Reference Manual

Personal Computer

Model No. CF-F8 Series

CF-W8 Series

CF-T8 Series

We recommend that this Reference Manual be printed.

Read Me First

zIn this manual, “Microsoft®Windows®XP Professional Service Pack 2 with Advanced Security Technologies” and

“Microsoft®Windows®XP Tablet PC Edition 2005” are indicated as “Windows” or “Windows XP” unless otherwise indi-

cated.

z<Only for CF-F8/CF-W8 Series>

In this manual, the following software package is described as follow:

• “WinDVD™ 8 (OEM Version)” as “WinDVD”

Illustrations and Terminology in this Reference Manual

NOTE NOTE provides a useful fact or helpful information.

CAUTION CAUTION indicates a condition that may result in minor or moderate injury.

Enter

This illustration means to press the

Enter

key.

This illustration means to press and hold the

key, then press the

key.

When using with the

key and the

Ctrl

key functions interchanged, read with the

key and the

Ctrl

key reversed.

[start] - [Run] This illustration means to click [start], then to click [Run].

Îor ⇒These symbols indicate related pages.

Î: If this is clicked, it will jump to the page corresponding Reference Manual.

⇒: Refer to the Operating Instructions.

xxxx*1 If *1 is clicked, it will jump to a related topic.

Using the Touch Pad

Use the Touch Pad to move the cursor on the screen and perform computer operations.

A. Work Surface (Touch Pad)

B. Left Button

C. Right Button

Function Operation

Moving the Cursor <CF-F8 Series>

<CF-W8/CF-T8 Series>

Move the tip of your finger lightly over the work surface.

Tapping/Clicking <CF-F8 Series>

<CF-W8/CF-T8 Series>

tapping or clicking

To right-click: Can only be performed by clicking the right

button.

CF-F8 Series

CF-W8/CF-T8 Series

Using the Touch Pad

NOTE

zYou can change the speed of the double-click or the operations of mouse buttons by clicking [start] - [Control Panel] -

[Printers and Other Hardware] - [Mouse].

Double-Tapping/

Double-Clicking

<CF-F8 Series>

<CF-W8/CF-T8 Series>

double-tapping or double-clicking

Dragging <CF-F8 Series>

<CF-W8/CF-T8 Series>

Two quick taps, but on the second tap leaving your finger

down (applying pressure) and moving it on the work surface.

While holding down the button, moving your finger on the work

surface.

Scroll Trace a circle around the Touch Pad. (Îpage 5)

Function Operation

Using the Touch Pad

There are two ways of scrolling with the Touch Pad: the Touch Pad utility, and the Virtual Scrolling Function. You cannot use

both functions at the same time.

The Touch Pad utility is enabled in the default setting.

zThe Touch Pad utility (below)

You can scroll continuously by tracing a circle on the Touch Pad (Start scrolling from the edge of the Touch Pad).

zThe Virtual Scrolling function (Îpage 9)

You can scroll vertically (or horizontally) by tracing repeatedly in the desired direction.

You can use separate settings for each account regarding whether to use the Touch Pad utility or the Virtual Scrolling func-

tion.

Using the Touch Pad Utility

You can scroll easily by tracing a circle on the Touch Pad.

NOTE

zExternal mouse drivers cannot be used at the same time as the Touch Pad utility. (Îpage 76)

1Make the following settings to use the horizontal scroll.

Once the settings have been made, it is not necessary to make the same settings the next time.

Scroll

Vertical scroll It can be used in the default setting.

Horizontal scroll A setting is required to use the horizontal scroll.

Vertical scroll The Virtual Scrolling function must be set to enable.

Horizontal scroll

Using the Touch Pad

AClick on the notification area, and click [Settings].

When is not displayed:

Click [start] - [All Programs] - [Panasonic] - [Touch Pad Utility settings].

If a message appears indicating that the Touch Pad utility is not running, click

[start] - [All Programs] - [Panasonic] - [Touch Pad Utility], and display .

BAdd a check mark for [Activate horizontal scroll function] in the [General

settings] screen, and click [OK].

2Display the scrollable screen.

3Place the cursor over the area that you want to scroll, and tap (click).

4Remove your finger from the pad, then place your finger in the appropriate area to begin

scrolling.

The finger position on the Touch Pad can be changed using the Touch Pad utility. (Îpage 8) This explanation

assumes in the default setting.

*1 If the horizontal scroll function has not been enabled, the segment shown in the figure above (A) is also included in the area

to begin vertical scrolling.

