Operating Instructions

SDI Output Card

Model No. AW-HHD100N

Before operating this product, please read the instructions carefully and save this manual for future use.

VQTB0340-1

AW-HHD100N(VQTB0340-1)英.indd 1 2008/09/02 10:50:02

責任者担当者

2008 年 月 日

法規

船

本

難

波

関

口

919

indicates safety information.

Safety precautions

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER SERVICEABLE PARTS INSIDE.

REFER TO SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol,

within an equilateral triangle, is intended to

alert the user to the presence of uninsulated

“dangerous voltage” within the product’s

enclosure that may be of sufficient magnitude

to constitute a risk of electric shock to

persons.

The exclamation point within an equilateral

triangle is intended to alert the user to the

presence of important operating and

maintenance (service) instructions in the

literature accompanying the appliance.

WARNING:

• TO REDUCE THE RISK OF FIRE OR ELECTRIC

SHOCK, DO NOT EXPOSE THIS APPARATUS TO

RAIN OR MOISTURE.

• THE APPARATUS SHALL NOT BE EXPOSED TO

DRIPPING OR SPLASHING AND THAT NO

OBJECTS FILLED WITH LIQUIDS, SUCH AS

VASES, SHALL BE PLACED ON THE

APPARATUS.

CAUTION:

TO REDUCE THE RISK OF FIRE OR SHOCK

HAZARD AND ANNOYING INTERFERENCE, USE

THE RECOMMENDED ACCESSORIES ONLY.

CAUTION:

TO REDUCE THE RISK OF FIRE OR SHOCK

HAZARD, REFER CHANGES OF SWITCH

SETTINGS INSIDE THE UNIT TO QUALIFIED

SERVICE PERSONNEL.

AW-HHD100N(VQTB0340-1)英.indd 2 2008/09/02 10:50:03

This Class A digital apparatus complies with Canadian

ICES-003.

Cet appareil numérique de la class A est conforme à

la norme NMB-003 du Canada.

For CANADA

indicates safety information.

FCC Note:

This equipment has been tested and found to comply

with the limits for a class A digital device, pursuant to

Part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful

interference when the equipment is operated in a

commercial environment. This equipment generates,

uses, and can radiate radio frequency energy, and if

not installed and used in accordance with the

instruction manual, may cause harmful interference

to radio communications. Operation of this equipment

in a residential area is likely to cause harmful

interference in which case the user will be required to

correct the interference at his own expense.

Warning:

To assure continued FCC emission limit compliance,

the user must use only shielded interface cables when

connecting to external units. Also, any unauthorized

changes or modifications to this equipment could void

the user’s authority to operate it.

AW-HHD100N(VQTB0340-1)英.indd 3 2008/09/02 10:50:03

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in

accordance with the manufacturer’s instructions.

8) Do not install near any heat sources such

as radiators, heat registers, stoves, or other

apparatus (including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized

or grounding-type plug. A polarized plug has two

blades with one wider than the other. A grounding-

type plug has two blades and a third grounding

prong. The wide blade or the third prong are

provided for your safety. If the provided plug does

not fit into your outlet, consult an electrician for

replacement of the obsolete outlet.

10) Protect the power cord form being walked on or

pinched particularly at plugs, convenience

receptacles, and the point where they exit from

the apparatus.

11) Only use attachments/accessories specified by

the manufacturer.

12) Use only with the cart, stand, tripod,

bracket, or table specified by the

manufacturer, or sold with the

apparatus. When a cart is used, use

caution when moving the

cart/apparatus combination to avoid

injury from tip-over.

13) Unplug this apparatus during lightning storms or

when unused for long periods of time.

14) Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has

been damaged in any way, such as power-supply

cord or plug is damaged, liquid has been spilled or

objects have fallen into the apparatus, the

apparatus has been exposed to rain or moisture,

does not operate normally, or has been dropped.

Read these operating instructions carefully before using the unit. Follow the safety instructions on the unit and the

applicable safety instructions listed below. Keep these operating instructions handy for future reference.

