Panasonic Lumix DMC-FH6 Manual de usuario

For Canadian assistance, please call: 1-800-99-LUMIX (1-800-995-8649) or

send e-mail to: [email protected]

VQT4G39

M1211KZ0

Basic Owner’s Manual

Digital Camera

Model No. DMC-FH6

DMC-FH4

DMC-FH6

Before connecting, operating or adjusting

this product, please read the instructions

completely.

More detailed instructions on the operation of

this camera are contained in “Owner’s Manual

for advanced features (PDF format)” in the

supplied CD-ROM. Install it on your PC to read it.

2 VQT4G39 (ENG)

Dear Customer,

Thank you for choosing Panasonic!

You have purchased one of the most sophisticated and reliable products

on the market today. Used properly, we’re sure it will bring you and your

family years of enjoyment. Please take time to fill in the information on

the below. The serial number is on the tag located on the underside of

your camera. Be sure to retain this manual as your convenient camera

information source.

Date of Purchase Dealer Phone No.

Dealer Purchased From Model No.

Dealer Address Serial No.

Please note that the actual controls and components, menu items, etc.

of your Digital Camera may look somewhat different from those shown in

the illustrations in this Owner’s Manual.

Carefully observe copyright laws.

• Recording of pre-recorded tapes or discs or other published or

broadcast material for purposes other than your own private use may

infringe copyright laws. Even for the purpose of private use, recording

of certain material may be restricted.

A lithium ion battery that is recyclable powers

the product you have purchased. Please call

1-800-8-BATTERY for information on how to recycle

this battery.

Information for Your Safety

The socket outlet shall be installed near the equipment and shall be

easily accessible.

This Class B digital apparatus complies with Canadian ICES-003.

(ENG) VQT4G39 3

WARNING:

To reduce the risk of fire, electric shock or product damage,

•Do not expose this unit to rain, moisture, dripping or splashing.

•Do not place objects filled with liquids, such as vases, on this

unit.

•Use only the recommended accessories.

•Do not remove covers.

•Do not repair this unit by yourself. Refer servicing to qualified

service personnel.

■Product identification marking

Product Location

Digital camera Bottom

Battery charger Bottom

■About the battery pack

CAUTION

Battery pack (Lithium ion battery pack)

• Use the specified unit to recharge the battery pack.

• Do not use the battery pack with equipment other than the specified unit.

• Do not get dirt, sand, liquids, or other foreign matter on the terminals.

• Do not touch the plug terminals (+ and −) with metal objects.

• Do not disassemble, remodel, heat or throw into fire.

If any electrolyte should come into contact with your hands or clothes,

wash it off thoroughly with water.

If any electrolyte should come into contact with your eyes, never rub

the eyes. Rinse eyes thoroughly with water, and then consult a doctor.

CAUTION

• Danger of explosion if battery is incorrectly replaced. Replace only

with the type recommended by the manufacturer.

• When disposing the batteries, please contact your local authorities or

dealer and ask for the correct method of disposal.

• Do not heat or expose to flame.

• Do not leave the battery(ies) in a car exposed to direct sunlight for a

long period of time with doors and windows closed.

4 VQT4G39 (ENG)

Warning

Risk of fire, explosion and burns. Do not disassemble, heat above

60 °C (140 °F) or incinerate.

■About the battery charger

CAUTION!

To reduce the risk of fire, electric shock or product damage,

•Do not install or place this unit in a bookcase, built-in cabinet or in

another confined space. Ensure this unit is well ventilated.

•Do not obstruct this unit’s ventilation openings with newspapers,

tablecloths, curtains, and similar items.

•Do not place sources of naked flames, such as lighted candles, on this

unit.

Battery charger

This battery charger operates on AC between 110 V and 240 V.

But

• In the U.S.A. and Canada, the battery charger must be connected to a 120 V

AC power supply only.

• When connecting to an AC supply outside of the U.S.A. or Canada, use a plug

adaptor to suit the AC outlet configuration.

(ENG) VQT4G39 5

-If you see this symbol-

Information on Disposal in other Countries outside the

European Union

This symbol is only valid in the European Union. If you

wish to discard this product, please contact your local

authorities or dealer and ask for the correct method of

disposal.

■Cautions for Use

• Do not use any other USB connection cables except the supplied one.

• Always use a genuine Panasonic AV cable (DMW-AVC1: optional).

