Panasonic DBS Series Guía de instalación

Panasonic Digital Business System - Overview

April 1997 Issue 6

Panasonic

Digital Business System

Overview

Panasonic Digital Business System - Overview

April 1997 Issue 6

Contents

INTRODUCTION 4

IMPORTANT SYSTEM DATA 4

PORT TYPES 4

SPECIAL AND OPTIONAL CIRCUITS SUPPORTED 4

PORT TO PORT CONNECTIONS PERMITTED 5

PORT TO PORT LOSS 5

RELATIVE LEVELS 5

LOUDNESS RATING 5

CABLING REQUIREMENT 6

OVER-VOLTAGE PROTECTION 6

PBX RECALL 6

1AS PORT LINE FEEDING 6

ANALOGUE EXTENSIONS 6

CALL PATH DELAY 7

POWER FAILURE 7

INTERCONNECTION OF PORTS 8

PREVENTION OF ACCESS BY THE USER 8

SIMPLE CALL ROUTING MODE 8

APPROVED FEATURES 9

SYSTEM CAPACITY AND SPECIFICATIONS 10

DBS EQUIPMENT DESCRIPTIONS 11

DBS CCU (DBS 38 / DBS 68 / DBS 90) 11

DBS 38 BUILT IN BATTERY 11

DBS 68 / 90 BUILT IN BATTERY 11

EXTERNAL BATTERY CABINET AND BATTERY 12

CPC-B CENTRAL PROCESSOR CARD 12

CPC-C CENTRAL PROCESSOR CARD 12

CPC-EX CENTREL PROCESOR CARD 12

SCC SYSTEM CONTROL CARD 12

RAI REMOTE ADMINISTRATION INTERFACE 13

EXCHANGE LINE CARD 13

DIGITAL EXTENSION CARD 13

ANALOGUE EXTENSION CARD 13

DTMF RECEIVER CARD 13

SLT RING GENERATOR 14

DOORPHONE INTERFACE 14

DOORPHONES 14

METER PULSE DETECTION CARD 14

-48V POWER SUPPLY 14

E&M CARD 14

AC15A CARD 15

PROPRIETARY KEY TELEPHONES 15

ISDN INTERFACE 16

DASS II EQUIPMENT LIST 16

DASS II FEATURES 16

DASS II FEATURES FOR FUTURE USE 16

Panasonic Digital Business System - Overview

April 1997 Issue 6

DASS II FEATURE DESCRIPTIONS 16

DASS II DETAILED FEATURE DESCRIPTIONS 17

DASS II RELATIONSHIP WITH EXISTING FEATURES 20

OTHER RESTRICTIONS WHEN USING DASS II ON DBS 22

VOICE ANNOUNCE UNIT 22

FEATURE ENHANCEMENTS WITH SOFTWARE VERSIONS 4.1 & ISDN 1.1 23

GROUP RINGING 23

INCOMING LINE NAME ASSIGNMENT 23

INTERNAL DTMF DIALLING FROM SYSTEM AND PERSONAL SPEED DIALS 24

CALL LOGGER INDICATION OF HELD AND TRANSFERRED CALLS 24

180 SYSTEM SPEED DIAL AVAILABILITY 25

CALL CHARGE RANGE INCREASED 25

SUPPRESSION OF CALL FORWARD INDICATIONS 25

ISDN DDI GROUP NAME DISPLAY 25

ABSENCE MESSAGE ENTRY WITHOUT A DSS CONSOLE 25

CALL FORWARD NO ANSWER SETTING FROM MENUS ON THE VB3411LDS 25

THE CPC-EX CARD 26

CPC-EX - EURO ISDN 27

EURO ISDN AND ISDN FEATURE ENHANCEMENTS 27

CALL FORWARD WITH GROUP RINGING 27

RINGING HUNTING FOR EXTERNAL CALLS 27

OPERATOR CALL FORWARD 28

EXTENSION FEATURE CLEAR 28

PROGRAMMING MODE FROM ANY DISPLAY KEYSET 28

CPC-EX - DBS DDI ENHANCEMENTS 29

DDI NIGHT SERVICE TABLE 29

ALTERNATIVE DDI DESTINATION - BUSY / NO ANSWER 29

DDI RING GROUP MEMBERSHIP 29

DDI HUNT GROUP 29

TONE AND LAMP INDICATION 31

Panasonic Digital Business System - Overview

April 1997 Issue 6

Introduction

The Digital Business System (DBS) range is a hybrid system allowing both digital key

telephone and analogue telephone handsets.

