Installation Instructions

High-spec Wired Remote Controller

Model No. CZ-RTC3

85464369763010 CV6233312170

4-15

16-27

28-39

40-51

52-63

64-75

76-87

ENGLISH

ITALIANO

ESPAÑOL

EΛΛΗΝΙΚΆ

FRANÇAIS

PORTUGUÊS

DEUTSCH

業務用リモコンCZ-RTC3据付書En.indd1業務用リモコンCZ-RTC3据付書En.indd1 2014/01/2414:25:042014/01/2414:25:04

Part Names

5) Cursor buttons

Selects an item.

Down

1) 2) 3) 4)

FRANÇAIS Écran LCD Bouton Retour

Retourne à l'écran

précédent.

Bouton Entrée

Fixe le contenu

sélectionné.

Bouton d'économie

d'énergie

Commute entre le mode Normal

et Économie d'énergie.

ESPAÑOL Pantalla

LCD

Botón Atrás

Regresa a la

pantalla anterior.

Botón Enter

Fija el contenido

seleccionado.

Botón Ahorro de energía

Alterna el funcionamiento en

modo ahorro de energía/normal.

DEUTSCH LCD-

Bildschirm

Return-Taste

Khrt zum

vorherigen

Bildschirm

zurücke.

Eingabe-Taste

Legt den

ausgewählten

Inhalt fest.

Energiespar-Taste

Schaltet zwischen

Energiesparendem/

Normalbetrieb.

ITALIANO Schermo

LCD

Tasto return

Ritorna alla

schermata

precedente.

Tasto enter

Fissa il contenuto

selezionato.

Tasto risparmio energetico

Passa da Risparmio energetico

a Funzionamento normale e

viceversa.

PORTUGUÊS

Ecrã LCD Botão de

retorno

Regressa ao ecrã

anterior.

Botão de

introdução

Estabelece

o conteúdo

selecionado.

Botão de poupança de

energia

Alterna entre o funcionamento

em poupança de energia/

normal.

EΛΛΗΝΙΚΆ Οθόνη

LCD

Πλήκτρο

Επιστροφής

Επιστροφή στην

προηγούμενη

οθόνη.

Πλήκτρο

Εισαγωγής

Καθορίζει το

επιλεγμένο

περιεχόμενο.

Πλήκτρο εξοικονόμησης

ενέργειας

Εναλλαγή μεταξύ Κανονικής

λειτουργίας / Λειτουργίας

εξοικονόμησης ενέργειας.

1) LCD screen

2) Return button

Returns to the

previous screen.

6) Menu button

Displays the menu

screen.

7) Operation

indicator

Illuminates during

operation.

Blinks during alarm.

8) Start/Stop button

Starts/Stops operation.

3) Enter button

Fixes the selected

content.

4) Energy saving

button

Switches Energy saving/

Normal operation.

RightLeft

業務用リモコンCZ-RTC3据付書En.indd2業務用リモコンCZ-RTC3据付書En.indd2 2014/01/2414:25:042014/01/2414:25:04

5) 6) 7) 8)

FRANÇAIS Curseurs

Sélectionne un

élément.

Bouton

Afﬁche l'écran

du menu.

Indicateur de

fonctionnement

Brille pendant le

fonctionnement.

Clignote en cas d'alarme.

Bouton Marche/

Arrêt

Démarre/Arrête le

fonctionnement.

ESPAÑOL Botones de

cursor

Seleccionan un

elemento.

Botón Menú

Muestra la

pantalla de

menú.

Indicador de

funcionamiento

Se ilumina durante el

funcionamiento.

Parpadea durante la alarma.

Botón Inicio/

Paro

Inicia/detiene el

funcionamiento.

DEUTSCH Marke-

Tasten

Wählen einen

Ggst. aus.

Menü-Taste

Zeigt den Menü-

Bildschirm an.

Betriebsanzeige

Leuchtet während des Betriebs.

Blinkt während eines Alarms.

Start/Stopp-

Taste

Startet/Stoppt den

Betrieb.

ITALIANO Tasti cursore

Seleziona un

elemento.

Tasto menù

Visualizza la

schermata del

menù.

Indicatore

funzionamento

Si illumina durante il

funzionamento.

Lampeggia durante l'allarme.

Tasto Avvia/

Arresta

Avvia/Arresta il

funzionamento.

PORTUGUÊS

Botões de

cursor

Permitem

selecionar uma

opção.

Botão de

menus

Apresenta o

ecrã de menus.

Indicador de

funcionamento

Acende durante o

funcionamento.

Fica intermitente durante um

problema.

Botão de

arranque/

paragem

Inicia/para o

funcionamento.

