Panasonic Lumix DMC-LS1S Manual de usuario

ORDERNO. DSC0503007C0

B26

Digital Camera

DMC-LS1PP / DMC-LS1PL / DMC-LS1EB / DMC-LS1EG /

DMC-LS1EGM / DMC-LS1GC / DMC-LS1GK / DMC-LS1GN /

DMC-LS1GT / DMC-LS1SG

Vol. 1

Colour

(S)...........Silver Type

(A)...........Blue Type (GCand GKonly)

(T)...........BrownType (GConly)

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

SPECIFICATIONS

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

Unauthorized copying and distribution isaviolation of law.

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

1. INTRODUCTION

1.1. INTRODUCTION

This service manual contains technical information, whichallowservice personnel’s to

understand and service this model.

Please place orders using the parts list and not the drawing reference numbers.

If the circuit is changedormodified, the information will be followedbyservice manual tobe

controlledwithoriginal service manual.

1.2. ABOUTLEAD FREE SOLDER(PbF)

Distinction of PbF PCB:

PCBs (manufactured) using leadfree solderwill have a PbF stampon the PCB.

Caution:

-Pb free solder has ahigher melting point than standard solder,

Typicallythe melting point is50-70°F (30-40°C)higher.

Please use ahigh temperature soldering iron. Incase of soldering

iron with temperature control, please set itto 700±20°F (370±10°C)

-Pb free solder will tend to splash when heated too high (about

1100°F/600°C).

Whensoldering orunsoldering, please completelyremove all of the solderon the pins orsolder

area, and be sure toheat the soldering points withthe Pbfree solderuntil it melts enough.

1.3. IMPORTANTNOTICE1: (Other than U.S.A. and Canadian Market)

1. The service manual does not containthe following information,

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

because of the impossibilityof servicing at component level.

A. Schematicdiagram, Block Diagram and C.B.A. layout of Main

C.B.A.

B. Parts list for individual parts of MainC.B.A.

When apart replacement isrequired for repairing MainC.B.A.,

replace as an assembled parts. (MainC.B.A.)

2. The following categoryis/are recyclemodulepart. please send it/

them to Central RepairCenter.

-MAINC.B.A. (VEP56021A):Excluding replacement of Lithium

Battery

1.4. HOWTO DEFINETHEMODEL SUFFIX(NTSCor PALmodel)

There are six kinds of DMC-LS1, regardless of the colours.

-DMC-LS1S

-DMC-LS1PP

-DMC-LS1EB/EG/EGM/GN

-DMC-LS1GC/SG

-DMC-LS1GT

-DMC-LS1PL/GK

(DMC-LS1S is exclusivelyJapandomestic model.)

What is the difference is that the “INITIALSETTING” data whichis storedinFlashROM

mountedon MainC.B.A.

1.4.1. Defining methods:

To define the model suffix tobe serviced, refertothe nameplate whichis puttedon the bottom

side of the Unit.

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

NOTE:

After replacing the MAINC.B.A., be sure to achieve adjustment.

The adjustment instruction isavailableat “software download” on

the “CS-Web from AVC”web-site in“TSNsystem”.

1.4.2. INITIALSETTINGS:

Whenyou replace the MainC.B.A., be sure toperform the initial settings afterachieving the

Adjustment, byordering the following procedure inaccordance withmodel suffix.

-Step 1. The temporarycancellation of factorysetting:

Set the mode dial to “[Normal Picture] (Red camera mark)”.

Whilekeep pressing [Optical Image Stabilizer] and “[UP] of

Cross key”simultaneously, turn the Power on.

-Step 2. The cancellation of factorysetting:

Set the mode dial to “[Playback] ”.

Whilekeep pressing [Optical Image Stabilizer] and “[UP] of

Cross key”simultaneously, turn the Power off.

-Step 3. Turn the Power on:

Set the mode dial to “[Normal Picture] (Red camera mark)”, and

then turn the Power on.

-Step 4. Displaythe INITIALSETTING:

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

Whilekeep pressing [MENU]and “[RIGHT] of Cross key”

simultaneously, turn the Power off.

