Panasonic WV-CF5SA Manual de usuario
Before attempting to connect or install this product,
please read these instructions carefully and save this manual for future use.
The model number is abbreviated in some descriptions in this manual.
Operating Instructions
Included Installation Instructions
Dome Cover
Model No.
WV-CF5SA
Precautions
Mounting procedures
Refer installation work to the dealer.
Installation work requires technique and experience. Failure to observe this may cause fire, electric
shock, injury, or damage to the product.
Be sure to consult the dealer.
Note:
● When a smoke type dome cover is used, the IR LED irradiation distance and the illuminance level
for switching between color and monochrome are lower than for a standard clear type dome
cover. Check the settings after attaching the enclosure.
n Attach to WV-SFN631L/WV-SFN611L
Read the following descriptions together with the Installation Guide of the camera. The WV-SFN631L
is used as an example in these descriptions.
Step1
Remove the enclosure from camera
Use the bit included with the camera to
loosen the 2 screws that secure the
enclosure, and then remove the enclo-
sure from the camera body.
Enclosure fixing
screws (x2)
Enclosure
Camera body
2
Step2 Remove the dome cover
Remove the screw that secures the dome cover holder
and the enclosure. Rotate the dome cover holder coun-
terclockwise until the dome cover holder can be
removed.
You can remove the dome cover holder, light-blocking
sheet, and dome cover (in this order) once the 3 protru-
sions on the enclosure are lined up with the notched
areas of the dome cover holder. (Do not remove the
case ring.)
The screw, dome cover holder, and light-blocking sheet
will be used again in step 3.
Step3
Replace the dome cover
1 Remove the cover film from the outside of the dome cover (WV-CF5SA). Keep the removed cover
film for future use. (Take care not to damage the outside or inside of the dome cover.)
2 Attach the dome cover (WV-CF5SA) to the enclosure. When attaching, align the 3 notched areas
on the dome cover with the 3 protrusions on the case ring.
3 Attach the light-blocking sheet and dome cover holder removed in step 2 to the dome cover from
the top, and then rotate the dome cover holder clockwise and secure it using the screw from step
2. (The recommended tightening torque: 0.39 N·m {0.29 lbf·ft})
4 Attach the cover film removed in 1 to the surface of the dome cover.
Dome cover holder
Dome cover
Light-blocking sheet
Notched areas on
the dome cover
Case ring
Protrusions on
the case ring Notched areas on the
dome cover, and protru-
sions on the case ring
Protrusions on
the enclosure Screw
Dome cover holder
3
Step4
Attach the enclosure to the camera
Secure the camera to the enclosure with the 2 enclosure fixing screws.
(The recommended tightening torque of the enclosure fixing screws is 0.59 N·m {0.44 lbf·ft})
⇒ Refer to the Installation Guide for more information about installing the camera.
IMPORTANT:
● When the enclosure is attached, the camera's focus may go out of focus. Use the "Auto focus"
function in the setup menu to adjust the focus.
● Remove the cover film after installation is complete.
● If there are fingerprints or dirt on the dome cover, wipe it clean with a soft cloth.
n Attach to WV-SF538/WV-SF539 and other models
Models that can use the WV-CF5S dome cover can also use the WV-CF5SA dome cover.
Read the following descriptions together with operating instructions of the camera.
Step1
Remove the enclosure from camera
1 Remove the enclosure fixing screw (M3, step screw).
2 Rotate the enclosure counterclockwise twice, align the marker with "OPEN", and then remove the
enclosure.
ADJUST
OPEN
LOCK
AF
Marker
Enclosure
1 Remove the
fixing screw.
2
4
Step2
Remove the clear dome cover
1 Remove the inner dome cover and clear dome cover from enclosure's stoppers. The inner dome
cover and clear dome cover can be removed by releasing the stoppers and then pushing the inner
dome cover and clear dome cover into the enclosure.
Stoppers (x3)
Push
2 Remove 1 stopper at a time while pushing down on the inner dome cover.
5
Step3
Attach the dome cover (WV-CF5SA)
1 Align the inner dome cover's 3 stoppers with notched areas of the dome cover.
2 Insert the dome cover and inner dome cover into the enclosure and make sure that they are stuck
in with the stoppers on the enclosure.
3 Rotate the dome cover and check that the dome cover and inner dome cover rotate smoothly
together.
Inner dome
Stopper
Notched area
Dome cover
Enclosure
Inner dome
Stopper
Dome cover
Enclosure
6
Step4
Attach the enclosure to the camera
Attach the enclosure to the main body of the camera.
Refer to the operating instructions of each model for information.
Specifications
Standard Accessories
Ambient operating temperature: –10 °C to +50 °C {14 °F to 122 °F}
Mass: Approx. 25.0 g {0.06 lbs}
Dimensions: Diameter: 92 mm {3-5/8 inches}
Height : 49.3 mm {1-15/16 inches}
Diameter of the dome: 40.1 mm {1-9/16 inches}
Operating Instructions .................................... 1 set
7
For U.S. and Canada:
Panasonic System Communications
Company of North America,
Unit of Panasonic Corporation
of North America
www.panasonic.com/business/
For customer support, call 1.800.528.6747
Two Riverfront Plaza, Newark, NJ 07102-5490
Panasonic Canada Inc.
5770 Ambler Drive, Mississauga,
Ontario, L4W 2T3 Canada
(905)624-5010
www.panasonic.ca
© Panasonic System Networks Co., Ltd. 2014
For Europe and other countries:
Panasonic Corporation
http://panasonic.net
Importer's name and address to follow EU rules:
Panasonic Testing Centre
Panasonic Marketing Europe GmbH
Winsbergring 15, 22525 Hamburg, Germany
PGQX1553ZA Cs0214-0
Printed in China