Keep this unit as far away as possible from electromagnetic equipment (such

as microwave ovens, TVs, video games etc.).

• If you use this unit on top of or near a TV, the pictures and/or sound on this unit

may be disrupted by electromagnetic wave radiation.

• Do not use this unit near cell phones because doing so may result in noise

adversely affecting the pictures and/or sound.

• Recorded data may be damaged, or pictures may be distorted, by strong

magnetic fields created by speakers or large motors.

• Electromagnetic wave radiation generated by microprocessors may adversely

affect this unit, disturbing the pictures and/or sound.

• If this unit is adversely affected by electromagnetic equipment and stops

functioning properly, turn this unit off and remove the battery or disconnect AC

adaptor (DMW-AC5PP: for dealer display purpose only). Then reinsert the battery

or reconnect AC adaptor and turn this unit on.

Do not use this unit near radio transmitters or high-voltage lines.

• If you record near radio transmitters or high-voltage lines, the recorded pictures

and/or sound may be adversely affected.

6 VQT4G39 (ENG)

Contents

Before use

Information for Your Safety .......2

Before use...................................6

Standard accessories ................7

Names and Functions of

Main Parts ...................................8

Charging the battery ................10

Inserting and removing the

card (optional)/the battery .......11

Sequence of operations...........12

Reading the Owner’s Manual

(PDF format)..............................13

Installing supplied software

(PHOTOfunSTUDIO) .................14

Specifications ...........................15

Digital Camera Accessory

System.......................................18

■Camera handling

●Keep the camera away from excessive vibration, force, or pressure.

●The camera is not dust resistant, splash resistant, or waterproof.

Avoid using the camera in places with excessive dust or sand, or

where water can come into contact with the camera.

■Condensation (When the lens or the LCD monitor is fogged up)

●

Condensation may occur when the camera is exposed to sudden

changes of temperature or humidity. Avoid these conditions, which may

make the lens or LCD monitor dirty, cause mold, or damage the camera.

●If condensation does occur, turn off the camera and wait about two

hours before using it. Once the camera adjusts to the surrounding

temperature, the fogging will clear naturally.

●Please note that the actual controls and components, menu items, and other

information for your digital camera may differ from those in the illustrations

and screens provided in this manual. When operation or other information is

more or less the same between models, DMC-FH6 is used as examples for the

instructions provided in this manual.

●The operations, procedures, or functions that differ among models are indicated

separately, together with the relevant model number.

(Example) DMC-FH6

DMC-FH4

(ENG) VQT4G39 7

Standard accessories

• SD Memory Card, SDHC Memory Card and SDXC Memory Card are

indicated as card in the text.

• Memory cards are optional. You can record or play back pictures on the

built-in memory when you are not using a card.

• For information about optional accessories, refer to the “Digital Camera

Accessory System”.

• If any accessories are lost, customers in Canada should contact 1 800

99-LUMIX (1-800-995-8649) for further information about obtaining

replacement parts.

• Please dispose of all packaging appropriately.

• Keep small parts in a safe place out of the reach of children.

Check that all the accessories are supplied before using the camera. Part

numbers are as of January 2012.

Battery pack

DMW-BCK7PP

• Charge the battery

before use.

Battery pack is indicated as

battery pack or battery in the

text.

Battery charger

DE-A91B

Battery charger is indicated as

battery charger or charger in

the text.

Hand strap

VFC4297

USB connection

cable

K1HY08YY0015

CD-ROM

VFF1014

• Software:

Use it to install the

software on your

PC.

• Owner’s Manual for

advanced features

8 VQT4G39 (ENG)

Names and Functions of Main Parts

12 5 678

14151618 171920

12 5 678

14151618 171920

DMC-FH6

DMC-FH4

(ENG) VQT4G39 9

1Self-timer indicator/AF Assist Lamp

2Flash

3Lens

4Lens barrel

5LCD monitor

6Power button

7Microphone

8Shutter button

9DMC-FH6

Zoom lever

DMC-FH4

Zoom button

10 [MODE] button

11 Hand strap eyelet

12 [AV OUT/DIGITAL] socket

13 [/ ] (Delete/Return) button

14 [MENU/SET] button

15 Playback button

16 Cursor button

17 Tripod receptacle

18 Speaker

19 DC coupler cover

For dealer display purpose only

• When using an AC adaptor, ensure that the Panasonic DC coupler (DMW-

DCC10: for dealer display purpose only) and AC adaptor (DMW-AC5PP: for

dealer display purpose only) are used.

