Panasonic EP-MA70 Manual de usuario

GB35

English

Adjustment of the reclining angle and/or legrest

1 Press the button to turn on the power.

• The power is turned o automatically if 3 minutes or more pass without operation.

2 Press the or button to adjust the angle.

• The movement will continue until a “beep-beep-beep” sound is heard if the buttons are held down.

• The movement of the legrest may be delayed slightly.

• The armrest will move in accordance with the reclining of the backrest.

Approx. 120˚

Approx.

170˚

Approx. 5˚

Approx. 85˚

Approx. 15˚

Approx.

95˚

• Do not raise or lower the backrest and/or legrest repeatedly for any purpose other than adjusting them to your preferred positions.

GB36

English

After completing the massage

Timer function

Interrupting the massage

Return the feet massage section to the

original position and then press the

button.

• The massage heads move to the retracted position.

• The legrest lowers and the backrest raises automatically.

(The backrest will move after the massage heads retract.) Lift your feet slightly and

the legrest returns.

If you experience any problems

Press the button.

• All operations will stop immediately.

• Get o the unit carefully to prevent the unit tipping over.

Returning to normal chair position

1 Flap the comfort cushion back onto the

backrest.

The massage will complete automatically approximately 16 minutes after the start of

operations.

• The feet massage section will retract, and the legrest will be lowered

automatically so you can stand up safely.

The feet massage section will not retract all the way when

the legrest is extended, since the sole massage section

will hit the oor.

Raise your legs to retract all the way.

• The backrest will not rise automatically.

• The massage heads move to the retracted position.

The backrest will rise by pressing button twice.

GB37

English

2 Store the legrest.

See Warning No. 2 on page GB2, and No. 16 and No. 21 on

page GB3.

1 Pull the lever in the direction of the arrow.

2 Rotate from top.

3 Rotate until it locks into place.

4 Release the lever.

5 Check that the legrest is locked.

Press rmly.

Let go.

Disconnecting the power

See Warning No. 1 and 6 on page GB1, No. 12 on page GB2, and Operating Precautions No. 16 on page GB4.

1 Slide the power switch to the

“o” position.

2 Turn the key to the “lock”

position and remove it.

Power switch section

3 Remove the power plug from the power socket.

4 The key must be stored out of the reach of children.

GB38

English

Cleaning and Maintenance

See Danger No. 2 on page GB1.

Areas covered with synthetic leather

Wipe these areas with a soft, dry cloth.

• When using commercially available leather-care products (wipes), follow its

instructions.

• If the synthetic leather is particularly dirty, wipe it in the following manner:

1. Soak a soft cloth in water or a 3% to 5% solution of mild detergent and wring it out

thoroughly.

2. Dab the surface with the moistened cloth.

3. Rinse the cloth in water, wring it out thoroughly, and then wipe any remaining

detergent from the surface.

4. Wipe the surfaces with a soft, dry cloth.

5. Allow to dry naturally.

• If it is dicult to remove dirt, soak a commercially available Melamine foam sponge in

mild detergent and wipe the unit with it.

• Do not use a hair dryer to dry the surface more quickly.

• Since colours may transfer from clothing to the synthetic leather surface, be careful

when using the unit with clothing such as jeans or coloured clothes.

• Do not allow these areas to come in contact with plastic for extended periods of time

as this may lead to discolouration.

• Never use chemicals such as thinner, benzine, alcohol, etc.

Plastic Area

1 Wipe the unit with a cloth moistened with mild

detergent and thoroughly wrung out.

• Never use chemicals such as thinner, benzine, alcohol, etc.

2 Wipe the unit with a cloth moistened with plain water

and thoroughly wrung out.

• Make sure to wring tightly before wiping the controller.

3 Allow the unit to dry naturally.

Seat Fabric

1 Wipe the unit with a cloth moistened with mild

detergent and thoroughly wrung out.

• Never use chemicals such as thinner, benzine, alcohol, etc.

2 Use water or a mild detergent and brush on areas

where the seat fabric is particularly soiled.

• Be careful not to brush the fabric too much to avoid damage.

