Before use, please read these instructions completely.

More detailed instructions on

the operation of this camera are

contained in “Operating

Instructions for advanced features

(PDF format)” in the supplied CD-ROM. Install

it on your PC to read it.

VQT3D47

Basic Operating Instructions

Digital Camera

Model No. DMC-FH25

DMC-FH5

DMC-FH2

until

2011/1/20

VQT3D47~Cover_eng.fm 1 ページ２０１０年１２月２０日　月曜日　午前１１時９分

VQT3D47 (ENG)

Dear Customer,

We would like to take this opportunity to thank you for purchasing this

Panasonic Digital Camera. Please read these Operating Instructions

carefully and keep them handy for future reference. Please note that the

actual controls and components, menu items, etc. of your Digital Camera

may look somewhat different from those shown in the illustrations in these

Operating Instructions.

Carefully observe copyright laws.

•Recording of pre-recorded tapes or discs or other published or broadcast

material for purposes other than your own private use may infringe copyright

laws. Even for the purpose of private use, recording of certain material may be

restricted.

Information for Your Safety

IF THE POWER CORD OF THIS EQUIPMENT IS DAMAGED, IT MUST BE

REPLACED WITH AN ELECTRICALLY APPROVED POWER CORD.

∫Product identification marking

WARNING:

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PRODUCT

DAMAGE,

•DO NOT EXPOSE THIS APPARATUS TO RAIN, MOISTURE, DRIPPING

OR SPLASHING AND THAT NO OBJECTS FILLED WITH LIQUIDS, SUCH

AS VASES, SHALL BE PLACED ON THE APPARATUS.

•USE ONLY THE RECOMMENDED ACCESSORIES.

•DO NOT REMOVE THE COVER (OR BACK); THERE ARE NO USER

SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

THE SOCKET OUTLET SHALL BE INSTALLED NEAR THE

EQUIPMENT AND SHALL BE EASILY ACCESSIBLE.

Product Location

Digital camera Bottom

Battery charger Bottom

DMC-FH25&FH5&FH2GN-VQT3D47_eng.book 2 ページ２０１０年１２月１８日　土曜日　午後１２時３分

(ENG) VQT3D47

∫About the battery pack

•Do not heat or expose to flame.

•Do not leave the battery(ies) in an automobile exposed to direct sunlight for a

long period of time with doors and windows closed.

∫About the battery charger

•The battery charger is in the standby condition when the AC power supply cord

is connected. The primary circuit is always “live” as long as the power cord is

connected to an electrical outlet.

CAUTION

Danger of explosion if battery is incorrectly replaced. Replace only with

the same or equivalent type recommended by the manufacturer. Dispose

of used batteries according to the manufacturer’s instructions.

Warning

Risk of fire, explosion and burns. Do not disassemble, heat above 60 xC

or incinerate.

CAUTION!

•DO NOT INSTALL OR PLACE THIS UNIT IN A BOOKCASE, BUILT-IN

CABINET OR IN ANOTHER CONFINED SPACE. ENSURE THE UNIT IS

WELL VENTILATED. TO PREVENT RISK OF ELECTRIC SHOCK OR FIRE

HAZARD DUE TO OVERHEATING, ENSURE THAT CURTAINS AND ANY

OTHER MATERIALS DO NOT OBSTRUCT THE VENTILATION VENTS.

•DO NOT OBSTRUCT THE UNIT’S VENTILATION OPENINGS WITH

NEWSPAPERS, TABLECLOTHS, CURTAINS, AND SIMILAR ITEMS.

•DO NOT PLACE SOURCES OF NAKED FLAMES, SUCH AS LIGHTED

CANDLES, ON THE UNIT.

•DISPOSE OF BATTERIES IN AN ENVIRONMENTALLY FRIENDLY

MANNER.

DMC-FH25&FH5&FH2GN-VQT3D47_eng.book 3 ページ２０１０年１２月１８日　土曜日　午後１２時３分

VQT3D47 (ENG)

∫Cautions for Use

•Do not use any other AV cables except the supplied one.

•Do not use any other USB connection cables except the supplied one.

In the event of abnormal operation (e.g. if the unit emits smoke or an unusual

smell), immediately stop operating the unit and consult the Panasonic

Customer Care Centre on 132600.

Keep this unit as far away as possible from electromagnetic equipment

(such as microwave ovens, TVs, video games etc.).

•If you use this unit on top of or near a TV, the pictures and/or sound on this unit

may be disrupted by electromagnetic wave radiation.

•Do not use this unit near cell phones because doing so may result in noise

adversely affecting the pictures and/or sound.

•Recorded data may be damaged, or pictures may be distorted, by strong

magnetic fields created by speakers or large motors.

•Electromagnetic wave radiation generated by microprocessors may adversely

affect this unit, disturbing the pictures and/or sound.

