Digital Color Imaging Systems

Operating Instructions

Before operating this machine, please carefully read this manual

and keep this documentation in a safe place for future reference.

(Illustration shows optional accessories that may not be installed on your machine.) English

(For Copier)

Model No. DP-C405 / C305 / C265

Operating Instructions

The following Operating Instruction manuals are included with this machine. Please refer to the appropriate manual

and keep all manuals for future reference. If you lose the manual, contact the authorized Panasonic dealer.

Accessories

Operating Instructions (For Setting Up)

This manual contains essential information for setting

up the machine.

Operating Instructions (For Basic Operations)

This manual contains essential information for proper

operation of the machine.

It describes basic Copy, Print, Facsimile/Internet Fax,

Scan/Email, and other functions.

For a more detailed explanation of each function, please

refer to the Operating Instruction manuals included on

two CD-ROMs as illustrated below.

Operating Instructions CD

Contains manuals with detailed information for Copy,

Facsimile/Internet Fax, Scan/Email functions, Function

Parameters, and User Authentication.

Document Management System CD

Contains the Panasonic Document Management

System Application software, and manuals with detailed

information for the Print function and Panasonic

Document Management System Application software.

Operating Instructions CD

Copy Function

Describes how to make a Color Copy with

creative features.

Facsimile and Internet Fax

Function

(The Facsimile function is available when

the optional G3 Fax Communication

Board is installed.)

Describes how to send/receive a

Facsimile/Internet Fax, and describes the

course of action to take when a trouble

message appears, etc.

Scan and Email Function

Describes how to scan and how to send

Email through the machine.

Function Parameters

Describes how to change the default

settings of each function using the Control

Panel of the machine.

User Authentication

Describes how to enable and use the

User Authentication function.

Document Management System CD

Print Function

Describes how to print with color and

change the default printer settings, and

describes the course of action to take

when a problem message appears, etc.

Application Software

Describes how to use the application

software.

Ex: Panafax Desktop, Fax Driver, Quick

Image Navigator, Device Monitor/

Device Explorer, Network Config/

Add Editor

Conventions

Icons

The following icons are used in this manual.

Notation

The following notations are used in this manual.

Icon Description

Indicates important information that must be read in detail.

Indicates reference information.

Notation Description

For Keys and Buttons Hard buttons on the Control Panel are depicted as **** key, and soft buttons on the Touch

Panel Display are depicted as “xxx”.

Ex:

Press the Start key and select “More Menus”.

Table of Contents

Chapter 1 Basic Menu Features

Basic Operation Procedure ................................................................................................. 6

Selecting the Color Mode .................................................................................................... 8

Full Color Mode............................................................................................ “Full Color”9

Black Mode ......................................................................................................... “Black”9

2 Color Mode.....................................................................................................“2 Color”10

1 Color Mode.....................................................................................................“1 Color”12

New Color Registration ............................................................................“Add Custom”14

Selecting Original Type and Adjusting the Density........................................ “Quality Adj.”16

Registering Quality Preset.........................................................................................“Save”18

Using Quality Preset............................................................................................... “Recall”20

Quality Adjusting........................................................................................ “More Settings”22

Background Removal............................................................... “Background Removal”24

BleedThrough Prevention ................................................. “BleedThrough Prevention”25

Tint ..........................................................................................................................“Tint”26

Contrast.......................................................................................................... “Contrast”27

Sharpness ...................................................................................................“Sharpness”28

Saturation.................................................................................................... “Saturation”29

Color Balance........................................................................................“Color Balance”30

Proof Copying.................................................................................................... “Proof Set”32

Confirming/Editing the Selected Copy Features................................... “Confirm Settings”33

Storing a Job in Memory................................................................................“Preset Jobs”34

Recalling a Preset Job Stored in Memory ........................................................................... 35

Checking the Waiting to Copy Job ............................................................ “Output Queue”36

Displaying a List of All Jobs ............................................................................................ 36

Displaying a List of Copy Jobs ........................................................................................ 36

Deleting Copy Jobs ......................................................................................................... 37

Completion Notice ............................................................................. “Completion Notice”38

Chapter 2 More Menus Features

2-Sided Copy Mode................................................................. “2-Sided / Original->Copy”40

Basic Operation for the 2-Sided Copy Mode................................................................... 40

Copying 2-Sided Original(s) onto Two Separate Sheets .....................................“2 -> 1”41

Copying Facing Page Original to Two Separate Sheets................................... “2 Page”42

From 1-Sided Originals to 2-Sided Copies Using Saddle Stitch (Booklet)....... “Booklet”43

Copying Mixed Size Originals from the ADF.......................................“Multi-Size Feed”45

Copying Special Originals (Thin Paper, etc.) from the ADF ........“Job Build and SADF”47