EΛΛΗΝΙΚΆ Πλήκτρα

Δρομέα

Επιλογή ενός

στοιχείου.

Πλήκτρο

μενού

Προβολή της

οθόνης του

μενού.

Ένδειξη λειτουργίας

Ανάβει κατά την λειτουργία.

Αναβοσβήνει κατά τη διάρκεια

ειδοποίησης.

Πλήκτρο

Έναρξης/

Διακοπής

Ξεκινά/Σταματά τη

λειτουργία.

Note/Remarque/Nota/Hinweis/Nota/Nota/Σημείωση

Press centre

Appuyez au centre

Pulsar en el centro

Mittlere Taste drücken

Premere al centro

Premir no centro

Πατήστε στο κέντρο

No pen

Pas de stylo

Bolígrafo no

Ohne Stift

Nessuna penna

Não usar pen

Όχι με στυλό

No glove

Pas de gant

Guantes no

Ohne Handschuh

Nessun guanto

Não usar luva

Όχι με γάντι

業務用リモコンCZ-RTC3据付書En.indd3業務用リモコンCZ-RTC3据付書En.indd3 2014/01/2414:25:042014/01/2414:25:04

4(EN)

Safety Precautions

Read before installation

Read the Installation Instructions

carefully to install the remote controller

correctly and safely.

Be sure to read the Safety Precautions

in particular before installation.

After the installation is complete,

perform test operation to conﬁrm that

no abnormality is present.

We assume no responsibility for

accidents or damages resulting from

methods other than those described in

the installation instructions or methods

without using speciﬁed parts.

Malfunctions that occurred due to the

unauthorised installation methods are

not covered by the product warranty.

Read the installation instructions

supplied with indoor units as well.

WARNING

This symbol refers to a hazard or unsafe

practice which can result in severe

personal injury or death.

CAUTION

This symbol refers to a hazard or unsafe

practice which can result in personal

injury or product or property damage.

Matters to be

observed

Prohibited

matters

WARNING

•Turn off the circuit breaker

of the units before

installation.

•Ask your dealer or

professionals for installation

and electric work.

•This controller shall be

installed in accordance with

National Wiring Regulations.

•

Connect and ﬁx the speciﬁed

cables for wiring securely.

•Do not allow the connection

to be exposed to the

external force of the cables.

•

Choose an installation location

that sufﬁciently supports the

weight of the remote controller.

CAUTION

Do not use the remote

controller at the following

locations.

•Location where

condensation occurs

•Location where ﬂammable

gases, etc. may leak

•Location where corrosive

gases, etc. may leak

•

Location with lots of water or oil

droplets (including machine oil)

•Location where voltage

ﬂuctuation frequently occurs

•Location where there

is a machine producing

electromagnetic radiation

•Location where droplets of

organic solvents spread

•Location where acidic or

alkaline solutions or special

sprays are frequently used



Do not operate with wet hands.

Do not wash with water.

ENGLISH

The English text is the original instructions. Other languages are translation of

the original instructions.

NOTICE

業務用リモコンCZ-RTC3据付書En.indd4業務用リモコンCZ-RTC3据付書En.indd4 2014/01/2414:25:042014/01/2414:25:04

(EN)

Part Names ....................................... 2

Safety Precautions........................... 4

Supplied accessories ...................... 5

Speciﬁcations................................... 5

Installation Precautions................... 6

Mounting........................................... 8

Exposed type................................ 8

Embedded type ............................ 9

Setting............................................. 10

Language ................................... 10

Clock .......................................... 10

Controller name.......................... 10

Service contact............................11

RC. setting mode........................ 12

Detailed settings......................... 12

Auto address .............................. 13

Set elec. consumption ................ 13

Conﬁrming Information ................. 14

Test Operation................................ 15

Supplied accessories

Wood screw

M3.8 x 16

(2)

Operating

Instructions

(1)

Quick

Reference

(1)

Clamper

(1)

CONTENTS

Model No. CZ-RTC3

Dimensions (H) 120 mm x (W) 120 mm x (D) 16 mm

Weight 180 g

Temperature/

Humidity range

0 ˚C to 40 ˚C / 20 % to 80 % (No condensation)

*Indoor use only.

Power Source DC16 V (supplied from indoor unit)

Clock

Precision ± 30 seconds/month (at normal temperature 25 ˚C)

*Adjust periodically.

Holding

time

72 hours (When fully charged)

*Approx. 8 hours are required for full charge.

