Panasonic WV-Q161 Manual de usuario

Operating Instructions

Inner Cover

Model No. WV-Q161

Before attempting to install this product,

please read these instructions carefully

and save this manual for future use.

The model number is abbreviated in some descriptions

in this manual.

Inner cover

Put on until a click is

heard

Cover

Hook

Be sure to read "Precautions" before installation.

How to engage the inner cover

Slide the covers located on the both lateral sides of the

camera and put the inner cover on the camera until the

hooks inside the inner cover are engaged in the holes of

the camera (until a click is heard).

Important:

• Put the inner cover down on the camera until the

outside cover of the camera cannot be seen from

the opening (from which the camera lens is visible)

of the inner cover.If this engagement work is not

successfully performed, the inner cover may be

removed or the hidden part at the top of the screen

may become larger in the wide mode.

• When the inner cover with this product and a dome

housing equipped is mounted, the clearance

between this product and the housing shall be

2mm or more.

This product is an inner cover that is exclusively

designed to be used with the network cameras. Refer to

the catalog or the installation guide of the camera for

supported cameras.

This inner cover is a component to lower the reflection

of the dome part of the network camera.

Preface

• Be sure to engage the inner cover onto the

camera main body before installation of the

camera main body.

Failure to observe this may cause a drop resulting in

injury or accidents.

• Refer installation work to the dealer.

Installation work requires skills and experiences.

Failure to observe this may cause fire, electric

shock, injury, or damage to the product. Be sure to

consult the dealer.

Precautions

Installations

Clearance of 2 mm

or more

How to remove the inner cover

• Press the inner cover from the front and rear sides

inward (at the same vertical position as the hooks)

to bend the cover and remove the inner cover from

the camera.

Ambient temperature : –10 °C to +50 °C

{14 °F to 122 °F}

Dimensions : ø117 mm × 79 mm (H)

{ø4-19/32 inches × 3-1/8 inches (H)}

Mass : Approx. 50 g{0.11 lbs.}

Finish : ABS resin Lusterless black

Specifications

Press from the front and rear sides

inward to bend

Operating Instructions (this document) 1 pc.

Standard Accessories

For U.S. and Canada:

Panasonic i-PRO Sensing Solutions Corporation

of America

800 Gessner Rd, Suite 700 Houston, TX 77024

https://www.security.us.panasonic.com/

Panasonic Canada Inc.

5770 Ambler Drive, Mississauga, Ontario, L4W 2T3 Canada

1-877-495-0580

https://www.panasonic.com/ca/

Ns0817-1109 PGQX2214YA Printed in China

For Europe and other countries:

Panasonic Corporation

http://www.panasonic.com

Panasonic i-PRO Sensing Solutions Co., Ltd.

Fukuoka, Japan

Authorised Representative in EU:

Panasonic Testing Centre

Panasonic Marketing Europe GmbH

Winsbergring 15, 22525 Hamburg, Germany