-Step 5. Set the INITIALSETTING:

Select the area with pressing “[UP] / [DOWN]of Cross key”,

and then press the “[RIGHT] of Cross key”.

The onlyset area isdisplayed, and then press the "[RIGHT] of

Cross key"after confirmation. (The unitispowered off

automatically.)

Confirm the displayof “PLEASE SET THECLOCK”inEnglish

when the unitisturned on again. / (For China and Taiwan market,

the displayshows“PLEASE SET THECLOCK”inChinese.)

-NOTE:

The displayshows“SET THECLOCK”when turn the Power on

again.

Connect the unitto PCwith USBcableand isdetected as

removablemedia.

1) As foryourreference Default setting condition is giveninthe following table.

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

-Defaultsetting (After “INITIALSETTINGS”)

MODEL VIDEO

OUTPUT LANGUAGE DATE

REMARKS

a) DMC-LS1S NTSC Japanese Year/Month/Date

b) DMC-LS1PP/PL NTSC English Month/Date/Year

c) DMC-LS1EB/EG/EGM/GC/GN

/SG PAL English Date/Month/Year

d) DMC-LS1GK PAL Chinese

(simplified) Year/Month/Date

e) DMC-LS1GT NTSC Chinese

(traditional) Year/Month/Date

2. SAFETY PRECAUTIONS

2.1. GENERALGUIDELINES

1. IMPORTANTSAFETY NOTICE

There are special components used inthisequipment which are

important for safety. These parts are marked byinthe

SchematicDiagrams, CircuitBoard Layout, Exploded Viewsand

Replacement Parts List. Itisessential that these critical parts

shouldbe replaced with manufacturer’sspecified parts to prevent

X-RADIATION, shock, fire, or other hazards. Donot modifythe

original design without permission of manufacturer.

2. AnIsolation Transformer shouldalwaysbe used during the

servicing of AC Adaptor whose chassisisnot isolated from the

AC power line. Use atransformer of adequate power rating as this

protects the technician from accidents resulting inpersonal injury

from electrical shocks. Itwill also protect AC Adaptor from being

damaged byaccidental shorting that mayoccur during servicing.

3. When servicing, observe the original lead dress. Ifashort circuit

isfound, replace all parts which have been overheated or

damaged bythe short circuit.

4. After servicing, see to itthat all the protective devices such as

insulation barriers, insulation papers shields are properly

installed.

5. After servicing, make the following leakage current checks to

prevent the customer from being exposed to shock hazards.

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

2.2. LEAKAGECURRENTCOLDCHECK

1. Unplug the AC cord and connect ajumper between the two

prongs on the plug.

2. Measure the resistance value, with an ohmmeter, between the

jumpered AC plug and each exposed metalliccabinet part on the

equipment such as screwheads, connectors, control shafts, etc.

When the exposed metallicpart has areturn path to the chassis,

the reading shouldbe between 1M and 5.2M . When the

exposed metal does not have areturn path to the chassis, the

reading must be infinity.

2.3. LEAKAGECURRENTHOTCHECK (See Figure 1.)

1. Plug the AC cord directlyinto the AC outlet. Donot use an

isolation transformer for thischeck.

2. Connect a1.5k , 10 Wresistor, inparallel with a0.15 F

capacitor, between each exposed metallicpart on the set and a

good earth ground, as showninFigure 1.

3. Use an AC voltmeter, with 1k /Vor more sensitivity, to measure

the potential across the resistor.

4. Check each exposed metallicpart, and measure the voltage at

each point.

5. Reverse the AC plug inthe AC outlet and repeat each of the above

measurements.

6. The potential at anypoint shouldnot exceed 0.75 VRMS. A

leakage current tester (Simpson Model 229 or equivalent) maybe

used to make the hot checks, leakage current must not exceed 1/2

mA. Incase ameasurement isoutside of the limits specified,

there isapossibilityof ashock hazard, and the equipment should

be repaired and rechecked before itisreturned to the customer.

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com