Number of

connected indoor

units

Up to 8 units

Speciﬁcations

ENGLISH

業務用リモコンCZ-RTC3据付書En.indd5業務用リモコンCZ-RTC3据付書En.indd5 2014/01/2414:25:042014/01/2414:25:04

6(EN)

Installation Precautions

Installation location

5 mm or more

50 mm or

1 to 1.5 m

Floor

Install at the height of 1 to 1.5 m from

the ﬂoor (Location where average

room temperature can be detected).

Install vertically against the ﬂoor.

When installing more than 1 remote

controller next to each other, keep

distance of 5 mm on the right and left

and 50 mm on top and bottom.

Avoid the following locations for

installation.

• By the window, etc. exposed to

direct sunlight or direct air

• In the shadow or backside of objects

deviated from the room airﬂow.

• Location where condensation

occurs (The remote controller is not

moisture proof or drip proof.)

• Location near heat source

• Uneven surface

Keep distance of 1 m or more from

the TV, radio and PC. (Cause of fuzzy

images or noise)

Remote control wiring

Wiring diagram

Indoor unit

Terminals for RC wiring

RC wiring (ﬁeld supply)

• No polarity

Type of wiring

Use cables of 0.5 to 1.25 mm2.

Total wire length: 500 m or less

(The wire length between indoor units

should be 200 m or less.)

Number of connectable units

Remote controller: Max. 2

Indoor unit: Max. 8

Attention

Be careful not to connect cables

to other terminals of indoor

units (e.g. power source wiring

terminal). Malfunction may occur.

Do not bundle together with the

power source wiring or store in

the same metal tube. Operation

error may occur.

If noise is induced to the unit

power supply, attach a noise ﬁlter.

業務用リモコンCZ-RTC3据付書En.indd6業務用リモコンCZ-RTC3据付書En.indd6 2014/01/2414:25:052014/01/2414:25:05

(EN)

*Wiring as shown below is prohibited.

R1 R2 R1 R2 12 R1 R2

12 12

Indoor unit Indoor unit Indoor unit

RC wiring

When setting both the main and sub remote controllers

After installation, set one remote controller to [Main] and the other to [Sub] for [Main/

sub] for “Setting” (P.12).

When using the remote controllers* in combination, set this unit to [Main].

*CZ-RTC2, CZ-RE2C2, CZ-RELC2

Using 1 indoor unit

12 12

R1 R2

RC wiring

(ﬁeld supply)

• No polarity Terminals for RC wiring

RC (main) RC (sub)

Indoor unit

Using more than 1 indoor unit or heat exchange ventilation unit

R1 R2 R1 R2 R1 R2 R1 R2

RC (main) RC (sub)

RC wiring (ﬁeld supply)

• No polarity

Terminals for

RC wiring

Indoor unit Indoor unit Indoor unit Indoor unit

Note

Remote controllers can be connected to any indoor unit for operation.

ENGLISH

業務用リモコンCZ-RTC3据付書En.indd7業務用リモコンCZ-RTC3据付書En.indd7 2014/01/2414:25:052014/01/2414:25:05

8(EN)

1Remove the bottom case. Attention

Mounting the bottom case

Tighten the screws securely until

the screw heads touch the bottom

case.

(Otherwise, loose screw heads may

hit the PCB and cause malfunction

when mounting the top case.)

Do not over-tighten the screws.

(The bottom case may be deformed,

resulting in fall of the unit.)

Connecting the remote control wiring

Arrange the wires as shown in the illustration for in

step 2, avoiding unnecessary wires being stored in the

remote controller case.

(Caught wires may destroy the PCB.)

Avoid wires touching parts on the PCB.

(Caught wires may destroy the PCB.)

2Mount to the wall.

Flat-blade

screwdriver

Insert the

driver and

slightly turn.

Bottom

case

Mounting

Exposed type

Mount the top case.

Align the claws of the top

case and then align the

claws of the bottom case.

Preparation: Make 2 holes for screws using a driver.

Mount the bottom case to the wall.

Cut here with a

nipper and remove

the burr with a ﬁle.

Claw (2 places)

Wood screw

(supplied)

Hole for screw

Claw (2 places)

Wall to which

the remote

controller is

ﬁxed

Connect the remote control

wiring

Arrange the wires along the groove

of the case.

Clamper

(supplied)

Pass through

the hole

Remote controller terminal board

Remove the coating. Approx. 6 mm

Remove the sheath. Approx. 180 mm

Make sure the wiring connection

is in the correct direction.

Bottom case

(Back side)

Top case

(Back side)

業務用リモコンCZ-RTC3据付書En.indd8業務用リモコンCZ-RTC3据付書En.indd8 2014/01/2711:22:252014/01/2711:22:25

(EN)

(mm)

2323

83.5

5-5x9

120

Embedded type

Preparation: Make 2 holes for screws using a driver.