3 Wipe the unit with a cloth moistened with plain

water and thoroughly wrung out.

4 Allow the unit to dry naturally.

• Since colour may transfer from clothing to the seat fabric, be careful when

using the unit with clothing such as jeans or coloured clothes.

GB39

English

Moving the Unit

See Warning No. 22 on page GB3.

Moving by lifting it with 2 or more persons

Move the unit with 2 or more people in front and back of the unit holding on the side of

the legrest and the groove on the back cover of the backrest.

Hold onto the sides.

Groove

Place the controller and

power cord on the seat.

Legrest Back cover

Place your ngers in the

groove.

Hold onto the sides of

the legrest.

Mat

Do not hold onto the front

side.

The sole massage section

might slide, and injuries

may occur.

* You may damage the oor by dropping the unit if you do not hold it correctly.

Never carry it by the armrest, because it may get damaged.

To put the unit down on the oor

• Put the unit down slowly and carefully watch your step.

• Put down the legrest by holding it with your hands until it has been set on the oor completely.

If you release your hands before the legrest is fully extended, the legrest will forcefully return to the initial position.

GB40

English

Using the wheels to move the unit

Move the unit by holding onto the side of the legrest and using the wheels.

Roll the unit slowly

Place the controller and

power cord on the seat.

The oor may get damaged, so it is recommended

to place a mat etc. on the oor.

Wheels

Lift it no higher than

waist height

Hold onto the sides.

Hold onto the sides of the legrest.

Do not hold onto the front side.

The sole massage section might

slide, and injuries may occur.

To put the unit down on the oor

• Put the unit down slowly and carefully watch your step.

• Put down the legrest by holding it with your hands until it has been set on the oor completely.

If you release your hands before the legrest is fully extended, the legrest will forcefully return to the initial position.

How to remove the armrest

It is easier to move the unit with the armrest removed.

1 Remove the air plugs.

(See Step 3 on page GB14.)

2 Remove the attachment screws.

(See Step 2-3 on page GB13.)

3 Slide the armrest toward the rear, then pull it up

holding on it with both hands.

GB41

English

About the Automatic programmes/About the massage

techniques/About the voice guidance function

About the Automatic programmes

(* Time spent on “Finishing Touches” diers depending on your height and intensity setting.)

Refresh programme

1) Tap/Swedish

on neck/

shoulders

2) Tap/knead on

lower back

Pelvis stretch

Tap/knead on neck/

lower back

Shoulder blade stretch

4) Tap/knead on

middle back/

lower back

5) Leg stretch 6) Tap/Swedish

on neck/

shoulders

7) Finishing

Touches*

Deep programme

1) Ultra knead/

knead on neck/

shoulders

2) Knead/roll on

lower back

3) Leg stretch

Pelvis stretch

4) Ultra knead/

knead on neck/

shoulders

5) Shoulder

blade stretch

6) Knead/roll on

middle back/

lower back

7) Finishing

Touches*

Shiatsu programme

1) Shiatsu/ultra

knead on neck/

shoulders

2) Shiatsu/knead

on lower back

Shiatsu/roll on middle

back

Shoulder blade stretch

4) Shiatsu/ultra

knead on neck/

shoulders

Shiatsu/knead on

middle back/lower

back

6) Pelvis stretch

Leg stretch

7) Finishing

Touches*

Hip programme

1) Pelvis stretch 3

times

Entire back roll

2) Leg stretch 3) Shoulder blade

stretch

Entire back roll

4) Pelvis stretch 2

times

Entire back roll

5) Leg stretch

Entire back roll

6) Pelvis stretch

Entire back roll

7) Finishing

Touches*

Neck/shoulder programme

1) Shiatsu/knead

on neck/

shoulders

Roll on middle back

Shoulder blade stretch

3) Shiatsu/knead

on neck/

shoulders

4) Roll on middle

back

5) Shiatsu/knead

on neck/

shoulders

6) Finishing

Touches*

Lower back programme

1) Knead/roll on

middle back/

lower back

2) Knead/roll on

middle back/

lower back

3) Pelvis stretch

Leg stretch

4) Knead/roll on

middle back/

lower back

5) Knead/roll on

middle back/

lower back

6) Finishing

Touches*

GB42

English

About the massage techniques (The gures are images of the respective operations.)

