TECHNICAL MANUAL
MC 353 Flow Rate Controller for belt weigher
Software version 1.9
Pag. 2
MC 353 software 1.9 ENG
SYMBOLS
Following are the symbols used throughout the manual to call reader’s attention:
Further details.
Warning! Electric shock risk
Warning! This operation shall be carried out by qualified staff.
Pay special attention to the following points.
WARNINGS
This manual provides texts and pictures to inform the operator about all prescriptions and criteria ne-
cessary for installing and using this instrument.
The equipment shall be installed only by qualified personnel that must have read this manual. With
the expression “qualified personnel” is meant the personnel that has been trained and thus expressly
authorised to carry out the installation by the person in charge for the system safety.
Power the instrument with a voltage value within the limits specified in the features.
The user must make sure that the installation is carried out in compliance with the relevant rules in force.
Please contact the nearest Assistance Centre for every fault you find. Any attempt of disassembly or
change that has not been previously authorised will null and void the warranty and will release the
Manufacturer from any responsibility.
The purchased instrument has been designed and produced to be used in the weighing and metering
processes thus any improper use will release the Manufacturer from any responsibility.
Pag. 3
MC 353 software 1.9 ENG
Table of conTenTs
SYMBOLS ..................................................................................................... 2
WARNINGS.................................................................................................. 2
CE DECLARATION OF CONFORMITY - ............................................................ 5
1 - INTRODUCTION....................................................................................... 6
1.1 - OTHER FUNCTIONS OF MC353............................................................. 8
1.2 - TECHNICAL FEATURES ........................................................................... 9
2 - MC353 INSTALLATION............................................................................ 12
2.1 - INSTALLATION WARNINGS AND INDICATIONS .................................... 12
2.2 - INSTRUCTIONS FOR A CORRECT INSTALLATION ................................... 13
2.3 - ELECTRIC CONNECTIONS ................................................................... 14
3 - MC353 STRUCTURE AND PARAMETERS ................................................... 25
3.1 - PARAMETERING GENERAL FEATURES.................................................... 25
3.2 - MC353 DISPLAYS ................................................................................ 27
3.3 - SET-UP MENU LEVELS ........................................................................... 31
3.4 - PARAMETERS TABLES............................................................................ 33
3.5 - LIST OF PARAMETERS TO BE SET ........................................................... 36
3.6 - LIST OF PARAMETERS PRIOR TO COMMISSIONING ............................... 42
4 - INSTRUMENT PROCEDURE ...................................................................... 45
4.1 - INSTRUMENT COMMISSIONING PROCEDURE ...................................... 45
4.2 - IN-OUT TEST PROCEDURE .................................................................... 46
4.3 - SIMULATION PROCEDURE .................................................................... 46
4.4 - MACHINE TEST PROCEDURE ................................................................ 47
5 - SYSTEM CALIBRATION ............................................................................ 48
5.1 - BELT HOMING DYNAMIC PROCEDURE ................................................. 48
5.2 - BELT CALIBRATION DYNAMIC PROCEDURE ........................................... 49
5.3 - ZERO STATIC CALIBRATION AND WITH SAMPLE WEIGHT ...................... 50
5.4 - MC353 OPERATION ALARMS............................................................... 51
6 - ADDITIONAL FUNCTIONS OF MC353 ..................................................... 53
6.1 - DATA LOGGER .................................................................................... 53
6.2 - SAVE AND LOAD SET-UP ...................................................................... 53
Pag. 4
MC 353 software 1.9 ENG
6.2 - FILE LOADING..................................................................................... 54
6.3 - RECEIPT PRINT..................................................................................... 55
7 - SERIAL COMMUNICATION AND PROTOCOLS.......................................... 56
7.1 - ASCII COMMUNICATION PROTOCOL .................................................. 56
7.2 - MODBUS COMMUNICATION PROTOCOL ............................................ 61
7.3 - PROFIBUS-DP COMMUNICATION PROTOCOL ....................................... 62
7.4 - SUPERVISION FUNCTIONS .................................................................. 71
7.5 - MASTER / SLAVE COMMUNICATION PROTOCOL.................................. 71
7.6 - REPETITOR TRANSMISSION PROTOCOL ................................................ 72
8 - TROUBLESHOOTING ............................................................................. 73
8.1 - TROUBLESHOOTING ........................................................................... 73
CONFIGURATION AND TEST FORM ............................................................. 76
Pag. 5
MC 353 software 1.9 ENG
- CE DECLARATION OF CONFORMITY -
· ELECTROMAGNETIC COMPATIBILITY DIRECTIVE
2004/108/EC
· EN61000-6-2, EN61000-6-3, EN61010-1, EN45501 STANDARDS
MANUFACTURER
Electronic commercial denomination: “Metering control electronic instrument”
Model: “MC353”
Protection class: “IP 65”
It is forbidden to start-up the electronic equipment provided with certication before
the electric panel it is going to be integrated or assembled has been declared conforming
with the Directives requirements.