There is a range of three cabinet sizes. DBS38 , DBS68 and DBS90. These can be used

individually or combined with a second DBS90 to give a range of systems DBS38 , DBS68 ,

DBS90 , DBS128 (DBS90+DBS38) , DBS158 (DBS90+DBS68) and DBS180

(DBS90+DBS90).

The cabinets are supplied empty, except for the power supply, and are configured using

modular cards and equipment options.

This section describes the port types and equipment for the DBS.

Important System Data

This is a class A product.

In a domestic environment this product may cause radio interference, in which case the user

may be required to take appropriate measures.

This product has been CE marked to show compliance with the EMC Directive 89/336/EEC

amended by 92./31/EEC and 93/68/EEC.

Port Types

Table 1 - Port Connections

Special And Optional Circuits Supported

Table 2 - Special & Optional Circuits

Port Type Permitted Connection

PAS

requirements

2 wire PSTN exchange line without DDI

2 wire PBX extension

Loop calling unguarded clearing, DTMF or LD

signalling, timed break or earth recall.

1AS

requirements

2 wire analogue speech band equipment

DTMF or LD dialling, timed break recall

E.g. SLT, cordless telephone, FAX, modem

ITS Panasonic proprietary DBS digital keytelephone

Panasonic digital Voice Announce Unit

Circuit Type Circuit Use

Meter Pulse, 50 Hz Call charge calculation

DC5, 2 wire + E&M Private circuit link

ISDN 30 , DASS 2 ISDN network connection

Panasonic Digital Business System - Overview

April 1997 Issue 6

Port To Port Connections Permitted

The following port to port connections can be made.

Table 3 - Call Paths

Port To Port Loss

The following table shows the maximum port to port and associated cable loss.

Table 4 - Port To Port Loss

Relative Levels

The input and output relative levels for each port type are shown below. These values

assume zero cable loss.

Table 5 - Relative Levels

Loudness Rating

The loudness rating for each port type is given below. (PTRP - )

Table 6 - Loudness Rating

Call Path Call Path Call Path Call Path

PAS > ITS ITS > ITS ITS > PAS 1AS > 1AS

PAS > 1AS ITS > 1AS 1AS > PAS 1AS > ITS

Port > Port Port > Port Loss Associated Cable Loss

PAS > 1AS 1.3 dB 0.7 dB

PAS > ITS

ITS > 1AS

Port Input (dBr) Output (dBr)

PAS -6 2.5

1AS 3.5 -7

ITS

PTRP > ITS 0 dB ITS > PTRP 2.5 dB

PTRP > 1AS 1AS > PTRP

PTRP > PAS PAS > PTRP

Panasonic Digital Business System - Overview

April 1997 Issue 6

Cabling Requirement

The cabling between the Central Control Unit (CCU) and each extension is 2 wire, 0.5mm

diameter copper conductor and terminated with a Line Jack Unit (LJU). Use a master LJU for

analogue extensions and a slave LJU for the digital extensions.

The following table shows the maximum cable length from the CCU.

Cabling from the Network Test and Termination Point (NTTP) must also comply with these

requirements.

Table 7 - Maximum Cable Distances

Over-voltage Protection

Surge arresters are fitted to the PAS, ITS and 1AS ports of the system. If the extension

cabling extends between buildings or runs around the outside of a building, surge arresters

should be fitted at both exit and entry points.

PBX Recall

The DBS can be installed as a host or subsidiary system to suitably approved PBX

equipment.

As a host the DBS will accept timed break recall signals from a PBX connected to a 1AS

port.

As a subsidiary the DBS can provide both timed break and earth recall signalling to the host

from PAS ports.

