Paradyne 8955 Manual de usuario

ATM Line Cards

Models 8955, 8965, 8968,

8975, and 8985

User’s Guide

Document No. 8900-A2-GB20-50

August 2005

AAugust 2005 8900-A2-GB20-50

Printed in U.S.A.

Notice

This publication is protected by federal copyright law. No part of this publication may be copied or distributed,

transmitted, transcribed, stored in a retrieval system, or translated into any human or computer language in any form

or by any means, electronic, mechanical, magnetic, manual or otherwise, or disclosed to third parties without the

express written permission of Paradyne Corporation, 8545 126th Ave. N., Largo, FL 33773.

Paradyne Corporation makes no representation or warranties with respect to the contents hereof and specifically

disclaims any implied warranties of merchantability or fitness for a particular purpose. Further, Paradyne Corporation

reserves the right to revise this publication and to make changes from time to time in the contents hereof without

obligation of Paradyne Corporation to notify any person of such revision or changes.

Changes and enhancements to the product and to the information herein will be documented and issued as a new

release to this manual.

Warranty, Sales, Service, and Training Information

Contact your local sales representative, service representative, or distributor directly for any help needed. For

additional information concerning warranty, sales, service, repair, installation, documentation, training, distributor

locations, or Paradyne worldwide office locations, use one of the following methods:

Internet: Visit the Paradyne World Wide Web site at www.paradyne.com. (Be sure to register your warranty at

www.paradyne.com/warranty.)

Telephone: Call our automated system to receive current information by fax or to speak with a company

representative.

— Within the U.S.A., call 1-800-795-8004

— Outside the U.S.A., call 1-727-530-2340

Document Feedback

We welcome your comments and suggestions about this document. Please mail them to Technical Publications,

Paradyne Corporation, 8545 126th Ave. N., Largo, FL 33773, or send e-mail to [email protected]. Include

the number and title of this document in your correspondence. Please include your name and phone number if you

are willing to provide additional clarification.

Trademarks

Acculink, ADSL/R, Bitstorm, Comsphere, DSL the Easy Way, ETC, Etherloop, FrameSaver, GranDSLAM, GrandVIEW,

Hotwire, the Hotwire logo, iMarc, Jetstream, MVL, NextEDGE, Net to Net Technologies, OpenLane, Paradyne, the

Paradyne logo, Paradyne Credit Corp., the Paradyne Credit Corp. logo, Performance Wizard, ReachDSL, StormPort,

TruePut are registered trademarks of Paradyne Corporation.

Connect to Success, Hotwire Connected, JetFusion, JetVision, MicroBurst, PacketSurfer, Quick Channel, Reverse

Gateway, Spectrum Manager, and StormTracker are trademarks of Paradyne Corporation.

All other products or services mentioned herein are the trademarks, service marks, registered trademarks, or

registered service marks of their respective owners.

Regulatory and Safety Information

Refer to the appropriate Broadband Loop Carrier (BLC) installation guide for all regulatory notices and safety

information.

8900-A2-GB20-50 August 2005 i

Contents

About This Guide

Document Purpose and Intended Audience . . . . . . . . . . . . . . . . . . . . iii

Document Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii

Product-Related Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv

1 About the ATM Line Cards

ATM Line Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

ATM Line Card Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

ATM Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Endpoint Support Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Sample Network Configurations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

SNMP Management Capabilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

Management Information Base (MIB) Support . . . . . . . . . . . . . . . 1-4

SNMP Trap Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

2 Accessing the SCP Card Web Interface

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Logging Into the Web Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Help Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Ending a Session . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

3 Configuration Using the Web Interface

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Configuring Spectrum Management . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Configuring ReachDSL Ports (8955 and 8975) . . . . . . . . . . . . . . . . . . 3-2

Configuring ADSL Ports (8965, 8968) . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

Configuring SHDSL Ports (8985) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5

Configuring Line Profiles (8955, 8965, 8975, 8968). . . . . . . . . . . . . . . 3-6

Creating Line Profiles for Ports (8985) . . . . . . . . . . . . . . . . . . . . . . . . . 3-7

Configuring Alarm Threshold Profiles (8955, 8965, 8968, 8975) . . . . . 3-8

Creating Alarm Threshold Profiles for Model 8985 . . . . . . . . . . . . . . . 3-10

Configuring Cross Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12

Default Mappings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12

Contents

ii August 2005 8900-A2-GB20-50

Adding a Port-to-Port Cross Connection . . . . . . . . . . . . . . . . . . . . 3-12

Adding a Slot-to-Slot Cross Connection . . . . . . . . . . . . . . . . . . . . 3-14