CERTIFICATION
WE, THE UNDERSIGNED OF THIS DOCUMENT, DECLARE UNDER OUR OWN
RESPONSIBILITY THAT THE CONCERNED ELECTRONIC EQUIPMENT IS
CONFORMINGWITHTHE ITALIAN LAWANDTHUSWITHTHE ELECTROMAGNETIC
COMPATIBILITY DIRECTIVE 2004/108/EC AS WELL AS THE EN61000-6-2, EN61000-
6-3, EN61010-1, EN45501 STANDARDS.
NAME: POSITION:
ISSUE DATE: SIGNATURE:
ELECTRONIC IDENTIFICATION
Pavone Sistemi S.r.l.
Via Dei Chiosi, 18
20873 Cavenago Brianza (MB) - ITALY
Tel. +39.02.95339165 - Fax +39.02.9501252
pavone@pavonesistemi.it - www.pavonesistemi.it
Donato Di Reda sole director
03/02/2012
Pag. 6
MC 353 software 1.9 ENG
1
Inverter
Encoder Flow Rate
Motor
Load Cells
MC 353
PLC / PC
MC 353
Inverter
MotorLoad Cells
Weighing Belt
Encoder
PC / PLC
1 - InTRoDUcTIon
The picture shows how the instrument controls the system adjustment ring.
The MC353 can operate as follows according to its set-up:
FLOW RATE TRANSMITTER
The instrument, thanks to the weight (load cells) and the speed (encoder) signal when it receives the run
input, calculates an instantaneous flow rate which is then transmitted externally through a configurable
analogue output (0÷10 V, 0÷5 V, 0÷20 mA, 4÷20 mA).
It is also possible to receive the following outputs:
- Weight totalization output;
- Conveyed weight preset output;
- Conveyed weight set output;
- Serial communication protocol, Ethernet included.
- Generic alarm output;
- Flow rate equal to 0 output;
- Conveyed weight reset input;
- USB device communication port;
- Optional USB HOST port with USB pen drive interface.
FLOW RATE CONTROLLER
The MC 353 control unit is configured with P.I. (instantaneous flow rate) regulator; it processes the weight
and speed variables to get the instantaneous hourly flow rate and the totalized weight. Furthermore it
acts as flow rate self-regulator.
Pag. 7
MC 353 software 1.9 ENG
1
The external supervisor transmits the work set-up (that can be set also through the keyboard) through
the serial communication to the MC353 control unit; the latter, according to the calculated flow rate
value, controls directly (through analogue output) the inverter frequency of the motor where the weighing
system has been installed.
The MC353 control unit has the following features:
- Weight totalization output;
- Conveyed weight total preset and set output;
- Generic alarm output;
- Flow rate out of tolerance alarm output;
- Flow rate output equal to 0;
- Retroaction analogue output (0÷10V;0÷5V, 0÷20 mA; 4÷20 mA);
- Flow rate proportional optional analogue output;
- Optional analogue input for setting-up the flow rate;
- Inputs for the selection of 15 preset set points;
- Conveyed weight reset input;
- Selection of the instrument state from manual to automatic and vice versa by means of the keyboard,
from the instrument rear side through external contact, and by means of serial communi-
cation protocol;
- Serial communication protocol, Ethernet included;
- Optional USB HOST port with USB pen drive interface.
Pag. 8
MC 353 software 1.9 ENG
1
1.1 - OTHER FUNCTIONS OF MC353
MASTER-SLAVE OPERATION
This instrument can operate as slave, thus acquiring the flow rate setpoint in continuous duty, through
analogue input (0÷10V / 4÷20mA) or digital input (RS485). The flow rate setpoint is updated accor-
ding to the current input: the flow rate setpoint is divided and it represents the input scale end (100%).