Sort Mode..................................................................................................... “Sort / Finish”50

Zoom Mode............................................................................................... “Zoom / Effects”52

Variable Ratios .................................................................................................... “Zoom”52

Auto Zoom..................................................................................................“Auto Zoom”54

Effect Modes............................................................................................. “Zoom / Effects”56

Setting a Blank Edge............................................................................................ “Edge”56

Eliminating Dark Inner Binding Shadows .............................................................“Book”58

Shifting Image to Right, Left, Up, or Down ........................................................ “Margin”59

Copying Mirror Image......................................................................................... “Mirror”61

Copying with Stamping..................................................................................“Stamping”62

Centering...................................................................................................... “Centering”71

Image Repeat........................................................................................ “Image Repeat”72

Copying Inverse Image..................................................................................... “Inverse”73

Insertion Modes ................................................................................... “Insertion/Overlay”74

Adding a Cover Page to Copies ..........................................................................“Cover”74

Inserting Blank/Copied Pages Between Copies ................................... “Page Insertion”76

Inserting Blank Pages Between Transparency Films ....... “Transparency Interleaving”78

Overlay Modes..................................................................................................................... 80

Overlaying an Image onto the Copies ..............................................................“Overlay”80

Overlay Copying with Registered Image ................................................“Form Overlay”83

File Edit............................................................................................................“File Edit”85

Chapter 3 Other Features

Making Copies with the ADF Opened.................................................................................. 90

Digital Skyshot Mode....................................................................................................... 90

Manual Skyshot Mode..................................................................................................... 91

Reserving the Next Copy Job while the Current Copy Job is Progressing ....

“Reverse a Job”92

Interrupt the Current Copy Jobs to Make an Urgent Copy .................................................. 93

Chapter 4 Appendix

Combined Copy Functions .................................................................................................. 94

Index .................................................................................................................................... 96

Chapter 1 Basic Menu Features

Chapter 1

Basic Menu Features

Basic Operation Procedure

The machine automatically detects original(s) and decides on the Copy Size and Color mode to use. If

the detection fails, manually set the settings.

Place original(s).

zRefer to Placing Originals (Copy) in the

Operating Instructions (For Basic

Operations) of provided booklet.

Press the Copy key if the machine is

set to other function mode.

Select the required settings if

necessary.

zThe original size is detected and a

corresponding Copy Size is automatically

selected.

zIf the orientation of original does not match

the orientation of copy paper, the image of

original is rotated automatically and copied.

zWhen copying 8.5" x 11" size originals,

selecting 8.5" x 11" for the Copy Size

accelerates the continuous copying speed.

If the orientation is not the same for both

settings, the copied image is automatically

rotated by 90 degrees.

zFor more details of the Basic Menu screen,

refer to Basic Menu Features (see pages 8

to 38).

zWhen setting other features, refer to More

Menus Features (see pages 40 to 88).

Ex: 2-Sided Copy, Sort / Finish, Zoom/

Effects, etc.

Face up. Up to 100 sheets (20 lb/

Letter)

Face down. Align with top left

corner. Close ADF.

Chapter 1 Basic Menu Features

Enter the desired number of copies.

(Up to 999)

zWhen inputting a number (4 to 8 digits) with

the optional Fax Communication Board

installed, the machine automatically

interprets it as a telephone number,

switches to the Fax mode, and displays the

Number Pad screen.

zThe number of digits interpreted as a fax

number can be set from 4 to 8 digits in the

Function Parameter “118 Fax Function

Detect” (Fax/Email Settings > Fax

Parameters). For more details, refer to Fax/

Email Settings in the Operating Instructions

(For Function Parameters) of provided CD-

ROM.

Press the Start key.

zAfter finishing copying, press the Reset key to

return to the initial screen of the currently active

mode.

Chapter 1 Basic Menu Features

Selecting the Color Mode

You can copy in the Color mode selected by the machine, or select the Color mode manually.

zThe default Color mode settings can be changed. Refer to Copier Settings (Key Operator Mode) in the

Operating Instructions (For Function Parameters) of provided CD-ROM.

zThe manually selected Color mode settings will return to the default settings under the following conditions.

- If the Reset key is pressed.

- If Auto Reset Time interval has lapsed (default = 1 min).

- If the power is turned OFF.

Place original(s).

zRefer to Placing Originals (Copy) in the

Operating Instructions (For Basic

Operations) of provided booklet.

Press the Copy key if the machine is

set to other function mode.

Select “Quality Adj.”.

Select the desired Color mode, and

then select “OK”.

Enter the desired number of copies.

Press the Start key.

zAfter finishing copying, press the Reset key to

return to the initial screen of the currently active

mode.

Full color Monochrome

Full Color

Monochrome

2 Color

1 Color

Monochrome

1 Color

Ex: Full Color

•Auto:

The color original is copied in Full

Color and the monochrome

original is copied in black and

white by automatically detecting

the original’s color.

