Basic Operating Instructions

Digital Camera

Model No. DMC-ZR3/DMC-ZX3

Before use, please read these instructions completely.

Please also refer to Operating

Instructions (PDF format)

recorded on the CD-ROM

containing the Operating Instructions

(supplied).

You can learn about advanced operation methods

and check the Troubleshooting.

DMC-ZX3&ZR3GC-VQT2M07_eng.book 1 ページ２０１０年１月２７日　水曜日　午後６時４１分

VQT2M07 (ENG)

Dear Customer,

We would like to take this opportunity to thank you for purchasing this

Panasonic Digital Camera. Please read these Operating Instructions

carefully and keep them handy for future reference. Please note that the

actual controls and components, menu items, etc. of your Digital Camera

may look somewhat different from those shown in the illustrations in these

Operating Instructions.

Carefully observe copyright laws.

•Recording of pre-recorded tapes or discs or other published or broadcast

material for purposes other than your own private use may infringe copyright

laws. Even for the purpose of private use, recording of certain material may be

restricted.

Information for Your Safety

WARNING:

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PRODUCT

DAMAGE,

•DO NOT EXPOSE THIS APPARATUS TO RAIN, MOISTURE, DRIPPING

OR SPLASHING AND THAT NO OBJECTS FILLED WITH LIQUIDS, SUCH

AS VASES, SHALL BE PLACED ON THE APPARATUS.

•USE ONLY THE RECOMMENDED ACCESSORIES.

•DO NOT REMOVE THE COVER (OR BACK); THERE ARE NO USER

SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

THE SOCKET OUTLET SHALL BE INSTALLED NEAR THE

EQUIPMENT AND SHALL BE EASILY ACCESSIBLE.

Product Identification Marking is located on the bottom of units.

DMC-ZX3&ZR3GC-VQT2M07_eng.book 2 ページ２０１０年１月２１日　木曜日　午後３時３９分

(ENG) VQT2M07

∫About the battery pack

•Do not heat or expose to flame.

•Do not leave the battery(ies) in an automobile exposed to direct sunlight for a

long period of time with doors and windows closed.

∫About the battery charger

•The battery charger is in the standby condition when the AC power supply cord

is connected. The primary circuit is always “live” as long as the power cord is

connected to an electrical outlet.

CAUTION

Danger of explosion if battery is incorrectly replaced. Replace only with

the same or equivalent type recommended by the manufacturer. Dispose

of used batteries according to the manufacturer’s instructions.

Warning

Risk of fire, explosion and burns. Do not disassemble, heat above 60 xC

or incinerate.

CAUTION!

•DO NOT INSTALL OR PLACE THIS UNIT IN A BOOKCASE, BUILT-IN

CABINET OR IN ANOTHER CONFINED SPACE. ENSURE THE UNIT IS

WELL VENTILATED. TO PREVENT RISK OF ELECTRIC SHOCK OR FIRE

HAZARD DUE TO OVERHEATING, ENSURE THAT CURTAINS AND ANY

OTHER MATERIALS DO NOT OBSTRUCT THE VENTILATION VENTS.

•DO NOT OBSTRUCT THE UNIT’S VENTILATION OPENINGS WITH

NEWSPAPERS, TABLECLOTHS, CURTAINS, AND SIMILAR ITEMS.

•DO NOT PLACE SOURCES OF NAKED FLAMES, SUCH AS LIGHTED

CANDLES, ON THE UNIT.

•DISPOSE OF BATTERIES IN AN ENVIRONMENTALLY FRIENDLY

MANNER.

DMC-ZX3&ZR3GC-VQT2M07_eng.book 3 ページ２０１０年１月２１日　木曜日　午後３時３９分

VQT2M07 (ENG)

∫Cautions for Use

•Always use a genuine Panasonic AC adaptor (DMW-AC5G; optional).

•When using an AC adaptor, use the AC cable supplied with the AC adaptor.

•Do not use any other AV cables except the supplied one.