1AS Port Line Feeding

The DBS is not a through fed system. Line feeding from 1AS ports to connected equipment is

derived internally from the DBS CCU. The maximum current that can be supplied to

extension equipment on 1AS ports is 50mA.

Analogue Extensions

When using separately approved extension apparatus, Panasonic recommend DTMF

signalling. The recall signalling must be timed break. The impedance class of the apparatus

must be class (a) of clause 4.3.2.1 of BS6305:1982.

Cable Maximum Loop Resistance Maximum Length

CCU > ITS 40 ohms 240m

CCU > DSS 20 ohms 120m

CCU > 1AS (A version) 100 ohms 480m

CCU > 1AS (B version) 100 ohms 880m

CCU > PFU 250m

NTTP > CCU 15m

Panasonic Digital Business System - Overview

April 1997 Issue 6

Call Path Delay

The maximum call path delay for each speech link is shown below. The times are in micro-

seconds.

Table 8 - Call Path Delay

Power Failure

If installed the batteries inside the CCU will back up the operation of the DBS for a short

time. The precise time will depend upon system size and the volume of call traffic.

Alternatively an external battery may be added to increase the running time in the event of a

power failure.

In addition a number of power fail telephone units (PFUs) can be connected. The CCU will

divert the first few lines to these units if the power and battery backup fails. The number of

PFUs varies according to the CCU used.

Call Path Max. Delay Call Path Max. Delay

PAS > ITS 1000 ITS > PAS 1000

PAS > 1AS 875 1AS > PAS 875

Panasonic Digital Business System - Overview

April 1997 Issue 6

Interconnection Of Ports

Warning

Interconnection directly or by way of other apparatus, of ports marked in accordance with

clause 5.2 of BS6301:1989 with ports marked or not so marked may produce hazardous

conditions on the network. Advice should be obtained from a qualified engineer before such a

connection is made.

SAFETY WARNING: See Instructions For Use !

The ports so marked do not provide isolation sufficient to satisfy BS6301. Apparatus

connected to such ports should either have been approved to BS6301 or have previously

been evaluated against British Telecommunications PLC, Technical Guides 2 or 26 and

given permission to attach. Other usage will invalidate any approval given to the apparatus.

Prevention Of Access By The User

The DBS is intended to be accessible only to authorised personnel. There are no user

accessible parts inside the equipment. Failure to prevent such user access will invalidate any

approval given to this apparatus.

Simple Call Routing Mode

The DBS works only in Simple Call Routing Mode (SCRM). All PSTN ports can be configured

for SCRM working. ITS and 1AS ports are associated with the SCRM PSTN ports.

Panasonic Digital Business System - Overview

April 1997 Issue 6

Approved Features

The DBS has been approved for the use of the following facilities. This list includes exchange

line related features only and does not include internal facilities.

•Direct exchange line access •Hold and transfer

•Group exchange line access •Music on hold

•Exchange line grouping •Hold reminder

•Exchange line key access •Call pick up

•On hook dialling •External conference

•Handsfree conversation •Busy override

•Speed (abbreviated) dialling •Call hunting

•Last number redial •Meter pulse detection

•Saved number redial •Remote programming

•Auto answer by lifting a handset •DISA

•Call barring •PBX and PSTN recall

•Call barring override •LD and DTMF dialling

•Station lock •Least cost routing

•Call duration display •Headset connection

•Trunk queuing •Night transfer

The CPC-C Card for ISDN provides all the above facilities and adds the following

•DASSII Primary Rate ISDN •Direct Dial In (144 Numbers)

•Calling Line Identity On ISDN Lines •Call Charge Information On ISDN Lines

The CPC-EX card provides ISDN and E&M/AC15A networking along with the facilities above

and the following

•Trunk To Trunk Conference •Trunk To Trunk Transfer

•External Call Forward •Internal / External Ring Priority

•DISA Break Out •CLI Name Look Up

Any other usage will invalidate the approval of the apparatus if as a result it then ceases to

comply with the standards against which approval was granted.

