Panasonic JS-925 series Manual de usuario

Before operating this product, please read these instructions carefully and save this document for

future use.

User’s Manual

POS Workstation

Model No. JS-925 Series

ontents

For USA / For CANADA

Read me First …..….............. 3

1.Getting Started …............. 4

2.Operation…..….…............... 7

3.Appendix.…..….…............... 8

For USA■

Federal Communications Commission Radio Frequency Interference Statement

This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial

environment.

This equipment generates, uses and can radiate radio frequency energy and, If not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at his own

expense.

Mercury caution

This product has a fluorescent lamp that contains mercury. Dispose may be regulated in your

community due to environmental considerations. For disposal or recycling information, please

contact your local authorities, or the Electronic Industries Alliance:

http://www.eiae.org

Ce produit possede une lampe fluorescente contenant du mercure. Ceci est a mettre au rebut

selon la regulation locale dans votre communaute en raison des considerations a prendre pour

la protection de l'environnement. Pour obtenir les informations relatives a la mise au rebut ou

au recyclage, veuillez prendre contact avec les autorites locales ou Electronic Industries

Alliance:

http://www.eiae.org

Battery

For C■anada

This product contains a CR Coin Cell Lithium Battery which contains Perchlorate

Material-special handling may apply.

See www.dtsc.ca.gov/hazardouswaste/Perchlorate.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) this device

must accept any interference received, including interference that may cause undesired

operation.

This Class A digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.

English

Read Me First

Introduction

Thank you for purchasing the JS-925 series Panasonic POS Workstation.

This manual describes the instructions for the POS Workstation.

Please read this manual carefully before using this product.

List of JS-925 series Product

Name Model Number. Remarks

JS-925WS-010 12inch type POS Workstation

JS-925WS-050 15inch type POS Workstation

Main Unit POS Workstation

JS-925WS-051 15inch type POS Workstation with HDD

Communication Board JS-925CB-010 IO extension board

Option Unit USB Board JS-925HU-010 USB HUB Board

JS-925HD-010 2.5 HDD module

Storage

Unit Storage module Unit JS-925SS-010 2.5 SSD module *1

List of Peripheral Product

MSR Unit JS-950MG-010 Magnetic stripe reader module

Dallas Key Reader Unit JS-950DP-010 Dallas KEY Reader module

ID module

Unit Fingerprint Sensor Unit JS-950FS-010 Fingerprint Sensor module

Rear

Display

Unit

Rear Display Unit JS-790RD-010 Rear Display module 2line

JS-950KT-W10 AC cord kit W

JS-950KT-UH0 AC cord kit UH

JS-950KT-E10 AC cord kit E

JS-950KT-F10 AC cord kit F

JS-950KT-A10 AC cord kit A

JS-950KT-Z10 AC cord kit Z

AC cord Kit AC cord kit

JS-950KT-K10 AC cord kit K

*1 Future option

1. Getting Started

Precautions■

[POS Workstation: JS-925 series]

IMPORTANT

Install a socket outlet adjacent to the equipment so that it will be easily accessible.

CAUTION

RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.

DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.

1. Avoid Radio Frequency Interference

Do not place the POS Workstation near a television or radio receiver.

2. Avoid Stacking

Do not place heavy objects on the POS Workstation.

3. Keep Small Objects Away

Do not insert paper clips or other small objects into POS Workstation.

There is the risk of heat, fire or explosion.

4. Keep Dry

There is the risk of heat, fire or explosion.

5. Do Not Disassemble the POS Workstation

Do not attempt to disassemble the POS Workstation. There is the risk of heat, fire or explosion.

6. Do Not Touch the Plug with Wet Hands.

There is the risk of electric shock.

7. Be Certain to Plug Fully Into the Outlet.

There is the risk of electric shock or fire.

8. When Unplugging, Make Sure to Hold the Body of the Plug.

If the power cord or outlet is damaged, there is a risk of electric shock, short circuit or fire.

9. Do Not Use a Damaged Power Cord or Plug.

There is the risk of electric shock or fire.

10. Clean the Dust off the Plug, Periodically.

There is the risk of heat or fire.

11. Do not use With Any Other Battery

Please use the specified battery.