Vertical scroll*1 Horizontal scroll

Position where finger is

placed

<CF-F8 Series>

<CF-W8/CF-T8 Series>

<CF-F8 Series>

<CF-W8/CF-T8 Series>

Icon on the notification area When you place your finger on the Touch Pad, the icon changes.

Using the Touch Pad

5Trace a circle around the Touch Pad without lifting your finger from the pad.

The scroll direction can be changed using [Reverse vertical scrolling] or [Reverse horizontal scrolling] in the Touch

Pad utility. (Îpage 8)

*2 When the horizontal scroll function has not been enabled, any scrolling will be vertical scrolling.

zThe screen will not scroll if you trace toward the center of the Touch Pad.

zOn screens that cannot be scrolled (e.g., desktop screen), if you scroll, the computer may try to scroll the screen,

causing the cursor to freeze. If this happens, remove your finger from the Touch Pad and begin again, this time

starting from the center of the Touch Pad.

zFor example, on a screen that will only scroll horizontally, even if you execute a vertical scroll, the screen will

scroll horizontally.

Vertical scroll Horizontal scroll*2

Trace clockwise To scroll down

<CF-F8 Series>

<CF-W8/CF-T8 Series>

To scroll right

<CF-F8 Series>

<CF-W8/CF-T8 Series>

Trace counter-clockwise To scroll up

<CF-F8 Series>

<CF-W8/CF-T8 Series>

To scroll left

<CF-F8 Series>

<CF-W8/CF-T8 Series>

Using the Touch Pad

6Once scrolling has begun, continue to trace a circle on the Touch Pad without removing

your finger from the pad.

zAs long as you are tracing a circle, you can continue scrolling using any position on the Touch Pad.

zTo scroll in the opposite direction, trace a circle in the opposite direction without removing your finger from the

Touch Pad.

7When you finish scrolling, remove your finger from the Touch Pad.

Change the settings for the Touch Pad utility

1Click on the notification area, and then click [Settings].

When is not displayed:Îpage 6, step1-A

2Change the settings.

zGeneral settings

Activate Touch Pad

function (On/Off)

If you add a check mark, you can use the Touch Pad

function (screen scroll). If you remove the check mark,

the Touch Pad function will be disabled, and will be

displayed on the notification area.

Show icon in task tray

(On/Off)

If you add a check mark, the icon will be displayed in the

notification area.

Show scroll direction

(On/Off)

If you add a check mark, the icon will change while

scrolling and the finger located within the region which

starts scrolling.

Activate scroll direction

with animate scroll (On/

Off)

If you add a check mark, the icon will rotate while you

are scrolling.

Scroll window under

mouse cursor (On/Off)

If you add a check mark, scroll the region where the

mouse cursor is located within the active window.

If you remove the check mark, scroll the selected region

within the active window. In either case, if the mouse

cursor is outside the active window, scroll the selected

region.

Using the Touch Pad

zScroll area

3Click [OK].

Using the Virtual Scrolling Function

Set the Virtual Scrolling function using the following procedure. The Touch Pad utility will be disabled.

1Click on the notification area, and click [Settings].

When is not displayed:Îpage 6, step 1-A

Reverse vertical scroll-

ing (On/Off)

You can change the direction in which the screen scrolls

when you trace the Touch Pad clockwise.

• When check mark is added: Upwards

• When check mark is removed: Downwards

Activate horizontal

scroll function (On/Off)

If you add a check mark, you can use the horizontal

scroll.

Reverse horizontal

scrolling (On/Off)

When you add a check mark for [Activate horizontal

scroll function], you can change the direction in which

the screen scrolls when you trace the Touch Pad clock-

wise.

• When check mark is added: Scroll left

• When check mark is removed: Scroll right

Set scroll speed You can change the scroll speed.

A. Width of the scroll

area

By dragging the inner circumference of the starting area,

you can change the width of the scroll area (A) in five

stages.

You can also change the width by sliding the [Scroll acti-

vation area] slide bar.

B. Vertical and

horizontal scroll

scroll area

You can change the scroll area (B) by dragging border

of the vertical and horizontal scroll scroll area. The max-

imum starting area for the horizontal scroll is half the cir-

cumference.

Using the Touch Pad

2Remove the check mark from [Activate Touch Pad function] in [General settings], and

then click [OK].

3Click [start] - [Control Panel] - [Printers and Other Hardware] - [Mouse] - [Device Set-

tings].

4Click the device name (e.g., Synaptics TouchPad V6.2) in [Devices], then click [Settings].