•Do not use any other cables except a genuine Panasonic HDMI mini cable

(RP-CDHM15, RP-CDHM30; optional).

Part numbers: RP-CDHM15 (1.5 m), RP-CDHM30 (3.0 m)

•Do not use any other USB connection cables except the supplied one.

Keep the camera as far away as possible from electromagnetic

equipment (such as microwave ovens, TVs, video games etc.).

•If you use the camera on top of or near a TV, the pictures and sound on the

camera may be disrupted by electromagnetic wave radiation.

•Do not use the camera near cell phones because doing so may result in noise

adversely affecting the pictures and sound.

•Recorded data may be damaged, or pictures may be distorted, by strong

magnetic fields created by speakers or large motors.

•Electromagnetic wave radiation generated by microprocessors may adversely

affect the camera, disturbing the pictures and sound.

•If the camera is adversely affected by electromagnetic equipment and stops

functioning properly, turn the camera off and remove the battery or disconnect

AC adaptor (DMW-AC5G; optional). Then reinsert the battery or reconnect AC

adaptor and turn the camera on.

Do not use the camera near radio transmitters or high-voltage lines.

•If you record near radio transmitters or high-voltage lines, the recorded pictures

and sound may be adversely affected.

∫How to replace the Fuse

The location of the fuse differ according to the type of AC cable (figures A

and B).

Confirm the AC cable fitted and follow the instructions below.

Illustrations may differ from actual AC cable.

1 Open the fuse cover

with a screwdriver.

2 Replace the fuse and

close or attach the fuse

cover.

Fuse cover

Figure A Figure B

Fuse

(5 ampere)

Fuse

(5 ampere)

DMC-ZX3&ZR3GC-VQT2M07_eng.book 4 ページ２０１０年１月２２日　金曜日　午後７時２５分

(ENG) VQT2M07

-If you see this symbol-

Information on Disposal in other Countries outside

the European Union

This symbol is only valid in the European Union.

If you wish to discard this product, please contact your

local authorities or dealer and ask for the correct

method of disposal.

DMC-ZX3&ZR3GC-VQT2M07_eng.book 5 ページ２０１０年１月２１日　木曜日　午後３時３９分

VQT2M07 (ENG)

Contents

Information for Your Safety ........................................................................... 2

Standard Accessories ................................................................................... 7

Names of the Components ........................................................................... 8

Charging the Battery ................................................................................... 10

About the Built-in Memory/the Card ............................................................ 12

Inserting and Removing the Card (optional)/the Battery ............................. 13

Setting Date/Time (Clock Set)..................................................................... 14

• Changing the clock setting.................................................................... 14

Setting the Menu......................................................................................... 15

Selecting the [REC] Mode........................................................................... 16

Taking pictures using the automatic function

(ñ: Intelligent Auto Mode) ......................................................................... 17

• Scene detection .................................................................................... 18

• AF Tracking Function............................................................................ 18

Recording Motion Picture............................................................................ 19

Playing back Pictures ([NORMAL PLAY])................................................... 20

Deleting Pictures ......................................................................................... 20

Reading the Operating Instructions

(PDF format) ............................................................................................... 21

Specifications.............................................................................................. 23

DMC-ZX3&ZR3GC-VQT2M07_eng.book 6 ページ２０１０年１月２１日　木曜日　午後５時２４分

(ENG) VQT2M07

Standard Accessories

Check that all the accessories are included before using the camera.

Product numbers correct as of January 2010. These may be subject to change.

1 Battery Pack

(Indicated as battery pack or

battery in the text)

Charge the battery before use.

2 Battery Charger

(Indicated as battery charger or

charger in the text)

3ACCable

4 USB Connection Cable

5AVCable

6 CD-ROM

•Software:

Use it to install the software to your

PC.

•Operating Instructions

7 Hand Strap

8 Battery Case

•SD Memory Card, SDHC Memory Card

and SDXC Memory Card are indicated

as card in the text.

