Paxar Pathfinder TC6035AN Suplemento
MONARCH
DOS-based
PATHFINDERUltra
System
TC6035AN Rev. A 7/98 ©1998 Monarch Marking Systems, Inc. All rights reserved.
Each product and program carries a respective written warranty, the only
warranty on which the customer can rely. Monarch reserves the right to make
changes in the product and the programs and their availability at any time and
without notice. Although Monarch has made every effort to provide complete
and accurate information in this manual, Monarch shall not be liable for any
omissions or inaccuracies. Any update will be incorporated in a later edition of
this manual.
©1997 Monarch Marking Systems, Inc. All rights reserved. No part of this
publication may be reproduced, transmitted, stored in a retrieval system, or
translated into any language in any form by any means, without the written
permission of Monarch Marking Systems, Inc.
Trademarks
Monarch, Pathfinder, and Ultra are registered trademarks of Monarch Marking Systems, Inc.
6035 is a trademark of Monarch Marking Systems, Inc.
Datalight is a registered trademark of Datalight, Inc.
ROM-DOS is a trademark of Datalight, Inc.
Greenleaf CommLib is a trademark of Greenleaf Software, Inc.
Aironet is a trademark of Aironet Wireless Communications, Inc.
Symbol is a registered trademark of Symbol Technologies, Inc.
Proxim is a trademark of Proxim, Inc.
Monarch Marking Systems, Inc.
P.O. Bo 608
Dayton, OH 45401
MONARCH
DOS-based
PATHFINDERUltra
System
TC6035AN Rev. A 7/98 ©1998 Monarch Marking Systems, Inc. All rights reserved.
Each product and program carries a respective written warranty, the only
warranty on which the customer can rely. Monarch reserves the right to make
changes in the product and the programs and their availability at any time and
without notice. Although Monarch has made every effort to provide complete
and accurate information in this manual, Monarch shall not be liable for any
omissions or inaccuracies. Any update will be incorporated in a later edition of
this manual.
©1997 Monarch Marking Systems, Inc. All rights reserved. No part of this
publication may be reproduced, transmitted, stored in a retrieval system, or
translated into any language in any form by any means, without the written
permission of Monarch Marking Systems, Inc.
Trademarks
Monarch, Pathfinder, and Ultra are registered trademarks of Monarch Marking Systems, Inc.
6035 is a trademark of Monarch Marking Systems, Inc.
Datalight is a registered trademark of Datalight, Inc.
ROM-DOS is a trademark of Datalight, Inc.
Greenleaf CommLib is a trademark of Greenleaf Software, Inc.
Aironet is a trademark of Aironet Wireless Communications, Inc.
Symbol is a registered trademark of Symbol Technologies, Inc.
Proxim is a trademark of Proxim, Inc.
Monarch Marking Systems, Inc.
P.O. Bo 608
Dayton, OH 45401
7/21/98 Table of Contents i
TABLE OF CONTENTS
Introduction..........................................................................................1-1
About this Manual...............................................................................1-1
Related Documentation.......................................................................1-2
Using Memory Cards ............................................................................2-1
Configuring Memory Cards..................................................................2-1
Using Radio Cards................................................................................3-1
Configuring Radio Cards.....................................................................3-1
Serial Communications ........................................................................4-1
Connector Pinouts..............................................................................4-1
Using I/O Routines..............................................................................4-2
International Configurations................................................................5-1
Configuring the Display.......................................................................5-1
Configuring the Keypad.......................................................................5-2
Generating International Characters....................................................5-2
International Keypad Maps..................................................................5-3
Universal Pathfinder Map (Country Code UP)...................................5-3
Turkish Map (Country Code TR) ......................................................5-4
ii Application Notes 7/21/98
7/21/98 Introduction 1-1
INTRODUCTION
The MONARCH® DOS-based PATHFINDER® Ultra® printer is very
versatile. In addition to running applications that you write with
MicrosoftC/C++ 1.52 (described in the Programmer’s Manual), it can
♦communicate with a host via a serial communications port.
♦use international configurations for its keypad and display.
The printer has one un-buffered PC-card slot. With it, the printer can
♦use extra memory.
♦communicate over a wireless network.
About this Manual
Technical personnel that set up application systems for the printer
should read this manual after they read the Programmer’s Manual. It is
a companion to the Programmer’s Manual.
The following table describes the conventions used in this manual.
Convention Description
[ ] Brackets indicate optional items.
…Ellipses indicate that the preceding item is
repeated one or more times.
Italics An item appearing in italics is a variable, a
function parameter, or a variable’s value.
Bold An item appearing in bold is being emphasized.
1
1-2 Application Notes 7/21/98
Related Documentation
The following table describes other manuals for the printer.
Manual Description
ROM-DOSUser Manual Describes the DatalightROM-
DOS operating system that runs on
the printer.
Equipment Manual Describes how to operate the
printer. For example, it covers
topics such as loading supplies,
using the scanner, etc.
Programmer’s Manual Describes how to create
applications with the C/C++
language libraries supplied with the
software development kit (SDK).
MPCLII Packet Reference
Manual Describes the MPCLII printer
language.
MONARCHquick-set
software Label Designer
Online Help
Describes how to use the Label
Designer. Use this utility to create
the design for the labels the
application prints.
MONARCH quick-set
software Font Utility
Online Help
Describes how to use the Font
Utility. Use this utility to convert
TrueType and HP fonts into MPCLII
font packets.
7/21/98 Using Memory Cards 2-1
USING MEMORY CARDS
You can use an AT-Attachment (ATA) memory card with the
appropriate device drivers to add memory to the printer. The card goes
in the printer’s PC-card slot. The application treats the memory card
as another disk drive.
Memory cards are flash-based. They have a built-in processor to track
bad locations and maximize flash life (ensuring no location is
overused).
Available memory cards come in 4, 8, 20, and 40 MB sizes.
Configuring Memory Cards
The following procedure describes how to configure memory cards.
Refer to the Programmer’s Manual for more information.
1. Place the following files (located in the SDK’s DOS sub-directory)
in the application disk image’s root directory:
Name Description
ATAINIT.EXE Memory card partition utility.
GENATA.CLB Generic configuration library for the memory
card.
CSALLOC.INI Initialization file for CSALLOC.EXE.
CARDID.INI Initialization file for CARDID.EXE. This file
contains references to configuration libraries
(.CLB files) for the memory card. At a
minimum, this file must refer to GENATA.CLB.
SSELAN.EXE SystemSoft Socket Services.
CS.EXE SystemSoft Card Services.
CSALLOC.EXE SystemSoft Card Allocation Module.
ATADRV.EXE Memory card driver.
CARDID.EXE Memory card ID driver.
2
2-2 Application Notes 7/21/98
2. Enter the following lines in the application’s CONFIG.SYS file:
DEVICE=SSELAN.EXE
DEVICE=CS.EXE
DEVICE=CSALLOC.EXE
DEVICE=ATADRV.EXE
DEVICE=CARDID.EXE
3. Create the disk image and load it into the printer.
4. Reboot the printer.
