Parkside PKLL 7 E4 Manual de usuario
Cross line laser PKLL 7 E4
Kreuzlinienlaser
Originalbetriebsanleitung
Cross line laser
Translation of the original instructions
IAN 385107_2107
Niveau laser en croix
Traduction des instructions d‘origine
Kruislijnenlaser
Vertaling van de originele
gebruiksaanwijzing
GB /IE Translation of the original instructions Page 4FR/BE Traduction des instructions d‘origine Page 18NL/BE Vertaling van de originele gebruiksaanwijzing Pagina 33DE/AT/CH Originalbetriebsanleitung Seite 48Before reading, unfold the page containing the illustrations and familiarise
yourself with all functions of the device.
Avant de lire le mode d‘emploi, ouvrez la page contenant les illustrations et
familiarisez-vous ensuite avec toutes les fonctions de l‘appareil.
Vouw vóór het lezen de pagina met de afbeeldingen open en maak u ver-
trouwd met alle functies van het apparaat.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen
Sie sich anschließend mit allen Funktionen des Gerätes vertraut.
1
3
5
2
4
8
9
10
6
5
7
3
4
GB IE
Content
Introduction...................... 4
Intended purpose.............. 5
General description .......... 5
Extent of the delivery ......5
Functional description.....6
Overview......................6
Technical specications ..... 6
Safety information............ 6
Symbols and icons .........6
General notes on safety .... 7
Safety Instructions for
Handling the Laser .........7
Safety Instructions for
Handling Batteries..........8
Initial Operation ............... 9
Inserting/replacing
batteries........................9
Operation ........................ 9
Working with the
automatic leveller...........9
Working without the
automatic leveller.........10
Introduction
Congratulations on the
purchase of your new
device. With it, you have
chosen a high quality pro-
UKCA declaration of
conformity...................... 63
Translation of the
original EC declaration
of conformity.................. 64
Working with the clamp
tripod .........................10
Working with the tripod..11
Cleaning ........................ 11
Storage.......................... 11
Maintenance .................. 12
Transport ....................... 12
Waste disposal and
environmental protection 12
Troubleshooting.............. 13
Guarantee...................... 14
Repair Service ................ 16
Service-Center ................ 16
Importer......................... 16
Spare parts/
Accessories..................... 17
duct. During production, this
equipment has been checked
for quality and subjected to
a nal inspection. The func-
tionality of your equipment is
therefore guaranteed.
5
GB IE
The operating instruc-
tions constitute part of
this product. They contain
important information on sa-
fety, use and disposal.
Before using the product,
familiarise yourself with all
of the operating and safety
instructions. Use the product
only as described and for the
applications specied. Keep
this manual safely and in
the event that the product is
passed on, hand over all do-
cuments to the third party.
Intended purpose
The cross-line laser is suitab-
le for projecting vertical and
horizontal lines.
The device is only intended
for indoor use.
The device is intended to be
used by do-it-yourselfers. It
was not designed for heavy
commercial use.
The device is to be used by
adults. Children under the
age of 16 may not use the
device except under super-
vision.
The manufacturer is not lia-
ble for damage caused by
improper use or incorrect
operation.
General
description
See the front fold-
out page for
illustrations.
Extent of the
delivery
Carefully unpack the ap-
pliance and check that it is
complete. Dispose of the pa-
ckaging material correctly.
•Cross Line Laser
•Clamp tripod
with clamping jaws
•2 x 1.5 V batteries,
AAA size
•Instruction Manual
6
GB IE
Functional
description
Refer to the following de-
scriptions for a functional
description of the controls.
Overview
1 On/off switch
2 LED ring
3 Battery compartment
4 Levelling stop / transport
securing device
5 Thread for tripod faste-
ning
6 Laser
7 Tripod screw
8 Retaining screw
9 Clamping nut
10 Clamping jaw
Technical
specifications
Cross Line Laser....PKLL 7 E4
Working range .......... 7 m*
Weight (incl. batteries)........
...................approx. 245 g
Power supply............3 V
......... (2 x AAA 1.5 V cells)
Protection type ............ IP20
Self-levelling range...... ± 4°
Levelling accuracy
at 0° to ± 4°...± 0.8 mm/m
from ± 4°.......± 1.0 mm/m
Laser
Wavelength.......... 635 nm
Laser class......................2
Levelling time.. approx. 6 sec
* The working range may be restric-
ted by environmental conditions
(e.g. bright light).
Safety information
Symbols and icons
Symbols on the device:
LASER CLASS 2
EN 60825-1:2014
λ = 635 nm
P0 < 1 mW
Caution! - Laser beam
Do not look into the beam!
Laser class 2
7
GB IE
General notes
on safety
•Observe the information
on operation, cleaning,
storage and disposal in the
operating instructions.