In case the current setpoint is set to 0, the setpoint will correspond to the input percentage value of the
system maximum flow rate.
The instrument can also operate as master by transmitting the instantaneous flow rate through the op-
tional analogue output or digital transmission (RS485) for the direct connection to instruments in SLAVE
operation.
PARAMETERS THAT CAN BE SET
It is possible to set the operation parameters through the touch screen user interface; all parameters are
organised on 3 levels with independent access criteria.
All parameters that can be set are listed in a table and clearly identified with a numerical code (address).
The parameters reading and writing access is available on the communication port with supervisor
(Rs422 / RS485 / Ethernet, optional), through the ModBus RTU protocol. Furthermore the parameters
reading and setting can be carried out by sharing files in CSV format on the COM2 communication
port (Rs232 or USB) or directly on USB pen drive connected to the USB Host port (optional).
For operation details see the relevant paragraphs.
DATA IMPORT / EXPORT
To facilitate the data set-up and acquisition in a format that can be used with standard informatic systems
the instrument is provided with files transfer functions (TXT or CSV). It features especially a reading/
writing (even partial) of the memory parameters from CSV files and a data logger procedure to acquire
operation parameters.
To customise the instrument it is possible to set the setpoint names, create Help pages and load the
image displayed upon switching-on (BMP file).
If the instrument is provided with a USB Host option, the import and export of the files mentioned above
can occur directly on USB pen drive.
Pag. 9
MC 353 software 1.9 ENG
1
1.2 - TECHNICAL FEATURES
STRUCTURAL FEATURES
Made of aluminium with polycarbonate screen
Protection class: IP 65
Overall dimensions: 196 mm x 105 mm (l x h)
Panel front projection: 5 mm
Built-in panel front.
Drilling template 187 mm x 97 mm (l x h)
Fixing by means of 4 metallic threaded rods
3 mm rubber seal along all perimeter
Stainless steel coating
Overall dimensions: 186 mm x 95 mm (l x h)
Embedding depth: 70 mm (terminal boards included)
5.08 / 7.5 mm pitch screw terminal board
Standard USB connectors (Host / Device)
RJ45 standard Ethernet connector
Front panel
Assembly
Rear panel
Connections
POWER SUPPLY
24 Vdc (± 15 %)
10W
Cat. II
Operation temperature: -10 °C ÷ + 50 °C
(85% humidity without condensate)
Storage temperature: -20 °C ÷ + 60 °C
Power supply
Max. absorption
Installation category
Temperatures
DISPLAY
5.2” LCD (118 mm x 58 mm visual area) (l x h)
Graphic (240x128 pixel)
Monochromatic (b/w) with high contrast
Backlit with white leds, adjustable intensity
4 wires resistive, suitable for use with gloves and buzzer
Display
Touch screen
Pag. 10
MC 353 software 1.9 ENG
1
LOAD CELLS INPUT
2 input channels for load cells. Acquisition at intervals
or simultaneously at low frequency
5 Vdc / 120mA (max. 8 350 Ohm cells in parallel)
Protected against short circuit
0.02 microV min
< 0.01% of the scale end
< 0.0003% of the scale end / °C
24 bit (16.777.216 points)
Up to 600,000 divisions on the flow rate
7.8 mV/V bipolar
From 12.5Hz to 250Hz
Adjustable from 0.2Hz to 50Hz
No. of channels
Cells supply
Input sensitivity
Linearity
Temperature warmup drift
Internal resolution
Weight resolution
Measure field
Acquisition frequency
Digital filter
ANALOGUE I/O
2 opto-isolated analogue outputs (1 optional)
1 analogue input (optional)
Analogue output: 16 bit
Analogue input: 24 bit
Outputs: 0÷5V, 0÷10V, 0÷20mA, 4÷20mA
Input: 0÷5V, 0÷10V, 4÷20mA
Voltage: 10KΩ min, current 300 max
< 0.03% of the Full Scale
< 0.001% of the Full Scale / °C
No. of channels
Resolution
Measure field
Output impedance
Output linearity
Output temperature
warmup drift
1 2-phase incremental encoder input (up-down, A-B).
As an alternative there are 2 pulse-counting inputs
24Vdc (100mA max)
2 KHz max
ENCODER INPUT
No. of channels
Power supply
Acquisition frequency
Tabla de contenidos
