INSTALLATION INSTRUCTIONS

Fan Heater

Model No.

Contents

General Safety Inf rmation

Description

Unpacking

Supplied Accessories

Dimensions

Wiring Diagram

Installation

Operating instructions

Maintenance

Practical Guide to Installation

Specifications

Product Service

Important Instructions

2-4

7-11

Back cover

READ AND SAVE THESE INSTRUCTIONS

Thank you for purchasing this Panasonic product.

Please read these instructions carefully before attempting to install,operate or service

the Panasonic product. Failure to comply with instructions could result in personal injury

or property damage. Please explain to users how to operate and maintain the product

after installation, and this booklet should be presented to users.

Please retain this booklet for future reference.

FV-07VFH3

GENERAL SAFETY INFORMATION

For Your Safety

To reduce the risk of injury, loss of life, electric shock, fire,malfunction, and damage to

equipment or pro always observe the following safety precautions.

Explanation of symbol word panels

The following symbol word panels are used to classify and describe the level of hazard,

injury, and property damage caused when the denotation is disregarded and improper

use is performed.

WARNING

Denotes a potential hazard that could result in

serious in jury or death.

CAUTION Denotes a hazard that could result in minor injury.

Denotes a hazard that could result in property

damage.

The following symbols are used to classify and describe the type of instructions to be observed.

Read all instructions before installing or using this fan heater.

This symbol is used to alert users to a specific operating procedure that must

not be performed.

This symbol is used to alert users to a specific operating procedure that must be

followed in order to operate the unit safely.

IMPORTANT INSTRUCTIONS

Make sure that the electric service supply voltage is AC 120V, 60Hz.

Always disconnect the power source before working on or near the fan, motor

or junction box.

This product must be properly grounde .d

Do not operate any heater after it malfunctions. Disconnect power at service

panel and have heater inspected by a reputable electrician before reusing.

Use this heater only as described in this manual. Any other use not recommended

by the manufacturer may cause fire, electric shock, or injury to persons.

Before servicing or cleaning unit, switch power off at service panel and lock panel

cabinet to prevent power from being switched on accidentally. If the panel

cabinet cannot be locked, securely fasten a clearly visible warning label to the

service panel.

Installation work and electrical wiring must be done by qualified person(s) in

accordance with all applicable codes and standards, including fire-rated

construction. Neither unauthorized modification,repair nor disassembly is allowed.

NOTICE

CAUTION

A heater has hot and arcing or sparking parts inside. Do not use it in areas where

gasoline,paint, or flammable vapors or liquids are used or stored.

IMPORTANT INSTRUCTIONS CONTINUED

Use only on 20 ampere branch circuit.

Do not disassemble the unit for reconstruction. It may cause fire or electric shock.

Never place a switch where it can be reached from a tub or shower.

Do not install with a method which is not approved in the instructions.

Do not use out doors.

To prevent a possible fire, do not block air intakes or exhuast in any manner.

A statement to the effect that when the product is to no longer be used, it must

not be left in place but removed, to prevent it from possibly falling.

Do not install this fan heater where air temperature may exceed 40°C(104°F) .

To reduce the risk of fire, electric shock or injury to persons, observe the following:

Use this unit only in the manner intended by the manufacturer. If you have

any questions, please contact the manufacturer.

When cutting or drilling into wall or ceiling, do not damage electrical wiring

and other hidden utilities.

Ducted fans must always be vented to the outdoors.

Celiling joist must be subjected to static load more than five times the weight

of the product.

The special-purpose or dedicated parts, such as mounting fixtures, must be used if

such parts are provided.

Follow all local electrical and safety codes, as well as the National Electrical Code

(NEC) and the Occupation Safety and Health Act (OSHA).

This heater is hot when in use. To avoid burns, do not let bare skin touch hot

surfaces. Keep combustible materials, such as furniture, pillows, bedding, papers,

clothes, etc. and curtains at least 3 feet(0.9m) from the front of the heater and

keep them away from the sides and rear.

Not to be installed in a ceiling thermally insulated to a value greater than R40.

(This is required for installation in Canada only.)

WARNING

Do not insert or allow foreign objects to enter any ventilation or exhaust opening

as this may cause an electric shock or fire, or damage the heater.

Do not install the unit where ducts are configured as shown in Fig. A.

Make sure that all duct work is properly vented.

Before cleaning, make sure the power has been turned off at the circuit breaker

panel and that the heating element of the heater is cool.

Prohibition

Prohibition Prohibition

Fig.A

Prohibition Adaptor

IMPORTANT INSTRUCTIONS CONTINUED

Not for use in cooking area.(Fig.B).

Fig.B

(Cooking area)

Do not install above or

inside this area

Cooking

equipment

Floor

Solid state controls may cause harmonic distortion which can cause motor

humming noise. To reduce the risk of fire or electric shock, do not use this unit

with any solid-state control device.

CAUTION

UNPACKING

Unpack and carefully remove unit from carton.

Refer to the Supplied Accessories list to verify that all parts are present.

