Oster 4 cup Continuous Flow Food Chopper Manual de usuario

P.N. 137281

For product questions contact:

Sunbeam Consumer Service

USA : 1.800.334.0759

Canada : 1.800.667.8623

www.oster.com

Distributed by Sunbeam Products, Inc. doing business as

Jarden Consumer Solutions, Boca Raton, Florida 33431.

Para preguntas sobre los productos llame:

Sunbeam Consumer Service

EE.UU.: 1.800.334.0759

Canadá : 1.800.667.8623

www.oster.com

Distribuido por Sunbeam Products, Inc. operando bajo el nombre

de Jarden Consumer Solutions, Boca Raton, Florida 33431.

SPR-110909

Printed in China

Impreso en China

4 CUP MINI FOOD PROCESSOR

MINI PROCESADORA DE ALIMENTOS PARA 4 TAZAS

User Guide/ Guía del Usuario:

FPSTFP4010

www.oster.com

Safety

Seguridad

How to use

Cómo usar

Cleaning

Cuidado y Limpieza

Warranty

Garantía

www.oster.com

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed

including the following:

1. Read all instructions before use.

2. To protect against risk of electrical shock, do not put food processor in water or any other liquid.This

may cause personal injury or damage to the product.

3. Close supervision is necessary when using this appliance near children.

4. Unplug from outlet when not in use, before putting on or taking o parts and before cleaning.

5. Do not contact moving parts.

6. Do not operate food processor with a damaged cord or plug or after the appliance malfunctions, or

is dropped or damaged in any manner. Return appliance to the nearest authorized service center for

examination, repair or mechanical adjustment.

7. The use of attachments not recommended or sold by the manufacturer may cause re,

electrical shock or injury.

8. Do not let cord touch hot surfaces or hang over table edges or counters.

9. Do not use your food processor if any part is broken.

10. Do not use outdoors or for commercial purposes.

11. Keep hands and utensils away from moving blades or discs while processing food to reduce the risk

of severe injury to persons or damage to the food processor. A scraper may be used but must be used

only when the food processor is not running.

12. Blade and processing disk are sharp. Handle carefully.

13. To reduce the risk of injury to persons, never place cutting blade on motor base without rst putting

container properly in place.

14. Be certain container cover is securely locked in place while operating appliance.

15. Never feed food into food chute by hand, always use the food pusher.

16. Be sure to turn switch to OFF position after each use.

17. Do not attempt to defeat the cover interlock mechanism.

18. Do not use this appliance for other than its intended use.

www.oster.com 3

THIS UNIT IS INTENDED FOR HOUSEHOLD USE ONLY.

This appliance has a polarized alternating current plug (one blade is

wider than the other). To reduce the risk of electric shock, as a safety

feature, this plug will t in a polarized outlet only one way. If the plug

does not insert fully in the outlet, reverse the plug. If it still fails to t,

contact a qualied electrician.

DO NOT ATTEMPT TO DEFEAT THIS SAFETY FEATURE.

EXTENSION CORD USE

A short power-supply cord is provided to reduce the risk resulting from

becoming entangled in or tripping over a longer cord. An extension cord

may be used if care is exercised in its use. If an extension cord is used, the

electrical rating of the cord must be at least as great as the electrical rating

of the appliance. The extension cord should be arranged so that it will

not drape over the countertop or tabletop where it can be pulled on by

children or tripped over unintentionally.

SAVE THESE INSTRUCTIONS

Thank you for purchasing the OSTER® 4 Cup Mini Food Processor.

Before you use this product for the rst time, please take a few moments to

read these instructions and keep it for reference. Pay particular attention to

the Safety Instructions provided. Please review the product service and

warranty statements. To learn more about Oster® products, please visit us

at www.oster.com or call us at 1-800-334-0759.

www.oster.com

LOCK

UNLOCK

Food Pusher

Food Chute

Flow Insert

Lid Locking Tab

Lid with continuous

Flow Chute

Slice/Shred Disc

Discharge Disc

Chopping Blade

LEARNING ABOUT YOUR

4 CUP MINI FOOD PROCESSOR

Disc Stem

Bowl

Center Post

Base

Control Knob

www.oster.com 5

About the Controls

1Pulse – The control knob must be turned to the left and

held for unit to operate. When released, unit will stop. Use

PULSE for short processing tasks, such as chopping nuts,

raw meats, or vegetables. This lets you check processed

results and control the consistency.

2On – When the control knob is turned to the right to the

ON position, unit will run continuously until the control knob is turned to OFF

position.

3O – Processor should always be left in OFF position when not in use.

Before Using Your Oster® Food Processor

•When unpacking the product and removing packing material, handle the

chopping blade and slice/shred disc carefully: they are very sharp.

