Getting Started

Model No. KX-HCM280

Please read the Operating Instructions for the details.

Keep this leaflet for the future reference.

The suffix of each model number is omitted.

Network Camera

Included Accessories

The following items are provided with a Network Camera.

Notes

• If any items are missing, contact the dealer immediately.

• The order numbers listed above are subject to change without notice.

• Save the original carton and packing materials for future shipping and

transportation of the unit.

AC Adaptor—1 pc.

Order No. PSLP1242Z AC cord (Type C-7)—1 pc.

Order No. PSJA1074Z

Ceiling Mounting Cover—1 pc.

Order No. PSKL1023Z

Ceiling Plate B—1 pc.

Order No. PSMD1045Z Setup CD-ROM—1 pc.

Order No.

PSQX2871Y

Screws A—2 pcs.

Order No. XYN3+J6FY Screws B—4 pcs.

Order No. XTB4+20AFY

Ceiling Plate A—1 pc.

Order No. PSZMHCM280M

Operating Instructions

Network Camera Configuration Type

A Network Camera can be connected on a LAN/Intranet and the Internet. Select

one of the four Network Camera configuration types. Network parameters differ

depending on the Network Camera configuration type.

[Type 1]—LAN/Intranet Connection with an Ethernet®

Switching Hub

The Network Camera can be installed on the LAN/Intranet.

*1Network traffic can be improved by using the Ethernet switching hub.

[Type 2]—Internet Connection with a Broadband Router

The Network Camera can be accessed from the Internet. The broadband router

needs Port Forwarding (IP Masquerade) feature on page 32 in the Operating

Instructions.

LAN/Intranet Ethernet switching hub*1

Modem Broadband

Router

CATV

xDSL

Optical cable

Internet WAN LAN

Operating Instructions

[Type 3]—Internet Direct Connection with a Modem

The Network Camera can be installed alone without PC on the network. When you

set up a Network Camera in [Type 3], connect it temporarily in [Type 1], [Type 2]

or [Type 4].

Note

Some xDSL services use PPPoE. The Network Camera does not support

PPPoE. If the Internet connection requires PPPoE, connect with the

broadband router supporting PPPoE like [Type 2].

[Type 4]—Direct Connection with a PC

The Network Camera can be connected to a PC directly.

Note

Use a category 5 cross cable when connecting directly with the cable to the

PC.

Modem

Internet

Category 5 cross cable

Operating Instructions

How to turn on the Network Camera for Installation

The Network Camera powers up when connecting AC plug to the power outlet.

Notes

• Do not hold or touch the Pan/Tilt as it starts moving when connecting AC

plug to the power outlet.

• AC adaptor is used as the main disconnect device, so ensure that the

power outlet is located/installed near the equipment and is easily

accessible.

• Use only specified Panasonic AC adaptor PSLP1242 (Order No.

PSLP1242Z).

• When you set up a Network Camera in [Type 3], connect it temporarily in

[Type 1], [Type 2] or [Type 4].

• When Indicator is orange, confirm that the Ethernet cable is properly

connected, or the PC, Ethernet hub or broadband router is properly

working.

External I/O

Ethernet port

AC cord

To Network

Category 5 straight/cross cable

Connect the DC plug of the

AC adaptor to the DC IN jack.

Hook the AC adaptor cord

to the Hook for AC Adaptor.

Connect the AC cord

to the AC adaptor. Connect the AC plug

of the AC cord to

the power outlet.

Connect a category 5

straight/cross cable

to the Ethernet port.

Power Outlet

Hook for AC Adaptor

DC IN jack

Operating Instructions

Network Parameters

Preparing the Network Parameters for the Network Camera

Before starting to set up the network parameters of a Network Camera, make note

of corresponding network parameters.

Refer to page 6 in this Getting Started and page 23 in the Operating Instructions

for network parameters.

Network parameters memo for Network Camera

The devices on the network may not be assigned the same IP address. Each

device must have its own IP address. Overlapped IP addresses can cause other

network devices to stop working and may result in widespread network problems.

[Type 1] Ask your network administrator for the network parameters.

[Type 2] Refer to the broadband router’s manual for the network parameters.

[Type 3] Ask your ISP (Internet Service Provider) for the network parameters.

[Type 4] Install the Network Camera in the default condition. Set the PC

"192.168.0.250" (IP address) and "255.255.255.0" (Subnet Mask).

Refer to page 24 in the Operating Instructions.