The Panasonic Fan Heater is specially developed for bathroom heating. It uses a sirocco

fan driven by a capacitor motor. The motor is designed to have an extended service life

with reduced energy consumption. It also incorporates a thermal cut-off for safety. The

louver covering the main body is screw-fixed type. A dumper driven by a gear motor is

designed to shift the heating and vent functions. A shutter for preventing counter-flow

is provided. The blower uses a high capacity sirocco fan to reduce noise level.

The heater for this unit is a 1300W PTC heater. A thermostat and thermal cut-off switch

have been added for safety in case of an abnormal temperature rise in the heater.

DESCRIPTION

Install

plate L

Install plate

Hanger holder

Installation

Instnuctions

Warranty

card

Adapter

Screw Ⅱ

(ST4.2X10)

Long screw

( X30)ST4.2

Switch

labels

SUPPLIED ACCESSORIES

Part name Part name

Appearance Appearance

Quantity Quantity

Louver 1

Suspension

bracket Ⅰ

Suspension

bracketⅡ

Screw Ⅰ

(M4x8)

DIMENSIONS

Unit:inches(mm) Aperture dimensions: 10 x10 inches(270x270mm)

No. No.

Part name Part name

Louver

Adaptor

Unit body

Heater assembly

Air outlet grille

Screw cap

Airproof shutter

Hanger unit

Inspection cover

Cord cover

(20) 5 (147)

4 (107)

( 98)

11 (295)

54"

12 (320)

10 (260)

13 (346)

10 (260)

11 (295)

6 (160)

WIRING DIAGRAM

INSTALLATIONⅠ(BETWEEN JOIST MOUNTING)

Top view of the recommended installation.

1.Make a hole of 10 10 inch(270

270mm in the ceiling between j ist.(Fig.1)

X X

2.Assemble the hanger unit

Insert the suspension

and put the adaptor

(Fig.2)

brackets into hanger

holder into the hanger

holder.

The bathroom size may affect the

room heating result of this product.

10 (270)

Fig.2

Fig.1

Suspension brackets

Hanger

holder

Adaptor

Unit:inches(mm)

Wall

Air duct

Product

Bathroom

Bathtub

63(1600)

31 (800)

(450)

Unit:inches(mm)

53"

INSTALLATIONⅠ(BETWEEN JOIST MOUNTING)

16 inches and

19.2 inches

horizontal joist

19.2 inches

vertical joist

19.2 inches vertical joists

19.2 inches horizontal joists

16 inches

Spacing A on center joists

Unit:inches (mm)

13 1/4 15 1/2(336 394)

~ ~

14 3/4 16 3/4(374 425)

~ ~

16 1/2 18 3/4(419 476)

~ ~

3.Fix the hanger unit to the ceiling.

(1) Using 1 of the ST4.2X30 tapping screws

provided accessory package to fix

the hanger unit to the ceiling.

in the

(Fig.3)

(2) Using 4 of the ST4.2X30 tapping screw

provided accessory package to fix

the suspension brackets to the joist .

in the

(Fig.4)

Fig.3

Fig.4

Joist

Circular duct

Duct tape

① Take out the cord cover and stress relief

two knockout holes.(Fig.5)

Cord cover

Knock-out hole

INSTALLATION JOIST MOUNTING-Ⅰ) CONTINUEDⅠ(BETWEEN

5. The connection of power wire and control

lead wire.

4. Slip the circular duct onto the adaptor and

secure it with duct tape.(Fig.4)

Control lead wires(4 wires)

Conduit

Power wires

(3 wires)

Fig.6

WARNING:

1.Wiring procedures and connections shall

be in accordance with the national and

local electrical codes having jurisdiction.

2.This product must be properly grounded.

Fig.5

② Secure conduits, pass house power wires

and control lead wires througth the holes.

(Fig.6)

Red to

wall switch

Blue to

wall switch

Brown to

wall switch

Green to earth

ground

Wire nut

White to neutral

Black to live

INSTALLATION JOIST MOUNTING-Ⅰ) CONTINUEDⅠ(BETWEEN

③ Refer to wiring diagram (Page.6) or Fig.9,

follow all the local electrical safety codes.

As well as the National Electrical code

(NEC),Using UL approved wire nuts,

connect house power wires and control

lead wires to product wires.(Fig.7)

Make sure all connections are fastened

firmly after wiring is finished.

For future inspection by qualified persons,

put the lead wires into the hook after

connection work.

④

(Fig.8)

Fig.7

Fig.8

Wire nut

Control

lead wines

Power

wires

Hook

HEAT/VENT

Fig.9

From red wire

From blue wire

From brown wire (wall switch)

Green wire

White

ON/OFF

Black

Green

⑤ Fix the cord cover with the screws that

taken off at step1.

1. Disconnect power source before working

on unit.

2. When making wiring connections take

care to prevent excessive slack in the

wiring since a layge of current is drawn

through the heater electrical wire.

3. To reduce the risk of fire, do not store or

use gasoline or other flammable vapors

and liquids in the vicinity of the heater

WARNING

1.High temperature, risk of fire, keep electrical

cords, drapery,furnishings, and other

combustibles at least 3 feet (0.9 m) from the

front of the heater and away from the side

and rear.

