Panasonic NFC-TAG Manual de usuario
1
Panasonic NFC-TAG Development kit
Installation Manual
Version 2.70
May 11, 2016
Panasonic Semiconductor Solutions Co., Ltd.
2
Setup procedure 5..................................................
Summary 3
..................................................
Usage 15..................................................
Contents
3Summary of Development kit(1)
1. Structure
Antenna
Serial-USB
converter
8bit MCU
NFC
TAG
UART
USB
mobile phone
(with NFC controller)
NFC-TAG board
MCU board
PC Android application
Development kit
① Read/write data in tunnel memory by PC.
② Read/write data in NFC-TAG memory by PC.
③ Read/write data in NFC-TAG memory by mobile phone with NFC function.
④ Read/write data in tunnel memory by mobile phone with NFC function.
⑤ Transfer the files from mobile phone to PC over NFC.
⑥ Transfer the files from mobile phone to PC over Bluetooth. (But a pairing-information is transferred over NFC.)
⑦ Transfer the files from mobile phone to PC over WiFi. (But a pairing-information is transferred over NFC.)
Panasonic
Microcomputer
NFC-TAG
memory
4096byte
tunnel
memory
③
④
②
①
PC software
⑤Bluetooth
⑥
312500
bps Serial-IF
※ NFC TAG memory = 512 byte : MN63Y1210A / MN63Y1213
1024 byte : MN63Y1214 / MN63Y1221
※ tunnel memory = microcomputer memory
※ Serial-IF MN63Y1213 / MN63Y1214 / MN63Y1221 ： I2C 100Kbps
MN63Y1210A ： UART 9600bps, 38400bps , Clock synchronous serial 1Mbps
NFC
2. Functions
⑦
4Summary of Development kit(2)
Software Version File Name outline
Microcomputer Software 2.42 ※It is written in the MCU board Microcomputer board control software
PC Software
(control MCU board)
2.50 NFCTAG_DumpTool_v250.exe Read/Write the NFC-TAG/MCU memory from PC
3.5.605 InTheHand.Net.Personal.dll
Control the Bluetooth adapter when performing the file
transfer by Bluetooth
※About how to obtain, please refer to [setup procedure (3)]
1.0.1 NfcWifiCtrl.dll Control the WiFi adapter when performing the file transfer by
WiFi
PC Software
(control PC-R/W)
1.50 NFCTAG_DumpTool_PCSC_V150.exe Read/Write the NFC-TAG/MCU memory from
PC-R/W (Sony PaSoRi) that is connect to the PC
2.2.2 NfcRW.dll Control the ‘PaSoRi’ made by SONY Corporation
Android
Application
Read/Write 1.51 Panasonic_TagRW_v151.apk Read/Write the NFC-TAG/MCU memory from mobile phone
File transfer 1.55 Panasonic_TagFileTx_v155.apk transfer the files such as photos to the PC from the mobile phone
NFC TAG
setting
1.50 Panasonic_TagSetting1210_v150.apk MN63Y1210A TAG setting
1.50 Panasonic_TagSetting1213_v150.apk MN63Y1213 TAG setting
1.54 Panasonic_TagSetting1214_v154.apk MN63Y1214 TAG setting
1.01 Panasonic_TagSetting1221_v101.apk MN63Y1221 TAG setting
3. Software Version
In this document, we have assumed the use of the following software.
Usage of PC Software(control PC-R/W) , Please refer to the Software Manual for NFC-R/W （NFC-RW Application Manual(E)_v160.pdf)
5
Development kit setup procedure
.
..
6Setup procedure(1)
Step1. Board setting
Step2. Install driver and application (for PC)
・Microsoft .NET Framework 4 Client Profile
download site http://www.microsoft.com/en-us/download/details.aspx?id=24872
(2) Download and install [.NET Framework] from the following site.
Refer board connection of the following figure.
MCU board
(BTPB-101[B])
.
..