Configuring ATM Ports. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16

Configuring Traffic Profiles. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-17

4 Monitoring

What to Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

Front Panel LEDs (Models 8955, 8965, 8975, and 8985) . . . . . . . . . . 4-3

Front Panel LEDs (Model 8968). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4

5 Diagnostics

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

Lamp Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

Loopback Test (Model 8985 Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2

6 Maintenance Procedures

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1

Uploading and Downloading a Configuration. . . . . . . . . . . . . . . . . . . . 6-2

Resetting the Configuration to Default Settings. . . . . . . . . . . . . . . 6-3

Resetting the Configuration to Downloaded Settings . . . . . . . . . . 6-3

Downloading and Switching Firmware . . . . . . . . . . . . . . . . . . . . . . . . . 6-4

Downloading Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4

Switching Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5

Restarting the Line Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5

A Connector Pin Assignments

8620 and 8820 Telco Connector Pinouts. . . . . . . . . . . . . . . . . . . . . . . A-1

Model 8968 Line Card Telco Connector Pinouts . . . . . . . . . . . . . . . . . A-2

B Technical Specifications

Index

8900-A2-GB20-50 August 2005 iii

About This Guide

Document Purpose and Intended Audience

This guide contains information needed to configure and operate the Models

8955-B1, 8965-B2, 8968-B1, 8975-B1, and 8985-B2 ATM line cards, and is

intended for installers and operators. Basic installation information can be found in

the ATM Line Cards, Models 8955, 8965, 8968, 8975, and 8985, Installation

Instructions.

Document Summary

Section Description

Chapter 1, About the ATM Line

Cards

Describes the cards’ features and capabilities.

Chapter 2, Accessing the SCP

Card Web Interface

Provides instructions for accessing the user interface.

Chapter 3, Configuration Using

the Web Interface

Provides instructions for configuring the line cards.

Chapter 4, Monitoring Describes how to locate information about a line card

and its status.

Chapter 5, Diagnostics Provides instructions for running a lamp test and

loopback test.

Chapter 6, Maintenance

Procedures

Provides instructions for uploading or downloading a

configuration, downloading firmware, and resetting the

card.

Appendix A, Connector Pin

Assignments

Lists the pin assignments for the Broadband Loop

Carrier (BLC) Telco connectors.

Appendix B, Technical

Specifications

Contains physical and regulatory specifications, and

power consumption values.

Index Lists key terms, acronyms, concepts, and sections in

alphabetical order.

About This Guide

iv August 2005 8900-A2-GB20-50

A master glossary of terms and acronyms used in Paradyne documents is

available on the World Wide Web at www.paradyne.com. Select Support →

Technical Manuals →Technical Glossary.

Product-Related Documents

Complete documentation for this product is available online at

www.paradyne.com. Select Support →Technical Manuals.

To order a paper copy of a Paradyne document, or to speak with a sales

representative, please call 1-727-530-2000.

Document Number Document Title

6381-A2-GN10 Hotwire ReachDSL Modem, Model 6381 with Inline Phone Filter,

Installation Instructions

6390-A2-GK40 Hotwire ReachDSL Modem, Model 6390 with Inline Phone Filter,

Installation and Operation Supplement

6390-A2-GN10 Hotwire ReachDSL Modem, Model 6390 with Inline Phone Filter,

Installation Instructions

7890-A2-GB22 GrandVIEW EMS User’s Guide

8000-A2-GB30 8620 and 8820 Broadband Loop Carrier SNMP Reference

8400-A2-GB20 Shelf Concentration and Processing (SCP) Card with ATM

Uplink User’s Guide

8400-A2-GB21 Shelf Concentration and Processing (SCP) Card with IP Uplink

User’s Guide

8400-A3-GB21 8620 and 8820 Broadband Loop Carrier TL1 Interface

Reference

8400-A3-GB22 8620 and 8820 Broadband Loop Carrier Command Line

Interface Reference

8620-A2-GN20 8620 Broadband Loop Carrier Installation Guide

8820-A2-GN20 8820 Broadband Loop Carrier Installation Guide

8900-A2-GZ40 ATM Line Cards, Models 8955, 8965, 8968, 8975, and 8985,

Installation Instructions

8900-A2-GB20-50 August 2005 1-1

About the ATM Line Cards

ATM Line Cards

The 8955, 8965, 8968, 8975, and 8985 Asynchronous Transfer Mode (ATM) Line

Cards are circuit boards mounted in an 8620 or 8820 Broadband Loop Carrier

(BLC) and used to transport ATM cells at high speeds over a single twisted-pair

connection or, optionally, two twisted-pair connections (8985 only).

