The Senser Xtreme R.2 is the complement to our proven Senser V2. It is a very powerful boost
constant current source that sets new standards. The (input) current can be up to 8 amps, so you can
already operate with very low input voltage, a large number of LED's with high currents. To be as
flexible as possible in your applications, many different output currents are set by solderbridges but
other currents through add / change the measuring resistors possible. The possibilities are endless,
please refer to our connection examples.
The Senser Xtreme has an external input which allows dimming by pulse width modulation. Either
you use this input for our final dimmer modules or your own development.
Specifications / Features:
• High power switch mode boost constant current source (step-up)
• No longitudinal controller!
• 5-40V / DC input voltage range / 8 amps! maximum current (on input side)
• Output voltage to 65 volts (Equivalent to approximately 20 high-power white LEDs,
other colors accordingly more)
• Output currents selectable by solderbridges or other currents are possible (tested up
to 3A)
• Factory output currents:
200/350/500/550/700/850/1000/1050/1200/1350/1500/1550/1700/1850/2050mA
up to 3050mA
• More than 100 Watt power Led
• Soft-start (to prevent any spikes when turning on)
• Efficiency depending on input voltage up to 97%
• High-quality components, ceramic chip capacitors instead of tantalum / electrolytic
capacitors
• Built-in temperature sensor (power reduction at high temperature)
• Qualitative two-sided board, thermal management design optimized 70μm copper
layer!
• For lighting projects of any kind, such as Lights, lamps, flashlights, cars, signs, lighting,
lighting engineering, etc.
• Extremely small dimensions: 28mm diameter x 16mm height
• External PWM and External shutdown and turnon input (max. 10V/DC)
• Dimming and controllable with our Led Stripe V4, NanoDim V2 or μ-Dim
•