2Connect the remote control

wiring

Mount the top case.

Align the claws of the

top case and then

align the claws of the

bottom case.

Avoid the

wire being

caught.

Claw (2 places)

Wood screw

(supplied)

Hole for screw

Claw (2 places)

Mount the bottom case to the wall.

Pass the wire through the hole in the centre

of the bottom case.

Remote controller terminal board

Remove the coating. Approx. 6 mm

Make sure the wiring connection is

in the correct direction.

Bottom case

(Back side)

Top case

(Back side)

Dimensions

ENGLISH

業務用リモコンCZ-RTC3据付書En.indd9業務用リモコンCZ-RTC3据付書En.indd9 2014/01/2414:25:052014/01/2414:25:05

10 (EN)

Setting Language Clock Controller name

1Press .

2Select [Initial settings].

▲▼→

Default setting : English

3Select the item to set.

▲▼→

Language

4Set.

▲▼→

Clock

4Set.

▲▼→►→

(Repeat)

Controller name

4Set.

▲▼◄►→

(Repeat the same procedure for all

characters.)

• Up to 16 characters

(Space is included in the number of

characters.)

To change the character type

Select the character type with

▲▼◄►and press .

To enter space

Select [Space] with ▲▼◄►and

press .

To delete 1 character

Select [BS] with ▲▼◄►and

press .

5Select [Conf].

▲▼◄►→

Controller name

業務用リモコンCZ-RTC3据付書En.indd10業務用リモコンCZ-RTC3据付書En.indd10 2014/01/2414:25:062014/01/2414:25:06

Otros manuales para CZ-RTC3

Tabla de contenidos

Idiomas:

Otros manuales de Mando a distancia de Panasonic

Panasonic

Panasonic AWRP50N - REMOTE CAMERA CONTROLLER Manual de usuario

Panasonic

Panasonic WVCU550CJ - SYSTEM CONTROLLER Manual de usuario

Panasonic

Panasonic EUR511111 Manual de usuario

Panasonic

Panasonic CZ-RTC4 Manual de usuario

Panasonic

Panasonic DMW-RSL1 Manual de usuario

Panasonic

Panasonic TY-RM50VW Manual de usuario

Panasonic

Panasonic AK-HRP1000G Manual de usuario

Panasonic

Panasonic EUR7722KM0 Manual de usuario

Panasonic

Panasonic CZ-RTC3 Manual de usuario

Panasonic

Panasonic CZ-02RT11P Manual de usuario

Panasonic

Panasonic CZ-RTC2 Manual de usuario

Panasonic

Panasonic EUR7603Z40 Manual de usuario

Panasonic

Panasonic FV-SWGR1 Manual de usuario

Panasonic

Panasonic CZ-RL511D Manual de instalación y operación

Panasonic

Panasonic AWCB400N - REMOTE OPERATION PANEL Manual de usuario

Panasonic

Panasonic EUR501453 Manual de usuario

Panasonic

Panasonic AW-RP120G Manual de usuario

Panasonic

Panasonic CZ-RTC5A Manual de usuario

Panasonic

Panasonic EUR7702KE0 Manual de usuario

Panasonic

Panasonic EUR7722X90 Manual de usuario

Panasonic

Panasonic AW-RP60G Manual de uso y cuidado

Panasonic

Panasonic EUR646464 Instrucciones de funcionamiento

Panasonic

Panasonic EUR511158 Manual de usuario

Panasonic

Panasonic AK-HRP1000G Manual de usuario

Manuales populares de Mando a distancia de otras marcas

Bang & Olufsen

Bang & Olufsen Beo4 Manual de usuario

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manual de usuario

Multiplex

Multiplex PROFI TX 9 Manual de usuario

One Remote

One Remote RMB4 Manual de usuario

FUTABA

FUTABA 9ZAP - PART2 Manual de usuario

HR Matic

HR Matic HR MULTI 3 Manual de usuario

Yamaha

Yamaha ACC-GNRST-30-20 Manual de usuario

EisSound

EisSound KBSOUND Manual de usuario

Marantz

Marantz RC101 Manual de usuario

Conrad

Conrad FS20 TC6 Manual de usuario

Anritsu

Anritsu MP1777A Manual de usuario

Niles

Niles WVC100 Guía de solución de problemas

RCA

RCA RCU1300 Manual de usuario

Bang & Olufsen

Bang & Olufsen BEO6 Manual de usuario

GE 94901 Manual de usuario

Onbon

Onbon YQ1-75 Manual de usuario

FUTABA

FUTABA R7108SB Instrucciones de instalación

Invacare

Invacare G91S Manual de usuario
