CYBERMAX AMP SE2

RF amplifiers for HF/VHF/UHF digital and analog appli ations

Manual

Brought to you by PCS Electronics, www.pcs-electronics.com

I M P O R T N T N O T E

t the time of receiving your order inspect the packaging material and unit for apparent

damage. ny damage should be reported immediately at the time of delivery with the

delivery service employee so we can make a claim with the shipping company later. lso

take photos; they may be used as a proof later.

IMPORT NT! Before you power up an amplifier please first make sure that drive power is

set correctly and does not exceed maximum allowable input power of the amplifier.

IMPORT NT! Never operate any amplifier without a properly tuned antenna or dummy load

attached.

IMPORT NT! Mains voltage is lethal! Whenever handling mains voltage be very careful and

observe safety regulations.

Study local regulations and ensure you are operating in compliance.

M KE SURE EXCITER OUTPUT POWER DOES NOT EXCEED MPLIFIER M XIMUM INPUT

POWER. EVEN VERY BRIEF OVERLO D OF YOUR MPLIFIER'S INPUT COULD C USE

D M GE TO THE MPLIFIER.

DO NOT FORGET TO CONNECT NTEN BEFORE YOU POWER UP THE MPLIFIER!

Brought to you by PCS Electronics, www.pcs-electronics.com

Table of Contents

Introducing the CYBERMAXAMP SE+ ..................................... 1

What makes this rack mounted amplifier so great? ........................ 1

Technical specifications: ................................................................. 1

RF section specifications for VHF model (Analog FM radio):.......... 1

RF section specifications for DAB+ model (digital FM radio): ......... 2

RF section specifications for analog TV model: .............................. 2

RF section specifications for digital TV model:................................ 2

Thank you for purchasing CYBERMAXAMP SE+ Amplifier ............ 2

Front and back panel layout ..................................................... 3

Using the CYBERMAXAMP SE+ Amplifier............................... 5

Lcd control module.......................................................................... 5

Lcd control module menu system ................................................... 5

Changing output power................................................................... 5

[AUTO FAN TEMP] ......................................................................... 6

[VIEW SELECT].............................................................................. 6

[SWR ALARM] ................................................................................ 6

[AMP TEMP ALARM]...................................................................... 6

[PSU TEMP ALARM] ...................................................................... 6

[CURENT ALARM].......................................................................... 6

[LCD CONTRAST] .......................................................................... 6

[SET PASSWORD] ......................................................................... 6

[OUTPUT LIMIT] ............................................................................. 6

Troubleshooting .............................................................................. 6

WINDOWS CONTROL PROGRAM – CYBERMAXAMP+........ 8

SOFTWARE INSTALLATION AND COMMUNICATION SETUP .... 8

Configuring communications port.................................................... 9

Installing USB driver (only for USB IO board) ............................... 10

Configuring USB driver ................................................................. 10

Appendix B – Setting up remote control via Ethernet ............. 11

Brought to you by PCS Electronics, www.pcs-electronics.com

Software installation...................................................................... 11

Appendix C – Warranty and legal info .................................... 14

Warranty and servicing! ................................................................ 14

Legal info ...................................................................................... 14

Limitation of liability....................................................................... 14

Also available from www.pcs-electronics.com .............................. 14

Revisions and errata .............................................................. 15

Index ...................................................................................... 16

Brought to you by PCS Electronics, www.pcs-electronics.com

Introducing the CYBERM X MP SE+

New family of our rack mounted amplifiers with new control board and many new features

Is your signal too weak? Boost it with this reliable and practical amplifier. It is very easy to use yet also provides all the bells

and whistles. This versatile and reliable new amplifier lets you monitor and set output power, monitor drive power, output

power, reflected power, several amplifier supply currents & voltages and 2 temperatures. ou can also set fan activation

temperature and several alarm levels. It also allows remote control via RS232, USB or Ethernet (optional upgrade).

What makes this rack mounted amplifier so great?

- Enables power adjustment without causing instability

- It automatically adapts the gain to your drive power - within reasonable limits, to obtain desired power output

- Supports up to 9,9KW (depending on the model)

- High-gain versions are available for DAB+ and DTV (digital TV)

- Models available for analog and digital FM radio, analog and digital TV or other HF/VHF/UHF services

- Can monitor up to 4 voltages and 4 currents

- Supports new 65V DC mains power supply models

- Automatic FAN activation at adjustable temperature.

- Power, SWR, voltage, current, drive power and temperature read-out.

