Panasonic KX-TG1061 Manual de usuario
PNQW1623ZA DC1208SY0
Setting up
Base unit
LUse only the supplied Panasonic AC adaptor PQLV219.
CHARGE FOR
ABOUT 7 HOURS
Handset
Charger
(120 V AC, 60 Hz)
LUse only the supplied
Panasonic AC adaptor
PQLV219.
Rechargeable Ni-MH ONLY
LUSE ONLY Ni-MH batteries AAA (R03) size.
LDo NOT use Alkaline/Manganese/Ni-Cd batteries.
LConfirm correct polarities (S, T).
To single-line
telephone jack (RJ11C)
DSL/ADSL filter* (Not supplied)
“Click”
Base
unit
Base
unit
Correct
Wrong
(120 V AC, 60 Hz)
Press plug firmly.
Hook
“Click” “Click”
“Click”
Confirm
“Charging”is
displayed.
*For DSL/ADSL service users
Model No. KX-TG1061
KX-TG1062
KX-TG1063
Quick Guide
TG106x_QG(e).fm Page 1 Friday, December 19, 2008 2:55 PM
– 2 –
Operating tips
Navigator key/Volume key (VOL., ?)
NScrolling through lists or items
By pressing this key ({^} or {V}) repeatedly, you can scroll
through (up or down) various lists or items.
NAdjusting the volume
By pressing this key ({^} or {V}) repeatedly, you can adjust
the receiver or speaker volume (up or down) while talking.
NMoving the cursor
Base unit: {^}, {V}, {7}, or {8}
Handset: {^} or {V}
By pressing the above keys repeatedly, you can move the
cursor to edit a number or name.
Soft keys
Each unit features 3 soft keys. By pressing a soft key, you can
select the feature shown directly above it on the display.
{C}, {MENU}, {REDIAL}, and other additional functions
are assigned to the soft keys. Pay attention to the display to
see what functions the soft keys are assigned during
operation.
Base unit
Handset
Date and time (Handset)
1{MENU}i{#}{1}{0}{1}
2Enter the current month, date, and year. i{OK}
3Enter the current hour and minute (12-hour clock format).
4{AM/PM}: Select “AM”or “PM”. i{SAVE}i{OFF}
For further information, visit http://www.panasonic.com/help or refer to operating instructions.
7 8
Base unit Handset
TG106x_QG(e).fm Page 2 Friday, December 19, 2008 2:55 PM
– 3 –
Basic operations
Making/Answering calls (Base unit/Handset)
Making calls Base unit: Dial the phone number. iLift the corded handset, or
press {SP-PHONE}.
Handset: Dial the phone number. i{C}/{s}
Answering calls Base unit: Lift the corded handset, or press {SP-PHONE}.
Handset: {C}/{s}
To hang up Base unit: Place the corded handset on the cradle. When the
speakerphone is used, press {SP-PHONE}.
Handset: {OFF}
To adjust the receiver or speaker
volume
Press {^} or {V} repeatedly while talking.
Making a call using the redial list 1{REDIAL}i{V}/{^}: Select the desired phone number.
2Proceed with the operation for your unit.
Base unit: Lift the corded handset.
Handset: {C}
To adjust the ringer volume 1{MENU}i{#}{1}{6}{0}
2{V}/{^}: Select the desired volume. i{SAVE}
3Proceed with the operation for your unit.
Base unit: {■}
Handset: {OFF}
Phonebook (Base unit/Handset)
Adding entries 1{C}i{ADD}
2Enter the party’s name (16 characters max.). i{OK}
3Enter the party’s phone number (24 digits max.). i{OK}
4{V}/{^}: Select the desired group. i{SELECT}2 times
5Proceed with the operation for your unit.
Base unit: {■}
Handset: {OFF}
LTo enter a name, see the character table in the operating
instructions.
Making calls 1{C}i{V}/{^}: Select the desired entry.
2Proceed with the operation for your unit.
Base unit: Lift the corded handset.
Handset: {C}
Answering system (Base unit)
Answering on/off Press {ANSWER ON}to turn on/off the answering system.
Listening to messages {6}
For further information, visit http://www.panasonic.com/help or refer to operating instructions.
TG106x_QG(e).fm Page 3 Friday, December 19, 2008 2:55 PM
– 4 –
Frequently asked questions
Question Cause/solution
Why is wflashing? LThe handset is too far from the base unit. Move closer.
LThe base unit’s AC adaptor is not properly connected. Reconnect
AC adaptor to the base unit.
