Panasonic Lumix DMC-TZ30 Especificaciones técnicas

VQT4B90

M0212KZ0

Basic Operating Instructions

Digital Camera

Model No. DMC-TZ30

Before use, please read these instructions completely.

More detailed instructions on the operation of this

camera are contained in “Operating Instructions

for advanced features (PDF format)” in the

supplied disc. Install it on your PC to read it.

2 VQT4B90 (ENG)

Dear Customer,

We would like to take this opportunity to thank you for purchasing this Panasonic

Digital Camera. Please read these Operating Instructions carefully and keep them

handy for future reference. Please note that the actual controls and components,

menu items, etc. of your Digital Camera may look somewhat different from those

shown in the illustrations in these Operating Instructions.

Carefully observe copyright laws.

• Recording of pre-recorded tapes or discs or other published or broadcast material

for purposes other than your own private use may infringe copyright laws. Even

for the purpose of private use, recording of certain material may be restricted.

Information for Your Safety

WARNING:

To reduce the risk of fire, electric shock or product damage,

•Do not expose this unit to rain, moisture, dripping or splashing.

•Do not place objects filled with liquids, such as vases, on this

unit.

•Use only the recommended accessories.

•Do not remove covers.

•Do not repair this unit by yourself. Refer servicing to qualified

service personnel.

The socket outlet shall be installed near the equipment and shall be

easily accessible.

■Product identification marking

Product Location

Digital camera Bottom

(ENG) VQT4B90 3

■About the battery pack

CAUTION

• Danger of explosion if battery is incorrectly replaced. Replace only

with the type recommended by the manufacturer.

• When disposing the batteries, please contact your local authorities or

dealer and ask for the correct method of disposal.

• Do not heat or expose to flame.

• Do not leave the battery(ies) in a car exposed to direct sunlight for a

long period of time with doors and windows closed.

Warning

Risk of fire, explosion and burns. Do not disassemble, heat above

60 °C or incinerate.

4 VQT4B90 (ENG)

■About the AC adaptor (supplied)

CAUTION!

To reduce the risk of fire, electric shock or product damage,

•Do not install or place this unit in a bookcase, built-in cabinet or in

another confined space. Ensure this unit is well ventilated.

• The unit is in the standby condition when the AC adaptor is connected. The

primary circuit is always “live” as long as the AC adaptor is connected to an

electrical outlet.

(ENG) VQT4B90 5

■Cautions for Use

• Do not use any other USB connection cables except the supplied one.

• Always use a genuine Panasonic HDMI mini cable

(RP-CDHM15, RP-CDHM30: optional).

Part numbers: RP-CDHM15 (1.5 m), RP-CDHM30 (3.0 m)

• Always use a genuine Panasonic AV cable (DMW-AVC1: optional).

In the event of abnormal operation (e.g. if the unit emits smoke or an unusual

smell), immediately stop operating the unit and consult the Panasonic Customer

Care Centre on 132600.

Keep this unit as far away as possible from electromagnetic equipment (such

as microwave ovens, TVs, video games etc.).

• If you use this unit on top of or near a TV, the pictures and/or sound on this unit

may be disrupted by electromagnetic wave radiation.

• Do not use this unit near cell phones because doing so may result in noise

adversely affecting the pictures and/or sound.

• Recorded data may be damaged, or pictures may be distorted, by strong

magnetic fields created by speakers or large motors.

• Electromagnetic wave radiation generated by microprocessors may adversely

affect this unit, disturbing the pictures and/or sound.

• If this unit is adversely affected by electromagnetic equipment and stops

functioning properly, turn this unit off and remove the battery or disconnect AC

adaptor (supplied). Then reinsert the battery or reconnect AC adaptor and turn

this unit on.

Do not use this unit near radio transmitters or high-voltage lines.

• If you record near radio transmitters or high-voltage lines, the recorded pictures

and/or sound may be adversely affected.

For information about the software used for this product, press [MENU/SET] and

select [Setup] to display [Version Disp.] before pressing [MENU/SET] again.

This product is licensed under the AVC patent portfolio license for the personal

and non-commercial use of a consumer to (i) encode video in compliance with

the AVC Standard (“AVC Video”) and/or (ii) decode AVC Video that was encoded

by a consumer engaged in a personal and non-commercial activity and/or was

obtained from a video provider licensed to provide AVC Video. No license is

granted or shall be implied for any other use. Additional information may be

obtained from MPEG LA, LLC.

