USER MANUAL
PCB Deco, Power, High Power & Photon
UV RESISTANT FROST
RESISTANT
SWIMMING POOL
ENVIRONMENT
MAC
ADAM
2
S D C M
BEND RADIUS
R
1.2" CRI
80+
SEA WATER
RESISTANT
RoHS
F5
System
IP40/IP68 ........
Table of Contents General
Warning
Product Information Product Dimensions Product
Specifications Asymmetric Diagram Cable Selection
Area Advice
Product Care and Handling Cutting Instructions
Connect
Soldering
Power Supply
Symbols
2
2
2
2
3
4
5
6
8
9
10
12
19
20
Table of Contents
Warning
Product Information
Product Dimensions
Bending Radius
Cutting Instructions
Connecting & Waterproofing
Connections IP40
Solder Connections IP20
General
Power Supply
Cable Selection
Product Specifications
Photometric Diagram
Symbols
PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE INSTALLATION & LEAVE
A COPY FOR THE END USER/ MAINTANANCE ENGINEER FOR FUTURE REFERENCE.
liniLED strip front view:
Warning
This product comes with a 5year warranty.
Warranty void if:
1. The installation guide has not been consulted (installation mistake).
2. The installation is not done by a certified installer.
3. Local rules and guidelines are not respected.
4. The invoice cannot be shown and/or has been altered.
5. Damage is caused by negligence, abnormal use or improper handling, use, maintenance and/or cleaning
of the product.
This product is intended for professional use only! This product must be installed by a qualified and
certified installer according to local rules and guidelines. Organic Lighting Systems, Inc. cannot
be held liable for (consequential) damage and/or injuries due to unintended use and/or installation
errors.
Product Information
Organic Lighting, 205 W. Blueridge Avenue, Orange, CA 92865 | 626.969.6140 | www.organiclighting.com
7.87 in
liniLED strip top view; cuttable sections:
Deco, Power:
Maximum bending radius is 0.79 in. Solely bend up or downward. Do not compress, stretch or bend the
LED strip.
Bending Radius
3.94 in
Photon:
1.97 in
0.47 in
High Power:
2
User Manual | liniLED® PCB Deco, Power, High Power, Photon
The liniLED® LED strip (IP40) is a high quality, flexible LED strip with a unique co-extrusion technology.
Designed for an endless range of indoor and outdoor applications.
* For use in wet environments, use mirror welded connectors or IP68 waterproof kits.
Product Dimensions
0.05 in
0.31 in
0.043 in
0.055in
0.31 in
0.31 in
0.47 in
0.47 in
0.79 in
0.79 in
Cutting Instructions
Top view | Make sure the cut is vertical as
illustraded in the image above. Only cut on the
dotted lines to prevent damaging the LED strip.
3
2
1
The LED strip has to be unreeled on a horizontal surface at the time of installation. Do not unreel the
spool of LED strip before installation. Lengths over 10ft should be installed with the help of a second
person to support the strip to ensure that the connector is not stressed.
10ft lengths require a second
person's assistance.
Organic Lighting, 205 W. Blueridge Avenue, Orange, CA 92865 | 626.969.6140 | www.organiclighting.com 3
Top view | Only cut on the dotted lines to prevent
damaging the LED strip.
Dispose of the unnecessary material through
waste recycling of electrical and electronic
equipment.
User Manual | liniLED® PCB Deco, Power, High Power, Photon
+
_
Choose your Connector - IP20
Organic Lighting, 205 W. Blueridge Avenue, Orange, CA 92865 | 626.969.6140 | www.organiclighting.com
4
User Manual | liniLED® PCB Deco, Power, High Power, Photon
Depending on the area where the liniLED® LED strip is installed we off er a range of solutions to cope with
external factors. The product portfolio for the liniLED® PCB LED strip includes a IP20 connector.liniLED
PCB requires either an IP20 connector or a soldered connection. (pg.5)
Indoor environment | (IP00) Solder
Indoor environment | (IP20) | liniLED® PCB
Connector Set
Solder Connection Assembly (IP20)
0.02 in
2
0.31 in
12
4
662°F
Organic Lighting, 205 W. Blueridge Avenue, Orange, CA 92865 | 626.969.6140 | www.organiclighting.com 5
Solder the wires to the PCB. We advise to use a
cable with an area not bigger then 0.5 mm2.
Pre-solder the connector pads.
Pre-solder the wires. Solder the wires to the connector pads.