Default Gateway

. . . DNS Server 1 . . .

IP Address . . .

DNS Server 2 . . .

Subnet Mask . . .

Operating Instructions

Network Parameters Table

*1Many ISP's intentionally block the port number 80 to guard against network

viruses. If your ISP blocks the port number 80, substitute it to another unused

port number.

*2When you use more than one Network Camera with a broadband router, each

Network Camera needs its own port number.

*3The Port Forwarding (IP Masquerade) feature needs to be set to the

broadband router. Refer to page 32 in the Operating Instructions.

*4Refer to the broadband router's manual.

When you use a Network Camera in DHCP feature, check [DHCP] and enter

the Host Name if your ISP requires. If you automatically get the address of

Default Gateway and DNS server from DHCP server, you do not need to set up.

Verify that your ISP supports DHCP. If your ISP supports DHCP, or if you assign a

domain name to the Network Camera, you need to contract and register for DDNS

service. If you set a static global IP address to the Network Camera and the

broadband router, you do not need to register for DDNS service. Refer to page 34

in the Operating Instructions

It can restrict the transmit bandwidth.

Select from 0.1 to Unlimited Mbit/s.

Max.

Bandwidth

Usage

Parameters

Network Camera ConfigurationType

Port No.

IP address

Subnet

Mask

Default

Gateway

DNS

Server 1, 2

DDNS

Check [Static],

and set the

static private

IP address.

192.168.0.253

(default)

255.255.255.0

(default)

Check [Static],

and set the

static global

IP address.*5

Check [Static],

and set the

static private

IP address.*4

Set Default

Gateway

address.

You do not

need to set up.

Set DNS server address.

[Type 1] [Type 2] [Type 3] [Type 4]

Set Default

Gateway

address.*5

Set DNS server

address.*5

Set the private

IP address of the

broadband router

(on your network),

not of the gateway

of your ISP.*

80 (default)*1

80 (default) 80 (default)

Set the Subnet Mask fitted to your network.

You do not

need to setup. You do not

need to setup.

*6*6

80 (default)

*1*3

Operating Instructions

Proxy Server Setting

A proxy server may prevent you from connecting directly to a Network Camera in

some corporate environments. The web browser can set up the IP address

communication without using a proxy server. Consult your ISP or network

administrator.

Note

A proxy server is generally used to protect security of a network that offers an

Internet connection. The network of a Network Camera with the proxy server

may cause some problems to the image quality such as taking much time in

refresh interval. Consult your ISP or network administrator for details.

1. Start up the Internet Explorer. (The window comes from Internet Explorer

5.50.)

2. Select [Tools] –> [Internet Options...] –> [Connections] tab and click [LAN

Settings]. See if the Use a proxy server check box is checked or not in the

next window. When checked, click [Advanced...].

When not checked, click [Cancel]. Your proxy settings are causing no

problems.

See if the check

box is checked or not.

When checked, click

[Advanced...].

Operating Instructions

3. Enter an IP address for the Network Camera assigned from your ISP or

network administrator into the Do not use proxy server for addresses

beginning with data field.

4. Click [OK] on all of the opening windows.

Operating Instructions

Simple Installation using the Setup CD-ROM

After finishing cabling, turn on the Network Camera and insert the Setup CD-ROM

in the CD-ROM drive of the PC. Setup CD-ROM should start the application

automatically. This program automatically finds Network Cameras on the network.

1. Turn on the Network Camera.

2. Insert the Setup CD-ROM in the CD-ROM drive of the PC.

(If Network Camera Setup window does not appear, click "setup.exe" on the

Setup CD-ROM.)

Operating Instructions

3. Click [Network Configuration]. Network Camera List window appears. The

Setup program finds all Network Cameras connected on your local network. It

lists all of MAC addresses and IP addresses of Network Cameras. Network

Cameras that are isolated by the use of a home gateway or broadband router

will not be detected. Record their MAC addresses on the Network Camera

Memo on page 3 in the Operating Instructions. It is useful for customer

servicing.

Notes

• The setup program finds and identifies Network Cameras by listening for

data, which the Network Cameras send out for the first 20 minutes after

powering up. If the installation is not completed within 20 minutes,

disconnect temporarily the AC adaptor to restart this operation.

• Each Network Camera has a unique MAC address labelled on the bottom.

Refer to page 15 in the Operating Instructions.

• Network Cameras that are isolated by the use of a home gateway or

broadband router will not be detected.

(A)