• Always use a genuine Panasonic AC adaptor (DMW-AC5PP: for dealer

display purpose only).

20 Card/Battery door

We recommend using

the supplied hand strap

to avoid dropping the

camera.

●The illustrations and screens in this manual may differ from the actual

product.

●Do not block the microphone when recording motion pictures.

●Some tripods or unipods, and some methods of holding the camera

may block the speaker, making it difficult to hear the beep, etc.

10 VQT4G39 (ENG)

Charging the battery

Insert the battery terminals and attach

the battery to the charger

Ensure [LUMIX] faces outwards.

Connect the charger to the electrical outlet

Charging light ([CHARGE])

On:

Charging in progress

(approx. 120 min. if fully depleted)

Off: Charging complete

■About batteries that you can use with this unit

The battery that can be used with this unit is DMW-BCK7PP.

•Use the dedicated charger and battery.

•The battery is not charged when the camera is shipped. Charge

the battery and set the clock before use.

•Charge the battery with the charger indoors (10 °C to 30 °C (50 °F

to 86 °F)).

Otros manuales para Lumix DMC-FH6

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cámara digital de Panasonic

Panasonic

Panasonic LUMIX DC-FZ81 Manual de usuario

Panasonic

Panasonic LUMIX DMC-FZ28 Manual de usuario

Panasonic

Panasonic AJ-D810A Manual de usuario

Panasonic

Panasonic Lumix DMC-LC33PP Manual de usuario

Panasonic

Panasonic Lumix DMC-FP8 Manual de usuario

Panasonic

Panasonic DC-BS1H Manual de usuario

Panasonic

Panasonic Lumix DMC-S2P Manual de usuario

Panasonic

Panasonic DMC-G7SINGLE Manual de usuario

Panasonic

Panasonic Lumix DMC-FT4 Especificaciones técnicas

Panasonic

Panasonic LUMIX DMC-G7 Especificaciones técnicas

Panasonic

Panasonic Lumix DMC-ZR3 Especificaciones técnicas

Panasonic

Panasonic Lumix DMC-3D1 Manual de usuario

Panasonic

Panasonic Lumix DMC-GM5 Manual de usuario

Panasonic

Panasonic HDCZ10000P Manual de usuario

Panasonic

Panasonic Lumix DMC-FS62EB Manual de usuario

Panasonic

Panasonic Lumix DMC-LS5 Manual de usuario

Panasonic

Panasonic Lumix DMC-FX78 Manual de usuario

Panasonic

Panasonic DMC-GX1 Lumix Especificaciones técnicas

Panasonic

Panasonic Lumix DMC-ZS10 Manual de usuario

Panasonic

Panasonic DMC-SZ5K Instrucciones de instalación y servicio

Panasonic

Panasonic DMC-GF6 Manual de usuario

Panasonic

Panasonic LUMIX DMC-G6GN Manual del propietario

Panasonic

Panasonic DMCG10K - DIGITAL CAMERA/LENS KIT Manual de usuario

Panasonic

Panasonic Lumix DMC-ZS5 Especificaciones técnicas

Manuales populares de Cámara digital de otras marcas

Mercury

Mercury 350K Manual de usuario

Pentax

Pentax Optio LS 465 Manual de usuario

Sanyo

Sanyo VPC-S1085 Manual de usuario

GE SMART A1255 Manual de usuario

Point Grey

Point Grey Gazelle Manual de usuario

Nikon

Nikon COOLPIX A Manual de usuario

Pentax

Pentax P-5 Manual de usuario

BlazeVideo

BlazeVideo A280 Manual de usuario

Sony

Sony MCA-20 Manual de usuario

Sony

Sony Alpha DSLR-A290 Manual de usuario

ATIK Cameras

ATIK Cameras One Manual de usuario

CohuHD Costar

CohuHD Costar 3930 Series Manual de usuario

Leica

Leica M10-R Manual de usuario

FujiFilm

FujiFilm FinePix A700 Manual de usuario

Lorex

Lorex LNZ81P25 Series Manual de usuario

GE J1470S Manual de usuario

Sony

Sony A6700 Guía del usuario

Canon

Canon EOS ELAN7 Manual de usuario
