Oricom PMR3000 Manual de usuario

Operating Instructions

PMR3000 1 watt UHF CB Radio

Read this manual carefully before use.

Table of contents

Safety Information and Warnings ................................... 4

Information on Safe Operation ....................................... 6

Your Oricom PMR3000 radio controls............................. 9

Your Oricom PMR3000 radio display ............................ 10

Getting Started ............................................................ 11

Operation..................................................................... 13

UHF channels and frequencies..................................... 23

Warranty information (Australia)................................... 25

Customer support ........................................................ 27

Safety Information and Warnings

CAUTION

Damaged Antenna

Do not use any radio that has a damaged

antenna. If a damaged antenna comes in

contact with the skin, a minor burn may result.

Batteries

All batteries can cause property damage and/

or bodily injury such as burns if conductive

material such as jewellery keys, or beaded

chains touches exposed terminals. The

material may complete an electrical circuit

(short circuit) and become quite hot. Exercise

care in handling any charged battery,

particularly when placing it inside a pocket,

purse, or other container with metal objects.

WARNING

For Vehicles with an Air Bag

Do not place your radio in the area over an

air bag or in the air bag deployment area.

Air bags inﬂate with great force. If a radio is

placed in the air bag deployment area and the

air bag inflates, the radio may be propelled

with great force and cause serious injury to

the occupants of the vehicle.

Potentially Explosive Atmospheres

Turn your radio OFF when in any area with a

potentially explosive atmosphere, unless it is

a type especially qualified for such use (for

example, Factory Mutual Approved). Sparks in

such areas could cause an explosion or fire

resulting in injury or even death.

Safety Information and Warnings

WARNING

Batteries

Do not replace or charge batteries in a

potentially explosive atmosphere. Contact

sparking may occur while installing or

removing batteries and cause an explosion.

Blasting Caps and Areas

To avoid possible interference with blasting

operations, turn your radio OFF near electrical

blasting caps or in a “blasting area” or in

areas posted: “Turn off the two way radio.”

Obey all signs and instructions.

NOTE: Areas with potentially explosive atmospheres are often,

but not always clearly marked. They include fueling areas

such as below deck on boats; fuel or chemical transfer or

storage facilities; areas where the air contains chemicals

or particles, such as grain, dust, or metal powders; and any

other area where you would normally be advised to turn off

your vehicle engine.

Cleaning and Care

To clean your radio, use a soft cloth dampened with water. Do not

use cleaners or solvent, which may cause damage that may not be

covered by the guarantee.

Information on Safe Operation

Read This Information Before Using Your Oricom Radio.

Transmit and Receive Procedure

Your two-way radio contains a transmitter and a receiver. To control

your exposure and ensure compliance with the general population/

uncontrolled environment exposure limits, always adhere to the

following procedure:

Transmit no more than 50% of the time.•

To receive calls, release the PTT button.•

To transmit (talk), press the Push to Talk (PTT) button.•

Transmitting 50% of the time, or less, is important because the

radio generates measurable RF energy exposure only when

transmitting (in terms of measuring standards compliance).

Exposure to Radio Frequency Energy

Your Oricom two-way radio complies with Australian

Communications Authority Radiocommunications (Electromagnetic

Radiation-Human Exposure) Standard, 2003.

To assure optimal radio performance and make sure human

exposure to radio frequency electromagnetic energy is within the

guidelines set out in the above standards always adhere to the

following procedures.

Radio Operation and EME Exposure

Unauthorized antennas, modiﬁcations, or attachments could

damage the radio and violate compliance.

Do NOT hold the antenna when the radio is “IN USE.” Holding the

antenna affects the effective range.

Do not use the radio if the antenna is damaged. If a damaged

antenna makes contact with your skin, a minor burn can result.

If you wear a radio on your body when transmitting, always ﬁt the

radio on the belt clip (supplied). Always ensure the radio and it's

antenna are at least 2.5 cm from your body when transmitting.

Information on Safe Operation

Radiocommunications (Citizen Band Radio

Stations) Class Licence 2002

No licence is required to own or operate this radio in Australia and

New Zealand.

The Radiocommunications (Citizen Band Radio Stations) Class

Licence 2002 contains the technical parameters, operating

requirements, conditions of licence and relevant standards for

Citizen Band (CB) radios. CB radios must comply with the class

licence for their use to be authorised under the class licence.

Electromagnetic Interference/Compatibility

Nearly every electronic device is susceptible to electromagnetic

interference (EMI). To avoid the possibility of electromagnetic

interference and/or compatibility conﬂicts, turn off your radio in any

location where posted notices instruct you to do so such as health

care facilities.

Aircraft

When instructed to do so, turn off your radio when onboard an

aircraft. Any use of a radio must be in accordance with applicable

regulations per airline crew instructions.

Medical Devices - Pacemakers

The Advanced Medical Technology Association recommends

that a minimum separation of 6 inches (15 cm) be maintained

between a handheld wireless radio and a pacemaker. These

recommendations are consistent with the independent research by

and recommendations of the U.S. Food and Drug Administration.

People with pacemakers should:

ALWAYS keep the radio more than 15 cm from their•

pacemaker when the radio is turned ON.

Not carry the radio in the breast pocket.•

Information on Safe Operation

Use the ear opposite the pacemaker to minimize the potential•

for interference.

Turn the radio OFF immediately if there is any reason to•

suspect that interference is taking place.

Medical Devices - Hearing Aids

Some digital wireless radios may interfere with some hearing aids.

In the event of such interference, you may want to consult your

hearing aid manufacturer to discuss alternatives.

Other Medical Devices

If you use any other personal medical device, consult the

manufacturer of your device to determine if it is adequately

shielded from RF energy. Your physician may be able to assist you

in obtaining this information.

N13134

Z765

This unit complies with all relevant Australian and New Zealand

approval requirements including radio communications

(Electromagnetic Radiation Human Exposure) standard 2003.

Your Oricom PMR3000 radio controls

Menu button

Volume down

and menu settings

On/off button

Volume up and

menu settings

Push to talk

(PTT) button

Call tone

button

Headset

socket

Scan and monitor

Key lock

Indicator light

Battery compartment

clip

Charging contacts

Your Oricom PMR3000 radio display

Key tone

Baby monitor

CTCSS code

Volume

Channel

Battery level

Keypad lock

Stopwatch

Automatic power

save mode

Squelech

Call tone

Scan/dual scan

Roger Beep

VOX

RX icon TX icon
