Operating Instructions

(Household) Sonic Vibration Toothbrush

Model No. EW‑DE92

EW-DE92_EU.indb 1 2013/10/10 18:23:24

English 3

Deutsch 21

Français 41

Italiano 61

Nederlands 81

Español 101

Dansk 121

Português 141

Norsk 161

Svenska 179

Suomi 197

Polski 217

Česky 237

Slovensky 257

Magyar 277

Română 295

Türkçe 315

EW-DE92_EU.indb 2 2013/10/10 18:23:24

English

Operating Instructions

(Household) Sonic Vibration Toothbrush

Model No. EW‑DE92

Thank you for purchasing this Panasonic product.

Before operating this unit, please read these instructions completely and save them for future use.

Safety precautions.....................5

Parts identication ..............................8

Storing and charging the toothbrush

...9

Before cleaning your teeth ...............10

Using the toothbrush ........................12

Tips on usage ....................................13

How to clean ......................................15

Frequently Asked Questions (Ion lamp)

...16

Troubleshooting ................................17

Battery life ..........................................19

Removing the built-in rechargeable

battery.................................................19

Specications ....................................19

Changing the brush head

(Sold separately)................................19

Contents

EW-DE92_EU.indb 3 2013/10/10 18:23:24

English

Warning

•Be sure to switch off the appliance and remove the plug

from a household outlet before performing any

maintenance. Failure to do so may result in electric shock.

•Do not wash the charger. Doing so may result in

electric shock.

•If the power cord of the charger is damaged, the entire

charger should be discarded.

•Toothbrushes can be used by children and persons with

reduced physical, sensory or mental capabilities or lack of

experience and knowledge if they have been given

supervision or instruction concerning use of the appliance

in a safe way and understand the hazards involved.

•Cleaning and user maintenance shall not be made by

children without supervision.

•Children shall not play with the appliance.

EW-DE92_EU.indb 4 2013/10/10 18:23:24

English

Safety precautions

To reduce the risk of injury, loss of life, electric shock, ﬁre,

malfunction, and damage to equipment or property, always

observe the following safety precautions.

Explanation of symbols

The following symbols are used to classify and describe the level

of hazard, injury, and property damage caused when the

denotation is disregarded and improper use is performed.

DANGER Denotes a potential

hazard that will result in

serious injury or death.

WARNING Denotes a potential

hazard that could result

in serious injury or death.

CAUTION

Denotes a hazard that

could result in minor injury.

The following symbols are used to classify and describe the type

of instructions to be observed.

This symbol is used to alert users to a speciﬁc operating

procedure that must not be performed.

This symbol is used to alert users to a speciﬁc operating

procedure that must be followed in order to operate the

unit safely.

DANGER

Never use this product near electronic medical

devices or home electrical therapy devices such as

the following:

•Pacemakers and other electronic medical devices

implanted in the body

•Heart-lung machines and other life-supporting

electronic medical devices

•Wearable electronic medical devices, such as

electrocardiographs and intravenous drip equipment

-Doing so may cause incorrect operation of electronic

medical devices and home electrical therapy devices,

resulting in accidents or causing patients to feel unwell.

This product has a built-in rechargeable battery.

Do not throw into ﬁre, apply heat, or charge, use, or

leave in a high temperature environment.

-Doing so may cause overheating, ignition, or explosion.

WARNING

Immediately stop using and remove the power plug

if there is an abnormality or failure.

-Failure to do so may cause ﬁre, electric shock, or injury.

•The main unit or charger is deformed or

abnormally hot.

•The main unit or charger smells of burning.

•There is abnormal sound during use or charging of

the main unit or charger.

-Immediately request inspection or repair at an authorized

service center.

EW-DE92_EU.indb 5 2013/10/10 18:23:24

English

WARNING

Always ensure the appliance is operated on an

electric power source matched to the rated voltage

indicated on the charger.

Fully insert the power plug.

-Failure to do so may cause ﬁre or electric shock.

Regularly clean the power plug to prevent dust from

accumulating.

-Failure to do so may cause ﬁre due to insulation failure

caused by humidity.

Disconnect the power plug and wipe with a dry cloth.

The following people should consult with a

physician before using this product.

•People with heart disease

•People who have had severe illnesses in the past

•People suffering from acute diseases

•People with febrile conditions

•People with abnormal blood pressure

•People with infectious diseases

•People with malignant tumors

•People with hemophilia

•People with allergic tendencies or who have

experienced irritation from metals or other items

-Failure to do so may result in accidents or cause them to

feel unwell.

Do not connect or disconnect the power plug to a

household outlet with a wet hand.

-Doing so may cause electric shock or injury.

Do not place the charger over or near water ﬁlled

sink or bathtub.

-

Doing so may cause electric shock or ﬁre due to a short circuit.

Never disassemble except when disposing of the

product.

-Doing so may cause ﬁre, electric shock, or injury.