2.Mount the cord cover carefully so that lead

wires are not pinched.

CAUTION

6. Main body fixed.

Push the main body upward into the ceiling,

use 4 of the ST4.2X30self-tapping screws

provided in the accessory package to fix it.

(Fig.10)

7.Install plate fixed.

Insert the install plates into the main body

jockey for position(one of each side), use the

ST4.2X10 self-tapping screws provided in the

accessory package to fix them. (Fig.11)

Fig.10

Fig.11

9.Install plates locked.

Using 2 of the ST4.2X30 self-tapping screws

provided in the accessory package to lock the

install plates (Fig.13),make sure the screws are

go through the hole of install plates,and the

drywall is clampped tightly.(Fig.14)

8.Use one of the ST4.2X30 self-tapping srews

in the accesso y package to fix the

and the hanger unit.(Fig.12)

provided r

product frame

Fig.12

Fig.13

INSTALLATION JOIST MOUNTING-Ⅰ) CONTINUEDⅠ(BETWEEN

Drywall

Fig.14

③ Insert a straight screw driver into the gap

of the screw cap (2 positions), and unclench

the screw cover outward.(Fig.17)

9.Louver fixed

① Pull out the filter mesh from the louver

assembly.(Fig.15)

② Hang the louver into the hook on the main

body.(Fig.16)

Main body hook

Fig.15

Fig.16

Fig.17

④ Fix the louver assembly with the 3 of the

M4X8 mechanical screws in the accessory.

(Fig.18)

INSTALLATION JOIST MOUNTING-Ⅰ) CONTINUEDⅠ(BETWEEN

⑤ Install the filter mesh again and attach the

unclenched screw caps again.(Fig.19)

10.Paste the switch label provided in the

accessory package on the switch panel.

(Fig.20)

[Optional]

Attach the given switch labels (in accessories)

on the wall switch (not included) as shown in

the diagram for clearer indication.(Fig.20)

Switch

labels

Heat

Off

Vent

Fig.20

Screw caps(2 pcs) Fig.18

Fig.19

INSTALLATION Ⅱ(JOIST MOUNTING)

1. Make a hole of 10 X 10 inches (270 X

270mm) adjacent to a joist.(Fig.21)

2. Assemble the hanger unit.

Put the adaptor into the hanger holder.

(Fig.22)

3. Fix the hanger unit to the ceiling.

(1) Using 1 of the ST4.2X30 tapping screws

provided accessory package to fix

the hanger unit to the ceiling.

(2)

in the

(Fig.23)

Using 2 of the ST4.2X30 tapping screws

provided in the accessory package to fix

the hanger unit to the joist.(Fig.24)

4.Slip the circular duct onto the adaptor and

secure it with duct tape.(Fig.24

Joist

Duct

tape

Circular

duct

Adaptor

Hanger

holder

Fig.21

Fig.22

Fig.23

Fig.24

10 (270)

Otros manuales para FV-07VFH3

Tabla de contenidos

Otros manuales de Calentador de Panasonic

Panasonic

Panasonic FY-3009U1 Manual de usuario

Panasonic

Panasonic PHK-12 Manual de usuario

Panasonic

Panasonic Basic Series Manual de usuario

Panasonic

Panasonic FV-11VH2 Manual de usuario

Panasonic

Panasonic FV-0511VH1 Manual de usuario

Panasonic

Panasonic FV-0511VHL1 Manual de usuario

Panasonic

Panasonic FV-0511VH1 Manual de usuario

Panasonic

Panasonic FV-07VFH3 Manual de usuario

Panasonic

Panasonic CU-8ME1XPK Manual de usuario

Panasonic

Panasonic FY-08ESN Manual de usuario

Panasonic

Panasonic FY-2509U1 Manual de usuario

Panasonic

Panasonic FY-08ESN Manual de usuario

Panasonic

Panasonic KX-TEA308CE Manual de usuario

Manuales populares de Calentador de otras marcas

oventrop

oventrop Regucor Series Manual de usuario

Blaze King

Blaze King CLARITY CL2118.IPI.1 Manual de usuario

ELMEKO

ELMEKO ML 150 Manual de usuario

BN Thermic

BN Thermic 830T Manual de usuario

KING

KING K Series Guía

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Guía de inicio rápido

Well Straler

Well Straler RC-16B Manual de usuario

EUROM

EUROM 333299 Manual de usuario

Heylo

Heylo K 170 Manual de usuario

Eterna

Eterna TR70W Manual de usuario

Clarke

Clarke GRH15 Manual de instrucciones

IRSAP

IRSAP The Radiator Company Ovali Manual de usuario

Empire Heating Systems

Empire Heating Systems WCC65 Manual de usuario

Wetekom

Wetekom 92 86 43 Manual de usuario

Desa

Desa SPC170-F Manual de usuario

Watlow

Watlow Watrod Electric Tubular Heaters Manual de usuario

Haverland

Haverland ECO-DRY GPS Series Manual de lista de piezas

Stelpro

Stelpro ASILVC2060 Series Manual de usuario