•Black (Monochrome) (see page 9)

•Full Color (see page 9)

•2 Color (see page 10)

•1 Color (see page 12)

Chapter 1 Basic Menu Features

Full Color Mode

Color original can be copied in Full Color.

Select “Full Color”, and then select

“OK”.

zTo display this screen, refer to steps 1 to 3 of

Selecting the Color Mode (see page 8).

zFor the following procedure, refer to steps 5

to 6 of Selecting the Color Mode (see page

8).

Black Mode

Color and monochrome originals can be copied

in black and white.

Select “Black”, and then select “OK”.

zTo display this screen, refer to steps 1 to 3 of

Selecting the Color Mode (see page 8).

zFor the following procedure, refer to steps 5

to 6 of Selecting the Color Mode (see page

8).

Full Color Full Color Full Color

Black & White

Chapter 1 Basic Menu Features

2 Color Mode

Color original can be copied in 2 colors, which can be achieved by using black and another specified

color.

The specified color can be selected from the basic colors (red, green, blue, yellow, magenta, and cyan)

and the registered colors.

zWhen the 2 Color mode is selected, the Original Type setting selection is not available.

Select “2 Color”.

zTo display this screen, refer to steps 1 to 3 of

Selecting the Color Mode (see page 8).

Select “Change Color”.

zThe color and the specified name are

displayed.

Select a color from the basic colors or

custom colors, and then select “OK”.



When selecting a color from the basic colors



When selecting a color from the custom colors

zWhen registering a custom color, refer to

New Color Registration (see page 14).

Ex: When copying a full color original in cyan

and black.

Otros manuales para Workio DP-C405

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Impresora todo en uno de Panasonic

Panasonic

Panasonic KXFLB881 - Network Multifunction Laser... Manual de usuario

Panasonic

Panasonic KX-MC6040 - Color Laser Multi-Function... Manual de instrucciones

Panasonic

Panasonic KX-MB2000 Manual de usuario

Panasonic

Panasonic DA-MC700 Manual de usuario

Panasonic

Panasonic DP-2010E Manual de usuario

Panasonic

Panasonic Workio DP-8016P Manual de usuario

Panasonic

Panasonic DP-MB300 Manual de usuario

Panasonic

Panasonic KX-MC6260E Manual de usuario

Panasonic

Panasonic KX-FLM650 Manual de usuario

Panasonic

Panasonic Workio DP-C262 Manual de instrucciones y seguridad

Panasonic

Panasonic KX-MB1500 Manual de usuario

Panasonic

Panasonic KX-MB2090CXW Manual de usuario

Panasonic

Panasonic DP-MB310EU Manual de usuario

Panasonic

Panasonic Workio DP-3030 Manual de usuario

Panasonic

Panasonic KX-MC6040 - Color Laser Multi-Function... Manual de usuario

Panasonic

Panasonic KX-FLB851 - All-in-One Flatbed Laser Fax Manual de lista de piezas

Panasonic

Panasonic DP-8020E Manual de usuario

Panasonic

Panasonic DP-MB340 Manual de usuario

Panasonic

Panasonic FP-D355 Manual de usuario

Panasonic

Panasonic KX-MB3020 - Laser Multi-Function Printer Manual de instrucciones

Panasonic

Panasonic DP-8020E Manual de usuario

Panasonic

Panasonic Workio DP-1820P Manual de usuario

Panasonic

Panasonic Workio DP-C405 Manual de usuario

Panasonic

Panasonic KX-MB2010BL Manual de funcionamiento

Manuales populares de Impresora todo en uno de otras marcas

Triumph Adler

Triumph Adler DC 2016 Manual

Epson

Epson WorkForce WF-2510 Guía del usuario

Epson

Epson Stylus Scan 2000 Manual de instalación y operación

Epson

Epson PictureMate Snap PM 240 Manual de instrucciones

Konica Minolta

Konica Minolta bizhub C35 Manual de usuario

Brother

Brother MFC-J430w Manual de usuario

Konica Minolta

Konica Minolta BIZHUB 558 Manual de usuario

Lexmark

Lexmark MX710 Series Manual

Brother

Brother MFC-9760 Manual de usuario

Lexmark

Lexmark XC8155 Manual de usuario

Lexmark

Lexmark X642E Manual de usuario

Sharp

Sharp MX-2310U Guía

Aficio

Aficio 200 Manual de usuario

Canon

Canon ImageCLASS 2300 Manual

Ricoh

Ricoh Pro C900 Manual de usuario

Lexmark

Lexmark X925 Manual de usuario

Brother

Brother Business Smart MFC-J4510dw Manual de usuario

Epson

Epson Stylus CX8400 Series Manual de usuario
