Panasonic GP-MF130E Manual de usuario

Machine Vision B/W CCD Camera

GP-MF130E

Before attempting to connect or operate this product,

please read these instructions completely.

DEUTSCHFRANÇAIS ENGLISH

ENGLISH VERSION

WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE THIS

APPLIANCE TO RAIN OR MOISTURE.

The lightning flash with arrow-

head symbol, within an equilat-

eral triangle, is intended to

alert the user to the presence

of uninsulated "dangerous volt-

age" within the product's enclo-

sure that may be of sufficient

magnitude to constitute a risk

of electric shock to persons.

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK). NO

USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE

PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

The exclamation point within an

equilateral triangle is intended to

alert the user to the presence of

important operating and mainte-

nance (servicing) instructions in

the literature accompanying the

appliance.

Remove dust on the faceplate of filter glass

before mounting the lens on the camera.

The serial number of this product may be found on

the top of the unit.

You should note the serial number of this unit in the

space provided and retain this book as a permanent

record of your purchase to aid identification in the

event of theft.

Model No.

Serial No.

CONTENTS

PREFACE ....................................................... 2

FEATURES ..................................................... 2

PRECAUTIONS .............................................. 3

MAJOR OPERATING CONTROLS AND

THEIR FUNCTIONS ........................................ 5

PREPARATIONS ............................................. 8

SYSTEM CONNECTIONS ............................... 9

EXTERNAL SYNCHRONIZATION .................. 10

PREVENTION OF BLOOMING AND SMEAR .. 10

SPECIFICATIONS ........................................... 11

OPTIONAL ACCESSORIES ............................. 12

- 1 -

We declare under our sole responsibility that the product to

which this declaration relates is in conformity with the stan-

dards or other normative documents following the provi-

sions of Directive EEC/89/336.

Nosotros declaramos bajo nuestra única responsabilidad

que el producto a que hace referencia esta declaración està

conforme con las normas u otros documentos normativos

siguiendo las estipulaciones de la directiva CEE/89/336.

Noi dichiariamo sotto nostra esclusiva responsabilità che il

prodotto a cui si riferisce la presente dichiarazione risulta

conforme ai seguenti standard o altri documenti normativi

conformi alle disposizioni della direttiva CEE/89/336.

Wij verklaren als enige aansprakelijke, dat het product

waarop deze verklaring betrekking heeft, voldoet aan de

volgende normen of andere normatiefve dokumenten,

overeenkomstig de bepalingen van Richtlijn 89/336/EEC.

Vi erklærer os eneansvarlige for, at dette produkt, som

denne deklaration omhandler, er i overensstemmelse med

den følgende standarder eller andre normative dokumenter i

følge bestemmelserne i direktiv 89/336/EEC.

Vi deklarerar härmed värt fulla ansvar för att den produkt till

vilken denna deklaration hänvisar är i överensstämmelse

med standarddokument, eller andra normativa dokument

som framstölls i Direktiv 89/336/EEC.

Ilmoitamme yksinomaisella vastuullamme, että tuote, jota

tämä ilmoitus koskee, noudattaa seuraavia standardeja tai

muita ohjeellisia asiakirjoja, jotka noudattavat direktiivin

89/336/EEC. säädöksiä.

Vi erklærer oss alene ansvarlige for at produktet som denne

erklæringen gjelder for, er i overensstemmelse med

følgende normer eller andre normgivende dokumenter som

fælger bestemmelsene i direktiv 89/336/EEC.

ENGLISH

- 2 -

PREFACE

The Panasonic GP-MF130 Machine Vision B/W

CCD Camera has a 1/3” Interline Transfer CCD

image sensor which features 440 000 pixels, a

horizontal resolution of 560 lines, and minimum

smear.

FEATURES

1. Newly developed multi-function solid state

image sensor 1/3” Inter Line Transfer type

CCD image sensor with 752 (H) x 582 (V)

pixels.

2. Selectable scanning system :

1-line interlace and 2-line interlace are avail-

able for the highest quality possible within

video processing.

3. External synchronization :

External HD/VD input enables system setup

with external video processors, etc.

4. High speed shutters up to 1/96 000 second

enables to capture the moving objects.

- 3 -

4. Do not use the strong or abrasive

detergents when cleaning the camera

body.

