Parker 890CS Manual de usuario

HA468445U002:890 Engineering Reference

Product Manual : Frames B, C & D

HA468445U002 Issue 3

Compatible with Version 2.3 Software

2007 Parker SSD Drives, a division of Parker Hannifin Ltd.

All rights strictly reserved. No part of this document may be stored in a retrieval system, or

transmitted in any form or by any means to persons not employed by a Parker SSD Drives

company without written permission from Parker SSD Drives, a division of Parker Hannifin Ltd .

Although every effort has been taken to ensure the accuracy of this document it may be necessary,

without notice, to make amendments or correct omissions. Parker SSD Drives cannot accept

responsibility for damage, injury, or expenses resulting therefrom.

WARRANTY

Parker SSD Drives warrants the goods against defects in design, materials and workmanship for

the period of 12 months from the date of delivery on the terms detailed in Parker SSD Drives

Standard Conditions of Sale IA058393C.

Parker SSD Drives reserves the right to change the content and product specification without

notice.

UK Head Office: Parker SSD Drives

NewCourtwickLane,Littlehampton,WestSussexBN177RZ

Tel:+44(0)1903737000 Fax:+44(0)1903737100

CANADA

Parker Hannifin Corporation

4391 Harvester Road

Unit # 1, Burlington,

Ontario L7L 4X1

Tel: +1 (905) 333 7787

Fax: +1 (905) 632 0107

CHINA

Parker Hannifin Motion & Control

(Shanghai) Co. Ltd.

SSD Drives

Suite B2109 21st Floor,

Hanwei Plaza, 7 Guanghua Road

Chaoyang District, Beijing 100004

Tel: +86 (10)6561 0520/1/2/3/4/5

Fax: +86 (10)6561 1070

FRANCE

Parker SSD Parvex

8 Avenue du Lac

B.P. 249

F-21007 Dijon Cedex

Tel: +33 (0)3 80 42 42 40

Fax: +33 (0)3 80 42 41 23

GERMANY

Parker Hannifin GmbH

Von-Humboldt-Strasse 10

64646 Heppenheim

Tel: +49 (6252) 798200

Fax: +49 (6252) 798205

ITALY

Parker Hannifin SPA

Via Gran Sasso 7

20030 Lentate Sul Seveso

Milano

Tel: +39 (0362) 557308

Fax: +39 (0362) 557312

USA

Parker Hannifin Corporation

SSD Drives

9225 Forsyth Park Drive

Charlotte

North Carolina 28273-3884

Tel: +1 (704) 588 3246

Fax: +1 (704) 588 3249

Local availability and service support also in:

Argentina ●Australia ●Austria ●Bangladesh ●Belgium ●Brazil ●Chile ●Colombia ●Costa Rica ●Cyprus

Czech Republic ●Denmark ●Ecuador ●Egypt ●Finland ●Greece ●Hong Kong ●Hungary ●India ●Indonesia

Iran ●Ireland ●Israel ●Japan ●Jordan ●Kenya ●Korea ●Kuwait ●Lithuania ●Malaysia ●Netherlands

New Zealand ●Nigeria ●Norway ●Peru ●Philippines ●Poland ●Portugal ●Quatar ●Romania ●Russia

Saudi Arabia ●Singapore ●Slovenia ●Slovakia ●South Africa ●Spain ●Sri Lanka ●Sweden ●Switzerland

Taiwan ●Thailand ●Turkey ●United Arab Emirates ●Vietnam ●Zimbabwe

Driven by experience,knowledge and strength

www.ssddrives.com

*HA468445U002*

890

S E R V I C E &

R E P A I R

C E N T R E S

Safety

890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D Page 1-1

Chapter 1

Safety

Please read these important Safety notes before installing and operating this equipment.

Caution

CAUTION notes in the manual warn of danger

to equipment.

WARNING

WARNING notes in the manual warn of

danger to personnel.

Safety

Page 1-2 890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D

Requirements IMPORTANT Please read this information BEFORE installing the equipment.

Intended Users

This manual is to be made available to all persons who are required to install, configure or service

equipment described herein, or any other associated operation.

The information given is intended to highlight safety issues, and to enable the user to obtain maximum

benefit from the equipment.

Complete the following table for future reference detailing how the unit is to be installed and used.

INSTALLATION DETAILS

Model Number

(see product label)

Where installed

(for your own information)

Unit used as a:

(refer to Certification) RComponent RRelevant Apparatus Unit fitted: RWall-mounted REnclosure

Application Area

The equipment described is intended for industrial motor speed control utilising AC induction or AC

synchronous machines.