•If this unit is adversely affected by electromagnetic equipment and stops

functioning properly, turn this unit off and remove the battery or disconnect AC

adaptor (DMW-AC5G; optional). Then reinsert the battery or reconnect AC

adaptor and turn this unit on.

Do not use this unit near radio transmitters or high-voltage lines.

•If you record near radio transmitters or high-voltage lines, the recorded pictures

and/or sound may be adversely affected.

DMC-FH25&FH5&FH2GN-VQT3D47_eng.book 4 ページ２０１０年１２月１８日　土曜日　午後１２時３分

(ENG) VQT3D47

-If you see this symbol-

Information on Disposal in other Countries outside

the European Union

This symbol is only valid in the European Union.

If you wish to discard this product, please contact your

local authorities or dealer and ask for the correct

method of disposal.

DMC-FH25&FH5&FH2GN-VQT3D47_eng.book 5 ページ２０１０年１２月１８日　土曜日　午後１２時３分

VQT3D47 (ENG)

Contents

Information for Your Safety ........................................................................... 2

Standard Accessories ................................................................................... 7

Names of the Components ........................................................................... 8

Charging the Battery ................................................................................... 11

• Charging ............................................................................................... 11

• Approximate operating time and number of recordable pictures .......... 13

About the Built-in Memory/the Card ............................................................ 14

Inserting and Removing the Card (optional)/the Battery ............................. 15

Setting Date/Time (Clock Set)..................................................................... 17

• Changing the Clock Setting .................................................................. 17

Selecting the [Rec] Mode............................................................................ 18

Taking pictures using the automatic function

(ñ: Intelligent Auto Mode) ......................................................................... 20

• Scene Detection.................................................................................... 21

Motion Picture Mode ................................................................................... 22

Playing Back Pictures ([Normal Play]) ........................................................ 23

Deleting Pictures ......................................................................................... 24

Setting the Menu ......................................................................................... 25

Reading the Operating Instructions (PDF format)....................................... 26

Specifications.............................................................................................. 28

∫About illustrations in these operating instructions

The procedure is described for (DMC-FH25) as an example.

VQT3D47~TOC_eng.fm 6 ページ２０１０年１２月２０日　月曜日　午前１１時４４分

(ENG) VQT3D47

Standard Accessories

Check that all the accessories are supplied before using the camera.

Product numbers correct as of January 2011. These may be subject to change.

1 Battery Pack¢

(Indicated as battery pack or

battery in the text)

Charge the battery before use.

2 Battery Charger

(Indicated as battery charger or

charger in the text)

3ACCable

4 USB Connection Cable

5AVCable

6 CD-ROM

•Software:

Use it to install the software to your

PC.

•Operating Instructions

7 Hand Strap

¢When purchasing a spare battery,

please purchase an optional battery

(DMW-BCK7E).

•SD Memory Card, SDHC Memory Card

and SDXC Memory Card are indicated

as card in the text.

•The card is optional.

You can record or play back pictures

on the built-in memory when you are

not using a card.

•Consult the dealer or your nearest

Service Centre if you lose the supplied

accessories. (You can purchase the

accessories separately.)

VFC4297VFF0729

(DMC-FH25)

K1HY08YY0019

(DMC-FH5)

(DMC-FH2)

K1HY08YY0015

(DMC-FH25)

K1HY08YY0020

(DMC-FH5)

(DMC-FH2)

K1HY08YY0016

NCA-YN101H DE-A92A

K2CJ2YY00052

VQT3D47~Body1_eng.fm 7 ページ２０１０年１２月１８日　土曜日　午後１２時１３分

VQT3D47 (ENG)

Names of the Components

1Flash

2Lens

3 Self-timer indicator

AF Assist Lamp

4 LCD monitor

5 [MENU/SET] button

6 [DISP.] button

7 [Q.MENU]/Delete/Cancel button

8 [MODE] button

9 [Rec]/[Playback] selector switch

1 2 3

(DMC-FH25)

1 23

(DMC-FH5) (DMC-FH2)

4109

DMC-FH25&FH5&FH2GN-VQT3D47_eng.book 8 ページ２０１０年１２月１８日　土曜日　午後１２時３分

(ENG) VQT3D47

10 Cursor buttons

A: 3/Exposure compensation

B: 4/Macro Mode

AF Tracking

C: 2/Self-timer

D: 1/Flash setting

11 Strap eyelet

•Be sure to attach the strap when

using the camera to ensure that

you will not drop it.

12 Lens barrel

13 [AV OUT/DIGITAL] socket

In these operating instructions, the cursor buttons are described as

shown in the figure below or described with 3/4/2/1.

e.g.: When you press the 4(down) button

or Press 4

DMC-FH25&FH5&FH2GN-VQT3D47_eng.book 9 ページ２０１０年１２月１８日　土曜日　午後１２時３分

VQT3D47 (ENG)

14 Camera ON/OFF switch

15 Zoom lever

16 Speaker

•Do not cover the speaker with

your fingers.

