Panasonic CF-29 Series Manual de usuario

Personal Computer

Reference Manual

Model No. CF-29 Series

XP 2000 We recommend that this Reference Manual be printed.

Read Me First

If the user has logged on without the administrator authority, some functions may not be

executable, and some screens may be not displayed as shown in this manual.

If this happens, log on with the administrator authority to enable these functions.

This manual covers two types of models, as distinguished by the type of LCD screen

models with touchscreen and models without touchscreen).

Confirm the latest information on optional products in catalogs, etc.

NOTE

NOTE provides a useful fact or helpful information.

CAUTION

CAUTION indicates a condition that may result in minor or moderate injury.

WARNING

WARNING indicates a hazard that may result in moderate or serious injury.

Windows XP

Information for Microsoft®Windows®XP Professional users. "Windows" or "Windows XP"

in this manual.

Windows 2000

Information for Microsoft®Windows®2000 Professional users. "Windows" or "Windows

2000" in this manual.



Enter

This illustration means to press the [Enter] key.



This illustration means to press and hold the [Fn] key, then press the [F5] key.

[Start] - [Run]

This illustration means to click [Start], then to click [Run]. For some applications, you may

need to double-click.

⇒Operating Instructions

This illustration means to refer to the Operating Instructions.

Windows XP screens are used in this manual when no specific OS (operating system)

notes are required.

Some of the illustrations in this manual may differ slightly in shape from the actual items in

order to make the explanation easier to understand.

The following drives are described as "CD drive".

CD-ROM drive, DVD-ROM drive, CD-R/RW drive, DVD-ROM & CD-R/RW drive

Illustrations and Terminology in this Reference Manual

Read Me First

About the terminology used in this manual and the Setup Utility concerning the internal

LCD and an external display

*1 To display [Intel(R) 82852/82855 GM/GME Graphics Controller properties]:

Windows XP

Select [Start] - [Control Panel] - [Other Control Panel Options] - [Intel(R) Extreme Graphics].

Windows 2000

Select [Start] - [Settings] - [Control Panel] - [Intel(R) Extreme Graphics].

This manual and the Setup

Utility

[Intel(R) 82852/82855 GM/

GME Graphics Controller

Properties]*1

To display the same screen

on both the LCD and

external display

Simultaneous display Intel(R) Dual Display Clone

Key Combinations

CAUTION

Do not press the following key combinations repeatedly in (quick) succession. Also, do

not press different key combinations quickly one after another.

Do not press the following key combinations while using the touch pad (external

mouse), touchscreen (only for models with touchscreen) or other keys.

NOTE

Do not press the following key combinations until you log on to Windows and the hard

disk drive indicator turns off. Note, however, that the key combinations

and

are operable in the Setup Utility.

The key combinations below may not work while some applications are running.

Besides, the popup window may not be displayed depending on the state of the

application you are using (e.g., when [Command Prompt] is set to "Full Screen").

Key Functions Popup Window

(Displayed after logging

on to Windows)

LCD brightness control (down)

LCD brightness control (up)

Pressing this key combination adjusts the

brightness of LCD.

The brightness setting is stored in memory

separately under the condition the AC adaptor is

connected and under the condition the AC adaptor

is not connected.

Key Combinations

Display change

By pressing this key combination, you can select

either an external display, internal LCD or

simultaneous. (page 68)

This key combination does not work when

[Command Prompt] is set to "Full Screen".

CAUTION

Do not press another key until the display

destination has been completely switched.

Do not press this key combination in the

following conditions.

• While MPEG files are playing.

• When the Extended Desktop is being

utilized.

NOTE

Windows XP

When switching to a different user with the

Fast User Switching function, this key

operation may not work. In this case, log off

all users and restart the computer.

Key Functions Popup Window

(Displayed after logging

on to Windows)

Key Combinations

Speaker on/off switch

Pressing this key combination turns on/off audio

from the internal speaker and headphone jack.