Model 8955 supports ReachDSL®. It automatically adjusts to the highest rate

the loop can support, from 32 to 2176 kbps. It has 24 ports.

Models 8965 and 8968 support Asymmetric Digital Subscriber Line (ADSL).

They can be set to adapt to the line conditions at startup, or set to the following

fixed rates depending on line code:

— G.lite: 64 to 3008 kbps downstream and 32 to 512 kbps upstream.

— G.dmt, ANSI T1.413, ADSL2, and ADSL2+: 32 to 8000 kbps downstream

and 32 to 832 kbps upstream.

— ADSL2: 32 to 16000 kbps downstream and 32 to 1056 kbps upstream.

— ADSL2+: 32 to 29000 kbps downstream and 32 to 2200 kbps upstream.

The Model 8965 has 24 ports and the Model 8968 has 48 ports.

Model 8975 supports ReachDSL+, providing ADSL or ReachDSL 2.2 on a

port-by-port basis depending on the capabilities of the line and endpoint.

Model 8985 supports Single-pair High-speed Digital Subscriber Line

(SHDSL). It can be set to adapt to the line conditions at startup, or set to a

fixed line rate from 192 to 2304 kbps (or 384 to 4608 kbps with two wire pairs).

It has 24 ports.

The 8955, 8965, 8968, 8975, and 8985 line cards are configured and managed

using the Shelf Concentration and Processing (SCP) card.

Part of Paradyne’s Hotwire Connected™ program, the cards interoperate with

third-party DSL endpoints providing end users with the ability to select the best

equipment to fit their application. The line cards also integrate support for multiple

DSL services on a single card.

1. About the ATM Line Cards

1-2 August 2005 8900-A2-GB20-50

ATM Line Card Features

The ATM Line Cards have these standard features:

Alarm indication. Activates front panel LEDs.

Diagnostics. Provides lamp test and SHDSL line loopback (8985).

Device and test monitoring. Provides the capability of tracking and

evaluating the unit’s operation, including health and status, and error-rate

monitoring.

Software upgrade. Supports software upgrades using FTP.

ATM Features

The cards’ ATM features include:

Classes of service. Supports traffic management service categories

necessary to support voice and data applications:

—CBR

— rt-VBR

—nrt-VBR

— UBR (only class of service supported for the Model 8955)

Auto configuration. Two Virtual Channel Connections (VCCs) per port are

automatically configured, providing data and voice services.

Multiple virtual circuits. Up to 250 additional VCCs can be configured by the

user and assigned among the DSL ports.

ATM statistics. Maintains statistics for:

— Total cells received

— Total cells transmitted

— Total cells dropped

— Loss of cell delineation events

— Cells with uncorrectable HEC

Endpoint Support Features

The cards’ endpoint support features include:

Third-party endpoint support. Models 8965, 8968, 8975, and 8985 line

cards support third-party endpoints through the Hotwire Connected program,

including Integrated Access Devices (IADs) and data-only endpoints from

numerous industry-leading vendors. The Model 8985 card supports third-party

endpoints using the ITU SHDSL standard.

1. About the ATM Line Cards

8900-A2-GB20-50 August 2005 1-3

Model 6381 and 6390 Modem support. Models 8955, 8965, 8975, and 8968

line cards support the Model 6381 Modem. The Model 8955 line card also

supports the discontinued Model 6390 Modem.

Model 8300 Modem support. The Model 8985 line card supports the

Model 8300 Modem.

Automatic rate adaptation. The card and the endpoint negotiate the best

rate, limited if desired by the user, through automatic rate adaptation.

Sample Network Configurations

Figure 1-1 shows the ATM Line Card used to carry voice over DSL.

Figure 1-1. Endpoint with Voice Interfaces

Figure 1-2 shows a configuration in which the endpoints include a router to provide

data encapsulation.

Figure 1-2. Router Endpoint

05-17444-02

AT M

Network

ATM Cells

DSL

Integrated

Access

Device

(IAD)

SCP Card

ATM

Line Card

8820 LC

Customer Premises

LAN

ISP

Corporate

Site

ATM Cells

Voice

Gateway

PSTN Voice

Traffic

05-17443-03

AT M

Network Router

ATM Cells

DSL

SCP Card

ATM

Line Card

8820 LC

Customer Premises

LAN

ISP

Corporate

Site

1. About the ATM Line Cards

1-4 August 2005 8900-A2-GB20-50

SNMP Management Capabilities

The ATM Line Cards support SNMP Version 1, and can be managed by

Paradyne’s GrandVIEW®or any industry-standard SNMP manager.