LYou are using the base unit or handset in an area with high
electrical interference. Re-position the base unit and use the
handset away from sources of interference.
LThe handset is not registered to the base unit. Register it.
How can I increase the handset
volume level?
LPress the navigator key {^} repeatedly while talking.
Why is the conversation noisy or
cutting off?
LTry to relocate the base unit so that the distance to the handset is
minimized.
LIf the same problem occurs even if the handset is next to the base
unit, call Panasonic customer support at 1-800-211-PANA (1-800-
211-7262).
Can I add another accessory handset
to my base unit?
LYes, you can add up to 6 handsets (including the handset(s) sold
with your base unit) to a single base unit.
LTo purchase additional accessory handset(s) (KX-TGA106),
please visit
http://www.panasonic.com
or call 1-800-332-5368. TTY users (hearing or speech impaired
users) can call 1-866-605-1277.
Can I keep the batteries charging all
the time?
LYou can leave the handset on the charger anytime. This will not
harm the batteries.
How can I answer a call waiting call
(2nd call)?
LPress {CALL WAIT}when you hear the call waiting tone.
For further information, visit http://www.panasonic.com/help or refer to operating instructions.
TG106x_QG(e).fm Page 4 Friday, December 19, 2008 2:55 PM
– 5 –
Quick troubleshooting
“No link. Reconnect base AC adaptor.”
Remove the batteries for 10 seconds from the handset, and then insert the batteries into the
handset again.
Your telephone may need service.
Please visit http://www.panasonic.com/help for further troubleshooting.
Try to re-register the handset (page 7).
“No link. Reconnect base AC adaptor.”is still displayed.
“No link. Reconnect base AC adaptor.”is still displayed.
Re-registration failed.
Move closer to the base unit. Unplug, then plug the AC adaptor properly to the base unit and
AC outlet.
1Cordless handset shows:
TG106x_QG(e).fm Page 5 Friday, December 19, 2008 2:55 PM
– 6 –
Quick troubleshooting
Lift up the handset from the charger.
Press {C} at the handset, then check if the display
shows “Talk”.
Check if the telephone
cord is properly connected
to both the base unit and
telephone line jack on the
wall.
Try to connect your
telephone into a different
line.
Press {s}, then check if
the dial tone is heard from
the speaker on the back.
No dial tone Dial tone is heard.
2No dial tone is heard from handset.
Try remedy for 1on
previous page.
See if “Check tel line”is shown on the handset display.
Your telephone may
need service when
only back speaker
provides a dial tone.
Your telephone may need service.
Please visit http://www.panasonic.com/help for further troubleshooting.
“No link. Re-
connect base
AC adaptor.”
is displayed.
“Talk”is displayed.
Displayed Not displayed
Still displayed
Still displayed
{C}
{s}
No link. Re-
connect base
AC adaptor. Talk
Talk
TG106x_QG(e).fm Page 6 Friday, December 19, 2008 2:55 PM
– 7 –
Registering a handset to the base unit
The supplied handset and base unit are pre-registered. If for some reason the handset is not registered to
the base unit, re-register the handset.
{MENU}i{#}{1}{3}{0}
Press and hold {LOCATOR}for about 5 seconds until
the registration tone sounds.
LThe next step must be completed within 90 seconds.
Press {OK}, then wait until a long beep sounds.
For further registration information, visit
http://www.panasonic.com/RegisterYourHandset
Handset
{MENU}
Base unit
{LOCATOR}
Handset
Press Locator
on base 5sec
then press OK
{OK}
TG106x_QG(e).fm Page 7 Friday, December 19, 2008 2:55 PM
– 8 –
IMPORTANT!
If your product is not working properly ...
1Reconnect AC adaptor to the base unit.
4
Read FAQ in this Quick Guide and
troubleshooting page in the Operating Instructions.
2
Check if telephone line cord is connected.
3
Use rechargeable Ni-MH batteries.
(Alkaline/Manganese/Ni-Cd batteries CANNOT be used.)
Visit our web site: http://www.panasonic.com/help
LOperating Instructions downloading, FAQ,
and troubleshooting hints are available.
Call us at: 1-800-211-PANA (1-800-211-7262)
LMonday- Friday 9:00am - 9:00pm (EST)
Saturday/Sunday 10:00am - 7:00pm (EST)
Contact us via the web at:
http://www.panasonic.com/contactinfo
To order replacement batteries,
please call: 1-800-332-5368
Or visit: http://www.panasonic.com/batterystore
TG106x_QG(e).fm Page 8 Friday, December 19, 2008 2:55 PM