Panasonic Digital Business System - Overview

April 1997 Issue 6

System Capacity And Specifications

DBS 38 DBS 68 DBS 90 DBS 128 DBS 158 DBS 180

Exchange Line Ports 6 12 18 24 30 36

Extension Ports 24 48 64 88 112 128

Extension/Line Ports 6/8 6/8 6/8 6/8 + 6/8 6/8 + 6/8 6/8 + 6/8

Max.Key Telephones 32 56 72 104 128 144

Max.Analogue Tels. 24 48 64 96 120 136

Max. DSS Consoles 444444

Exch/Extn Speech Non-Blocking

Conf Speech Paths 8

Operator Positions 2

Paging Groups 8

Speed Personal 10

Dial System 90 x 2

Digits 24

Table 9 - System Capacity

DBS 38 DBS 68 DBS 90 DBS 128 DBS 158 DBS 180

Power Standby 170W 250W 320W 490W 570W 640W

Consumption Maximum 216W 324W 444W 660W 768W 888W

Dimensions

HxWxD 532x441x

210 532x554x

210 DBS

90+38 DBS

90+68 DBS

90+90

Weight (Kg) 24 29.5 30.8 54.8 60.3 61.6

Table 10 - Size & Power Specifications

Otros manuales para DBS Series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Teléfono de Panasonic

Panasonic

Panasonic KXTG2343F - 2.4 GHZ DIGITAL CDL Manual de usuario

Panasonic

Panasonic KX-TG9472C Manual de usuario

Panasonic

Panasonic KX-T7735 Manual de usuario

Panasonic

Panasonic EASA-PHONE KX-T30850 Manual de usuario

Panasonic

Panasonic KX-TS2365RUB Manual de usuario

Panasonic

Panasonic DBS 576HD Manual de usuario

Panasonic

Panasonic KX-TA1232 Manual de usuario

Panasonic

Panasonic KX-DT543 Guía de referencia

Panasonic

Panasonic KX-DT 333 Series Manual de usuario

Panasonic

Panasonic KX-TGM430 Manual de usuario

Panasonic

Panasonic T7020B - KX - Digital Phone Manual de usuario

Panasonic

Panasonic KX-DT 343 Series Manual de usuario

Panasonic

Panasonic KX-T7135 Manual de usuario

Panasonic

Panasonic T-SMART DBS-EX23-530 Manual de usuario

Panasonic

Panasonic KX-TG5200C Manual de usuario

Panasonic

Panasonic KX-NS300 Manual del propietario

Panasonic

Panasonic KX-T7720 Manual de usuario

Panasonic

Panasonic KX-T336 Manual de usuario

Panasonic

Panasonic KX-TG2236S Manual de usuario

Panasonic

Panasonic KX-TG7622B Manual de usuario

Panasonic

Panasonic HYBRID IP-PBX KX-TDA200 Manual del propietario

Panasonic

Panasonic KX-PRW130C Manual de usuario

Panasonic

Panasonic KX-HDV230 Manual de usuario

Panasonic

Panasonic KX-AT7730 Manual de usuario

Manuales populares de Teléfono de otras marcas

GE 2-9480 Manual de usuario

Geemarc

Geemarc PHOTOPHONE 155 Manual de usuario

D-Link

D-Link DWR-720/PW Manual de usuario

Interquartz

Interquartz Gemini IQ333 Manual de usuario

SSS Siedle

SSS Siedle HT 840-0 Manual de usuario

Motorola

Motorola TITANIUM Manual de usuario

LG H870DS Manual de usuario

Samsung

Samsung GT-I9500 Manual de usuario

AT&T

AT&T Trimline 205 Manual de usuario

Selta

Selta zenyth 600 Manual de usuario

Doro

Doro AFTI 20 Manual de usuario

UNIQCELL

UNIQCELL A1 Manual de usuario

Jabra

Jabra SP5050 - Bluetooth hands-free Speakerphone Manual de usuario

BT Decor 425 Manual de usuario

NEC

NEC SV8500 Manual de usuario

Teledex

Teledex PEARL Manual de usuario

Ericsson

Ericsson Dialog 3213 Manual de usuario

Yealink

Yealink VP530 Manual de usuario