Use a dry cloth to clean the camera when

dirty.

In case the dirt is hard to remove, use a

mild detergent and wipe gently.

5. Clean the CCD faceplate with care.

Do not clean the CCD with strong or abra-

sive detergents. Use lens tissue or a cotton

tipped applicator and ethanol.

6. Never face the camera towards the sun.

Do not aim the camera at bright objects.

Whether the camera is in use or not, never

aim at the sun or other extremely bright

objects. Otherwise, blooming or smear may

be caused.

PRECAUTIONS

1. Do not attempt to dissemble the camera.

To prevent electric shock, do not remove

screws or covers.

There are no serviceable parts inside. Ask a

qualified service person for servicing.

2. Handle the camera with care.

Do not abuse the camera. Avoid striking,

shaking, etc. The camera could be dam-

aged by improper handling or shortage.

3. Do not expose the camera to rain or

moisture, or try to operate it in wet areas.

This camera is designed for indoor use.

Turn the power off immediately and ask a

qualified service person for servicing.

Moisture can damage the camera and also

create the danger of electric shock.

- 4 -

7. Do not drop anything inside the camera.

Dropping metal for example inside the cam-

era could permanently damage the unit. If

anything is dropped inside the camera, turn

the power off immediately and ask a quali-

fied service person for servicing.

8. Do not operate the camera beyond the

specified temperature, humidity or power

source ratings.

Use the camera under conditions where

temperature is between −10°C - +50°C

(14°F - 122°F), and humidity is below 90 %.

The input power source is DC 12 V, 170 mA.

- 5 -

MAJOR OPERATING CONTROLS AND THEIR FUNCTIONS

12P

VIDEO

130

OFF

1. 1/3” Manual Iris Lens (Sold Separately)

2. Camera Connector (12-pin)

This is connected with the optional Camera

Cable GP-CA34 , GP-CA33, GP-CA59 or

GP-CA60.

Pin No. Description

1 Ground

2 +12V IN

3 Ground for Video Out

4 Video Out

5 Ground for HD

6 HD IN

7 VD IN

8 Ground

9 No connection

10 No connection

11 No connection

12 Ground for VD

3. Pedestal Control

This controls the pedestal level from 0 mV to

100 mV.

- 6 -

w!0i

e!1 u!2

rty

CAUTION: CONNECT

THIS TO A DC 12V

CLASS 2 POWER

SUPPLY ONLY.

4. Manual Gain Control

This controls the gain level from 0 to 6 dB.

5. Video Output Connector

This connector is used to connect with the

VIDEO IN connector of the monitor.

6. Switch 1 No.1 (1/ON) 1ON

This switch selects the Field or Frame

Accumulation.

ON : Field Accumulation

OFF: Frame Accumulation

7. Switch 1 No.2 (2/ON) 2ON

8. Switch 1 No.3 (3/ON) 3ON

9. Switch 1 No.4 (4/ON) 4ON

10. Switch 1 No.5 (5/ON) 5ON

These switches (Switch 1 No. 2, 3, 4, and 5)

are used to set the shutter speed.

Switch 1

- 7 -

The shutter speed can be set as below: 11. Switch 1 No.6 (6/ON) 6ON

This switch is not available for this model.

12. Switch 2 No.1 (1/ON) 1ON

Switch 2 No.2 (2/ON) 2ON

Switch 2 No.3 (3/ON) 3ON

Switch 2 No.4 (4/ON) 4ON

These switches are not available for this

model. Keep these switches at OFF posi-

tion.

13. Switch 2 No.5 (5/ON) 5ON

This switch turns on or off the termination for

HD signal with 75 Ω.

14. Switch 2 No.6 (6/ON) 6ON

This switch turns on or off the termination for

VD signal with 75 Ω.

Not Specified

Shutter Speed

No. 2 No. 3 No. 4 No. 5

OFF OFF OFF OFF

ON OFF OFF OFF

OFF ON OFF OFF

ON ON OFF OFF

OFF OFF ON OFF

ON OFF ON OFF

OFF ON ON OFF

ON ON ON OFF

OFF OFF OFF ON

ON OFF OFF ON

OFF ON OFF ON

Other Combinations

Normal

1/120

1/500

1/1 000

1/2 000

1/4 000

1/8 000

1/16 000

1/32 000

1/64 000

1/96 000

And to control the pedestal level or gain

level, remove the cover fixing screw on the

rear panel as shown below.

