Panduit SmartZone E24 Manual de usuario

Release 1.0

Issue 2

SmartZone™ Gateway E24

User Manual

SmartZone Gateway E24 User Manual

-2-

by any means, electronic, mechanical, photocopying, recording or otherwise, without written permission from Panduit. No patent liability

is assumed with respect to the use of the information contained herein.

Although every precaution has been taken in the preparation of this book, Panduit assumes no responsibility for errors or omissions.

Neither is any liability assumed for damages resulting from the use of the information contained herein.

SmartZone Gateway E24 User Manual

-3-

Table of Contents

Introduction 6

Overview 6

Safety and Installation Statement 6

Grounding 6

Servicing 6

Waste Electrical and Electronic Equipment (WEEE) Statements 7

Disposal of Waste Equipment by Users in Private Household in the European

Union 7

SmartZone Gateway Applications 9

Remote Temperature and Humidity Sensing 9

Power Monitoring 9

E24 Package 9

LEDs 9

Buttons 10

Rear of E24 10

Port Information 11

Installation Requirements 12

Rack – Mounting 12

Additional Equipment Required 12

Before You Begin 12

Installation Warning Statements 12

Rack-Mount the E24 13

Initial Setup 14

Default Settings 14

Connecting to the Web Management Interface 14

Changing your PC's IP Address 14

Initial Network Setup 19

Entering NMS Details 19

Entering Trap Receiver Details 20

Adding Users 20

Web Management Interface 22

Network Setup - Overview 22

Setup - IP Configuration 23

System Name 23

System Location 23

Contact Name 24

IP Address 24

Subnet Mask 24

Gateway 24

Setup - HTTP 25

Setup – LDAP Servers 26

SmartZone Gateway E24 User Manual

-4-

Disabled 26

Primary 26

Secondary 26

Both 27

Credential Cache 27

Display Name 27

IP Address 27

Unit Base DN 27

Users Base DN 1 27

Users Base DN 2 27

Setup - SNMP NMS 28

IP Address 28

Community String 28

NMS Access 28

Setup - SNMP Trap Receivers 29

IP Address 29

Community String 29

Receive Traps 29

Setup - Modbus 30

Setup - Users 31

Username 31

Password 31

Level 31

Setup - Email Alerts 32

Setup - Time Settings 33

Time Adjustments 33

Setup - Syslog Servers 34

Setup - Events 35

Setup - Preferences 35

Setup – Restart 36

Restart Unit 37

Restart Now 37

Reset to Factory Defaults 37

Sensor Inputs – Configuration and Status 38

Status 38

Status Indicators 38

Input Sensors – Defaults 39

Calibration Offset 39

Hysteresis Value 40

Limits and Traps 40

Repeat Timer 40

Normal State 41

Trigger Type 41

Level 41

SmartZone Gateway E24 User Manual

-5-

Normal to Non-Normal (Positive Edge) 42

Non-Normal to Normal (Negative Edge) 42

Input Sensors - Configure 42

Name 43

Type 43

LDAP 43

E24 LDAP Overview 43

E24 LDAP Structure 43

Group Membership and Access Level 45

E24 Unit Configuration 46

Temperature Sensor Adapter Installation 48

New Installations 48

Existing Installations. 49

Fitting the Adapter In-line. 49

Troubleshooting 51

Resetting the SmartZone Gateway to Factory Default Settings 51

Problem: The NMS Cannot Poll the SmartZone Gateway Unit 51

Technical Support 52

Appendix A: Technical Details 53

Factory Default Settings 53

Operating Information 53

Unit Dimensions 53

Appendix B: Hysteresis Demystified 54

Appendix C: Encryption and Security 56

SmartZone Gateway E24 User Manual

-6-

Introduction

Overview

The SmartZone™ Gateway E24 is a compact device used to monitor up to twenty four

input sensors (Temperature, Humidity, Digital or Analog voltage).

