oticon HIT CIC Manual de usuario
CIC, MIC, ITC, HS/LP
INSTRUCTIONS FOR USE
HIT PRO/HIT
Thank you
Thank you for choosing our product as your means to better hearing.
To support your efforts, we have put great care and attention into making sure that your
new hearing instruments are of the highest quality and that they are easy to use and
maintain.
We recommend that you read this manual carefully to achieve the maximum benefit from
your new hearing instruments.
Congratulations on your decision to actively improve your hearing with today’s most
advanced hearing technology in the market.
Contents
Instrument View CIC/MIC 5a
Instrument View ITC 5b
Instrument View HS/LP 5c
Changing batteries 7
Turning your instruments ON and OFF 9
Inserting your hearing instruments 10
Programs (Optional) 11
Stand-by – (only for instruments with push-button) 13
Volume Control (Optional for ITE only) 14
Telecoil (Optional) 15
AutoPhone (Optional) 16
Caring for your hearing instruments 18
Seven easy steps to better hearing 23
Common problems and their solutions 28
Warnings Yellow Pages
IMPORTANT NOTICE
Please familiarize yourself with the entire contents of this booklet before using your
hearing instruments. It contains instructions and important information about the use
and handling of your hearing instruments and batteries.
5a
Instrument View CIC/MIC
Microphone opening Battery door
Ventilation opening
Sound outlet + wax
protection system
Ventilation opening
Removal string
Battery size: 10
5b
Instrument View ITC
Microphone openings
Battery door Ventilation opening
Ventilation opening
Sound outlet + wax
protection system
Push-button (Optional)
Battery size: 312
5c
Instrument View HS/LP
Battery size: 312
Microphone openings Push-button (Optional) Sound outlet +
wax protection system
Ventilation openingVolume Control Wheel
(Optional)
Battery door
7
Changing batteries
The correct battery size appears in the instrument overview in the first section of this
document.
A worn out battery should be removed immediately and disposed of according to local
regulations.
When the battery power is low, you will hear 2 beeps. This pre-warning starts when
the battery has only a few hours of operation left. The pre-warning will be repeated
in moderate intervals to indicate it is time to change the battery.
To replace the battery, follow these instructions:
Open the battery door with your fingernail and remove•
the old battery. The old battery may be removed by
using the magnetic end of your MultiTool.
Use the magnet at the end of the tool to assist in handling the battery.
MultiTool
8 9
Remove the sticky label from the + side of the new battery.•
Insert the new battery so that its + marking faces the + sign•
printed on the battery door.
Close the battery door. If you feel any resistance, you may•
have inserted the battery incorrectly. Reinsert the battery
and try again.
It will take a few seconds before the battery works to full capacity.
Turning your instruments ON and OFF
Turn ON your hearing instrument by closing the battery door
completely with the battery in place.
When the battery door is closed the instrument will start up
by playing a jingle. This indicates that the battery is working
and the instrument is operating.
Turn OFF your hearing instrument by opening the battery
door with your finger nail.
To preserve the battery, make sure your hearing instrument
is switched off when you are not wearing it.
ON
OFF
IMPORTANT NOTICE
Open the battery compartment fully to allow air to circulate whenever you are not using
your hearing instrument, especially at night!
10 11
Inserting your hearing instruments
Place the tip of the hearing instrument in your ear canal.
Gently pull your earlobe and push the hearing instrument
into the ear canal, twisting slightly if necessary, following
the natural contour of the ear canal.
DO NOT use the battery door as a handle to insert or remove
your instruments. It is not designed for this purpose.
Programs (Optional)
Your hearing instruments may have a push-button for switching between different programs.
Push briefly on the button to switch between programs.
Your hearing instrument can have up to 4 different programs. When switching between
the different programs, your hearing instrument will beep. The number of beeps will
indicate which program you are using.
eOne beep, when you switch to program 1
ee Two beeps, when you switch to program 2
eee Three beeps, when you switch to program
eeee Four beeps, when you switch to program 4
12 13
Below you can see a description of the programs available in your hearing instrument.
Prg. 1:
Prg. 2:
Prg. 3:
Prg. 4:
To be filled out by your Hearing Care Professional.
Stand-by – (only for instruments with push-button)
If your hearing instrument has a push-button, push the button for a minimum of seconds
to set the instrument in standby mode.
To reactivate the instrument, push the button briefly again.
Use the standby function if you need to silence the instrument.
PUSH
for 3 seconds
IMPORTANT NOTICE
Do not use the stand-by function as an off switch as the hearing instrument still
draws current from the battery in this mode.
14 15
Volume Control (Optional for ITE only)
Your ITE instrument may have a volume control wheel. The volume control wheel can be
turned with the tip of a finger and can be rotated infinitely both ways.
The volume control allows you to adjust the volume in specific listening situations to the
level you feel comfortable with.
To increase volume, turn the wheel forward.
To decrease volume, turn the wheel toward
the back of your head.
You will hear a beep when you increase or
decrease the volume.
When the hearing instrument is turned on, it starts up at a preferred volume level. When
adjusting the volume control to the preferred level, this is indicated by 2 short beeps.
Telecoil (Optional)
The telecoil is an inductive receiver for audio signals. The telecoil is meant for telephone
conversations and for loop systems in e.g. theaters, churches or lecture rooms.
The telecoil is activated by the push-button. When activated, you will hear a certain
number of beeps corresponding to the telecoil program.
See Programs for the telecoil program setting.
Volume
Control Wheel
