Panasonic CF-20 series Manual de usuario
Useful Information
Handling and Maintenance.......................... 21
Installing Software ....................................... 26
Getting Started
Introduction..................................................... 2
Description of Parts ........................................ 4
First-time Operation..................................... 14
Turning On / Turning Off.............................. 20
Troubleshooting
Troubleshooting (Basic)............................... 31
Appendix
LIMITED USE LICENSE AGREEMENT...... 36
Specications .............................................. 40
LIMITED WARRANTY................................. 45
Standard Limited Warranty.......................... 52
Useful Information
Troubleshooting
Appendix Getting Started
Contents
OPERATING INSTRUCTIONS
Basic Guide
Personal Computer
Model No. CF-20series
Please read these instructions carefully before using this product, and save this manual for future use.
2
Getting Started
Thank you for purchasing this Panasonic product. For optimum performance and safety, please
read these instructions carefully.
In these instructions, the names are referred as follows.
indicates Windows 10 Operating System.
indicates Windows 7 Operating System.
nTerms and illustrations in these instructions
CAUTION : Conditions that may result in minor or moderate injury.
NOTE : Useful and helpful information.
Enter
: Press [Enter] key.
Fn
+
F5
: Press and hold [Fn] key, and then press [F5] key.
- [All Apps] : Click (Start) and then click [All Apps].
(Start) - [All Programs] : Click (Start), and then click [All Programs]. You may need to
double-click in some cases.
è: Page in these Operating Instructions or in the Reference Manual.
: Reference to the on-screen manuals.
l Someillustrationsaresimpliedtohelpyourunderstandingandmaylookdifferentfromthe
actual unit. Some types of software are automatically updated, and differences may occur
from descriptions in this manual.
lIf you do not log on as an administrator, you cannot use some functions or cannot display
some screens.
lRefer for the latest information about optional products to the catalogs, etc.
lIn these instructions, the names and terms are referred as follows.
“Windows 10 Pro 64-bit” as “Windows” or “Windows 10”
“Windows 7 Professional 32-bit Service Pack 1” and “Windows 7 Professional 64-bit Service
Pack 1” as “Windows” or “Windows 7”
DVD MULTI drive as “CD/DVD drive”
Circular media including DVD-ROM and CD-ROM as “discs”
“Multilanguage User Interface” as “MUI”
The Digitizer + Touch Screen (Capacitive) as the “digitizer”, and the Touch Screen as the
“touchscreen”.
The digitizer pen and the stylus as the “pen (included)”.
“Operating Instructions Reference Manual” and “Operating Instructions Connect to a net-
work” as the “Reference Manual” and “Connect to a network”.
l
Screen messages are explained in [English (United States)].
(Depending on the language preference, some screen messages in these instructions are dif-
ferent from the actual screen messages. For example, [Flight mode] may be displayed instead
of [Airplane mode] in some language preference.)
nDisclaimer
Computerspecicationsandmanualsaresubjecttochangewithoutnotice.PanasonicCorpora-
tion assumes no liability for damage incurred directly or indirectly from errors, omissions or dis-
crepancies between the computer and the manuals.
Introduction
3
Getting Started
nTrademarks
Microsoft®, Windows®, the Windows logo, and IntelliMouse are registered trademarks of Microsoft
Corporation of the United States and/or other countries.
Intel, Core and PROSet are either registered trademarks or trademarks of Intel Corporation.
SDXC and microSDXC Logos are trademarks of SD-3C, LLC.
Adobe, the Adobe logo and Adobe Reader are either registered trademarks or trademarks of
Adobe Systems Incorporated in the United States and/or other countries.
Bluetooth®is a registered trademark owned by Bluetooth SIG, Inc., U.S.A. and licensed to
Panasonic Corporation.
HDMI,theHDMILogoandHigh-DenitionMultimediaInterfacearetrademarksorregistered
trademarks of HDMI Licensing LLC in the United States and other countries.
Names of products, brands, etc., appearing in this manual are trademarks or registered trade-
marks of their respective own companies.
nOn-screen Manual
For further information about the computer, you can refer to the on-screen manual.
lOperating Instructions - Reference Manual
This Manual contains the practical information to help you fully enjoy the computer’s perfor-
mance. Update it to the latest version for reference.
lImportant Battery Tips
The Important Battery Tips will provide you with the battery information so that you can use
the battery in the optimum condition to obtain longer operation time.
lUpdate the on-screen manuals
This describes the procedures to update the on-screen manual.
lOperating Instructions - Connect to a network
This describes the connection procedures using the network devices mounted on this unit.
To access the on-screen manuals, follow the steps below.
Double-click [Manual Selector] on the desktop, and select the manual and click [Open].
1. Double-click the [Panasonic PC Settings Utility] on the desktop screen, and then click [Support]
- [Manual] - [Launch Manual Selector].
2. Select the manual and click [Open].
NOTE
[Contents] tab or [Search] tab of the on-screen manuals is displayed on the left side of the
window. Select tab and display the desired item.