ULTRA KNEAD SHIATSU KNEAD SWEDISH

Fast kneading in small circles. Strong pointed massage. Deep kneading action. Softer planar massage action.

ROLL TAP FULL BACK ROLL

• The respective techniques are

suitable for specic body

parts.

Actions of Shiatsu for the

“NECK” are dierent from of

the actions for the

“SHOULDER”.

Regional roll & stretch massage. Tapping massage. Stretching massage along the

backbone.

About the voice guidance function

This is a function which briey explains the operation procedures and contents of the actions.

When ready, select one of the Auto programmes

from the ashing buttons.

This is a programme for those who prefer an

intense Shiatsu-type massage from above the

shoulders.

Adjusting the voice guidance volume

Press the button to shift the volume level by one up/down.

Display

Volume “O” “Soft” “Medium”

Default Setting “Loud”

The single beep (when a button is pressed) and

the triple beep (when the adjustable setting limit

is reached) will always be audible.

This can be used with the volume saved during the Automatic programme. (See page GB24.)

GB43

English

Troubleshooting

Problem

Cause and Remedy

Motor Noises

• It sounds and feels like the massage heads are straining to get over wrinkles in the cloth.

• There is operational noise of kneading or tapping actions.

• There is a creaking noise when the massage heads are in operation.

• There is a rattling sound when the massage heads move up or down.

• The belt can be heard rotating.

• The motor groans when it comes under load.

• There is a strange sound when the massage heads move in and out.

• There is a noise when I sit down.

• There is a noise when the comfort cushion moves over the armrest when the seat is reclining.

• There is a rubbing sound produced by the massage heads rubbing on the seat fabric.

• There is a noise of discharging air.

• There is operational noise when applying air pressure.

• The legrest rattles.

• There is a humming sound from the pump.

• There is operational noise of valves under the seat.

• There is an unstable sound when air escapes during the leg stretch.

These sounds are perfectly normal and will not have any eect on the operation of the unit.

The massage heads stop during operation.

(All the displays and buttons on the controller will ash and then turn o.)

If excessive force is applied to the massage heads during operation, in the interests of safety the massage heads may stop moving.

If all markings and buttons on the controller start to ash, which is extremely unusual, turn o the power switch, wait for

approximately 10 seconds and then turn the power switch on again.

If the massage heads stop again, position yourself so that your back is not completely in contact with the backrest. (Caution should

be exercised particularly when used by persons weighing 100 kg or more.)

It is not possible to recline the unit.

The legrest cannot be raised or lowered.

(All the displays and buttons on the controller will ash and then turn o.)

If the unit encounters an obstacle or if excessive force is exerted on it during operation, in the interests of safety the unit will come

to a stop.

When all displays and buttons are ashing and the backrest or the legrest has stopped, turn o the power of the unit once, turn

“on” the power again after approximately 10 seconds, and then operate the unit.

The massage heads do not come up to the shoulder or neck.

If your head does not contact with the pillow or your back does not contact with the backrest, the shoulder position may be

detected as lower than the actual position during the body scanning. Sit on the seat in the deepest position and put your head on

the pillow, and then repeat the operations again from the start. (See page GB21.)

The height of the left and right massage heads is dierent.

An alternating tapping method is employed, which means that this phenomenon will naturally occur. There is nothing wrong with

the unit.

GB44

English

Problem

Cause and Remedy

“Heat” massage heads do not get warm.

• button is set to O.

• Sense of warmth from the massage heads will dier depending on your body shape, massage area, massage action, clothing, and

ambient temperature.

The “Heat” massage heads do not cool down even after the “Heat” massage heads setting is turned o.

• Because of the structure of the heater, the “Heat” massage heads will feel warm for a while after heating due to the residual heat.

• The temperature you feel may rise when you massage the same area for a long time even if the “Heat” massage heads setting is

set to O.

Reclining does not take place even though a massage is started in pre-programmes.

(The backrest does not automatically recline.)