- Remote monitoring available via USB, RS232 or Ethernet, communication protocol is available for free

Technical specifications:

- General power range for all models: 0 – 9900W (can be expanded if needed)

- Mains power: worldwide universal 110-240V 50/60Hz

- Ambient temperature: -5° to +45°C

- Over-current protection, overvoltage protection, overdrive protection, temperature protection

- Rack size depends on power rating, 2H and 3H units

RF section specifications for VHF model ( nalog FM radio):

- Output power: 200W/400W/600W/800W/1000W/1500W/2000W/3000W/5000W/10000W

- Output: 50 ohm (N female or 7/16 connector)

- VSWR less than 2:1 for full output

- Input connector: N female or BNC

- Drive power: 1W-20W depending on the model

- Frequency range: 87.5 to 108MHz

- RF Harmonics > -60 dBc Standard

- External dimensions 200W/400W ( W x D x H ) 19" x depth (170mm) x height 2HE (88mm), weight ~10Kg

- External dimensions 600W, 800W ( W x D x H ) 19" x depth (170mm) x height 2HE (88mm), weight ~12Kg

Chapter

Brought to you by PCS Electronics, www.pcs-electronics.com

- External dimensions 1000W, 1500W ( W x D x H ) 19" x depth (492mm) x height 2HE (88mm), weight ~15Kg

- External dimensions 2000W ( W x D x H ) 19" x depth (550mm) x height 3HE (132mm), weight ~25Kg

RF section specifications for D B+ model (digital FM radio):

- Output power: 25W (150W pp) or 400W (1200W pp)

- Output: 50 ohm (N female or 7/16 connector)

- VSWR less than 2:1 for full output

- Input connector: N female or BNC

- Drive power: 0.1mW to 10mW (high gain model) or 2-5W (regular model)

- Frequency range: 175MHz to 225MHz

- RF Harmonics: Mask filter not included

- External dimensions 25 ( W x D x H ) 19" x depth (170mm) x height 2HE (88mm), weight ~10Kg

- External dimensions 400W ( W x D x H ) 19" x depth (550mm) x height 3HE (132mm), weight ~25Kg

RF section specifications for analog TV model:

- Output power: 200W/400W/600W/1000W

- Output: 50 ohm (7/16 connector)

- VSWR less than 2:1 for full output

- Input connector: N female

- Drive power: 1W-20W depending on the model

- Frequency range: 175-855MHz depending on the model

- External dimensions 200W

- External dimensions 400W, 600W ( W x D x H ) 19" x depth (170mm) x height 2HE (88mm), weight ~12Kg

- External dimensions 1000W ( W x D x H ) 19" x depth (492mm) x height 2HE (88mm), weight ~15Kg

RF section specifications for digital TV model:

- Output power: 50W or 250W (1000W pp)

- Output: 50 ohm (7/16 connector)

- VSWR less than 2:1 for full output

- Input connector: N female

- Drive power: 0.01mW to 10mW

- Frequency range: 470MHz to 855MHz

- RF Harmonics: Mask filter not included

- External dimensions 50W ( W x D x H ) 19" x depth (170mm) x height 2HE (88mm), weight ~10Kg

- External dimensions 250W ( W x D x H ) 19" x depth (550mm) x height 3HE (132mm), weight ~25Kg

Thank you for purchasing CYBERM X MP SE+ mplifier

We hope you will enjoy it as much as we do and remember to tell your friends about it. Please feel free to leave your

comments at our website or post your experience in our forum. From all of us we wish you happy broadcasting!

our PCS Electronics team

Brought to you by PCS Electronics, www.pcs-electronics.com

Front and back panel layout

Fig. 1: Front panel for 3H model, 2H model is very similar

Referen e Fun tion

1 Control rotary button, everything is adjusted with this button

2 LCD display that lets you control the unit and monitor various parameters.

3 LED diodes showing power status, temp alarm, swr alarm, current alarm or general alarm.

4 Power switch in the middle of the panel is actually a standby switch. To really fully disconnect the unit

from mains power use the main switch at the back.

5 Monitor output at the front provides a small sample of the transmitter signal; this can be used to attach

frequency counter, modulation index monitor, spectrum analyzer or similar equipment.

6 VU bar meters. When used for amplifier they show drive power on two bars on the left. The third and

fourth bar are used for power and reflected power.

Chapter

Brought to you by PCS Electronics, www.pcs-electronics.com

Fig. 2: Back panel for 3H model, 2H model is very similar

Referen e Fun tion

1 Main mains switch (total off)

2 Mains power, universal input 110-240V, IEC jack (same as for PC)

3 Exchangeable power supply (you can replace it without any opening or soldering)

4 Antenna connector, 7/16 female. Do not operate without antenna.

5 N female for drive input

6 RS232/USB for remote control

7 Optional ETHERNET input

8 Optional DIGIAMP interface for easy connection to CyberMaxFM exciters

Brought to you by PCS Electronics, www.pcs-electronics.com

Using the CYBERM X MP SE+ mplifier

Power-up procedure

In order to have the auto-gain-adjustment function work correctly you have to follow proper power-up procedure:

1. Connect antenna

2. Connect mains power to amplifier (still powered off)

3. Using dummy load or antenna set exciter drive power in accordance with amplifier model

4. Connect exciter to amplifier and power it up

5. Power up the amplifier. If amplifier is in stand-by also press button on the front to return it from stand-by

6. Set desired output power with rotary button and wait for amplifier to adjust output (slow ramp-up).

7. Adjust any desired parameters as required

8. If you can’t reach rated output power please ensure antenna is well matched. If everything is OK you can try

to increase drive power a little.