See http://www.mpegla.com.

6 VQT4B90 (ENG)

Contents

Before use

Information for Your Safety .......2

Before use ...................................6

Standard accessories ................7

Names and Functions of

Main Parts ...................................8

Touch operations ........................9

Inserting and removing the

card (optional)/the battery .......10

Charging the battery ................11

Setting the clock .......................12

Setting the menu ......................14

Taking pictures .........................15

Taking motion pictures ............16

Viewing your pictures

[Normal Play] ............................18

Deleting pictures ......................18

GPS and map functions ...........19

Reading the Operating

Instructions (PDF format) ........22

Installing supplied software ....23

Specifications ...........................24

■Camera handling

●Keep the camera away from excessive vibration, force, or pressure.

●The camera is not dust resistant, splash resistant, or waterproof.

Avoid using the camera in places with excessive dust or sand, or

where water can come into contact with the camera.

■Condensation (When the lens or the LCD monitor is fogged up)

●Condensation may occur when the camera is exposed to sudden

changes of temperature or humidity. Avoid these conditions, which

may make the lens or LCD monitor dirty, cause mould, or damage the

camera.

●If condensation does occur, turn off the camera and wait about two

hours before using it. Once the camera adjusts to the surrounding

temperature, fogginess will clear naturally.

(ENG) VQT4B90 7

Standard accessories

• SD Memory Card, SDHC Memory Card and SDXC Memory Card are

indicated as card in the text.

• Memory cards are optional. You can record or play back pictures on the

built-in memory when you are not using a card.

• Consult the dealer or your nearest Service Centre if you lose the

supplied accessories. (You can purchase the accessories separately.)

• Please dispose of all packaging appropriately.

• Keep small parts in a safe place out of the reach of children.

• The illustrations and screens in this manual may differ from the actual

product.

Check that all the accessories are supplied before using the camera. Part

numbers are as of January 2012.

Battery pack

DMW-BCG10E

• Charge the battery

before use.

Battery pack is indicated as

battery pack or battery in the

text.

AC adaptor

VSK0776

Hand strap

VFC4297

USB connection

cable

K1HY08YY0025

DVD

VFF0978

• Software:

Use it to install the

software on your

PC.

• Map data

• Operating

Instructions for

advanced features

DVD is indicated as disc in the

text.

8 VQT4B90 (ENG)

Names and Functions of Main Parts

Camera ON/OFF switch

Shutter button

Mode dial

Flash

Self-timer indicator/AF Assist Lamp

Lens barrel

Lens

Zoom lever

We recommend using the

supplied hand strap to

avoid dropping the camera.

GPS status indicator

[EXPOSURE] button

[MAP] button

LCD monitor

Cursor buttons

[DISP.] button

[Q.MENU]/[ / ] (Delete/Cancel)

button

Built-in GPS antenna

Microphone

Speaker

Motion picture button

REC/PLAY switch

[HDMI] socket

[AV OUT/DIGITAL]

socket

[MENU/SET] button

Charging lamp

Tripod receptacle

• Ensure that the tripod is stable.

Card/Battery door

Release lever

(ENG) VQT4B90 9

Touch operations

This camera’s touch screen senses pressure that is applied to the screen.

Touch

To “touch” is to press the touch screen and then pull

the finger back again.

Touching is used to select icons or pictures, among other

actions.

• Touch an icon near its centre. If multiple icons are

touched simultaneously, the camera may not operate

normally.

Drag

To “drag” is to touch and slide your finger across the

touch screen surface.

Dragging (sliding your finger across the screen) is used

to scroll the pictures or change the range of the pictures

displayed.

●If the type of sheet to protect LCD screens that are available on the

market is to be used, observe the precautions that are contained with

the sheet. (Some types of protective sheets may impair the screen’s

visual recognition and ease of operation.)

●If the camera is used with a protective sheet available on the market

attached to its screen or if the screen is not very responsive, touch the

screen with a little more pressure.

●If your hand is pressed against the touch screen when holding the

camera, the touch screen will not work properly.

●Do not press on the LCD monitor with hard pointed tips, such as

ballpoint pens.

●Do not press the touch screen with your fingernails.