The unit comprises both an SNMP interface and a secure web-based interface for mon-

itoring and management.

Some of the main features of the E24 unit are:

lSecure web management and configuration interface.

lSNMP enabled.

lTwenty Four sensor channels.

lOptional LCD Status module.

Safety and Installation Statement

Grounding

This is a Class II product that uses double insulation to provide electrical safety of the

product from the main power source.

To ensure correct operation, compliance with Class A and Class B electromagnetic emis-

sion standards, and optimal safety, connect the 4mm grounding stud (labeled “Earth” on

rear face of unit) to an electrical ground.

If the network covers an area served by more than one PDU, be sure their electrical

safety grounds are securely interconnected.

Network cabling may occasionally be subject to hazardous transient voltages (such as

lightning or disturbances in the electrical utilities power grid). Handle exposed metal

components of the installation with caution.

Servicing

There are no user-serviceable parts inside these products. Any maintenance or repair

must be performed by approved service-trained personnel.

SmartZone Gateway E24 User Manual

-7-

This product does not have a power switch; it is powered on when the adapter’s power

cord is plugged in.

Waste Electrical and Electronic Equipment

(WEEE) Statements

Disposal of Waste Equipment by Users in Private House-

hold in the European Union

This product must not be disposed of with your other household waste. It is your respons-

ibility to dispose of your WEEE equipment by handing it over to a designated collection

point for the recycling of waste electrical and electronic equipment.

For more information about where you can drop off your waste equipment for recycling,

please contact your local city or council office, your household waste disposal service or

the organisation where you purchased the product.

EC Declaration of Conformity

In accordance with EN ISO 17050-1:2005

In accordance with the following Directives:

l2006/95/ECThe Low Voltage Directive

l2004/108/ECThe Electromagnetic Compatibility Directive

l2002/95/EC The Restriction of the Use of certain Hazardous Substances in Elec-

trical and Electronic Equipment (RoHS)

l1907/2006/ECThe Registration, Evaluation, Authorisation & Restriction of Chem-

icals. (REACH)

The equipment:E24

Model Numbers:ZAEH2-01

Is in conformity with the applicable requirements of the following documents:

SmartZone Gateway E24 User Manual

-8-

Reference No. Title

BS EN 55022:1998

Information technology equipment. Radio disturbance

characteristics. Limits and methods of measurement.

Class A.

BS EN

55024:1998+A2:2003

Information technology equipment. Immunity char-

acteristics. Limits and methods of measurement.

BS EN 60950-1:2006 Information technology equipment. Safety. General

requirements

SmartZone Gateway E24 User Manual

-9-

SmartZone Gateway Applications

Remote Temperature and Humidity Sensing

The SmartZone Gateway monitors temperature and humidity and raises alarms or takes

action if a user-configured threshold is crossed.

Power Monitoring

This equipment allows around-the-clock monitoring of the electrical power environment

of the rack.

E24 Package

The standard E24 package contains a E24 unit with supporting hardware:

lE24 l Unit

lMains voltage cable

lRack mounting kit

lSupporting CD-ROM including MIB file and manuals

LEDs

Nine LEDs can be found on the front of the E24. Their purpose is described below the

illustration of the unit below:

Network

SmartZone Gateway E24 User Manual

-10 -

lSpeed: Illuminates when 100Mb/s network connected

lLink: lluminates when a network connection is present

Status

lCPU : Flashes when the unit is running normally

lAlarm: Illuminates when an alarm is present on the unit

Mode

lReserved for future use

Power

lON: Illuminates when unit is powered.

lFeed A: Illuminates when Power is connected to Feed A

lFeed B: Illuminates when Power is connected to Feed B

Buttons

lReset: Allows the user to reboot the unit.

lMode: The mode select switch is used to reset the unit to factory defaults. See the

Troubleshooting section for details.

Rear of E24

The following image show the rear panel of the E24 unit:
