Parkside BMR 1400 Manual de usuario
Anleitung_BMR_1400_4258582:_ 29.01.2009 9:47 Uhr Seite 1
14
23
32
Anleitung_BMR_1400_4258582:_ 29.01.2009 9:47 Uhr Seite 2
3
1
2
4
44
6
4
1
3
2
5
5
6a 6b
12
Anleitung_BMR_1400_4258582:_ 29.01.2009 9:47 Uhr Seite 3
4
4
3
Anleitung_BMR_1400_4258582:_ 29.01.2009 9:47 Uhr Seite 4
5
GB/IE/
CY
Table of contents: Page
1. Introduction .............................................................................7
2. Safety instructions ..................................................................7-9
3. Layout .....................................................................................9
4. Items supplied.........................................................................9
5. Intended use ...........................................................................9
6. Technical data ........................................................................9-10
7. Before starting the equipment.................................................10
8. Operation ................................................................................10
9. Replacing the power cable ....................................................10
10. Cleaning, maintenance and ordering of spare parts...............11
11. Disposal and recycling............................................................11
12. Declaration of conformity ........................................................12
13. Guarantee Certificate .............................................................13
The reprinting or reproduction by any other
means, in whole or in part, of documentation
and papers accompanying products is
permitted only with the express consent of ISC
GmbH. Technical changes subject to change
Anleitung_BMR_1400_4258582:_ 29.01.2009 9:47 Uhr Seite 5
GB/IE/
CY
6
“Caution - Read the operating instructions to reduce the risk of inquiry”
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Wear a breathing mask.
Dust which is injurious to health can be generated when working on wood and other
materials. Never use the device to work on any materials containing asbestos!
Wear safety goggles.
Sparks generated during working or splinters, chips and dust emitted by the device
can cause loss of sight.
Anleitung_BMR_1400_4258582:_ 29.01.2009 9:47 Uhr Seite 6
GB/IE/
CY
7
1. Introduction
Important!
When using equipment, a few safety
precautions must be observed to avoid injuries
and damage. Please read the complete
operating manual with due care. Keep this
manual in a safe place, so that the information
is available at all times. If you give the
equipment to any other person, give them
these operating instructions as well.
We accept no liability for damage or accidents
which arise due to non-observance of these
instructions and the safety information.
2. Safety instructions
CAUTION!
Read all safety regulations and
instructions.
Any errors made in following the safety
regulations and instructions may result in an
electric shock, fire and/or serious injury.
Keep all safety regulations and instructions
in a safe place for future use.
The term “electric tool” used in the safety
regulations refers to electric tools operated from
the mains power supply (with a power cable)
and to battery operated electric tools (without a
power cable).
1. Workplace safety
Keep your work area clean and well
illuminated. Untidy or unlit work areas can
result in accidents.
Do not use this tool in a potentially
explosive environment containing
combustible liquids, gases or dust.
Electric tools generate sparks, which can in
turn ignite dust or vapors.
Keep children and other persons away
from the electric tool while it is being
used.
Allowing yourself to get distracted can
cause you to lose control of the tool.
2. ELECTRICAL SAFETY
The tool’s connector plug must be able
to fit into the socket outlet. Do not
modify the plug in any way! Do not use
adapter plugs in conjunction with
electrically grounded tools.
Unmodified plugs and matching socket
outlets reduce the risk of an electric shock.
Avoid touching grounded surfaces,
such as those of pipes/tubes, heaters,
cookers and refrigerators.
There is an increased risk of getting an
electric shock if you are electrically
grounded.
Keep the tool away from rain and
moisture/wet conditions.
Penetration of water into an electric tool
increases the risk of an electric shock.
Do not use the cable to carry the tool,
hang it up or pull the plug out of the
socket. Keep the cable away from
sources of heat, oil, sharp edges and
moving tool parts.
Damaged or tangled cable increases the
risk of an electric shock.
If you intend to use an electric tool
outdoors, ensure that you only use
extension cable that is approved for
outdoor applications.
Using extension cable that is approved for
outdoor applications reduces the risk of an
electric shock.
If operation of the electric tool in a
damp environment can not be avoided,
use a earth-leakage circuit-breaker.
