Panasonic SB-PC930P Manual de usuario

ORDERNO. MD0412609C0

Speaker System

SB-PC930P

Colour

(S)... Silver Type

SPECIFICATIONS

Specification

Type 2way, 3speaker system (Bass

reflex)

Speaker unit(s) Impedance 4

1. Woofer 6.5cm (2-1/2”) Conetype

2. Woofer 6.5cm (2-1/2”) Conetype

3. Tweeter 6 cm (2-3/8”) Ring shapeddome

type

Input power (IEC) 260 W*(Max)

Output sound pressure 82 dB/W(1.0m)

Cross over frequency 5 kHz

Frequencyrange 110 Hz - 50 kHz (-16 dB)

140 Hz - 45 kHz (-10 dB)

Dimensions(WxH xD) 320 mm x88 mm x96 mm

(12-19/32” x3-15/32” x3-25/32”)

Mass 1.36 kg(3lbs)

Notes :

1. Specificationsaresubject to changewithoutnotice.

2. Mass and dimensionsareapproximate.

SB-HT930P-S consistsof : SB-FS930P-S (x2), SB-FS931P-S (x

and SB-PC930P-S (x1)

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

Unauthorized copying and distribution isaviolation of law.

1. System Combination

System SC-HT930P-S SC-HT930PC-S

Music Center SA-HT930P-S SA-HT930PC-S

Front Speakers SB-FS930P-S

Surround Speakers SB-FS931P-S

Centre Speaker SB-PC930P-S

Active Subwoofer SB-WA930PP-S

System SC-HT930PX-S

Music Center SA-HT930PX-S

Front Speakers SB-FS930P-S

Surround Speakers SB-FS931P-S

Centre Speaker SB-PC930P-S

Active Subwoofer SB-WA930PX-S

System SC-HT930EE-S SC-HT930GCTS SC-HT930GN-S SC-HT935EE-S

Music Center SA-HT930EE-S SA-HT930GCTS SA-HT930GN-S SA-HT935EE-S

Front Speakers SB-FS930P-S

Surround

Speakers SB-FS880EB-S

Centre Speaker SB-PC930P-S

Active

Subwoofer SB-WA930EE-S SB-WA930GCTS SB-WA930GN-

SSB-WA935EE-

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

System SC-HT930GC-S SC-

HT930GCSS SC-HT930GS-S

Music Center SA-HT930GC-S SA-

HT930GCSS SA-HT930GS-S

Front Speakers SB-FS930P-S

Surround

Speakers SB-FS880EB-S

Centre Speaker SB-PC930P-S

Active

Subwoofer SB-WA930GC-S

System SC-HT880EB-S SC-HT880WEBS

Music Center SA-HT880EB-S SA-HT880WEBS

Front Speakers SB-FS930P-S

Surround Speakers SB-FS880EB-S

Centre Speaker SB-PC930P-S

Active Subwoofer SB-WA880EB-S

System SC-HT880GN-S SC-HT880WGNS

Music Center SA-HT880GN-S SA-HT880WGNS

Front Speakers SB-FS930P-S

Surround Speakers SB-FS880EB-S

Centre Speaker SB-PC930P-S

Active Subwoofer SB-WA880GN-S

System SC-HT880E-S SC-HT880EG-S SC-

HT880WEGS

Music Center SA-HT880E-S SA-HT880EG-S SA-

HT880WEGS

Front Speakers SB-FS930P-S

Surround

Speakers SB-FS880EB-S

Centre Speaker SB-PC930P-S

Active Subwoofer SB-WA880EG-S

2. Disassembly Process

2.1. Disassemblyof the Front Panel

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

Step1: Remove 8 screws fromthe RearCabinet Assembly.

Step2: Pushthe Front Panel forwardtodetachfromthe RearCabinet Assemblyas arrow

shownabove.

2.2. Disassemblyof the Woofer 1

-Repeat step 1to step 2initem 2.1.

Step1: Detachthe wires (+) redand (-) black fromthe Woofer1.

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

Step2: Remove 4 screws fromthe Woofer1.

2.3. Disassemblyof the Woofer 2

-Repeat step 1to step 2initem 2.1.

Step1: Detachthe wires (+) black and (-) black fromthe Woofer2.

Step2: Remove 4 screws fromthe Woofer2.

2.4. Disassemblyof the Tweeter

-Repeat step 1to step 2initem 2.1.

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

Step1: Detachthe wires (+) grayand (-) black fromthe Tweeter.

Step2: Remove 4 screws fromthe Tweeter.

2.5. Disassemblyof the Terminal

-Repeat step 1to step 2initem 2.1.

Step1: Detachthe wires (+) redand (-) black fromthe Terminal.

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

Step2: Remove 1 screwfromthe Terminal.

Step3: Remove the Terminal fromthe RearCabinet Assembly.

3. Connection of the Speaker Cables

-Besure to connect speaker cables before connecting the AC

power supplycord.

-The load impedance of anyspeaker used with thisunitmust be 4 .

-Besure to connect the cablefrom the right speaker to the right

terminal and the cablefrom the left speaker to the left terminal.

1. Stripoff the outer covering, and twist the center conductor. Make

sure the bare ends of the wires are not unravelled. (Iftheyare,

twist them tight again.)

2. Insert the wire to the rear panel of the unitand close the lever.

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

Notes :

-To prevent damage to circuitry, never short-circuitpositive (+)and

negative (-) speaker wires.

-Besure to connect onlypositive (copper) wires to positive (+)

terminalsand negative (silver) wires to negative (-) terminals.

Incorrect connection can damage the speakers.

4. Connection of Wiring Diagram

5. Cabinet Parts Location

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

6. Replacement Parts List

Notes :

-Important safetynotice :

When replacing anyof these components, be sure to use only

manufacturer’sspecified parts showninthe parts list.

-[M] indicates inthe Remarks columns indicates parts supplied by

PAVCSG.

Ref. No. PartNo. PartName& Description Remarks

CABINETAND CHASSIS

1RYBX0082-H REAR CABINETASS’Y [M]

1-1 K4BC02B00017 TERMINAL JACK [M]

1-2 XTB3+10GFJ SCREW [M]

2RYBX0090-S FRONTPANEL ASS’Y [M]

3XTB3+6GFJ SCREW (TWEETER) [M]

4XTB3+12GFJ SCREW (REAR CAB) [M]

5RGNX0275-K SPEC LABEL [M]

6RKA0072-KJ LEG CUSHION [M]

7REEX0437 NETWORK ASS’Y [M]

8REEX0457 TRANSITWIRE [M]

CAPACITOR

C1 ECEA1HAY1R8 1.8uf50V [M]

PACKING MATERIALS

P1 RPNX0304 POLYFOAM [M]

P2 RPFX0110 MIRAMATBAG [M]

SPEAKERS

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

Ref. No. PartNo. PartName& Description Remarks

SP1 EAST6PH17D6 TWEETER [M]

SP2 L0AA06A00015 WOOFER [M]

7. Packaging

FLE0412W/S

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com