17 Microphone

18 Shutter button

19 (DMC-FH25)

[E.ZOOM] button

20 Tripod receptacle

21 Card/Battery door

23 (DMC-FH5) (DMC-FH2)

Release lever

22 DC coupler cover

•When using an AC adaptor,

ensure that the Panasonic DC

coupler (DMW-DCC10; optional)

and AC adaptor (DMW-AC5G;

optional) are used.

•Always use a genuine Panasonic

AC adaptor (DMW-AC5G;

optional).

•When using an AC adaptor, use

the AC cable supplied with the AC

adaptor.

•It is recommended to use a fully

charged battery or AC adaptor

(DMW-AC5G; optional) and DC

coupler (DMW-DCC10; optional)

when recording motion pictures.

•If while recording motion pictures

using the AC adaptor and the

power supply is cut off due to a

power outage or if the AC adaptor

is disconnected etc., the motion

picture being recorded will not be

recorded.

16 17 18 19

(DMC-FH25)

14 15

17 18

(DMC-FH5) (DMC-FH2)

ヮユヮヰンヺチヤモンュチバ

ャモヵヵユンヺ

ヮユヮヰンヺチヤモンュチバチャモヵヵユンヺ

ヰヱユワロヰヤレ

2322

DMC-FH25&FH5&FH2GN-VQT3D47_eng.book 10 ページ２０１０年１２月１８日　土曜日　午後１２時３分

Otros manuales para Lumix DMC-FH25

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cámara digital de Panasonic

Panasonic

Panasonic LUMIX DMC-ZS100 Manual de usuario

Panasonic

Panasonic DMCFS3P - Lumix Digital Camera Manual de usuario

Panasonic

Panasonic Lumix DMC-FZ300 Manual de usuario

Panasonic

Panasonic DMC-FT2EB Manual de usuario

Panasonic

Panasonic DMC-LX7K Instrucciones de instalación y servicio

Panasonic

Panasonic LUMIX DC-FZ80 Especificaciones técnicas

Panasonic

Panasonic Lumix DMC-G10W Manual de usuario

Panasonic

Panasonic DMCFZ18 - DIGITAL STILL CAMERA Manual de instrucciones

Panasonic

Panasonic LUMIX DMC-FZ70 Especificaciones técnicas

Panasonic

Panasonic AW-UN70KPC Manual de usuario

Panasonic

Panasonic Lumix DMC-FZ200 Manual de usuario

Panasonic

Panasonic PalmCam PV-SD5000 Manual de usuario

Panasonic

Panasonic Lumix DC-FZ10002 Especificaciones técnicas

Panasonic

Panasonic DMC-FZ8P Manual de usuario

Panasonic

Panasonic Lumix DMC-TZ10 Especificaciones técnicas

Panasonic

Panasonic Lumix DMC-GF5X Especificaciones técnicas

Panasonic

Panasonic Lumix DMC-FH2P Manual de usuario

Panasonic

Panasonic KX-TGA573 Manual de usuario

Panasonic

Panasonic lumix VQT0W41 Manual de usuario

Panasonic

Panasonic Lumix DMC-FX8 Manual de usuario

Panasonic

Panasonic DMCFZ30PP - DIGITAL STILL CAMERA Manual de usuario

Panasonic

Panasonic Lumix DMC-XS3 Especificaciones técnicas

Panasonic

Panasonic DMC-G1K - Lumix Digital Camera Manual de usuario

Panasonic

Panasonic Lumix DMC-LZ20E Manual de usuario

Manuales populares de Cámara digital de otras marcas

Mercury

Mercury 350K Manual de usuario

Pentax

Pentax Optio LS 465 Manual de usuario

Sanyo

Sanyo VPC-S1085 Manual de usuario

GE SMART A1255 Manual de usuario

Point Grey

Point Grey Gazelle Manual de usuario

Nikon

Nikon COOLPIX A Manual de usuario

Pentax

Pentax P-5 Manual de usuario

BlazeVideo

BlazeVideo A280 Manual de usuario

Sony

Sony MCA-20 Manual de usuario

Sony

Sony Alpha DSLR-A290 Manual de usuario

ATIK Cameras

ATIK Cameras One Manual de usuario

CohuHD Costar

CohuHD Costar 3930 Series Manual de usuario

Leica

Leica M10-R Manual de usuario

FujiFilm

FujiFilm FinePix A700 Manual de usuario

Lorex

Lorex LNZ81P25 Series Manual de usuario

GE J1470S Manual de usuario

Sony

Sony A6700 Guía del usuario

Canon

Canon EOS ELAN7 Manual de usuario