IMPORTANT SAFETY INSTRUCTIONS

indicates safety information.

AW-HHD100N(VQTB0340-1)英.indd 4 2008/09/02 10:50:03

Contents

Accessory ........................................................................... 5

Preface ............................................................................... 5

Warning/caution for safety .................................................. 6

Precautions ......................................................................... 7

Major operating controls and their functions ....................... 8

Mounting ............................................................................. 9

Appearance ...................................................................... 10

Specifications ................................................................... 11

Accessory

Operating Instructions ............................ 1

Preface

This product is an option card which can be installed in

the option slot of the AW-HE100N HD integrated camera.

It is made for HD-SDI/SD-SDI signal output and is

equipped with two BNC output jacks (dual channel).

AW-HE100N settings can be used to switch between

HD-SDI and SD-SDI output.

The AW-HHD100N can be installed only to the

AW-HE100N.

Note

AW-HHD100N(VQTB0340-1)英.indd 5 2008/09/02 10:50:03

Warning/Caution for safety

WARNING

Refer all servicing to qualified personnel

To reduce the risk of electric shock, don’t remove cover

or back, unless you are a qualified personnel. Refer all

mountings, connections, servicing to qualified service

personnel.

No water or moisture inside

Do not let water or moisture into the product, or expose it

to moisture, to prevent a fire and electric shock.

If you see smoke or smell an odor from the product, if

water or other foreign matter gets inside, if it is damaged

by dropping, or if you find anything wrong with it,

immediately stop using it.

Do not disassemble or modify the product to prevent

a fire and electric shock.

CAUTION

Do not drop the product, do not expose it to strong shock,

or do not step on it, to prevent a fire and injuries.

Do not install the product at a place full of moisture and

dust, which may cause a fire and electric shock.

AW-HHD100N(VQTB0340-1)英.indd 6 2008/09/02 10:50:03

Precautions

Power off before connecting or disconnecting cables

Before plugging or unplugging the cables, be sure to

switch power off.

Handle carefully.

Do not drop the product, or subject it to strong shock or

vibration. This is important to prevent trouble.

Avoid humidity and dust.

Avoid using the product at a humid, dusty place because

much humidity and dust will cause damage to the parts

inside.

Operating temperature range

Avoid using the product at a cold place below 32 °F

(0 °C) or at a hot place above 104 °F (+40 °C) because

extremely low or high temperature will adversely affect

the parts inside.

When the SDI output card is to be discarded at the

end of its service life, ask a specialized contractor

to dispose of it properly in order to protect the

environment.

Caution

AW-HHD100N(VQTB0340-1)英.indd 7 2008/09/02 10:50:03

Major operating controls and their functions

1SDI output connector [SDI OUT1, SDI OUT2]

Serial digital component signal can be output.

AW-HHD100N(VQTB0340-1)英.indd 8 2008/09/02 10:50:03

Mounting

Be sure to ask your dealer, where you purchased the

product, for mounting.

Unplug the AW-HE100N power cord and all the cables

before performing the installation work.

Before handling the card, touch a metal part of the

camera to discharge the static from the human body.

An anti-static wrist strap is recommended for added

safety.

If you touch the card while you are still charged with

static, it may cause trouble.

Keep the metal parts of the card free of contact with

other metal parts.

Notes

1Remove the 2 screws from the option slot cover.

2Remove the option slot cover.

3Line up the card with the guide rails and insert it.

(Make sure that it is inserted all the way.)

4Fasten the card in place with the 2 setscrews.

Card setscrews

Option slot cover

SDI Output Card

AW-HHD100N

HD Integrated Camera

AW-HE100N

AW-HHD100N(VQTB0340-1)英.indd 9 2008/09/02 10:50:03

Appearance

Unit: inch (mm)

6-1/4 (159)

1-1/16 (26.5) 5/16 (8) 4-3/8 (111)

AW-HHD100N(VQTB0340-1)英.indd 10 2008/09/02 10:50:04
