Partner PT-6910 Series Manual

PT-6910 Series

Unpacking and Setup Instructions

The PT-6910 Series and its

accessories are packed in a

cardboard carton with foam padding

for protection during shipment.

Carefully unpack the system and

keep the packing materials for

future use.

Verify that all of the items shown

below are included in the box. If

an item is missing or appears to be

damaged, contact your Partner Tech

dealer immediately.

1. User Manual and Driver CD

2. WEPOS Recovery DVD (optional)

Power Cord and Power Supply PT-6910 Series

Rotate the display until it is inA.

an upright position.

Release the rear coverB.

latches.

Remove the rear cover byC.

lifting it upward.

Step 1: Unpack the box and check the contents.

Step 2: Remove the rear cover.

Step 3: Connect the peripheral devices.

CAUTION: Be sure to connect the peripheral devices to the

appropriate ports, as shown below. A device may not function

correctly if it is connected to the wrong port.

Connect your peripheral devices to the PT-6910 Series, as shown in the

illustration below.

NOTE: Drivers and utilities needed for PT-6910 Series are included in the

“User Manual and Driver CD”.

Step 4: Connect the power adapter.

Step 5: Replace the rear cover and turn on power.

Replace the rear cover andA.

close the rear cover latches.

(Reverse steps B and C on

the previous page.)

Press the power button onB.

the underside of the display

panel.

Adjust the display for theC.

best viewing angle.

Connect the power cableA.

to the power supply socket

located on the rear side of

the PT-6910 Series.

Plug the power cable into anB.

electrical outlet.

Power socket

USB Compliant

devices

Mouse Printer

MR HS AA CD OH SD RD TR

28800bps

ADSL modem

or router

MonitorKeyboard Cashdrawer

Microphone

!MPLIFIEROR

SPEAKERS Headphones COM2

COM3

COM4 COM1

Power plug

www.partner.com.tw

Note: Using adaptor higher than

19V/4.75A may damage the system!