• Keep children away from
the device.
•Check the device each
time before using. If da-
maged, have the device
repaired. Do not use the
device if damaged.
• Turn off the device when
not in use. Do not leave the
device unsupervised.
• Keep the device away from
medical devices, magnetic
data storage media and
magnetically sensitive de-
vices.
Safety Instructions
for Handling the
Laser
•Caution: Leaser beam
– Do not look into the
beam! Laser class 2
•Do not aim the laser beam
at people.
Electrical machines
do not belong with
domestic waste.
Direct voltage
Producer
UKCA mark
indicates conformity
with relevant Great
Britain regulations
applicable for the product.
Symbols used in the
instructions:
Hazard symbols
with information
on prevention of perso-
nal injury and property
damage.
Precaution symbol with
information on preven-
tion of harm / damage
Notice symbol with infor-
mation on how to handle
the device properly.
8
GB IE
Safety Instructions
for Handling
Batteries
•Ensure at all times that
the batteries are inserted
with the correct polarity
(+and–), as shown on the
battery itself.
•Do not short-circuit the bat-
teries.
•Do not charge non-rechar-
geable batteries.
•Do not overcharge batte-
ries!
•Do not mix old and new
batteries or batteries of a
different type or from diffe-
rent manufacturers! Repla-
ce all batteries of a set at
the same time.
•Remove used batteries im-
mediately from the device
and dispose of them cor-
rectly!
•Do not heat the batteries!
•Do not carry out any wel-
ding or soldering work
directly on the batteries!
•Do not take the batteries
apart!
•Do not deform the batteries!
•Do not throw the batteries
into re!
•Store the batteries out of
the reach of children.
•Do not allow children to re-
place the batteries without
supervision!
•Do not store the batteries
close to a re, cookers or
other sources of heat. Do
not place the battery in di-
rect sunlight and do not use
or store it in motor vehicles
in hot weather.
•Store used batteries in the
original packaging and
keep them away from
metal objects. Do not mix
(up) unpacked batteries!
Otherwise this may cause
the battery to short-circuit,
resulting in damage, burns
or even the danger of re.
•Remove batteries from the
device if this is not going
to be used for a prolonged
period, unless it is to be
used in emergencies!
•NEVER touch batteries
which have leaked without
appropriate protection. If
the leaked liquid comes
9
GB IE
into contact with the skin,
you should rinse off this
area of the skin immedia-
tely under running water.
Make sure at all events that
your eyes and mouth do not
come into contact with the
liquid. If they do, seek me-
dical advice immediately.
•Clean the battery contacts
and the equivalent contacts
in the device before inser-
ting the batteries.
Initial Operation
Inserting/replacing
batteries
1. Open the battery com-
partment (3).
2. Insert two AAA batteries.
Ensure you place the bat-
teries into the compart-
ment in accordance with
the illustration.
3. Close the battery com-
partment (3).
The LED ring (2) will ash
red when the battery
charge is low.
Operation
Caution! - Laser beam.
Do not look into the
beam. Turn your head away
or close your eyes to prevent
looking into the laser beam.
Danger of eye injury!
Working with the
automatic leveller
1. Place the device on a
horizontal solid surface.
The on/off switch (1) must
be pointing upwards.
Or fasten the device to a
tripod (see “Working with
the clamp tripod” / “Wor-
king with the tripod”).
2. Align the device so it is
parallel with the oor
3. Switch the device on by
releasing the levelling
stop: position .
The LED ring (2) will illu-
minate:
Green: if automatic le-
velling is possible.
Levelling is complete
once the laser lines no
longer move.
10
GB IE
Red: if automatic level-
ling is not possible.
The laser lines will ash
and longer be at exact
right-angles to one
another.
4. Switch the device off by
locking the levelling stop:
position .
In the event of vibra-
tions, the laser will level
itself automatically; wait until
the laser lines no longer
move.
Working without the
automatic leveller
Caution! - Laser beam.
Do not look into the
beam. Turn your head away
or close your eyes to prevent
looking into the laser beam.
Danger of eye injury!
The LED ring (2) will il-
luminate permanently
in red when working without
the automatic leveller. The la-
ser lines depicted are not le-
velled.
Switching on:
Turn the device on using
the on/off switch (1). The
levelling stop (4) must be in
position .
Switching off:
Turn the device off using the
on/off switch (1).
Working with the
clamp tripod
The clamp tripod provided
can be used to attach the de-
vice to various objects.
1. Release the clamping
nut(9).
2. Position the clamping
jaws (10) to the desired
location.
3. Turn the clamping nut (9)
until fastened.
4. Place the device with
thread (5) onto the tripod
screw (7) and tighten by
hand.
Do not use excessive
force as this may dama-
ge the device.
