Panasonic Lumix DMC-SZ1 Instrucciones de instalación y servicio

Basic Owner’s Manual

Digital Camera

Model No. DMC-SZ1

DMC-FH8

Before connecting, operating or adjusting this product,

please read the instructions completely.

More detailed instructions on the

operation of this camera are

contained in “Owner’s Manual for

advanced features (PDF format)” in the supplied

CD-ROM. Install it on your PC to read it.

DMC-SZ1 DMC-FH8

VQT3Z31

F1211MR0

For Canadian assistance, please call: 1-800-99-LUMIX (1-800-995-8649) or

send e-mail to: [email protected]

until

2012/3/1

DMC-SZ1&FH8PC-VQT3Z31_eng.book 1 ページ２０１１年１２月２２日　木曜日　午後４時２分

VQT3Z31 (ENG)

Dear Customer,

Thank you for choosing Panasonic!

You have purchased one of the most sophisticated and reliable products on the market

today. Used properly, we’re sure it will bring you and your family years of enjoyment.

Please take time to fill in the information on the below. The serial number is on the tag

located on the underside of your camera. Be sure to retain this manual as your

convenient camera information source.

Please note that the actual controls and components, menu items, etc. of your Digital

Camera may look somewhat different from those shown in the illustrations in this

Owner’s Manual.

Carefully observe copyright laws.

•Recording of pre-recorded tapes or discs or other published or broadcast material for

purposes other than your own private use may infringe copyright laws. Even for the purpose

of private use, recording of certain material may be restricted.

A lithium ion battery that is recyclable powers the product you have

purchased. Please call 1-800-8-BATTERY for information on how

to recycle this battery.

Date of Purchase

Dealer Purchased From

Dealer Address

Dealer Phone No.

Model No.

Serial No.

DMC-SZ1&FH8PC-VQT3Z31_eng.book 2 ページ２０１１年１２月２２日　木曜日　午後４時２分

(ENG) VQT3Z31

Information for Your Safety

∫Product identification marking

WARNING:

To reduce the risk of fire, electric shock or product damage,

•Do not expose this unit to rain, moisture, dripping or splashing.

•Do not place objects filled with liquids, such as vases, on this unit.

•Use only the recommended accessories.

•Do not remove covers.

•Do not repair this unit by yourself. Refer servicing to qualified service personnel.

The socket outlet shall be installed near the equipment and shall be easily

accessible.

Product Location

Digital Camera Bottom

This Class B digital apparatus complies with Canadian ICES-003.

DMC-SZ1&FH8PC-VQT3Z31_eng.book 3 ページ２０１１年１２月２２日　木曜日　午後４時２分

VQT3Z31 (ENG)

∫About the battery pack

•Do not heat or expose to flame.

•Do not leave the battery(ies) in a car exposed to direct sunlight for a long period of time with

doors and windows closed.

CAUTION

Battery pack (Lithium ion battery pack)

•Use the specified unit to recharge the battery pack.

•Do not use the battery pack with equipment other than the specified unit.

•Do not get dirt, sand, liquids, or other foreign matter on the terminals.

•Do not touch the plug terminals (iand j) with metal objects.

•Do not disassemble, remodel, heat or throw into fire.

If any electrolyte should come into contact with your hands or clothes, wash it off

thoroughly with water.

If any electrolyte should come into contact with your eyes, never rub the eyes. Rinse

eyes thoroughly with water, and then consult a doctor.

CAUTION

•Danger of explosion if battery is incorrectly replaced. Replace only with the type

recommended by the manufacturer.

•When disposing the batteries, please contact your local authorities or dealer and ask for

the correct method of disposal.

Warning

Risk of fire, explosion and burns. Do not disassemble, heat above 60 xC (140 oF) or

incinerate.

DMC-SZ1&FH8PC-VQT3Z31_eng.book 4 ページ２０１１年１２月２２日　木曜日　午後４時２分

(ENG) VQT3Z31

∫About the AC adaptor (supplied)

∫Cautions for Use

•Do not use any other USB connection cables except the supplied one.

•(DMC-SZ1)

Do not use any other AV cables except the supplied one.

•(DMC-FH8)

Always use a genuine Panasonic AV cable (DMW-AVC1: optional).

Keep this unit as far away as possible from electromagnetic equipment (such as

microwave ovens, TVs, video games etc.).

•If you use this unit on top of or near a TV, the pictures and/or sound on this unit may be

disrupted by electromagnetic wave radiation.

•Do not use this unit near cell phones because doing so may result in noise adversely

affecting the pictures and/or sound.