•Wash all parts except the Base in hot, soapy water. Rinse them dry.

These parts can also be placed in the dishwasher. Be sure to read the

Care & Cleaning Section of this manual to learn the correct methods

for taking the unit apart and cleaning.

Control Knob

www.oster.com

HOW TO:

Using Your Food Processor

NOTE: Do not attempt to chop ice in this food processor; it will damage the bowl

and dull the Chopping Blade. This unit will not whip cream, beat egg whites,

grind coee beans, spices or other items with high oil content, or slice or shred

hard-cooked eggs, marshmallows, or soft cheeses.

Important: For your protection, this unit has an interlock system. The processor

will not operate unless the bowl is properly locked onto the base and cover

is properly locked onto the bowl. Do not attempt to operate the unit without

the bowl lid and bowl correctly in place. Be sure base is on a at, dry and clean

surface before you begin processing.

NOTE: Before you begin, PLEASE BE SURE THAT THE ELECTRIC CORD IS

UNPLUGGED.

How to Assemble the Bowl

Slip the bowl over the center post (Figure 1).

Align the bowl handle with the UNLOCK ▲

mark on the base. Twist the bowl handle and

bowl clockwise until it clicks onto the base.

The bowl handle should now align with the

LOCK ▲ mark on the base.

NOTE: There is only one position for the

bowl to lock onto the base. The unit will not

operate if the bowl does not lock onto the base.

How to Lock the Cover

Place the cover with continuous ow chute

onto the bowl with the lid locking tab to

the right of the bowl handle. Twist the cover

clockwise until it clicks onto the bowl. The ▲

mark on the lid should now align with the ▲

mark on the handle (Figure 2).

NOTE: When the cover is locked into position,

the safety mechanism on the cover and bowl

will align. The unit will not operate if the cover

is not locked onto the bowl.

NOTE: BOWL MUST BE LOCKED INTO BASE BEFORE COVER CAN BE

LOCKED INTO POSITION.

Figure 1

LOCK

UNLOCK

Figure 2

www.oster.com 7

How to Chop

NOTE: Make sure the unit is turned OFF and

unplugged before use. Never use hand to

push food into processor. Do not use the

processor continuously for more than 3

minutes at a time.

1Lock the bowl onto base.

(See “How to assemble the bowl”)

2 Grasp the chopping blade by its stem and

slide it onto the center post. (Figure 3).

3Place food into bowl.

4Lock the cover with continuous ow chute

onto bowl. (See“How to Lock the Cover”)

NOTE: Make sure the Flow Insert is pushed

down so food will remain in the bowl. (See

Figure 4).

5Plug the cord into an electrical outlet.

6Turn the knob to the ON position for

continuous processing or the PULSE

position for short processing tasks. When

using the PULSE setting, hold the knob in

the PULSE position for about 2–3 seconds

at a time, check results and repeat if

desired.

7When nished processing, release the

knob, or if you were using Continuous

ON, turn the knob to the OFF position

and allow the chopping blade to stop

rotating.

8Twist the cover counter-clockwise to

remove.

9Hold the Chopping Blade by its stem and

remove. Unlock the bowl by turning it

counter- clockwise and lifting o. Empty

the processed food.

NOTE: Chopping Blade is very sharp, use

caution when handling.

Figure 3

Figure 4

www.oster.com

How to Slice or Shred

NOTE: Make sure the unit is turned OFF

and unplugged before use. Never use hand

to push food into processor. Do not use

the processor continuously for more than

3 minutes at a time.

Processing Into the 4 Cup Bowl

1Lock the bowl onto base.

(See “How to assemble the bowl”)

2 Slide the disc stem onto the center post of

the base. With the desired side facing up

(slicing or shredding), push the slice/shred

disc onto disc stem (Figure 5). Use caution

when handling, blades are extremely

sharp.

3 Lock the cover with continuous ow chute

onto bowl. (See “How to lock the cover”)

NOTE: Make sure the Flow Insert is pushed

down so sliced/shredded food will remain in

the bowl (Figure 6).

4Plug the cord into an electric outlet.

5Fill the Food Chute with desired food to

be processed.

6 Turn the knob to the ON position for

continuous processing. Push down with

a light but steady pressure onto the Food

Pusher (Figure 7).

7When nished processing, turn the knob

to the OFF position and allow the slice/

shred disc to stop rotating. Twist the bowl

lid counter-clockwise to remove.

8Carefully remove the Shredding Disc,

Discharge Disc and Disc Stem. Unlock the

bowl by turning it counter-clockwise to

remove.

NOTE: Shredding Disc is very sharp, use

caution when handling.