CAUTION: Risk of explosion if battery is replaced by an incorrect type.

Dispose of used batteries according to the instructions and local requirements.

12. Do not Touch the Power-cord or Plug During a Storm.

There is the risk of electric shock or fire.

13. Do not use the POS Workstation outdoors.

This product assumes the indoor use. There is the risk of breakdown.

14. Do not put the POS Workstation on a slope or an unstable place.

This can cause damage to the unit or injury by falling.

Note: Do not open the Rear cover and Filter cover while the POS Workstation is operating.

Name of■each part & function

1. Operator’s Display

2. Rear Display

3. POP Holder

4. Power LED

5. LAN LED

6. HDD LED

7. Soft Switchr

4 5 6 7

8 9 10 11 12 13

1714 15 16 18 19

8. COM1(Powered)

9. COM2(Powered)

10. RJ Drawer#1, #2

11. Ethernet

12. USB#1, USB #2

13. VGA

14. COM3

15. COM4

*Option：JS-925CB install type

16. DIN Drawer#3

17. LINE-OUT

18. USB#3, USB #4

19. Speaker

Front Rear

Bottom

2. Operation

AC Cord Kit Installation■

1. How to install the AC Cord

(1) Carefully lay the Main Body Unit on a clear, flat surface as shown in figure (1).

(2) Unpack the AC Cord, and then connect it to AC Inlet as shown in figure (2).

(3) Fit the Cord Clamp to AC Cord, as shown in figure (3).

(4) Carefully replace the Main Body Unit in upright position as shown in figure (4).

Note:

Confirm the AC Code doesn't move after fixing the AC Code with the clamper.

(1)

AC Inlet

(3)

(4)

(2)

3. Appendix

Specifications■

[Common Specifications]

Environmental condition

Item Specification

Operating Temperature +5°C – +40°C

Operating Humidity 15% RH – 85% RH (no dew)

Strage Temperature -30°C – +60°C

Strage Humidity 10%RH – 90%RH

[POS Workstation: JS-925WS- ]

Item Specification

Power Supply input AC100V-240V, 50/60 Hz, 1.6A

Size 12.1”: Approx. W320mm x D263mm x H392mm

15”: Approx. W364mm x D291mm x H413mm

Mass 12.1”: Approx. 6.7 kg

15”: Approx. 7.6kg

Safty cULus, TÜV, CE,GOST, BSMI, SABS

Standard

EMI &

immunity FCC Part15 Class A, ICES-003 Class A, CISPR22 Class A,

CE (EN55022 Class A, EN55024, EN61000), GOST Class A,

C-tick Class A, BSMI Class A, KCC Class A, SABS Class A

1: Power supply cord is not attached.

Please use the AC cord kit in accordance with safety standards in the country of use.

Outside drawing

12.1” TFT-LCD installed model Dimensional outline drawing

15” TFT-LCD installed model Dimensional outline drawing

Cleaning■

Cleaning of outer case

Light soil - Wipe case lightly with a dry, soft cloth.

Heavy soil - Wipe case lightly with soft cloth pre-moistened with very diluted, mild detergent.

Lightly wipe case dry with a dry, soft cloth.

Cleaning of Display

Wipe display gently with a dry, soft cloth to remove light dirt and dust.

Do not wipe or press display hard, hit display or exert force on display as LCD in the display is

breakable.

Do not use OA Cleaner for cleaning it, because it will cause change color or change in quality.

Maintenance of outer case

Outer cases are made of plastic.

Do not apply benzine, thinner, glue, alkalinity detergent, alcohols detergent, glass cleaner, wax,

abrasive cleanser, detergent powder, or pesticide, because it will cause change color or

change in quality. (follow to the cautionary statement if chemical cloth is used.)

Do not leave rubber and vinyl product touched for a long time, because it will cause change

color or change in quality.

Operation■

Carrying/moving terminals

Do not lift or carry the terminal by holding the Display Unit/Unit. Lift and carry the terminal by

securely holding the Main Body Unit from the bottom, with two hands.

Display angle adjustment

Take care not to place the fingers between Display and Main Unit when the angle of Display is

adjusted. Injury may occur. Adjust Display tilt-angle with two hands placed on outside, bezel

edges of Display unit.