•Recorded data may be damaged, or pictures may be distorted, by strong magnetic fields

created by speakers or large motors.

•Electromagnetic wave radiation generated by microprocessors may adversely affect this unit,

disturbing the pictures and/or sound.

•If this unit is adversely affected by electromagnetic equipment and stops functioning properly,

turn this unit off and remove the battery or disconnect AC adaptor (supplied). Then reinsert

the battery or reconnect AC adaptor and turn this unit on.

Do not use this unit near radio transmitters or high-voltage lines.

•If you record near radio transmitters or high-voltage lines, the recorded pictures and/or sound

may be adversely affected.

CAUTION!

To reduce the risk of fire, electric shock or product damage,

•Do not install or place this unit in a bookcase, built-in cabinet or in another

confined space. Ensure this unit is well ventilated.

•Do not obstruct this unit’s ventilation openings with newspapers, tablecloths,

curtains, and similar items.

•Do not place sources of naked flames, such as lighted candles, on this unit.

AC adaptor

This AC adaptor operates on AC between 110 V and 240 V.

But

•In the U.S.A. and Canada, the AC adaptor must be connected to a 120 V AC power

supply only.

•When connecting to an AC supply outside of the U.S.A. or Canada, use a plug adaptor to

suit the AC outlet configuration.

DMC-SZ1&FH8PC-VQT3Z31_eng.book 5 ページ２０１１年１２月２２日　木曜日　午後４時２分

VQT3Z31 (ENG)

-If you see this symbol-

Information on Disposal in other Countries outside the

European Union

This symbol is only valid in the European Union.

If you wish to discard this product, please contact your local

authorities or dealer and ask for the correct method of disposal.

DMC-SZ1&FH8PC-VQT3Z31_eng.book 6 ページ２０１１年１２月２２日　木曜日　午後４時２分

(ENG) VQT3Z31

Contents

Information for Your Safety......................................................................................... 3

Before Use .................................................................................................................... 7

Standard Accessories ................................................................................................. 8

Names and Functions of Main Parts .......................................................................... 9

Inserting and Removing the Card (optional)/the Battery ....................................... 11

Charging the Battery.................................................................................................. 12

Sequence of operations ............................................................................................ 13

Reading the Owner’s Manual (PDF format) ............................................................. 14

Installing supplied software...................................................................................... 15

Specifications............................................................................................................. 16

Digital Camera Accessory System ........................................................................... 19

Before Use

∫Care of the camera

•Do not subject to strong vibration, shock, or pressure.

•This camera is not dust/splash/water proof.

Avoid using the camera in places with a lot of dust, water, sand, etc.

∫About Condensation (When the lens is fogged up)

•Condensation occurs when the ambient temperature or humidity changes. Be careful of

condensation since it causes lens stains, fungus and camera malfunction.

•If condensation occurs, turn the camera off and leave it for about 2 hours. The fog will

disappear naturally when the temperature of the camera becomes close to the ambient

temperature.

•Please note that the actual controls and components, menu items, and other information

for your digital camera may differ from those in the illustrations and screens provided in this

manual. When operation or other information is more or less the same between models,

(DMC-SZ1) are used as examples for the instructions provided in this manual.

•The operations, procedures, or functions that differ among models are indicated

separately, together with the relevant model number.

e.g.: (DMC-SZ1)

(DMC-FH8)

DMC-SZ1&FH8PC-VQT3Z31_eng.book 7 ページ２０１１年１２月２２日　木曜日　午後４時２分

VQT3Z31 (ENG)

Standard Accessories

Check that all the accessories are supplied before using the camera.

Product numbers correct as of January 2012. These may be subject to change.

1 Battery Pack

(Indicated as battery pack or battery

in the text)

Charge the battery before use.

2 AC Adaptor

Can be used for charging and

playback.

3 USB Connection Cable

4(DMC-SZ1)

AV Cable¢

5 CD-ROM

•Software

•Owner’s Manual for advanced features

Install on your PC before use.

6 Hand Strap

¢AV cable is not provided in (DMC-FH8).

•SD Memory Card, SDHC Memory Card and

SDXC Memory Card are indicated as card in

the text.

•The card is optional.

You can record or play back pictures on

the built-in memory when you are not

using a card.

•For information about optional accessories,

refer to the “Digital Camera Accessory

System”.

•If any accessories are lost, customers in

Canada should contact 1-800-99-LUMIX

(1-800-995-8649) for further information about

obtaining replacement parts.