Do not store within the reach of children or infants.

Do not let them use it.

-Doing so may cause an accident or injury due to

accidental ingestion of removable parts.

Do not use this product if you are pregnant or are

within one month of having given birth.

Do not use if you feel unwell or have a fever.

-

Doing so may result in accidents or cause them to feel unwell.

Do not use when the cord or the power plug is

damaged or when the ﬁtting into the household

outlet is loose.

Do not damage, modify, forcefully bend, pull, twist,

or bundle the cord.

Also, do not place anything heavy on or pinch the

cord.

-Doing so may cause electric shock or ﬁre due to a short

circuit.

Do not use anything other than the supplied

charger. Also, do not charge any other product with

the supplied charger.

-Doing so may cause burn or ﬁre due to a short circuit.

Do not use in a way exceeding the rating of the

household outlet or the wiring.

-Exceeding the rating by connecting too many power plugs

to one household outlet may cause ﬁre due to overheating.

Do not modify or repair.

-Doing so may cause ﬁre, electric shock, or injury.

Contact an authorized service center for repair (battery

change, etc.).

EW-DE92_EU.indb 6 2013/10/10 18:23:24

English

CAUTION

Disconnect the power plug from the household

outlet when not using for extended period of time.

-Failure to do so may cause electric shock or ﬁre due to

electrical leakage resulting from insulation deterioration.

Disconnect the power plug by holding onto it

instead of the cord.

-Failure to do so may cause electric shock or ﬁre due to a

short circuit.

People who have severe gum disease, have teeth

being treated, or are concerned about symptoms

within their mouth should consult a dentist before use.

-Failure to do so may cause injury or damage to teeth and

gums.

Do not use the brush with toothpaste that contains

a high abrasive content, such as toothpaste for

removing tar or for whitening.

Do not let anyone that cannot operate the brush

themselves use it.

People with a low sensitivity within their mouth

should not use the brush.

Do not apply the brush head strongly against teeth

or gums, or use it continuously against same spot.

Do not apply the plastic part of the main unit or

brush head to teeth.

-Doing so may cause injury or damage to teeth and gums.

Never use for a purpose other than cleaning your

teeth.

-Doing so may cause an accident or injury.

Do not use if doing so causes you to feel unwell.

-

Doing so may result in accidents or cause them to feel unwell.

Do not share the brush head with your family or

other people.

-Doing so may result in infection or inﬂammation.

Do not drop or subject to shock.

-Doing so may cause injury.

Do not wrap the cord tightly around the charger

when storing.

-Doing so may cause the wire in the cord to break with the

load, and may cause ﬁre due to a short circuit.

Do not place a metallic object such as a coin or a

clip on top of the charger.

-Doing so may cause burns due to excessive heat.

►Notes

When you ﬁrst begin using the toothbrush, you may experience slight

bleeding of the gums even though your gums may be healthy. This is

because your gums are receiving stimulation by the toothbrush for

the ﬁrst time. The bleeding should stop after one or two weeks of use.

Bleeding that persists for more than two weeks may be indication of

an abnormal condition of your gums, such as pyorrhea. In this case,

stop using the toothbrush and consult your dentist.

EW-DE92_EU.indb 7 2013/10/10 18:23:24

English

Parts identiﬁcation

   

 









































A Main unit

1 Ion panel

2 Toothbrush shaft

3 Waterproof rubber seal

4 Ion lamp

5 Power switch [0/1]

6 Mode selector

7 Mode indicator

8 Charge status lamp ( )

9 Battery capacity lamp ( )

B Ionic stain care brush

 Tongue cleaner

 Identiﬁcation ring

 Extra ﬁne side bristles

 High‑density bristles

 Brush head electrode section

C Ionic two-way silicone brush

D Point brush

E Charger (RE8-52)

(The shape of the power plug differs

depending on the area.)

 Cord

 Power plug

 Charger base

 Charging section

 Main unit guide

 Brush head storage

Accessories

F Brush stand

G Carrying case

Characteristics of brush bristles ()

The bristles in the center (high‑density bristles) are arranged in a diamond shape, which is designed for stain care.

EW-DE92_EU.indb 8 2013/10/10 18:23:24

English

Storing and charging the toothbrush

•If the toothbrush stops operating when ﬁrst using it (immediately

after purchasing it, or after not using it for 3 months or more) or

during use, charge the main unit.

•Adequate ambient temperature for charging is 5 °C – 35 °C.

The battery may not charge properly or not at all under extreme

low or high temperatures.

•You can keep the main unit attached on the charger when not in

use to maintain the full battery capacity. It will not overcharge the

main unit.

•The main unit may become warm during use and charging.

However, this is normal.

1Place the charger on a stable

horizontal surface such as

countertop.

Align the main unit so it is

facing forward, and set it

straight into the charging

section.

3Insert the power plug into the

household outlet.

•The charge status lamp glows and

the charging will start.