JP2
JP1
Jumper setting MN63Y1210A
UART
Clock synchronous serial
Serial-IF select switch
MN63Y1213/1214/1221
(1) Copy an application file to a personal computer.
Sample application : NFCTAG_DumpTool_vXXX.exe
※Supported OS : Microsoft Windows 7 SP1
7Setup procedure(2)
・Virtual COM Port Driver (FTDI)
download site http://www.ftdichip.com/Drivers/VCP.htm
→ Please choose an appropriate driver from the item of VCP Drivers.
(3) Download and install [driver of the MCU board] from the following site.
① Connect MCU Board to PC by USB
② Open the Device Manager
Right-click the
mouse on the
"computer"
Select
"Properties" Select "Device Manager"
③ Install driver for FT232
Right-click the mouse on
the "FT232R USB UART" Select
"Update Driver Software"
Select
"Browse my computer for driver software" Set the downloaded driver in the input box of
[Search for driver software in this location],
and Install the driver
④ Install driver for USB serial port
Right-click the mouse
on the "USB Serial Port" Select
"Update Driver Software"
8Setup procedure(3)
・32feet.NET (http://32feet.codeplex.com/)
download site http://32feet.codeplex.com/downloads/get/386489
※ file name : 32feet.NET 3.5.zip
・ PC application needs the library file that is included in “32feet.NET 3.5.zip”. (InTheHand.Net.Personal.dll)
・ Install the library file (InTheHand.Net.Personal.dll) in the same directory as the PC application.
Bluetooth Icon
Install step (run Setup.exe)
Input install folder
InTheHand.Net.Personal.dll
is installed in the “NET” folder in a
specification folder.
Microsoft standard driver
Confirm in device manager
(4) Download and install [library] from the following site.
About Bluetooth driver
OS standard driver of Microsoft should be used for the Bluetooth driver.
※When using Bluetooth, Bluetooth function is required for the personal computer.
We use following USB-Bluetooth Adapter
BT-MicroEDR2X, BT-Micro4 (PLANEX COMMUNICATIONS INC.)
http://www.planex.co.jp/product/bluetooth/bt-microedr2x/
This procedure is necessary for
performing a file transfer by Bluetooth
9Setup procedure(4)
Put the following library file in the same directory as the PC application.
・Library : NfcWifiCtrl.dll
※Supported OS : Microsoft Windows 7 SP1
(5) Copy WiFi control library(DLL) to a personal computer.
※When using WiFi, WiFi function is required for the personal computer.
We use following USB-WiFi Adapter
WLI-UC-GNM2 (BUFFALO INC.)
http://buffalo.jp/product/wireless-lan/client/wli-uc-gnm2/
About WiFi function
Our development kit uses "Virtual Wi-Fi (wireless hosted network)" that is Microsoft Windows7 standard function.
So Virtual Wi-Fi-enabled WiFi adapter is required.
(Our development kit supports one Virtual Wi-Fi-enabled WiFi adapter)
※After the PC software startup (startup as administrator),
you can see whether your PC has Virtual Wi-Fi-enabled WiFi adapter.
If your PC has Virtual Wi-Fi-
enabled WiFi adapter,
IP address is displayed.
If your PC doesn't have Virtual
Wi-Fi-enabled WiFi adapter,
"NO Adapter" is displayed.
This procedure is necessary for
performing a file transfer by WiFi
10 Setup procedure(5)
Step3. Install Android application
Install Android application to the mobile phone.
Android sample application
・Panasonic_TagRW_vXXX.apk (Data transfer application)
・Panasonic_TagFileTx_vXXX.apk (File transfer application)
・Panasonic_TagSettingXXXX_vXXX.apk (MN63Y1210A/1213/1214/1221 TAG setting application)
TagRW TagFileTx TagSetting
MN63Y1213
MN63Y1210A
MN63Y121４
MN63Y1221
Usage of the applications, refer to each manuals.
XX