Management Information Base (MIB) Support

For a detailed description of supported MIBs, visit Paradyne’s Web site at

www.paradyne.com. The following MIBs are supported:

ATM Forum SNMP M4 Network Element View (af-nm-0095.001)

Definitions of Managed Objects for the ADSL Lines (RFC 2662)

Definitions of Managed Objects for ATM Management (RFC 2515)

Definitions of Managed Objects for HDSL2 and SHDSL Lines

(draft-ietf-adslmib-hdsl2-10.txt)

Definitions of Textual Conventions and OBJECT-IDENTITIES for ATM

Management (RFC 2514)

Evolution of MIB II Interfaces (RFC 2863)

ADSL Extension MIB (Models 8965, 8975, and 8968)

(draft-ietf-adslmib-adslext.txt)

SHDSL MIB (Model 8985 only) (draft-ietf-adslmib-hdsl2.txt)

Entity MIB Using SMIv2 (RFC 2037)

MIB II and the Interfaces Group MIB (RFC 1213, RFC 2233)

Paradyne enterprise MIBs for:

— xDSL Interface

— SLE Device Control

— SLE Device Health and Status

—MaxVciVpi-MIBTable

—IF-MIBTable

— ATM VPL Statistics Table

SNMP Trap Support

The ATM Line Cards support SNMP traps as shown in the 8620 and 8820

Broadband Loop Carrier SNMP Reference.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Tarjeta de red de Paradyne

Paradyne

Paradyne Hotwire 8335 Manual de usuario

Paradyne

Paradyne Hotwire 8343 Manual de usuario

Paradyne

Paradyne 3162 Manual de usuario

Paradyne

Paradyne Hotwire ATM Line Cards 8335 Manual de usuario

Paradyne

Paradyne Hotwire 8310 Manual de usuario

Paradyne

Paradyne Hotwire 8312 Manual de usuario

Paradyne

Paradyne FrameSaver 9120 Manual de usuario

Paradyne

Paradyne 8975 Manual de operación y mantenimiento

Paradyne

Paradyne HOTWIRE 5171 Manual de usuario

Paradyne

Paradyne Hotwire 8303 Manual de usuario

Paradyne

Paradyne HOTWIRE 8310 MVL Manual de usuario

Paradyne

Paradyne BitStorm 2600 IP DSLAM Manual de usuario

Paradyne

Paradyne 3166 DSU Manual de usuario

Paradyne

Paradyne Hotwire 8335 Manual de usuario

Paradyne

Paradyne Hotwire 8323 Manual de usuario

Paradyne

Paradyne Hotwire 8510 Manual de usuario

Paradyne

Paradyne HotWire 8546 Manual de usuario

Paradyne

Paradyne 8411-A1-000 Manual de usuario

Paradyne

Paradyne UIM-10/100 Manual de usuario

Paradyne

Paradyne 8968 Manual de operación y mantenimiento

Paradyne

Paradyne FrameSaver 9620 Manual de usuario

Paradyne

Paradyne Hotwire 8373 Manual de usuario

Paradyne

Paradyne Adapter Bracket Manual de operación y mantenimiento

Paradyne

Paradyne Hotwire 8303 Manual de usuario

Manuales populares de Tarjeta de red de otras marcas

FirstComm

FirstComm OBiWiFi5G Manual de usuario

Sun Microsystems

Sun Microsystems Interface Adapter Manual de usuario

TRENDnet

TRENDnet TU2-ETG Manual de usuario

YASKAWA

YASKAWA SI-EN3 Manual de usuario

Belkin

Belkin F5D7050 Manual de usuario

3Com

3Com EtherLink 3C509B Manual de usuario

TRENDnet

TRENDnet TEG-PCITX Manual de usuario

Cisco

Cisco MC16E Manual de usuario

Delta Electronics

Delta Electronics Braking Modules VFDB Series Manual de usuario

TwinMOS

TwinMOS Booming Manual de usuario

Dialogic

Dialogic Media Board DM/V1200BTEPEQ Manual de usuario

Buffalo

Buffalo AirStation WLI-PCM-L11GP Manual de usuario

National Instruments

National Instruments NI 9234 Manual de usuario

Hama

Hama 49276 Manual de usuario

Linksys

Linksys WCF54G - Wireless-G Compact Flash Card Manual de operación

Compaq

Compaq Wireless LAN 100 Manual de usuario

Bose

Bose PowerMatch Dante Manual de usuario

TRENDnet

TRENDnet TEG-PCITXR Manual de usuario
