2
User's Manual Version : CS-WMV02G_manual_HK_US-A_V2
The information provided in this document are subject to change without
notice.
3
Before You Use This Product
The use of surveillance devices may be prohibited by law in your country. The Network
Camera is not only a high-performance web-ready camera but also can be part of a
flexible surveillance system. It is the user’s responsibility to ensure that the operation of
such devices is legal before installing this unit for its intended use.
It is important to first verify that all contents received are complete according to the list
in the "Package Contents" chapter. Take notice of the warnings in “Quick installation
guide” before the Network Camera is installed, then carefully read and follow the
instructions in the “Installation” chapter to avoid damages due to faulty assembly and
installation. This also ensures the product is used properly as intended.
The Network Camera is a network device and its use should be straightforward for those
who have basic network knowledge. The “Troubleshooting” chapter in the Appendix
provides remedies to the most common errors in set up and configuration. You should
consult this chapter first if you run into a system error.
The Network Camera is designed for various applications including video sharing, general
security/surveillance, etc. The “How to Use” chapter suggests ways to best utilize the
Network Camera and ensure proper operations. For the creative and professional
developers, the "URL Commands of The Network Camera " chapter serves to be a helpful
reference to customize existing homepages or integrating with the current web server.
For paragraphs preceded by
the reader should use caution to understand
completely the warnings. Ignoring the warnings may result in serious hazards or
injuries.
4
Table of Contents
Before You Use This Product........................................................................ 3
Package Contents ...................................................................................... 6
Installation ............................................................................................... 7
Hardware installation............................................................................ 7
Software Installation ............................................................................ 9
Initial Access to the Network Camera.................................................... 13
Check Network Settings ................................................................ 13
Add Password to Prevent Unauthorized Access.................................. 13
How to Use ....................................................................................... 14
Authentication.............................................................................. 14
Installing plug-in................................................................................ 15
Primary user’s capability ..................................................................... 16
Main Screen with Camera View....................................................... 16
Client settings.............................................................................. 20
Administrator’s capability .................................................................... 22
Fine-tuning for Best Performance.................................................... 22
Opening accounts for new users ..................................................... 24
Build a security application ............................................................ 24
Definitions in Configuration ....................................................................... 26
System parameters ............................................................................ 27
Security settings ................................................................................ 28
Network settings................................................................................ 29
Network type ............................................................................... 29
HTTP .......................................................................................... 30
RTSP Streaming ........................................................................... 30
WLAN Configuration ...................................................................... 31
DDNS............................................................................................... 33
Access List ........................................................................................ 34
Audio and Video................................................................................. 35
General....................................................................................... 35
Video Settings.............................................................................. 35
Video orientation .......................................................................... 36
Audio settings .............................................................................. 36
Image Settings ............................................................................ 37
Camera Control ................................................................................. 38
Email & FTP....................................................................................... 40
5
Email .......................................................................................... 40
FTP ............................................................................................ 40
Motion detection ................................................................................ 42
Application settings ............................................................................ 43
Snapshot..................................................................................... 43
Weekly schedule........................................................................... 43
Snapshot file name prefix .............................................................. 43
Send out the snapshot while motion detection .................................. 43
Sequential operation ..................................................................... 43
Method for sending snapshot.......................................................... 44
System log........................................................................................ 45
Viewing system parameters................................................................. 46
Maintenance...................................................................................... 47
Appendix................................................................................................ 48
A. Troubleshooting ............................................................................. 48
Status LED .................................................................................. 48
Reset and restore ......................................................................... 48
Technology License Notice................................................................... 49
6
Package Contents
CS-WMV02G
LAN cable (Straight)
Power Adapter
Lens cleaner
Camera Mount Kit & Pads
Quick Installation Guide
Antenna
Safety Information / Warranty Card
CD-ROM (Software & Users Manual)
7
Installation
In this manual, "User" refers to whoever has access to the Network Camera, and
"Administrator" refers to the person who can configure the Network Camera and grant
user access to the camera.
Hardware installation
Please verify that your product package contains all the
accessories listed in the foregoing Package Contents.
Depending on the user’s application, an Ethernet cable may be
needed. The Ethernet cable should meet the specs of UTP
Category 5 and not exceed 100 meters in length.
Upon powering up, the front red LED will become lighted first and then the device will go
through booting process. During the booting process, red, blue and green LEDs will be
on. After booted, the Network Camera will standby for getting IP address. After getting IP
Address, the green LED will blink every second.
The Network Camera will first detect Ethernet. If it does not connect to Ethernet, the
Network Camera will try WLAN. During the searching and connecting process to the
wireless access point or station, the red LED of the Network Camera will flash every
second. Until the Network Camera connects to the other wireless device, the red LED
will become lighted. Operating in either network mode, the green LED will flash every
second as heartbeat to indicate alive. If the red LED is blinking, please check the network
connections.
Connect the power adapter jack to the Network
Camera before plugging in to the power socket. This will
reduce the risk of accidental electric shock.
8
To install in Ethernet
Make sure the Ethernet is firmly connected to a switch hub. After attaching the Ethernet
cable plug in the power adapter. If the LED turns out to be steady blue, go to next
paragraph “Software installation”. If the Ethernet is not available, Network Camera will
switch to wireless LAN mode.
To install in wireless LAN
If the Ethernet is not available while power on, the Network Camera will search for any
access point with the SSID “Planexuser”. Once any access point is found, the LED will turn
blue to wait for installation. If the network environment cannot meet the default settings,
install Network Camera in Ethernet to proceed with wireless LAN configuration.
9
Software Installation
In this manual, "User" refers to whoever has access to the Network Camera, and
"Administrator" refers to the person who can configure the Network Camera and grant
user access to the camera.
At the end of the hardware installation, the Administrator must place the product
software CD into the CD-ROM drive of the PC running in MS Windows. An auto-run
program will pop up (If the program is not on auto-run, go to the root directory of the
software CD and click on “AutoLoader.exe”).
Click on “Installation Wizard Software” item, after the window contains changed, click on
“Installation Wizard” to run installation program.
10
After you click “Installation Wizard” icon on the desktop, a searching box will pop up. This
program searches for product on the same LAN:
After searching, Video Servers or Network
Cameras will be located by the Installation
Wizard. There may be several entries
shown in the window. The Administrator
may differentiate the Network Cameras
with the serial number.
For the series number in the “Node ID” field, please check the label on the bottom of the
camera.
