ENGLISH

MECHANICAL WATCH <DM(48Y)>

INSTRUCTION MANUAL

Thank you for choosing our product. To ensure prolonged use and optimum

performance, please read this instruction manual carefully and familiarize

your-self with the terms of the guarantee.

Please keep this instruction manual handy for future reference.

SAFETY PRECAUTIONS

Make absolutely sure to observe the demarcated contents indicated below to

prevent any possible physical danger and property damage to you as well as

other people concerned.

... A demarcation with this symbol represents the contents

assuming possibility for death or serious injury

when the product is used in any manner different from

given instructions.

... A demarcation with this symbol represents the contents

assuming possibility of causing human injury or

material damage only when a product is used in any

manner different from given instructions.

WARNING

CAUTION

ENGLISH

IN HANDLING THE WATCH

(1) Water-resistance

Conditions

of use

Type

Underwater

operation of

crown and

operation

of crown

with drops

of water

on it

Exposure

to small

amounts

of water

(face-

washing,

rain, etc.)

Water sports

(swimming,

etc.),

frequent

contact with

water (car-

washing,

etc.)

Skin diving

(air tanks

are not

used)

Scuba

diving

(air tanks

are used)

Mixed-gas

Diving

(using

helium

gas)

Non water resistant

Without

WATER

RESISTANT

(WATER

RESIST)

××××××

Water

resistant

watches

Water

resistant for

daily life

WATER

RESISTANT

(WATER

RESIST) ×××××

Reinforced

water

resistance

for daily

life I

WATER

RESISTANT

(WATER

RESIST)

50m (5bar)

×  ×××

Reinforced

water

resistance

for daily

life II

WATER

RESISTANT

(WATER

RESIST)

100m (10bar)

200m (20bar)

×× ×

Diver’s

watches

Diver’s

watch for Air

Diving

AIR DIVER’S

100m / 150m

200m ××

Diver’s

watch for

Mixed-gas

Diving

He-GAS

DIVER’S

200m / 300m /...

×

* It is recommended that you use the watch correctly following the above-mentioned scope of usage

after ascertaining water resistance precautions marked on the dial or caseback.

ENGLISH

1A watch with water resistance for daily life 30m (3 bar) can be used during

face-washing, etc. but cannot be used in an environment in which it will be

submerged in water.

2A watch with reinforced water resistance for daily life I 50m (5 bar) can be

used while swimming, etc. but cannot be used during any type of diving

including skin diving.

3A watch with reinforced water resistance for daily life II 100m or 200m (10

or 20 bar) can be used while skin diving, but cannot be used while scuba

diving using oxygen tanks or saturation diving using helium gas, etc.

4Keep the crown pushed in at all times (in the normal position) while using

the watch. If the crown is the screwed-down type, check that it is securely

screwed down.

5Do not operate the crown underwater, or while the watch is wet. Water

may enter the interior of the watch and defeat the water resistance.

6If your watch is non-water resistant, beware of splashes of water (during

face washing, rain, etc.) and sweat. If the watch becomes wet from water

or sweat, wipe the moisture off with a dry, soft cloth.

7Even with a water resistant watch for everyday use, avoid directing strong

jets of mains water onto the watch. Water pressure above the limit can

apply, which may defeat the water resistance.

8With a water resistant watch for everyday use, rinse sea water off the case

after exposure, then wipe it thoroughly to avoid corrosion and other effects.

9The interior of the watch contains some amount of moisture, which may

cause fogging on the inside of the glass when the outside air is cooler than

the internal temperature of the watch. If the fogging is temporary it causes

no harm inside the watch, but if prolonged, or if water enters the watch,

consult your place of purchase and do not leave the problem untreated.

CAUTION

WARNING

ENGLISH

(2) Shock

1Be sure not to carry the watch when you engage in strenuous

sports, whereas playing such light sports as golf, etc., will not

adversely influence the watch.

2Avoid a violent shock such as dropping the watch on the

floor.

(3) Magnetism

1If the watch is left at a location with strong magnetism for an extended

period of time, the components may be magnetized, resulting in

malfunction. Be careful.

2The watch may temporarily speed up or slow down when exposed to

magnetism. Precision is restored when placed away from magnetism. In

such a case, reset the time.