Personnel

Installation, operation and maintenance of the equipment should be carried out by qualified personnel. A

qualified person is someone who is technically competent and familiar with all safety information and

established safety practices; with the installation process, operation and maintenance of this equipment; and

with all the hazards involved.

Safety

890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D Page 1-3

Product Warnings

Caution

Risk of electric shock

Caution

Refer to documentation

Earth/Ground

Protective Conductor

Terminal

Hazards

DANGER! - Ignoring the following may result in injury

1. This equipment can endanger life by exposure to

rotating machinery and high voltages.

2. The equipment must be permanently earthed due to

the high earth leakage current, and the drive motor

must be connected to an appropriate safety earth.

3. Ensure all incoming supplies are isolated before

working on the equipment. Be aware that there may

be more than one supply connection to the drive.

4. There may still be dangerous voltages present at

power terminals (motor output, supply input phases,

DC bus and the brake, where fitted) when the motor is

at standstill or is stopped.

5. For measurements use only a meter to IEC 61010 (CAT III or

higher). Always begin using the highest range.

CAT I and CAT II meters must not be used on this product.

6. Allow at least 5 minutes for the drive's capacitors to discharge

to safe voltage levels (<50V). Use the specified meter capable

of measuring up to 1000V dc & ac rms to confirm that less

than 50V is present between all power terminals and between

power terminals and earth.

7. Unless otherwise stated, this product must NOT be dismantled.

In the event of a fault the drive must be returned. Refer to

"Routine Maintenance and Repair".

Safety

Page 1-4 890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D

WARNING! - Ignoring the following may result in injury or damage to equipment

SAFETY

Where there is conflict between EMC and Safety requirements, personnel safety shall always take precedence.

•Never perform high voltage resistance checks on the

wiring without first disconnecting the drive from the

circuit being tested.

•Whilst ensuring ventilation is sufficient, provide guarding

and /or additional safety systems to prevent injury or

damage to equipment.

•When replacing a drive in an application and before

returning to use, it is essential that all user defined

parameters for the product’s operation are correctly

installed.

•All control and signal terminals are SELV, i.e. protected

by double insulation. Ensure all external wiring is rated

for the highest system voltage.

•Thermal sensors contained within the motor must have at

least basic insulation.

•All exposed metalwork in the Inverter is protected by

basic insulation and bonded to a safety earth.

•RCDs are not recommended for use with this product but,

where their use is mandatory, only Type B RCDs should

be used.

EMC

•In a domestic environment this product may cause radio

interference in which case the user may be required to take

adequate counter-measures.

•This equipment contains electrostatic discharge (ESD)

sensitive parts. Observe static control precautions when

handling, installing and servicing this product.

•This is a product of the restricted sales distribution class

according to IEC 61800-3. It is designated as

“professional equipment” as defined in EN61000-3-2.

Permission of the supply authority shall be obtained

before connection to the low voltage supply.

Safety

890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D Page 1-5

CAUTION!

APPLICATION RISK

•The specifications, processes and circuitry described herein are for guidance only and may need to be adapted to the

user’s specific application. We can not guarantee the suitability of the equipment described in this Manual for individual

applications.

RISK ASSESSMENT

Under fault conditions, power loss or unintended operating conditions, the drive may not operate as intended. In particular:

•Stored energy might not discharge to safe levels as

quickly as suggested, and can still be present even

though the drive appears to be switched off

•The motor's direction of rotation might not be controlled

•The motor speed might not be controlled

•The motor might be energised

A drive is a component within a drive system that may influence its operation or effects under a fault condition.

Consideration must be given to:

•Stored energy •Supply disconnects •Sequencing logic •Unintended operation

Safety

Page 1-6 890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D

Getting Started

890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D Page 2-1

Chapter 2

Getting Started

A few things you should do when you first receive the unit.

♦How the manual is organised

♦Initial steps

♦Inspect the unit for transit damage

♦Packaging and lifting

Getting Started

Page 2-2 890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D

About this Manual

IMPORTANT Motors used must be suitable for Inverter duty.

Note Do not attempt to control motors whose rated current is less than 25% of the drive rated current. Poor

motor control problems may occur if you do.

This manual is intended for use by the installer, user and programmer of the 890 drive. It assumes a

reasonable level of understanding in these three disciplines.

Note Please read all Safety information before proceeding with the installation and operation of this unit.

It is important that you pass this manual on to any new user of this unit.

How the Manual is Organised

This Engineering Reference manual is organised into chapters, indicated by the numbering on the edge of

each page.

Information for all 890 units is included (890CS Common Bus Supply, 890CD Common Bus Drive, 890SD

Standalone Drive).

The manual is more detailed than the relevant QuickStart manual, and so is of use to the unfamiliar as well

as the high-end user.
