This manual contains supplementary instructions regarding the use of the

computer. It explains the cases where the operation of the computer differs from

that in the Operating Instructions.

Your computer is equipped with the HSPA modem enabling you to communicate

using radio frequencies.

Contents

Precautions .................................................................. 2

Description of Parts..................................................... 3

Inserting/Removing a SIM Card.................................. 4

Installing the Software................................................. 6

Disabling/Enabling Wireless Communication........... 8

Troubleshooting........................................................... 9

Speciﬁcations............................................................... 9

Appendix..................................................................... 10

NOTE:Useful and helpful information.

CAUTION:Condition that may result in minor or moderate injury.

(Start) - [All Programs] :

Click (Start), and then click [All Programs].

[start] - [Run]: Click [start], and then click [Run].

You may need to double-click in some cases.

: Page in these Supplementary Instructions or in the

Reference Manual for the computer.

: Reference to the on-screen manuals.

Some of the illustrations in this manual may differ slightly in shape from the

actual items in order to make the explanation easier to understand.

About the abbreviations in this manual, refer to the table on page 10.

Terms and illustrations in this Manual

Supplementary Instructions

for HSPA Modem

Personal Computer

Model No. CF-H1 Series

Declaration of Conformity (DoC)

“Hereby, Panasonic Corporation declares that this Personal

Computer is in compliance with the essential requirements and

other relevant provisions of the Directive 1999/5/EC.”

Hint:

If you want to get a copy of the original DoC of our above mentioned products, please

contact our web address: http://www.doc.panasonic.de

Authorised Representative:

Panasonic Testing Centre

Panasonic Marketing Europe GmbH

Winsbergring 15, 22525 Hamburg, Germany

Network connection of WWAN.

This device is intended for connection to the following public network;

- Wireless public network; HSPA/UMTS, EDGE/GPRS,

Precautions

Description of Parts

Except the followings, refer to the Operating Instructions for the computer.

SIM Card Slot (in

the Battery 1 Case)

( page 4)

Antenna

Inserting/Removing a SIM Card

Before using the HSPA modem, set a SIM card to the SIM card slot.

CAUTION

Be sure to shut down the computer before inserting or removing the SIM

card.

1Turn off the computer.

2Open the Battery 1 cover and

remove the battery pack.

3Inserting a SIM card

AInsert the SIM card into the SIM

card slot with the contact side facing

upward and with the cut corner

oriented as shown in the illustration.

CAUTION

Do not insert the SIM card

upside down.

SIM card Contact

Removing a SIM card

A Push the card.

It will come out of the slot a little bit.

4Insert the battery pack and close

the Battery 1 cover.

B Pull the card all the way out and

remove the SIM card.

Installing the Software

The steps below must be taken before using the HSPA modem.

1Turn off the computer and set the computer to the Cradle.

2Connect the CD/DVD drive and an external keyboard to

the Cradle.

3Turn on the computer, and run the Setup Utility by

pressing

Del

while [Panasonic] boot screen is

displayed.

If [Enter Password] is displayed, input the Supervisor Password.

4Select the [Advanced] - [Wireless Conﬁguration] menu,

and set [Wireless WAN] to [Enabled].

5Set [Wireless LAN] to [Enabled].

6Save the settings and exit the Setup Utility.

7Log on to Windows as an administrator.

If the [Found New Hardware Wizard] screen is displayed, click [Cancel] to

close the screen.

8Install the Wireless WAN software by following

procedures.

ASet the Wireless WAN (HSPA) Software CD-ROM into the CD/DVD

drive.

B<Model with Windows XP>

Click [start] - [Run], enter “x:*1\SETUP\SETUP. exe”, and click [OK].

Click (Start) and enter “x:*1\SETUP\SETUP. exe” in [Start Search],

and press

Enter

*1“x:” is the drive letter of the CD/DVD drive. Change this to match the drive

letter on your own computer.

CFollow the on-screen instructions, and install the software.

Uninstalling the software

Click [start] - [Control Panel] - [Add or Remove Programs] - [Wireless WAN

Software Installer for Gobi(TM)], and then click [Remove] to uninstall the

software.

Click (Start) - [Control Panel] - [Uninstall a program] - [Wireless WAN

Software Installer for Gobi(TM)], and then click [Uninstall] to uninstall the

software.

Disabling/Enabling Wireless Communication

The Wireless Switch Utility icon appears in the notiﬁcation area when the

computer is turned ON. It shows the status of wireless devices.

: Indicates that the wireless devices are enabled.

: Indicates that the wireless devices are off.

(gray indication): Indicates that the wireless devices have been disabled in

the Setup Utility.

( Reference Manual for the computer “Disabling/Enabling Wireless

Communication”)

To enable or disable particular wireless devices

1Click the Wireless Switch Utility icon to show the pop-

up menu.

2Select ON or OFF for the device you want to enable or

disable.

To check the wireless communication status

1Place the cursor over the Wireless Switch Utility icon

on the notiﬁcation area.

A tool tip appears.

NOTE

zTo use wireless WAN, set [Wireless WAN] to [Enable] (default) in the [Advanced]

- [Wireless Conﬁguration] menu of the Setup Utility.

Troubleshooting

Cannot

communicate.

•Conﬁrm that [Wireless WAN] is set to [Enabled] in the

[Advanced] menu of the Setup Utility.

•Use the Wireless Switch Utility and conﬁrm that the wireless

WAN is on.

•Conﬁrm that the SIM card is inserted correctly.

Data Communication HSUPA Category 5, 2.0 Mbps

HSDPA Category 8, 7.2 Mbps

UMTS 3GPP Release 5

EDGE/

GPRS

MultiSlot Class 12

Other Features SMS Mobile Originated SMS (MO-SMS)

Mobile Terminated SMS (MT-SMS)

FAX No Support

Voice No Support

SIM 1.8/3V SIM Support

Speciﬁcations

Abbreviations

EDGE Enhanced Data rates for Global Evolution

GPRS General Packet Radio Service

HSDPA High Speed Downlink Packet Access

SIM Subscriber Identity Module

SMS Short Message Service

UMTS Universal Mobile Telecommunications System

HSPA High Speed Packet Access

HSUPA High Speed Uplink Packet Access

Appendix