NOTE

Disabling the speakers will also disable the

warning beep.

Speakers connected to the USB port

cannot be muted.

OFF

(MUTE)

Volume control (down)

Volume control (up)

Pressing this key combination adjusts the volume

of the internal speaker and headphone jack.

NOTE

This key combination cannot be used to

adjust the volume of the warning beep or

speakers connected to the USB port.

Power off using the standby function

Pressing this key combination causes the current

status of the computer to be saved to memory, and

powers off the computer. (page 31)

Key Functions Popup Window

(Displayed after logging

on to Windows)

Key Combinations

Remaining capacity of the battery pack

Pressing this key combination displays the

remaining battery capacity on the screen.

When the battery pack is

inserted in the computer

(example)

When the battery pack is

not inserted in the

computer

F10

Power off using the hibernation function

Pressing this key combination causes the current

status of the computer to be saved to the hard disk,

and powers off the computer. (page 31)

Key Functions Popup Window

(Displayed after logging

on to Windows)

Key Combinations

There are two Fn key functions as follows:

Fn key lock function

After

is pressed once, it stays in the "pressed" position until another key is pressed.

This is convenient when it is difficult to press two buttons simultaneously.

Popup windows display ON/OFF

1Run the Hotkey Settings.

Windows XP

Select [Start] - [All Programs] - [Panasonic] - [Hotkey Settings].

Windows 2000

Select [Start] - [Programs] - [Panasonic] - [Hotkey Settings].

2Set the parameters.

A. Use Fn key lock

Add the check mark if you want to enable the Fn key lock function. The following

Fn key lock function will then be enabled.

To use

only once:

1Press

once. (Locked)

2Press another key for combination. (Lock released)

To use

successively:

1Press

twice. (Locked)

2Press another key for combination.

Fn key remains locked until

is pressed once more.

B. Notification

This setting is only available when [Use Fn key lock] is checked.

[Make sounds when Fn key is pressed]*1

Notifies the user with a sound when

is locked or released.

[Show status on screen]:

Displays the Fn key status on the taskbar.

is locked

is not locked

C. Disable popup

Add the check mark if you want to turn the popup window display function OFF.

The full-screen display of [Command Prompt] screen or MPEG files may change

Hotkey Settings

Key Combinations

to a window display if

*2 keys are pressed. To prevent this, turn the popup

window display function OFF.

3Select [OK].

NOTE

Each user can select separate settings for whether or not to use the Hotkey settings.

*1 If MUTE is set, you will not hear a beep.

*2 "

" indicates any function key from

F10

LED Indicators

Power status Not lit

Power off / Hibernation mode

Green

Power on

Blinking green

Standby mode

Battery pack status Not lit

Battery pack is not connected or charging not being performed.

Orange*1

Charging in progress.

Green*1

Fully-charged.

Blinking green

In high temperature mode, the battery pack is discharging to a level of

80%*2 in normal temperature mode. Do not remove the battery pack while

the battery indicator is blinking green.

Red

The battery level is very low (the charge is less than approx. 9% capacity).

Connect the AC adaptor. You can use the computer when the battery

indicator light is orange. If you do not have an AC adaptor, save your data

and power off your computer. After replacing the battery pack with a fully

charged one, turn your computer on.

Blinking red*1

Battery pack or charging may not be working properly. Quickly save your

data and power off your computer. Remove the battery pack and

disconnect the AC adaptor, then connect them again. If the problem

persists, contact Panasonic Technical Support. Possible failure in the

battery pack or charging circuit.

Blinking orange*1

Battery cannot be recharged temporarily because the internal temperature

of the battery pack is outside of the acceptable temperature range for

recharging. Once the allowable range requirement is satisfied, charging

begins automatically. Your computer can be used normally in this state.

Blinking green and orange alternately

Warming up the system to prevent hard disk drive malfunctions at low

temperature. Leave your computer as is. Once the allowable range

requirement is satisfied, your computer will start automatically.