The earth-leakage circuit-breaker reduces
the risk of an electric shock.
3. PERSONAL SAFETY
Be alert, work conscientiously and
exercise appropriate caution when
using the electric tool. Do not use the
tool if you are tired or are under the
influence of drugs/medication or
alcohol.
One moment of carelessness or lack of
attention when using the electric tool can
cause serious bodily injury!
Always wear personal protective
equipment (PPE), including safety
Anleitung_BMR_1400_4258582:_ 29.01.2009 9:47 Uhr Seite 7
GB/IE/
CY
8
goggles.
Wearing personal protective equipment
such as a dust mask, non-slip footwear,
protective headgear and ear muffs
(depending upon the type of electric tool
and the particular application) reduces the
risk of sustaining injury.
Make sure that the tool cannot start up
accidentally. Ensure that the electric
tool is switched off before you connect
the tool to the power supply and/or
insert the battery, or pick up or carry the
tool.
Physically touching the switch with your
finger when carrying the tool or connecting
the tool to the power supply switched on
can lead to accidents.
Remove adjusting tools/wrench(es)
prior to switching on the power tool.
A tool or wrench that is positioned inside a
rotating power tool part can cause injury.
Avoid abnormal working postures. Make
sure you stand squarely and keep your
balance at all times.
This way, you will be able to have better
control over the tool in unexpected
situations.
Wear suitable clothes. Never wear loose
fitting clothes or jewelry. Keep hair,
clothes and gloves away from moving
parts.
Loose clothing, dangling jewelry and long
hair can be caught by moving parts.
If dust extraction and dust collection
devices can be mounted, ensure that
these are connected and are properly
used.
The use of a dust extraction system can
reduce the danger posed by dust.
4. Using the treatment of electric tools
Do not overload your tool. Only use
suitable electric tools to perform your
work.
Using the right electric tool allows you to
work better and safer within the tool’s
quoted capacity range.
Do not use an electric tool whose switch
is defective.
An electric tool that no longer can be
switched on or off is dangerous and must
be repaired.
Pull the plug out of the socket and/or
remove the battery before making any
adjustments to the tool, changing
accessories or put the tool down.
This precaution eliminates the possibility of
inadvertently starting the tool.
When not in use, store electric tools out
of the reach of children. Do not allow
those persons to use this tool who are
unfamiliar with it or who have not read
these instructions.
Electric tools are dangerous when they are
used by inexperienced persons.
Take good care of your tool. Check that
moving parts properly function and do
not jam, that parts are not broken off or
damaged in any way and that the tool
can be used to its full capacity. Have
damaged parts repaired prior to using
the tool.
The cause of many accidents can be traced
back to poorly maintained electric tools.
Keep your blades sharp and clean.
Properly maintained blades with sharp
edges jam less frequently and are easier to
use.
Make sure to use electric tools,
accessories, attachments, etc. in
accordance with these instructions.
Take the conditions in your work area
and the job in hand into account.
Using electric tools for applications other
than those intended can lead to dangerous
situations.
5. SERVICE
Have your tool repaired only by
authorized specialists using original
replacement parts.
This will ensure that your tool remains safe
to use.
Anleitung_BMR_1400_4258582:_ 29.01.2009 9:47 Uhr Seite 8
GB/IE/
CY
9
Additional Safety rules
The equipment must never be used in
surroundings where an explosive
atmosphere exists. Never mix in solvents or
substances containing solvent that have
flashpoints below 21°C.
Do not let the cable touch any parts of your
body.
Only use the extension cable approved for
use in the working area.
The unit must only be started and stopped
when it is inside a mixing vessel. Ensure
that the mixing vessel is placed on a solid,
secure base.
Never reach into the mixing vessel with your
hands or any other object during the mixing
process.
We recommend that you always wear
industrial safety gloves and safety googles
when working with the mixer.
Wearing close-fitting clothes is mandatory.
Always allow for reaction torque
The appliance is to be fused with a residual
current protective device (RCD) with rated
residual current of no more than 10mA, to
avoid danger. Test this at regular intervals.
Save this instructions.