Automatic reclining will not activate when the backrest is reclined to at position more than massage position and legrest is in

upper position.

The backrest does not return to the upright position.

If the unit is stopped by automatic shut-o or by pressing the button, it will not return automatically.

(To return from the reclined position to the original position, press the button twice.)

The unit will not operate at all.

• Upper body (neck to lower back) massage

• Lower body massage

• Arm massage

• The power cord has been disconnected. (See page GB18.)

• The power switch on the unit has not been turned on.

• An Automatic programme button or Manual Operation button hasn’t been pressed after pressing .

It is not possible to massage hands and arms.

The air plug on the armrest is disconnected. (See page GB14.)

Sometimes the power won’t turn on when is pressed again when a massage has nished.

Approximately 5 seconds are required for programme termination after a massage nishes. Wait at least 5 seconds once all

movement has stopped before pressing .

The unit has been damaged.

Stop using the unit immediately.

The power cord or power plug is abnormally hot.

Stop using the unit immediately.

See Warning No. 17 on page GB1, and No. 9 and 10 on page GB2.

Otros manuales para EP-MA70

Tabla de contenidos

Otros manuales de Masajeador de Panasonic

Panasonic

Panasonic EP-MA70 Manual de usuario

Panasonic

Panasonic EP-MA10 Manual de usuario

Panasonic

Panasonic EP-MAS1 Manual de usuario

Panasonic

Panasonic EP30007KX Manual de usuario

Panasonic

Panasonic EP1273 - MASSAGE LOUNGER Manual de usuario

Panasonic

Panasonic EP30102 Manual de usuario

Panasonic

Panasonic EP1285KL Manual de usuario

Panasonic

Panasonic EP3513-U1 Instrucciones de construcción

Panasonic

Panasonic EP3203 - MASSAGE LOUNGER - MULTI-LANG Manual de usuario

Panasonic

Panasonic EP1022-U1 Manual de usuario

Panasonic

Panasonic EP1005 - MASSAGE LOUNGER Manual de usuario

Panasonic

Panasonic EP-MA70KX Manual de usuario

Panasonic

Panasonic EP-MA70 Manual de usuario

Panasonic

Panasonic EP1015 - MASSAGE LOUNGER - MULTI-LANG Manual de usuario

Panasonic

Panasonic EV-281 Manual de usuario

Panasonic

Panasonic EV-293 Manual de usuario

Panasonic

Panasonic SW50 Manual de usuario

Panasonic

Panasonic Real Pro Ultra EP-30003 Manual de usuario

Panasonic

Panasonic EP1022 - MASSAGE LOUNGER Manual de usuario

Panasonic

Panasonic EP1285 Manual de usuario

Panasonic

Panasonic EP-MA70 Manual de usuario

Panasonic

Panasonic EP1082KL-COMBO Manual de usuario

Panasonic

Panasonic Real Pro Ultra EP30005 Manual de usuario

Panasonic

Panasonic REAL PRO Elite EP3513 Manual de usuario

Manuales populares de Masajeador de otras marcas

ELEEELS

ELEEELS P2 Manual de usuario

Cenocco

Cenocco CC-9111 Manual de usuario

Human Touch

Human Touch NOVO Manual de usuario

Adler

Adler AD 2167 Manual de usuario

Taurus

Taurus Wellness TW-MC-M Manual de usuario

Infinity

Infinity Syner-D Circadian Manual de usuario

Hydas

Hydas LH-095 Manual de usuario

AEG

AEG FM 5567 Manual de usuario

OBH Nordica

OBH Nordica Shiatus Tunes Manual de usuario

Hutech

Hutech Q9 Manual de usuario

Medisana

Medisana MM 825 Manual de usuario

SOLAC

SOLAC Therma Hydro Manual de usuario

Invacare

Invacare Texas Manual de usuario

Casada

Casada Bismarck II Manual de usuario

Fujiiryoki

Fujiiryoki Cyber-Relax EC-1700 Manual de usuario

Medisana

Medisana HM 886 Manual de usuario

HoMedics

HoMedics BA-C200 Manual de usuario

Repose

Repose Lynton Manual de usuario