VFC4297VFF0940

(DMC-SZ1)

K1HY08YY0025

(DMC-FH8)

K1HY08YY0015

(DMC-SZ1)

K1HY08YY0026

DMW-BCK7PP VSK0768

DMC-SZ1&FH8PC-VQT3Z31_eng.book 8 ページ２０１１年１２月２２日　木曜日　午後４時２分

(ENG) VQT3Z31

Names and Functions of Main Parts





789

623

1916 17

2354

14 1511

21 22

12 13





789

1916 17

23 6

54 14 1511

21 22

12 13

(DMC-SZ1)

(DMC-FH8)

DMC-SZ1&FH8PC-VQT3Z31_eng.book 9 ページ２０１１年１２月２２日　木曜日　午後４時２分

VQT3Z31 (ENG)

1 Motion picture button

2 Shutter button

3 Camera ON/OFF switch

4Flash

5 Microphone

6 Speaker

•Be careful not to cover the speaker with your finger. Doing so may make sound difficult

to hear.

7 Zoom lever

8Lens

9 Lens barrel

10 Self-timer indicator

AF Assist Lamp

11 LCD monitor

12 [MODE] button

13 Charging lamp

14 REC/PLAY switch

15 Strap eyelet

•Be sure to attach the strap when using the camera to ensure that you will not drop it.

16 Cursor buttons

17 [DISP.] button

18 [MENU/SET] button

19 [Q.MENU]/[ ] (Delete/Cancel) button

20 [AV OUT/DIGITAL] socket

21 Tripod receptacle

22 Card/Battery door

23 Release lever

DMC-SZ1&FH8PC-VQT3Z31_eng.book 10 ページ２０１１年１２月２２日　木曜日　午後４時２分

Otros manuales para Lumix DMC-SZ1

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cámara digital de Panasonic

Panasonic

Panasonic Lumix DMC-TZ60 Manual de usuario

Panasonic

Panasonic Lumix DMC-LX100 Manual de usuario

Panasonic

Panasonic Lumix DMC-ZS6 Manual de usuario

Panasonic

Panasonic Lumix DMC-FH24 Instrucciones de instalación y servicio

Panasonic

Panasonic LUMIX DMC-FS25 Manual de usuario

Panasonic

Panasonic Lumix DMC-LX5 Especificaciones técnicas

Panasonic

Panasonic Lumix DMC-ZS6 Manual de usuario

Panasonic

Panasonic DMC-3D1K Instrucciones de instalación y servicio

Panasonic

Panasonic NV-DCF3 Series Manual de usuario

Panasonic

Panasonic AK-HC3900G Manual de usuario

Panasonic

Panasonic VQT1T63 Manual de usuario

Panasonic

Panasonic Lumix DMC-LC43A Manual de usuario

Panasonic

Panasonic DMC-TZ6EB Manual de usuario

Panasonic

Panasonic Lumix DMC-LZ30 Manual de usuario

Panasonic

Panasonic DC-S5M2 Instrucciones de montaje

Panasonic

Panasonic DMC-ZS20W Instrucciones de instalación y servicio

Panasonic

Panasonic Lumix DMC-FZ5 Manual de usuario

Panasonic

Panasonic Lumix DMC-FS33 Manual de usuario

Panasonic

Panasonic Lumix DMC-FH6P Manual de usuario

Panasonic

Panasonic Lumix DMC-TZ50 Manual de usuario

Panasonic

Panasonic WV-CP474E Manual de usuario

Panasonic

Panasonic Lumix DMC-FX36 Manual de usuario

Panasonic

Panasonic Lumix DC-TZ220D Manual de usuario

Panasonic

Panasonic LUMIX DMC-FX33 Manual de usuario

Manuales populares de Cámara digital de otras marcas

Mercury

Mercury 350K Manual de usuario

Pentax

Pentax Optio LS 465 Manual de usuario

Sanyo

Sanyo VPC-S1085 Manual de usuario

GE SMART A1255 Manual de usuario

Point Grey

Point Grey Gazelle Manual de usuario

Nikon

Nikon COOLPIX A Manual de usuario

Pentax

Pentax P-5 Manual de usuario

BlazeVideo

BlazeVideo A280 Manual de usuario

Sony

Sony MCA-20 Manual de usuario

Sony

Sony Alpha DSLR-A290 Manual de usuario

ATIK Cameras

ATIK Cameras One Manual de usuario

CohuHD Costar

CohuHD Costar 3930 Series Manual de usuario

Leica

Leica M10-R Manual de usuario

FujiFilm

FujiFilm FinePix A700 Manual de usuario

Lorex

Lorex LNZ81P25 Series Manual de usuario

GE J1470S Manual de usuario

Sony

Sony A6700 Guía del usuario

Canon

Canon EOS ELAN7 Manual de usuario