(4) Vibration

The watch may lose precision if subjected to strong

vibrations such as from riding motorcycles, using

jackhammers, chain saws, etc.

(5) Temperature

In environments below and above normal temperatures (5°C-35°C), the

watch may malfunction and stop.

Do not use the watch at high temperatures, such as in a sauna. The watch

may heat and cause burns.

(6)Chemicals, Gases, etc.

Utmost caution must be exercised when coming into contact with gases,

mercury, chemicals (paint thinner, gasoline, various solvents, detergents

containing such components, adhesives, paint, drugs, perfumes,

cosmetics, etc.), and so forth. Such may cause discoloration of the

watchcase, watchband, and dial face. Discoloration, deformation, and

damage to various resin-based component parts may also occur.

CAUTION

ENGLISH

(7) About accessory parts

Do not attempt to disassemble or modify the watch.

Store the bracelet/strap pin and other small parts out of the reach of

children.

If any small parts are swallowed, immediately contact a doctor.

(8) Allergic reactions

If you develop a skin rash or your skin becomes abnormally irritated due to

contact with the watch or strap, stop wearing the watch immediately and

consult a doctor.

(9) About “luminous light”

Some models have luminous light on the hands and dial.

The luminous light is a safe paint that stores sunlight and artificial light

without using any radioactive material, and emits that light in a dark

setting. As the paint discharges the stored light, it will become dimmer

over time. The amount of light emitted and the time that light is emitted

depends on various factors when the light is stored, such as the shape

of the glass, the thickness of the paint, surrounding brightness level, the

distance from the watch to the light source, and the light absorption level.

Please note that when not enough light energy is stored, the watch may

emit weak light or emit light for only a short time.

(10)Water resistant watchband

Some models employ leather and nylon bands on which a special

treatment to resist perspiration and water absorption have been applied.

Please understand that the water resisting effect of this watchband can be

lost depending on the period and conditions of use.

WARNING

CAUTION

ENGLISH

SPECIFICATIONS

(1) Vibrations: 21.600 vibrations/hour

(2) Number of Jewels: 21 jewels

(3) Daily accurancy: 25 sec. to -15 sec.

(4) Running time: More than 40 hours

(5) Date indicator

(6) Shock-proof bearings to protect the balance with hairspring from shocks.

(7) Rotating picture: With a total of seven different picture designs, the

picture changes daily automatically.

The picture design can also be changed manually if the click button is

pressed twice.

The stated daily accuracy is in the following conditions:

•After 24 hours at room temperature with the mainspring wound fully and the

dial facing up.

• Due to the characteristics of the automatic winding watch, the time may

deviate from the stated “daily accuracy” depending on the following

conditions: amount of time the watch is worn each day, position of the

watch, movement of your arm, winding condition of the mainspring.

Product specifications may change without notice, for improvement.

ENGLISH

NAMES AND FUNCTIONS OF INDIVIDUAL COMPONENT PARTS

A : Minute hand

B : Hour hand

C : Rotating picture

D : Second hand

E : Click button

F : Date

G: Crown

H : Dial

1: Normal position

2: First click : Date setting

3: Second click : Time setting

* The position of the crown, date indicator, design and position of the rotating

picture, shape of the window, etc. may vary on some models.

AUTOMATIC WINDING MECHANISM

(1) This is an automatic winding mechanical watch.

(2) The mainspring is wound by natural movements of your

arm when wearing the watch on your wrist.

(3) If your watch stops, swing the watch back and forth ten

or more times to re-start the second hand. After it starts

moving, set the date, time, and rotating picture.

(4) This watch will run approximately 40 hours after it is fully

wound. If it is not wound enough, the watch may lose

accuracy. In order to maintain the watch’s accuracy, we

recommend wearing the watch at least 8 hours a day.

䃩

1 2 3

䃩

1 2 3

ENGLISH

MODELS WITH SCREWED-DOWN CROWN

Depending on the model, you may not be able to pull the crown out without

unscrewing it (models with screwed-down crown).

Operate this type of watch as follows:

(1) Before setting the date, time, or rotating picture, first turn the crown to the

left to loosen the screw lock.

(2) After setting the date, time, or rotating picture, turn the crown to the right

while pressing in, until it stops turning to securely tighten the screw.

HOW TO SET THE TIME

(1) Pull out the crown to the second click.

The second hand does not stop.