3. Layout (Fig. 1/2/4)
1. On/Off switch
2. Locking knob
3. Speed control
4. Open-ended wrench for changing the
mixing tool
5. Mixer holder
6. Mixer
4. Items supplied
Take all the parts out of the packaging.
Check that nothing is missing.
Paint and Mortar Mixer BMR 1400
Mixing tool
2 open-ended wrench for changing the
mixing tool
5. Intended use
The machine has been designed to mix liquid
and powderery building materials such as paint,
mortar, adhesive, plaster and similar
substances. The relevant mixing action (which
depends on the consistancy of the materials
and the quantity that has to be mixed) must be
set up for the appropriate mixing tool.
The equipment is to be used only for its
prescribed purpose. Any other use is deemed
to be a case of misuse. The user / operator
and not the manufacturer will be liable for any
damage or injuries of any kind caused as a
result of this.
Please note that our equipment has not been
designed for use in commercial, trade or
industrial applications. Our warranty will be
voided if the machine is used in commercial,
trade or industrial businesses or for equivalent
purposes.
6.Technical data
Mains voltage: 230 V ~ 50 Hz
Power input: 1400 W
Idling speed: 0-700 min-1
Mixing tool mount: M14
Protection class: II / 쓑
Weight: 3.6 kg
Anleitung_BMR_1400_4258582:_ 29.01.2009 9:47 Uhr Seite 9
GB/IE/
CY
10
Sound and vibration
Sound and vibration values were measured in
accordance with EN 60745.
LpA sound pressure level 84.5 dB(A)
KpA uncertainty 3 dB
LWA sound power level 95.5 dB(A)
KWA uncertainty 3 dB
Wear ear-muffs.
The impact of noise can cause damage to
hearing.
Total vibration values (vector sum of three
directions) determined in accordance with EN
60745.
Mixing of paint and mortar
Vibration emission value ah= 2.92 m/s2
K uncertainty = 1.5 m/s2
Important!
The vibration value changes according to the
area of application of the electric tool and may
exceed the specified value in exceptional
circumstances.
7. Before starting the equipment
Important!
Before you connect the equipment to the
mains supply make sure that the data on the
rating plate are identical to the mains data.
Always pull the power plug before making
adjustments to the equipment.
Assembly of the mixing tool (Fig. 2):
Screw mixing tool part (6a) securely to mixing
tool part (6b). Then screw the mixing tool (6)
into the mount (5).
Use 2 open ended wrenches to do this (4).
With one open ended wrench, hold the mount
(5) securely. With the other, tighten the mixing
tool (6). In order to remove the mixing tool,
proceed in reverse order.
8. Operation
8.1 ON/OFF switch (Fig. 3/Item 1)
First fit a suitable mixing tool (6) to the
appliance (see 7).
Connect the mains plug to a suitable
socket.
To switch on:
Press the ON/OFF switch (1)
To switch off:
Release the ON/OFF switch (1)
Switching on continuous operation:
Secure the ON/OFF switch (1) with the locking
button (2).
Switching off continuous operation:
Press the ON/OFF switch (1) briefly.
8.2 Adjusting the speed (Fig. 4/Item 3)
Use the speed control (3) to pre-select the
speed.
9. Replacing the power cable
If the power cable for this equipment is
damaged, it must be replaced by the
manufacturer or its after-sales service or
similarly trained personnel to avoid danger.
Anleitung_BMR_1400_4258582:_ 29.01.2009 9:47 Uhr Seite 10
Otros manuales para BMR 1400
2
Tabla de contenidos
Idiomas:
Otros manuales de Equipos de construcción de Parkside
Parkside
Parkside PFMR 1400 A1 Manual de usuario
Parkside
Parkside PDTA 5 A1 Manual de usuario
Parkside
Parkside 106628 Manual de usuario
Parkside
Parkside PFMR 1400 C2 Manual de usuario
Parkside
Parkside PFMR 1400 D3 Manual de usuario
Parkside
Parkside PFMR 1400 C2 Manual de usuario
Parkside
Parkside PDRW 1800 A1 Manual de usuario
Parkside
Parkside PFMR 1400 B1 Manual de usuario
Parkside
Parkside PFMR 1600 A1 Manual de usuario
Parkside
Parkside PFMR 1600 A1 Manual de usuario