User Manual | liniLED® PCB Deco, Power, High Power, Photon
Read the instructions and safety precautions before installation, usage and storage of the products to secure
safety of the user and reliability of the product. Hand over the instructions to the end-user and/or those
responsible for installation, maintenance and usage.
- Organic Lighting Systems, Inc. cannot be held responsible for improper handling, product installation,
usage or storage.
Handling
- Handle with care.
- The product may not be modifi ed or converted otherwise than prescribed.
- Products are transported in proper packaging. Products should remain packed until installation.
Installation
- Attention: The power has to be switched off the main power supply or the connection before installation.
Not doing so may damage the product.
- Use a suitable LED power supply/driver: 24 V DC constant voltage. Do not drive the product on other
voltages than described in their datasheet/products specifi cations.
- Installation has to be done by a certifi ed professional with knowledge of electrical circuits or a specialised
maintenance person known with valid directives.
- General and local construction, safety- and installation regulations should be respected.
- Use only supplied parts, accessories and required tools as prescribed in the installation manual to
guarantee a safe installation and use of the product.
- Products may solely be installed in the areas according to their prescribed IP-rating, IK-rating,
temperature range and chemical resistances.
- Do not fasten anything on the product, same applies for hanging.
- Do not install the product in the following cases:
- Damage is visible on the product or its cables.
- The inside of the product is moistened or dirty.
- The product or its cables have been modifi ed. It could lead to an electrical shock or a short circuit
may occur.
- Children may not play unsupervised with electrical products as they cannot judge the dangers in dealing
with electrical circuits correctly.
Operation and Use
Solely use the productwhen its working correctly. If not, switch the power offimmediately and advise
an electrical specialist in the following c-ase.
-Damage is visible on the product.
-The product does not function.
-Smoke or steam rises from the product.
-Crackling sounds are noticeable.
-The product is overheating.
-Repairs on the installation may only be performed by qualifi ed electricians. Product repairs may solely
be done by Organic Lighting Systems, Inc.
Cleaning and Maintanence
- Attention: Disconnect the power before maintenance and cleaning.
- Dust and dirt accumulated over time should be removed from the light-emitting surface to assure
optimal functioning of the product.
- Paints, solvents and corrosive cleaning chemicals may not contact and thus aff ect the product.
Environment and Waste
- Exterior decorative lighting should only be used after sunset.
- This product may not be treated as household waste. Dispose of the material through the waste
recycling of electrical and electronic equipment.
General
Organic Lighting, 205 W. Blueridge Avenue, Orange, CA 92865 | 626.969.6140 | www.organiclighting.com 6
User Manual | liniLED® PCB Deco, Power, High Power, Photon
Power Supply
Organic Lighting, 205 W. Blueridge Avenue, Orange, CA 92865 | 626.969.6140 | www.organiclighting.com 7
L
N
Power
Supply
24 V
DC
-+
120-277V AC
Control
IP20
User Manual | liniLED® PCB Deco, Power, High Power, Photon
Cable Selection
The following chart gives the maximum 24V supply cable run lengths based on 22AWG, 20AWG, 18AWG,
16AWG and 14AWG wire gauge to avoid voltage drop to the strips, with a 3ft liniLED connector cable
length.
A wiring plan with branches from a single power supply connection cannot exceed the maximum
connector strip length shown on the charts and if complex will require special electrical calculations to
ensure adequate power to maintain full LED output.
Result = Maximum cable length based on the cable thickness and power supply voltage.