(2) Turn the crown clockwise and set the

current time.

* Since this watch comes with a calendar,

make sure that you set either a.m. or

p.m. without fail.

The date changes at [twelve o’clock

midnight].

* When setting the time, first bring the

hand back slightly later the actual time

and then move it forward to the actual

time.

(3) Press the crown in to the normal position.

Turn clockwiseTurn clockwise

ENGLISH

HOW TO SET THE DATE

(1) Pull the crown out to the first click.

The crown on this watch can be pulled

out to the first and second clicks.

(2) Turn the crown counterclockwise until

you reach today’s date.

(3) Press the crown in to the normal position.

The position of the crown, date indicator, etc. may vary on some models.

About date correction at month’s end:

Date correction is necessary for months with 30 days or less. Set the date to

the [1st day] on the first day of the next month.

Turn

counterclockwise

Turn

counterclockwise

ENGLISH

HOW TO CHANGE THE ROTATING PICTURE

(1) Press the click button at the 2 o’clock position to set the desired picture

design.

☆Δ

Once Twice

* The Rotating Picture changes each time the button is pressed twice.

( The picture will not change to the correct position if the button is only

pressed once.)

Continue pressing the button to set the picture to the desired picture

design.

There are seven different picture designs in total.

* Models with click buttons that cannot be pressed with a finger (models with

hidden buttons)

To change the Rotating Picture, press the button using something that

has a fine tip (a precision screwdriver, tweezers, etc.) to rotate through the

designs.

CAUTION

Avoid setting the date or rotating picture between 10:00 p.m. and 4:00 a.m.

since the calendar or rotating picture changes during this time. If the date or

rotating picture is set during this time period, the date or rotating picture may

not change or the watch may malfunction. Be sure to move the hour and minute

hands away from this time period when setting the date or rotating picture.

Tabla de contenidos

Idiomas:

Otros manuales de Mirar de Orient

Orient

Orient BEM5L003 Manual de usuario

Orient

Orient CFA02001B Manual de usuario

Orient

Orient FTD10002B0 Manual de usuario

Orient

Orient M14 Manual de usuario

Orient

Orient TT(KFB) Manual de usuario

Orient

Orient TT(KFB) Manual

Orient

Orient EMAM80 Manual de usuario

Orient

Orient UT (H4A) Manual de usuario

Orient

Orient SY(KFF) Manual de usuario

Orient

Orient KU(RMC) Manual de usuario

Orient

Orient KFA (TD) Manual de usuario

Orient

Orient ST(KUD) Manual de usuario

Orient

Orient ES 46C Manual de usuario

Orient

Orient BF J50 Manual de usuario

Orient

Orient WE (KL7) Manual de usuario

Orient

Orient RK-AU0301B Manual de usuario

Orient

Orient FUN8G001 Manual de usuario

Orient

Orient UG1R002B Manual de usuario

Orient

Orient RA-KV0403S Manual de usuario

Orient

Orient UU(KHA) Manual de usuario

Orient

Orient OrientStar DIVER'S WATCH 200m Manual de usuario

Orient

Orient KFB TT Manual de usuario

Orient

Orient TV(KFC) Manual de usuario

Orient

Orient GNA Manual de usuario

Manuales populares de Mirar de otras marcas

Pandora

Pandora WATCH2 Manual de usuario

Casio

Casio QW-4343 Manual de usuario

Suunto

Suunto X6 Manual de usuario

Seiko

Seiko N830 Manual de usuario

MotionX

MotionX 365 Manual de usuario

Garmin

Garmin VENU SQ 2 Manual de usuario

QCY

QCY Watch GTC Manual de usuario

Canyon

Canyon Cindy CNE-KW41WP Manual de usuario

Esq

Esq Watches Guía de instalación

Crane

Crane AA5-CDSM-3A Manual de usuario

Timex

Timex W-214 Manual de usuario

DETOMASO

DETOMASO MATERA Manual de usuario

Geemarc

Geemarc Watch N Shake Manual de usuario

LORUS

LORUS W590 Manual de usuario

STENLILLE

STENLILLE Actío Manual de usuario

Casio

Casio 5594 Manual de usuario

Sinn

Sinn HUNTER'S WATCH 3. Edition Manual de usuario

Slazenger

Slazenger SLZ800 Manual de usuario
