
Midea America Corp
759 Bloomfield Ave., # 386
West Caldwell, NJ 07006-6701
Phone: 866 646 4332
7
Tabla de contenidos
Otros manuales de Calentador de Pelonis
Pelonis
Pelonis PSH700G Manual de usuario
Pelonis
Pelonis PSH17PF2HDB Manual de usuario
Pelonis
Pelonis HO-202C Manual de usuario
Pelonis
Pelonis HC-0155M Manual de usuario
Pelonis
Pelonis HC-1010 Manual de usuario
Pelonis
Pelonis 1500W-II Manual de usuario
Pelonis
Pelonis Safe-T FURNACE HC-445 Manual de usuario
Pelonis
Pelonis HB-211 Manual de usuario
Pelonis
Pelonis NTH15-18MR Manual de usuario
Pelonis
Pelonis HB-215T Manual de usuario
Pelonis
Pelonis HC-451 Manual de usuario
Pelonis
Pelonis HF-0063 Manual de usuario
Pelonis
Pelonis CH1001 Manual de usuario
Pelonis
Pelonis NTK15A Manual de usuario
Pelonis
Pelonis PSH700R Manual de usuario
Pelonis
Pelonis PSH20Q3ABB Manual de usuario
Pelonis
Pelonis NF15-9BMB Manual de usuario
Pelonis
Pelonis HC-0113 Manual de usuario
Pelonis
Pelonis NY1506-18SRA Manual de usuario
Pelonis
Pelonis PSHF2022EOC Manual de usuario
Manuales populares de Calentador de otras marcas
Empire Heating Systems
Empire Heating Systems WCC65 Manual de usuario
Wetekom
Wetekom 92 86 43 Manual de usuario
Desa
Desa SPC170-F Manual de usuario
Watlow
Watlow Watrod Electric Tubular Heaters Manual de usuario
Haverland
Haverland ECO-DRY GPS Series Manual de lista de piezas
Stelpro
Stelpro ASILVC2060 Series Manual de usuario