4
Getting Started
Description of Parts
A: Wireless WAN Antenna / GPS Antenna
<Only for model with wireless WAN/GPS>
èReference Manual “Wireless WAN”
èReference Manual “GPS”
B: Microphone
C: Camera Lens
D: Ambient Sensor
E: Camera Indicator
èReference Manual “Camera”
F: LCD
G: Wireless LAN Antenna / Bluetooth
Antenna
H: Wireless LAN Antenna
èReference Manual “Bluetooth”
Connect to a network “Wireless LAN”
I: Tablet Buttons
èReference Manual “Tablet Buttons”
J: LED Indicator
: Battery Status
: Power Status
Off: Power off/Hibernation
Green: Power on
Blinking Green: Sleep
Blinking green rapidly:
Cannot power on or resume due to
low temperature.
: Wireless ready
This indicator lights when Wireless
LAN, Bluetooth, and/or Wireless WAN
are connected and ready. It does not
necessarily indicate the On/Off condi-
tion of the wireless connection.
èConnect to a network
: Caps Lock indicator
: NumLk (numeric lock) indicator
: ScrLk (scroll lock) indicator
K: Power Switch
L: Detach Lock
M: Release Lever
N: Function (Fn) Keys
èReference Manual “Function Keys”
O: Keyboard
P: Touchpad
èReference Manual “Touchpad”
Q: Display Latch
R: Security Lock (Clamshell)
When the main unit is connected, both the
main unit and keyboard base can be se-
cured at the same time.
S: Security Lock (Keyboard base)
A Kensington cable can be connected. For
further information, read the manual that
comes with the cable.
A
C
B
F
I
S
R
U
V
T
O
P
J
M
N
J
K
Q
L
G
H
D
EMain Unit
Keyboard Base
Camera
5
Getting Started
T: USB 3.0 Port
èReference Manual “USB Devices”
U: LAN Port
èConnect to a network “LAN”
V: Serial Port
èReference Manual “Serial Port”
6
Getting Started
Description of Parts
A: DC-IN Jack
Only the main unit can be charged.
B: Pen Holder
C: Pen
D: Tether Hole
E: Security Lock (Main Unit)
A Kensington cable can be connected. For
further information, read the manual that
comes with the cable.
F: Speaker
The speaker contains a magnet and
magnetic products. Avoid leaving metallic
object or magnetic media in contact with
these areas.
G: SD Memory Card Indicator
(Blinking: During access or a password is
requested)
H: microSD Memory Card Slot
Keep microSD Memory Cards away from
infants and small children.
èReference Manual “SD Memory
Card”
I: Headset Jack
A headset or headphone can be connect-
ed.
J: USB 3.0 Port (CHG)
Do not insert any foreign object in the USB
port.
èReference Manual “USB Devices”
K: HDMI Port
èReference Manual “External Dis-
play”
L: LAN Port
è
Connect to a network “LAN”
A B C D E
DE F HG I J K L
Main Unit (Right Side)
Main Unit (Left Side)
7
Getting Started
A: DC-IN Jack
B: SD Memory Card Indicator
(Blinking: During access or a password is
requested)
C: SD Memory Card Slot
Keep SD Memory Cards away from infants
and small children.
èReference Manual “SD Memory
Card”
D: HDMI Port
èReference Manual “External Dis-
play”
E: USB 2.0 Port
èConnect to a network “USB Devic-
es”
F: VGA Port
èReference Manual “External Dis-
play”
A CB D E F
Keyboard Base (Left Side)
8
Getting Started
Description of Parts
A: Carrying Handle
B: External Antenna Connector (CH2)
C: External Antenna Connector (CH1)
D: Expansion Bus Connector
èReference Manual “Port replicator”
E: Battery Cover
F: Battery Cover Latch
G: LED Indicator
: Battery Status
èReference Manual “Battery Power”
H: Battery Pack Latch
èReference Manual “Battery Power”
A
B
D
C
F
G
E
H
Keyboard Base (Bottom Side)
9
Getting Started
Rear Camera
<Only for model with Rear Camera>
A: Camera Indicator
B: Camera Light
C: Camera Lens
èReference Manual “Camera”
D: Back Cover
The shape of this may vary depending on
the model.
E: Release Latch
F: microSIM Card Slot
<Only for model with wireless WAN>
èConnect to a network “Wireless
WAN”
G: Battery Pack Latch
èReference Manual “Battery Power”
H: LED Indicator
<Only for model with built-in bridge bat-
tery>
: Battery Status
èReference Manual “Battery Power”
A CB
D
E
F
G
H
Main Unit (Bottom Side)
10
Getting Started
Description of Parts
A: Tether Hole
B: LED Indicator
: Battery Status
: Power Status
Off: Power off/Hibernation
Green: Power on
Blinking Green: Sleep
Blinking green rapidly:
Cannot power on or resume due to
low temperature.
C: Barcode Reader
<Only for model with Barcode Reader>
èReference Manual “Barcode Read-
er”
A B B C A
Main Unit (Top Side)
