642 LCD Keypad
User Manual
Esprit 642 LCD Keypad
Table of Contents
Introduction .......................................................1
Legend ......................................................................... 1
Basic Operation ................................................2
Keypad Indicator Lights ................................................2
Visual Feedback ........................................................... 2
Auditory Feedback ........................................................ 3
Info List ......................................................................... 4
Access Codes ...................................................5
User Codes ................................................................... 5
Duress Code .................................................................5
Programming Access Codes ........................................ 6
Deleting an Access Code .............................................7
Arming & Disarming .........................................8
Exit Delay ..................................................................... 8
Disarming & Deactivating an Alarm ..............................8
Alarm Memory Display ................................................. 8
Regular System Arming ................................................9
Stay Arming ................................................................ 10
Fast Exit ..................................................................... 10
Instant Arming ............................................................ 11
Force Arming .............................................................. 12
Manual Bypass Programming .................................... 12
Bypass Recall ............................................................. 13
One-Touch Arming ..................................................... 14
User Manual
Keyswitch/Push-Button Arming ...................................14
Timed Auto-Arming .....................................................15
No Movement Automatic Arming ................................16
Fire Alarms ..................................................................16
Additional Features ........................................18
Chime Zone Selection .................................................18
Keypad Muting ............................................................18
Panic Alarms ...............................................................19
Setting Time and Day .................................................20
Quick Function Keys ...................................................20
Keypad Settings ..........................................................22
Event List ....................................................................22
Partitioning the System ...............................................24
Testing & Maintenance ...............................................26
Trouble Display ...............................................28
System Check list ...........................................30
Panic Buttons ..............................................................30
Zone Checklist ............................................................30
User Access Code List ................................................32
Esprit 642 LCD Keypad 1
1.0 Introduction
Thank you for selecting the Esprit security system from
Paradox Security Systems. The Esprit line of security
systems brings together reliable, yet simple products that
offer state-of-the-art security options. These options enable
you to customize many of the advanced features through a
straightforward keypad interface.
The Esprit system reports a wide range of status conditions
to the monitoring station. Automatic test reports can also be
sent to the monitoring station to ensure that your system is
functioning properly. We recommend that such tests be
conducted regularly. Consult your alarm system installer for
instructions.
All of the actions performed in your security system will be
executed and displayed through the keypad. We recommend
that you read this manual thoroughly and have your installer
explain basic system operation to you.
1.1 Legend
Throughout this book there are icons to represent points of
interest. The following are used:
= to indicate notes or reminders.
= to indicate a warning or caution.
= to indicate a button on the keypad.
[
KEY
]
2 User Manual
2.0 Basic Operation
Many of the features in your system must be enabled by your
installer. If the feature is not programmed, the keypad will
emit a rejection beep and the action will be canceled.
2.1 Keypad Indicator Lights
The state of each light on the Esprit 642 keypad represents a
specific condition in your system as shown in Figure 2.1.
Figure 2.1: Keypad Indicator Lights
2.2 Visual Feedback
Everything you need to know about your security system is
displayed on the Esprit 642 keypad. The zones in your
security system are immediately identified and important
messages regarding system status appear on the screen.
When zone status is normal, the LCD display will read:
system ready. If any zones are open, the display will
Ready (Green)
ON = Zone(s) closed
OFF = Zone(s) open
FLASH = During exit delay
Arm (Red)
ON = System armed
OFF = System disarmed
FAST FLASH = Alarm
Esprit 642 LCD Keypad 3
read: zones open. While the display will automatically
show which zones are open, you can also press the [U]or
[V]keys to view a specific zone.
Figure 2.2: Overview of Esprit 642 LCD Keypad
2.3 Auditory Feedback
Every time you press a key the system will emit a beep. This
sound affirms that you have made an entry. When you enter
information on the keypad, it will guide you with these tones
to communicate acceptance or rejection of your entries. You
should be familiar with the following keypad beep tones:
•Confirmation Beep: when an operation (i.e. arming/
disarming) is successfully entered on the keypad or when
the system switches to a new status/mode, the keypad
sounder will produce an intermittent beep tone (four short
beeps).
The messages on the LCD
screen display system status
and guide you through
operations.
AC indicates power
(option programmed by your
installer).
Use these buttons to scroll
through menus.
4 User Manual
•Rejection Beep: when the system reverts to its previous
status, or when an operation is incorrectly entered on the
keypad, the sounder will emit a continuous beep tone
(beeeeep).
2.4 Info List
Your installer can program the control panel to include
important information such as emergency numbers, tips, or
notes. This information will be saved even after a total power
loss.
How do I view the Info List?
1. Press the [INFO] key.
2. Use the [U]or [V]keys to scroll through the info list.
3. Press the [CLEAR]key to exit.
Esprit 642 LCD Keypad 5
3.0 Access Codes
Access codes are personal identification numbers that allow
you to enter certain programming modes and arm or disarm
the system. In addition to the Master Code, the Esprit control
panel can be programmed to accept up to 48 user codes,
each with a unique access code.
Avoid programming simple or obvious access codes,
such as your telephone number, address, or codes
like 1234.
3.1 User Codes
Your installer will program the panel to accept four- or six-digit
access codes and will assign code definitions to all user
codes. The Master Code (default: 474747) and user codes
are identified by a two digit code number, where code
numbers 01-48 represent access codes 1-48 and code
number 00 represents the Master Code. To create or modify
access codes please see Programming Access Codes on
page 6 and Deleting an Access Code on page 7.
3.2 Duress Code
The last user code (code number 48) can be programmed as
a Duress code. If you are forced to arm or disarm your
system under threat, you can enter this access code to
produce a silent alarm at the monitoring station. Check with
your installer to see if this option is enabled on your system.
6 User Manual
3.3 Programming Access Codes
The display will read: none to indicate that an
access code is available (does not contain
information).
How do I create an access code?
The Master Code or User Code 01 must be used to enter
programming mode in order to create access codes.
1. Press the [ENTER]key. The display will briefly read:
enter code to programming mode.
2. Enter the [MASTER CODE]or [USER CODE 01]in order to
create access codes. The display will read:
Programming mode section.
3. Enter a two digit code number (00 to 48). The display
will read: programming in process. This
message remains until you have entered a valid
access code.
4. Enter a four- or six-digit access code. A valid entry will
return the programming mode section
message.
5. Return to step 3 to include additional entries or press
[CLEAR]to exit.