●Clean the LCD monitor with a soft dry cloth if there are fingerprints or

other kinds of dirt on it.

10 VQT4B90 (ENG)

Inserting and removing the card (optional)/

the battery

To charge the battery, insert it into the camera.

Set the camera ON/OFF switch

to OFF and slide the release

lever ( ) to [OPEN] before

opening the card/battery door

[OPEN] [LOCK]

Insert the battery and card,

making sure that their

orientation is correct

• Battery:

Insert all the way firmly until a

locking sound is heard, and check

that it is locked by lever ( ).

• Card: Insert all the way firmly until it

clicks.

Do not touch the

terminals on the

back of the card.

Close the card/battery door

Slide the release lever to the [LOCK]

position.

■To remove

•To remove battery:

Move lever in direction of arrow.

•To remove card:

Push the card until it clicks,

then pull the card out.

Lever

●Always use genuine Panasonic batteries (DMW-BCG10E).

●If you use other batteries, we cannot guarantee the quality of this

product.

●Keep the Memory Card out of reach of children to prevent swallowing.

●We recommend using a Panasonic Memory card.

Otros manuales para Lumix DMC-TZ30

Tabla de contenidos

Otros manuales de Cámara digital de Panasonic

Panasonic

Panasonic DMC-GX85K/DMC-GX85 Instrucciones de instalación y servicio

Panasonic

Panasonic Lumix DMC-G2 Manual de usuario

Panasonic

Panasonic Lumix DMC-G2K Manual de usuario

Panasonic

Panasonic LUMIX DMC-LS75 Manual de usuario

Panasonic

Panasonic Lumix DMC-FT20 Especificaciones técnicas

Panasonic

Panasonic DMC-ZS40 Manual de usuario

Panasonic

Panasonic Lumix DMC-FZ50 Guía de referencia

Panasonic

Panasonic Lumix DMC-TZ20 Manual de usuario

Panasonic

Panasonic H-HS043PP Manual de usuario

Panasonic

Panasonic Lumix DMC-FZ200 Especificaciones técnicas

Panasonic

Panasonic Lumix DC-G9 Manual del propietario

Panasonic

Panasonic Lumix DMC-SZ10 Especificaciones técnicas

Panasonic

Panasonic Lumix DMC-ZS10 Manual de usuario

Panasonic

Panasonic P2HD AJ-HPX3700 Manual de usuario

Panasonic

Panasonic DMC-SZ7K Manual de usuario

Panasonic

Panasonic DMCG10K - DIGITAL CAMERA/LENS KIT Manual de usuario

Panasonic

Panasonic LUMIX DMC-LX2 Manual de usuario

Panasonic

Panasonic LUMIX DMC-FZ30EB Manual de usuario

Panasonic

Panasonic CoolShot KXL-600A Manual de usuario

Panasonic

Panasonic DMCFZ30PP - DIGITAL STILL CAMERA Manual de usuario

Panasonic

Panasonic DMCFH22 - DIGITAL STILL CAMERA Manual del propietario

Panasonic

Panasonic Lumix DMC-TZ70 Especificaciones técnicas

Panasonic

Panasonic lumix DC-TZ90 Manual de usuario

Panasonic

Panasonic Lumix DMC-FX550 Manual de usuario

Manuales populares de Cámara digital de otras marcas

Mercury

Mercury 350K Manual de usuario

Pentax

Pentax Optio LS 465 Manual de usuario

Sanyo

Sanyo VPC-S1085 Manual de usuario

GE SMART A1255 Manual de usuario

Point Grey

Point Grey Gazelle Manual de usuario

Nikon

Nikon COOLPIX A Manual de usuario

Pentax

Pentax P-5 Manual de usuario

BlazeVideo

BlazeVideo A280 Manual de usuario

Sony

Sony MCA-20 Manual de usuario

Sony

Sony Alpha DSLR-A290 Manual de usuario

ATIK Cameras

ATIK Cameras One Manual de usuario

CohuHD Costar

CohuHD Costar 3930 Series Manual de usuario

Leica

Leica M10-R Manual de usuario

FujiFilm

FujiFilm FinePix A700 Manual de usuario

Lorex

Lorex LNZ81P25 Series Manual de usuario

GE J1470S Manual de usuario

Sony

Sony A6700 Guía del usuario

Canon

Canon EOS ELAN7 Manual de usuario