OCK

Figure 5

Figure 6

Figure 7

www.oster.com 9

NOTE: Make sure the unit is turned OFF and

unplugged before use. Never use hand to

push food into processor. Do not use the

processor continuously for more than 3

minutes at a time.

Processing Into a Separate Bowl

1Lock the bowl onto base.

(See“How to assemble the bowl”)

2 Slide the disc stem onto the center post

of the base. Slide the discharge disc over

the disc stem. With the desired side facing

up (slicing or shredding), push the slice/

shred disc onto discharge disc (Figure 8).

Use caution when handling, blades are

extremely sharp.

3 Lock the cover with continuous ow chute

onto bowl. (See “How to lock the cover”)

NOTE: Make sure the Flow Insert is pulled up

so sliced/shredded food will process into the

separate bowl (Figure 9).

4Place a large, low serving/preparation bowl

under the continuous ow chute to catch

food and spatter (Figure 9). A rimless bowl

works better than bowls with a lip.

5Plug the cord into an electric outlet.

6Fill the Food Chute with desired food to

be processed.

7 Turn the knob to the ON position for

continuous processing. Push down with

a light but steady pressure onto the Food

Pusher (Figure 10).

8When nished processing, turn the knob to

the OFF position and allow the slice/shred

disc to stop rotating. Twist the bowl lid

counter-clockwise to remove.

Carefully remove the Shredding Disc,

Discharge Disc and Disc Stem. Unlock the bowl

by turning it counter-clockwise to remove.

NOTE: Shredding Disc is very sharp, use caution when handling.

Food Processing Tips/Liquids

•Hot liquids (less than 176˚F, not boiling) and hot foods can be

processed in the bowl.

Figure 8

Figure 9

Figure 10

Otros manuales para 4 cup Continuous Flow Food Chopper

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Procesador de alimentos de Oster

Oster

Oster FPSTFP4250 Manual de usuario

Oster

Oster FPSTFP1455 Manual de usuario

Oster

Oster FPSTFP4253 Manual de usuario

Oster

Oster FPSTFP4250 Manual de usuario

Oster

Oster 4 cup Continuous Flow Food Chopper Manual de usuario

Oster

Oster 6700-33 Manual de usuario

Oster

Oster TOP CHOP FPSTMC1250 Manual de usuario

Oster

Oster TOTAL PREP FPSTFP1355 Manual de usuario

Oster

Oster 3322 Manual de usuario

Oster

Oster 3-Cup Mini Chopper Manual de usuario

Oster

Oster FPSTFP4263-DFL Manual de usuario

Oster

Oster FPSTFP4050 Manual de usuario

Oster

Oster FPSTMC6613A-G Manual de usuario

Oster

Oster 3320 Manual de usuario

Oster

Oster 3320 3320 Manual de usuario

Oster

Oster 6700-33 In2itive Manual de usuario

Oster

Oster FPSTFP4600 Manual de usuario

Oster

Oster BVSTBMH23 Manual de usuario

Oster

Oster FPSTFP3340 Manual de usuario

Oster

Oster FPSTFP4263-DFL Manual de usuario

Oster

Oster FPSTFP4263-DFL Manual de usuario

Oster

Oster FPSTFP3322 Manual de usuario

Oster

Oster FPSTFP5273-DFL Manual de usuario

Oster

Oster BLSTFP-W00-011 Manual de usuario

Manuales populares de Procesador de alimentos de otras marcas

INNOLIVING

INNOLIVING INN-727 Manual de usuario

Berkel

Berkel C32 Manual de usuario

Beko

Beko CHP5554W Manual de usuario

KitchenAid

KitchenAid 5KFP0719 Manual de usuario

QUIGG

QUIGG KM 2017Wi.20 Manual de usuario

Lakeland

Lakeland PRESS AND CHOP 31557 Manual de usuario

Bosch

Bosch MMR08 GB Series Manual de usuario

HOFFEN

HOFFEN Chef Express T9532 Manual de usuario

Garland

Garland 852 ZG Manual de usuario

Robot Coupe

Robot Coupe CL50 Gourmet Manual de usuario

SAPIRHOME

SAPIRHOME SP-1111-K Manual de usuario

Moulinex

Moulinex DJ3051 Manual de usuario

Bosch

Bosch MUM5 Manual de usuario

cecotec

cecotec Mambo Touch Manual de usuario

KitchenAid

KitchenAid 9KFC0516 Manual de usuario

Black & Decker

Black & Decker hc 300 Instrucciones de instalación

Gorenje

Gorenje SBR 1000 DV Manual de usuario

Arzum

Arzum AR 1128 Manual de usuario