5Click [Virtual Scrolling], add a check mark for the scroll functions you want to use, then

click [OK].

6Click [OK] at [Mouse Properties].

NOTE

zBecause the Touch Pad utility and the Virtual Scrolling function both offer scrolling

functions that use the Touch Pad, these two features cannot be used simultaneously.

If you try to use them at the same time, a message may be displayed asking you if

you want to enable the Touch Pad utility.

• To use the Touch Pad utility: Click [Yes]. The Virtual Scrolling function will be

disabled.

• To use the Virtual Scrolling function: Click [No].

You can uninstall the Touch Pad utility using the following procedure.

AClick or on the notification area, and then click [Exit].

BClick [start] - [Control Panel] - [Add or Remove Programs] - [Touch Pad Utility], and then click [Remove] to remove

the program.

zTo begin using the Touch Pad utility again:

AClick [start] - [Control Panel] - [Add or Remove Programs].

When [Touch Pad Utility] is not displayed, perform the following procedures from step B.

When [Touch Pad Utility] is displayed, perform the following procedures from step C.

BInput [c:\util\wheelpad\setup.exe] in [start]-[Run] and then click [OK].

Follow the on-screen instructions.

CConduct steps 3to 4(above).

DClick [Virtual Scrolling], remove a check mark from [Enable vertical scrolling] and [Enable horizontal scrolling], then

click [OK].

EClick [OK] at [Mouse Properties].

FClick [start] - [All Programs] - [Panasonic] - [Touch Pad Utility settings].

GClick [General settings], add a check mark for [Activate Touch Pad function], then click [OK].

Otros manuales para CF-W8 Series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de De oficina de Panasonic

Panasonic

Panasonic Toughbook CF-18 Series Manual de usuario

Panasonic

Panasonic CF-W2 Series Manual de usuario

Panasonic

Panasonic Toughbook CF-18 Series Diagrama de cableado

Panasonic

Panasonic FZ-55 Series Manual de usuario

Panasonic

Panasonic CF-52 Series Manual de usuario

Panasonic

Panasonic Toughbook CF-28 Series Diagrama de cableado

Panasonic

Panasonic CF-74 Series Diagrama de cableado

Panasonic

Panasonic Toughbook CF-47 Series Manual de usuario

Panasonic

Panasonic Toughbook CF-25LJF8EAM/E Manual de usuario

Panasonic

Panasonic CF-17 Manual de usuario

Panasonic

Panasonic CF-54 Series Manual de usuario

Panasonic

Panasonic CF-17 Manual de usuario

Panasonic

Panasonic JS-970 Series Manual de usuario

Panasonic

Panasonic CF-195RAAXBE Manual de usuario

Panasonic

Panasonic CF-73JCLTXKM - Toughbook 73 - Pentium M 1.6... Manual de usuario

Panasonic

Panasonic CF-W2 Series Manual de usuario

Panasonic

Panasonic Touchbook CF-50 Series Manual de usuario

Panasonic

Panasonic ToughBook CF-72 Series Diagrama de cableado

Panasonic

Panasonic CF-SV Series Manual de usuario

Panasonic

Panasonic CF-52AJCBUAE Manual de usuario

Panasonic

Panasonic FZ-40 Manual de usuario

Panasonic

Panasonic Toughbook CF-48 Series Manual de usuario

Panasonic

Panasonic CF-T7 Series Manual de usuario

Panasonic

Panasonic CF-51 B Series Diagrama de cableado

Manuales populares de De oficina de otras marcas

HP m9060n - Pavilion - Elite Hoja de especificaciones

Asus

Asus E210 Series Manual de usuario

Dell

Dell Inspiron 600m Manual de usuario

Dell

Dell Inspiron 3662 Manual de usuario

TotalFlow

TotalFlow uFLO Manual de usuario

HP Presario SV7000 - Desktop PC Manual de usuario

HP ProDesk 400 G5 Manual

Logitech

Logitech MK320 Manual de usuario

Dell

Dell XPS 730 H2C Manual de usuario

Sony

Sony Vaio Series Manual de usuario

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manual de usuario

Alto

Alto MD 250 Manual de usuario

Lenovo

Lenovo ThinkCentre Edge 72 Manual

Lenovo

Lenovo ThinkStation D20 Manual

Arbor Technology

Arbor Technology FPC-7800 Series Manual de usuario

Sony

Sony VAIO VGX-TP1 Series Manual de usuario

Asus

Asus Eee Box B204 Manual de usuario

Dell

Dell Optiplex 9010 All In One Manual de usuario