- 8 -

1. Power Supply for Camera

Prepare a regulated DC power supply

which can supply DC 12 V ±10 % 170 mA

or more current and rated CLASS 2.

2. Lenses

Be sure to use the optional manual iris lens

having the following items.

Focus : Adjustable

Lens Weight : Less than 300 g(0.66 lbs.)

Note: If the lens is heavier than 300 g(0.66

lbs.), both the lens and the camera

should be secured by using the sup-

porter.

Mount : C-mount

The protrusion

at the rear of

the lens should

be as shown in

the illustration.

Less than 8 mm (Less than 5/6")

3. Switch Covers Removal

Caution: The following preparation should

be made by qualified service person-

nel or system installers.

For setting the Switch 1 No.1 to 6 and 2 No.

1 to 6, remove the switch cover fixing screw

on the side panel as shown below.

PREPARATIONS

Remove this screw

12P

VIDEO

Remove

this screw

Tabla de contenidos

Otros manuales de Cámara de seguridad de Panasonic

Panasonic

Panasonic i-pro WV-NP1004 Manual de usuario

Panasonic

Panasonic WV-SF330 Series Manual de usuario

Panasonic

Panasonic WVNP1000 - NETWORK CAMERA Manual de usuario

Panasonic

Panasonic K-EF234L03E Manual de usuario

Panasonic

Panasonic WVSF332 - IP NETWORK CAMERA Manual de usuario

Panasonic

Panasonic BL-C101A - Fixed MPEG-4 Network Camera Manual de usuario

Panasonic

Panasonic WV-X4173 Guía de instalación

Panasonic

Panasonic WV-SW458 Manual de usuario

Panasonic

Panasonic WV-BP310 Manual de usuario

Panasonic

Panasonic BB-HCM705A - Fixed MP H.264 Dome POE Indoor Network... Manual de usuario

Panasonic

Panasonic WV-CP504 Manual de usuario

Panasonic

Panasonic WV-BP510 Manual de usuario

Panasonic

Panasonic WVNP472 - COLOR CCTV CAMERA Manual de usuario

Panasonic

Panasonic AK-HC1800G Manual de usuario

Panasonic

Panasonic AW-UE100WP Manual de usuario

Panasonic

Panasonic i-Pro WV-SP102 Manual de usuario

Panasonic

Panasonic WVNM100 - NETWORK COLOR CAMERA Manual de usuario

Panasonic

Panasonic WVCW474F - COLOR CCTV CAMERA Manual de usuario

Panasonic

Panasonic OneHome KX-HCM110A Manual de usuario

Panasonic

Panasonic BB-HCM371A - Outdoor Wireless Network Camera Manual de usuario

Panasonic

Panasonic WV140 - B & W CAMERA Manual de usuario

Panasonic

Panasonic WVCL350 - COLOR CAMERA Manual de usuario

Panasonic

Panasonic WV-SFV631L Manual de funcionamiento

Panasonic

Panasonic KX-HCM280 Manual de usuario

Manuales populares de Cámara de seguridad de otras marcas

Okina USA

Okina USA SIR36-870VF650LP Manual de usuario

Divio

Divio NDR155PA Manual de usuario

Canon

Canon VB-C500D Manual de usuario

Easy Access

Easy Access EasyGuard Manual de usuario

Vivotek

Vivotek FD9389-EHV-v2 Manual de usuario

TUYA

TUYA COSMO W2 Manual de usuario

Eusso

Eusso UNC7500-IR Guía de configuración

urmet domus

urmet domus 1096/204 Manual de usuario

VC VC20 series Manual de usuario

Axis

Axis Q1614 Manual de usuario

ieGeek

ieGeek DD201 Manual de usuario

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manual de usuario

Vicon

Vicon V662-D-1 Instrucciones de funcionamiento

Grundig

Grundig GCH-K0274P Manual de usuario

Lorex

Lorex VANTAGE LBC7032 Manual de usuario

4xem

4xem WPT Manual de usuario

Samsung

Samsung SCV-3082 Manual de usuario

Vitek

Vitek VTC-C544 Manual de usuario
