8
ENGLISH
■Pre-season Inspection
●Is the discharged air cold?
Operation is normal if 15 minutes after the start of
operation, the difference between the air intake and
outlet vents temperature is:
●Are the air intake or outlet vents of the indoor or
outdoor units obstructed?
●Are the remote control batteries weak?
If the remote control display appears weak, replace
the batteries.
■When the Air Conditioner is Not Used
for an Extended Period of Time
1To dry the internal parts of the indoor unit, operate
the unit for 2 - 3 hours using:
2Stop the operation by remote control and switch off
the circuit breaker.
Note: If the unit is not switched off by the remote
control, it will start operating when the circuit
breaker is switched to ON. (the unit is equipped
with Auto Restart Control).
3Remove the remote control batteries.
■Recommended Inspection
•After using for several seasons, the unit will become
dirty. This may decrease the unit’s performance.
Depending upon the operation conditions, a dirty
unit may produce odour and/or dust may pollute the
dehumidification system. Therefore, a seasonal
inspection is recommended in addition to regular
cleaning. (Consult an authorized dealer).
CARE AND MAINTENANCE
■Cleaning the Indoor Unit and Remote
Control
•Wipe gently with a soft, dry cloth.
•Do not use water hotter than 40˚C or polishing fluid
to clean the unit.
■Cleaning the Air Filter
(Recommendation: If the unit is operated in a dusty
environment, clean the filters every two weeks,
continuous use of dirty filters will reduce cooling
efficiency)
1Remove dirt using a vacuum cleaner.
2Wash the back of the air filter with water.
3If badly soiled, wash it with soap or a mild household
detergent.
4Let it dry and reinstall it.
Be sure the “FRONT”mark is facing you.
*Damaged air filter.
Consult the nearest authorized dealer.
Part No.: CWD001049.
•Do not use benzene, thinner, scouring powder or a
cloth soaked in caustic chemicals to clean the unit.
■Cleaning the Front Panel
(Must be removed before washing)
1Raise the front panel higher than the horizontal and
pull to remove it.
2Gently wash with water and a sponge.
•Do not press the front panel too hard when washing.
•
When using kitchen cleaning fluid (neutral detergent),
rinse throughly.
•Do not dry the front panel under direct sunlight.
3To fix the front panel, raise the front panel
horizontally, match the protruding portion on the
indoor unit to the fulcrum and push into place.
■Air Purifying Filters
●Solar Refreshing Deodorizing Filter
•Used to remove unpleasant odour and deodorize
the air in the room.
•Reusable.
•Vacuum, place under direct sunlight for 6 hours and
fit it back in place.
(Recommended: every 6 months)
●Catechin Air Purifying Filter
•The filter is coated with catechin to prevent the
growth of bacteria and viruses.
•Reusable.
•Vacuum and fit it back in place
(Recommended: every 6 months)
•Recommended to change these filters every 3 years.
Do not reuse damaged filters.
Consult the nearest authorized dealer to purchase a
new filter.
Catechin Air Purifying Filter No.: CZ-SF70P
Solar Refreshing Deodorizing Filter No.: CZ-SFD70P
•If you operate the air conditioner with dirty filters:
–Air is not purified
–Cooling capacity decreases
–Foul odour is emitted
COOL –8°C or above
FAN operation
Fulcrum
Protruding portion on indoor unit
2
Remove the air filters
1
Raise the
front panel
Catechin Air
Purifying Filter
Solar Refreshing
Deodorizing Filter