•The card is optional.

You can record or play back pictures

on the built-in memory when you are

not using a card.

•Consult the dealer or your nearest

Service Centre if you lose the supplied

accessories. (You can purchase the

accessories separately.)

A:Hong Kong Special Administrative

Region of China and Saudi Arabia

B:Areas Other than Hong Kong

Special Administrative Region of

China and Saudi Arabia

DE-A66B

(DMC-ZR3GC/

DMC-ZR3GH)

DE-A66E

(DMC-ZX3SG)

VFF0585

(DMC-ZR3GC/

DMC-ZR3GH)

VFF0584

(DMC-ZX3SG)

VFC4297

: K2CT39A00002

(DMC-ZR3GC/

DMC-ZR3GH)

: K2CQ29A00002

(DMC-ZR3GC)

DMW-BCG10E

K2CA29A00023

(DMC-ZX3SG)

VGQ0E45

K1HA08AD0002 K1HA08CD0028

DMC-ZX3&ZR3GC-VQT2M07_eng.book 7 ページ２０１０年２月１日　月曜日　午後２時５１分

VQT2M07 (ENG)

Names of the Components

1Flash

2Lens

3 Self-timer indicator

AF assist lamp

4 LCD monitor

5 [MENU/SET] button

6 [DISPLAY] button

7 [Q.MENU]/Delete button

8 [REC]/[PLAYBACK] selector switch

9 Motion picture button

10 Cursor buttons

A:3/Exposure compensation/Auto

Bracket/White Balance fine adjustment

B:4/Macro Mode

AF Tracking

C:2/Self-timer button

D:1/Flash setting button

In these operating instructions, the cursor buttons are described as shown

in the figure below or described with 3/4/2/1.

e.g.: When you press the 4(down) button

or Press 4

123

675

DMC-ZX3&ZR3GC-VQT2M07_eng.book 8 ページ２０１０年１月２１日　木曜日　午後３時３９分

(ENG) VQT2M07

11 Camera ON/OFF switch

12 Zoom lever

13 Speaker

14 Microphone

15 Shutter button

16 Mode dial

17 Hand strap eyelet

•Be sure to attach the hand strap

when using the camera to ensure

that you will not drop it.

18 Lens barrel

19 [HDMI] socket

20 [AV OUT/DIGITAL] socket

21 Tripod receptacle

•When you use a tripod, make sure the

tripod is stable when the camera is

attached to it.

22 Card/Battery door

23 Release lever

24 DC coupler cover

•When using an AC adaptor, ensure that

the Panasonic DC coupler (DMW-DCC5;

optional) and AC adaptor (DMW-AC5G;

optional) are used.

•We recommend you use a battery with

sufficient battery power or the AC adaptor

when recording motion pictures.

•If while recording motion pictures using the

AC adaptor and the power supply is cut off

due to a power outage or if the AC adaptor

is disconnected etc., the motion picture

being recorded will not be recorded.

13 14 15

11 12





21 22

2324

DMC-ZX3&ZR3GC-VQT2M07_eng.book 9 ページ２０１０年１月２１日　木曜日　午後６時５３分

VQT2M07 (ENG)

Charging the Battery

∫About batteries that you can use with this unit

The battery that can be used with this unit is DMW-BCG10E.

•Use the dedicated charger and battery.

•The camera has a function for distinguishing batteries which can be used

safely. The dedicated battery (DMW-BCG10E) supports this function. The

only batteries suitable for use with this unit are genuine Panasonic

products and batteries manufactured by other companies and certified by

Panasonic. (Batteries which do not support this function cannot be used).

Panasonic cannot in any way guarantee the quality, performance or safety

of batteries which have been manufactured by other companies and are

not genuine Panasonic products.

∫Charging

•The battery is not charged when the camera is shipped. Charge the battery

before use.

•Charge the battery with the charger indoors.

•Charge the battery in a temperature between 10 oC to 35 oC. (The battery

temperature should also be the same.)