•Charging cannot start when the main

unit is tilted or the bottom of the main

unit is not in contact with the charging

section.

If not charging constantly

•You can fully charge the toothbrush in approx. 17 hours.

The charging time may decrease depending on the charging

capacity.

•A full charge will supply enough power for approx. 90 minutes

use.

•

Disconnect the power plug when the charge status lamp turns off.

►About storage

The toothbrush can only be stored in a compact size with the main

unit guide.

Slide and remove the main unit guide, and

place it on horizontal and stable place.

2. Store the main unit and the brush head.

EW-DE92_EU.indb 9 2013/10/10 18:23:25

English

About the lamp

When the battery

capacity is low While charging After charging is

completed

The battery

capacity lamp

blinks.

The charge status

lamp glows.

The charge status

lamp turns off

•The toothbrush may not charge even if the charge status lamp

turns on when a charger other than the supplied charger is used.

Before cleaning your teeth

The brush head of this sonic vibration toothbrush vibrates at a

high speed.

Therefore:

•You only need to lightly press the bristles against your teeth for

brushing.

•When ﬁrst using this appliance, some may experience a tickling

or tingling sensation caused by the high‑speed vibrations. The

sensation should subside after you use the toothbrush several

more times.

•When in use, the main unit of this toothbrush emits a very weak

electric current (ionic current) in the oral cavity.

•Touching the ion panel with your hand when you hold the main

unit to brush your teeth causes a very weak electric current (ionic

current) to ﬂow between your teeth and the brush head.









a Brush head (negative

electrode)

b Ion panel (positive

electrode)

c Very weak electric current

d Mechanism that generates

very weak electric current

•The ion lamp on the mechanism that generates the very weak

electric current (see ﬁgure above) turns on or blinks to indicate

whether ionic power is being applied to the teeth.

EW-DE92_EU.indb 10 2013/10/10 18:23:25

Otros manuales para EW?DE92

Tabla de contenidos

Idiomas:

Otros manuales de Cepillo de dientes eléctrico de Panasonic

Panasonic

Panasonic EW1000W Operating Manual de usuario

Panasonic

Panasonic EW-DC12 Manual de usuario

Panasonic

Panasonic EW-DS32 Manual de usuario

Panasonic

Panasonic ER-CTB1 Manual de usuario

Panasonic

Panasonic ER-CTB1 Manual de usuario

Panasonic

Panasonic EW-DS32 Manual de usuario

Panasonic

Panasonic EW-DL75 Manual de usuario

Panasonic

Panasonic ER-CTB1 Manual de usuario

Panasonic

Panasonic EW?DE92 Manual de usuario

Panasonic

Panasonic EW DL84 Manual de usuario

Panasonic

Panasonic EW-DP52 Manual de usuario

Panasonic

Panasonic EW?DL82 Manual de usuario

Panasonic

Panasonic EW-DL40 Manual de usuario

Panasonic

Panasonic EW?DE92 Manual de usuario

Panasonic

Panasonic EW-DL83 Manual de usuario

Panasonic

Panasonic EW-DS11 Manual de usuario

Panasonic

Panasonic EW-DL83 Manual de usuario

Panasonic

Panasonic EW-DS13 Manual de usuario

Panasonic

Panasonic EW-DS90 Manual de usuario

Panasonic

Panasonic EW-PDA52 Manual de usuario

Panasonic

Panasonic EW-DS90-K Manual de usuario

Panasonic

Panasonic EW-DS11 Manual de usuario

Panasonic

Panasonic ER-CTB1 Manual de usuario

Panasonic

Panasonic EW-DC12 Manual de usuario

Manuales populares de Cepillo de dientes eléctrico de otras marcas

Omron

Omron Colgate ProClinical C600 Manual de usuario

Philips

Philips sonicare 3000 Series Manual de usuario

Philips

Philips Sonicare Airfloss HX8181 Manual de usuario

Dentle

Dentle One Plus Manual de usuario

Philips

Philips Sonicare HX6211/04 Manual de usuario

SPORT ELEC

SPORT ELEC Smilyss HC5305C Manual de usuario

Philips

Philips Sonicare 1000 Series Manual de usuario

Philips

Philips ESSENCE + Manual de usuario

Kompernass

Kompernass dentalux DAZ 2.4 A1 Manual de usuario

ONE

ONE PERSONAL OSEB001-W Manual de usuario

Philips

Philips Sonicare FlexCare+ HX6972 Manual de usuario

Jula

Jula 804-193 Manual de usuario

Braun

Braun OC17525 Manual de usuario

Philips

Philips HX6932/34 Manual de usuario

Waterpik

Waterpik Sensonic Professional Plus SR-3000 Manual de usuario

TrueLife

TrueLife SonicBrush T100 Manual de usuario

Braun

Braun Oral-B 450 Manual de usuario

Braun

Braun Oral-B Professional Care 7000 Manual de usuario