9. If your output power is too high and amplifier is not able to regulate it so low (control range may be limited)

you can also reduce drive power slightly to obtain desired output.

10. IMPORTANT: Always follow this pro edure: First power up ex iter, only then the amplifier!

Lcd control module

There is a rotary button available on the left side of the display unit. ou can rotate this button LEFT, RIGHT or you can

PUSH it. By pushing it you enter the MENU system and move between the MENU options. LEFT and RIGHT let you

change the selected setting.

Lcd control module menu system

In normal mode the LCD simply shows the frequency and power or whatever view you select. Rotating left or right in this

mode will increase or decrease output power. Pressing the rotary button can be used to enter the menu mode, repeatedly

pressing this key brings up the following menus: [AUTO FAN TEMP], [VIEW SELECT], [LCD CONTRAST], ,

[ALARMS UP/DWN],[CURRENT ALARM], [TEMP ALARM], [SWR ALARM], [U AMP ALARM], [DRIVE LIMIT],

[OUTPUT LIMIT], [FIRMWARE VER], [SET PASSWORD] and [RAMP UP/DOWN]. Rotating LEFT/RIGHT key

selects the desired parameter and allows you to modify its value. Another press on the rotary button and you’re back to the

normal mode. Note that all these settings except power and frequency are already set as they should be so changing them

should not be necessary and is not recommended.

Note alarms are all gathered into deeper level of menu system (to reduce clutter). So when you get to [ALARMS UP/DWN]

you can either jump over the alarms submenues (if you press button you will move straight to drive limit) or enter the alarms

submenues by turning button left or right. Once in alarms submenues you can now select desired alarm menu by pressing

the button and turning LEFT/RIGHT to select it and than again LEFT/RIGHT to adjust value. It may sound a little

confusing right now but if you try it you will find that it works pretty well.

Changing output power

Chapter

Brought to you by PCS Electronics, www.pcs-electronics.com

Simply rotate LEFT/RIGHT to adjust power to desired percentage of max output power. Selected setting is displayed on

the LCD as a percentage. Power in watts is shown on the LCD next to this percentage. It may take a while for the amplifier

to adjust the power as it will adjust the gain to obtain desired power level.

Note: Rotating LEFT/RIGHT changes power also when you have set a view type which does not show set power output.

[ UTO F N TEMP]

This setting allows you to set automatic fan activation temperature. Select desired activation temperature. Setting this too

high may compromise reliability and long-term performance due to running at high temperature.

[VIEW SELECT]

Amplifier is capable of displaying a number of various parameters. Since the LCD real-estate is limited to 4x16 characters we

prepared a number of pre-programmed views that only show a selected number of parameters. ou can select desired view

to access all parameters. [Auto Scroll] shows each of the above listed views for a short while and than moves on to the next

in an endless loop. This way you can see all the relevant parameters without having to go through the menu system to

change the view type, ou just have to wait a few seconds for the view to change.

[SWR L RM]

This option allows you to set SWR alarm level.

[ MP TEMP L RM]

This option allows you to set AMP temp alarm level.

[PSU TEMP L RM]

This option allows you to set AMP temp alarm level.

[CURENT L RM]

This option allows you to set current alarm level.

[LCD CONTR ST]

LCD contrast adjustment.

[SET P SSWORD]

This option allows you to set password. For this to work a jumper must be installed on LCD module (jumper LOCK)

[OUTPUT LIMIT]

Set in factory, protects the unit from overdrive. If you change this it may damage the amplifier which is why this value is

protected.

Troubleshooting

We hope you’ll never get to this step. We all know bad things happen but do not despair! Check the troubleshooting table on

the next page. If you have problems you cannot solve yourself, please see our website for contact information and support

resources in our forum.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Amplificador de PCS Electronics

PCS Electronics

PCS Electronics CyberMax Series Manual de usuario

PCS Electronics

PCS Electronics CYBERMAX FM+ 500W Manual de usuario

Manuales populares de Amplificador de otras marcas

ASTRO

ASTRO HVO V40 P Manual de usuario

Marantz

Marantz SUPERSCOPE BLA-545 Instrucciones de montaje

NAD

NAD CI980 Manual de usuario

Technics

Technics SE-CH770 Manual de usuario

Harman Kardon

Harman Kardon HK6300 Manual de usuario

NAD

NAD T975 Manual de usuario

McIntosh

McIntosh MA6850 Manual de usuario

Electro-Harmonix

Electro-Harmonix ENGLISH MUFF’N Manual de usuario

Viatron

Viatron Autrix Manual de usuario

GME

GME GA9800 Manual de usuario

Atlas

Atlas CP700 Manual de usuario

Roland

Roland KC-1000 Manual de usuario

Pyle

Pyle PFMRA350BW Manual de usuario

Advantage

Advantage S-250 Manual de usuario

IRT Electronics

IRT Electronics DVA-3007 Manual de usuario

Dimavery

Dimavery BA-100 Series Manual de usuario

Sony

Sony XM-S400D Manual de usuario

Schertler

Schertler ROY X Manual de usuario