It has been found that counterfeit battery packs which look very similar

to the genuine product are made available to purchase in some markets.

Some of these battery packs are not adequately protected with internal

protection to meet the requirements of appropriate safety standards.

There is a possibility that these battery packs may lead to fire or

explosion. Please be advised that we are not liable for any accident or

failure occurring as a result of use of a counterfeit battery pack. To

ensure that safe products are used we would recommend that a genuine

Panasonic battery pack is used.

Attach the battery paying

attention to the direction of the

battery.

DMC-ZX3&ZR3GC-VQT2M07_eng.book 10 ページ２０１０年１月２１日　木曜日　午後６時５３分

Otros manuales para Lumix DMC-ZR3

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cámara digital de Panasonic

Panasonic

Panasonic DMC-FZ200K Instrucciones de instalación y servicio

Panasonic

Panasonic Lumix DMC-FZ330 Especificaciones técnicas

Panasonic

Panasonic LUMIX DMC-FS4 Manual de instrucciones

Panasonic

Panasonic Lumix DMC-LZ20 Instrucciones de instalación y servicio

Panasonic

Panasonic DMC-FT5EB Manual de usuario

Panasonic

Panasonic Lumix DMC-TZ5; Lumix DMC-TZ4 Instrucciones de montaje

Panasonic

Panasonic LUMIX DMC-FX66 Manual de usuario

Panasonic

Panasonic DMC-G85M Manual de usuario

Panasonic

Panasonic LUMIX DMC-GM1K Instrucciones de instalación y servicio

Panasonic

Panasonic Lumix DMC-G3 Instrucciones de instalación y servicio

Panasonic

Panasonic Lumix DMC-FX37P Manual de usuario

Panasonic

Panasonic DMCFZ8K - Lumix Digital Camera Manual de instrucciones

Panasonic

Panasonic Lumix DMC-ZS35 Manual de usuario

Panasonic

Panasonic Lumix DC-GF10 Manual del propietario

Panasonic

Panasonic Lumix DMC-TZ40 Especificaciones técnicas

Panasonic

Panasonic Lumix DMC-F2 Manual de usuario

Panasonic

Panasonic BL-MS103A Manual de usuario

Panasonic

Panasonic lumix dmctz55 Especificaciones técnicas

Panasonic

Panasonic DMCFZ30PP - DIGITAL STILL CAMERA Manual de usuario

Panasonic

Panasonic Lumix DMC-TS5 Manual de instrucciones

Panasonic

Panasonic Lumix DMC-FX33P Manual de usuario

Panasonic

Panasonic SDR-SW20PL Manual de usuario

Panasonic

Panasonic Lumix DMC-G5 Instrucciones de instalación y servicio

Panasonic

Panasonic Lumix DMC-FX77 Especificaciones técnicas

Manuales populares de Cámara digital de otras marcas

Mercury

Mercury 350K Manual de usuario

Pentax

Pentax Optio LS 465 Manual de usuario

Sanyo

Sanyo VPC-S1085 Manual de usuario

GE SMART A1255 Manual de usuario

Point Grey

Point Grey Gazelle Manual de usuario

Nikon

Nikon COOLPIX A Manual de usuario

Pentax

Pentax P-5 Manual de usuario

BlazeVideo

BlazeVideo A280 Manual de usuario

Sony

Sony MCA-20 Manual de usuario

Sony

Sony Alpha DSLR-A290 Manual de usuario

ATIK Cameras

ATIK Cameras One Manual de usuario

CohuHD Costar

CohuHD Costar 3930 Series Manual de usuario

Leica

Leica M10-R Manual de usuario

FujiFilm

FujiFilm FinePix A700 Manual de usuario

Lorex

Lorex LNZ81P25 Series Manual de usuario

GE J1470S Manual de usuario

Sony

Sony A6700 Guía del usuario

Canon

Canon EOS ELAN7 Manual de usuario