1. Color Temperature
2. LED Strip Length
3. Voltage 24V DC 25V DC 24V DC 25V DC 24V DC 25VDC 24V DC 25V DC
4. Cable Size 22 AWG 304' 587' 57' 114' 27' 55' 11' 25'
20 AWG 457' 883' 86' 172' 40' 82' 17' 38'
18 AWG 608' 1174' 114' 228' 53' 110' 22' 51'
16 AWG 914' 1767' 173' 343' 80' 165' 33' 76'
14 AWG 1521' 2940' 287' 571' 133' 275' 56' 127'
1. Color Temperature
2. LED Strip Length
3. Voltage 24V DC 25V DC 24V DC 25V DC 24V DC 25VDC 24V DC 25V DC
4. Cable Size 22 AWG 227' 439' 42' 84' 19' 40' 7' 18'
20 AWG 341' 661' 63' 127' 28' 60' 11' 27'
18 AWG 453' 879' 84' 169' 38' 80' 14' 36'
16 AWG 682' 1322' 127' 254' 57' 121' 22' 54'
14 AWG 1135' 2200' 210' 423' 95' 201' 37' 90'
DECO RED & AMBER
3' 16' 33' 66'
3' 16' 33' 66'
DECO 2400 - 6500K
Organic Lighting, 205 W. Blueridge Avenue, Orange, CA 92865 | 626.969.6140 | www.organiclighting.com 8
+-
1
2
3
4
Result
1. Color Temperature
2. LED Strip Length
3. Voltage 24V DC 25V DC 24V DC 25V DC 24V DC 25VDC 24V DC 25V DC
4. Cable Size 22 AWG 402' 776' 77' 152' 36' 74' 16' 35'
20 AWG 605' 1168' 116' 228' 55' 111' 24' 52'
18 AWG 805' 1553' 154' 304' 73' 148' 32' 70'
16 AWG 1210' 2336' 233' 457' 110' 222' 48' 105'
14 AWG 2015' 3888' 386' 761' 182' 370' 81' 174'
DECO BLUE & GREEN
3' 16' 33' 66'
User Manual | liniLED® PCB Deco, Power, High Power, Photon
Cable Selection
1. Color Temperature
2. LED Strip Length
3. Voltage 24V DC 25V DC 24V DC 25V DC 24V DC 25VDC 24V DC 25V DC
4. Cable Size 22 AWG 118' 231' 57' 113' 20' 43' 8' 19'
20 AWG 178' 347' 86' 170' 31' 64' 12' 29'
18 AWG 236' 462' 114' 227' 40' 86' 16' 38'
16 AWG 356' 695' 172' 341' 61' 129' 24' 58'
14 AWG 592' 1156' 285' 567' 101' 214' 40' 96'
1. Color Temperature
2. LED Strip Length
3. Voltage 24V DC 25V DC 24V DC 25V DC 24V DC 25VDC 24V DC 25V DC
4. Cable Size 22 AWG 137' 267' 66' 131' 24' 50' 10' 23'
20 AWG 206' 401' 100' 197' 36' 75' 15' 34'
18 AWG 274' 534' 133' 262' 48' 100' 20' 46'
16 AWG 412' 803' 199' 395' 72' 150' 30' 69'
14 AWG 686' 1336' 332' 657' 119' 250' 50' 114'
3' 6' 16' 33'
3' 6' 16' 33'
POWER BLUE & GREEN
POWER RED & AMBER
1. Color Temperature
2. LED Strip Length
3. Voltage 24V DC 25V DC 24V DC 25V DC 24V DC 25VDC 24V DC 25V DC
4. Cable Size 22 AWG 221' 429' 109' 213' 41' 82' 18' 39'
20 AWG 333' 646' 163' 320' 61' 124' 28' 59'
18 AWG 443' 859' 217' 425' 82' 165' 37' 78'
16 AWG 667' 1292' 327' 640' 123' 248' 55' 118'
14 AWG 1110' 2150' 544' 1065' 205' 413' 92' 196'
POWER 2400 - 6500K
3' 6' 16' 33'
Organic Lighting, 205 W. Blueridge Avenue, Orange, CA 92865 | 626.969.6140 | www.organiclighting.com 9
1. Color Temperature
2. LED Strip Length
3. Voltage 24V DC 25V DC 24V DC 25V DC 24V DC 25VDC 24V DC 25V DC
4. Cable Size 22 AWG 121' 236' 58' 116' 21' 44' 10' 22'
20 AWG 182' 356' 88' 175' 31' 66' 14' 34'
18 AWG 242' 473' 117' 232' 42' 88' 19' 45'
16 AWG 365' 712' 176' 350' 63' 132' 29' 68'
14 AWG 607' 1185' 293' 582' 104' 220' 49' 113'
PHOTON 2400-6500K
3' 6' 16' 29'
1. Color Temperature
2. LED Strip Length
3. Voltage 24V DC 25V DC 24V DC 25V DC 24V DC 25VDC 24V DC 25V DC
4. Cable Size 22 AWG 110' 215' 53' 105' 18' 39' 7' 18'
20 AWG 165' 324' 79' 158' 28' 59' 11' 27'
18 AWG 220' 430' 106' 211' 37' 79' 14' 35'
16 AWG 331' 647' 159' 317' 56' 119' 22' 53'
14 AWG 551' 1077' 265' 528' 93' 198' 36' 89'
HIGH POWER 2400 - 6500K
3' 6' 16' 33'
User Manual | liniLED® PCB Deco, Power, High Power, Photon
Cable Selection
Organic Lighting, 205 W. Blueridge Avenue, Orange, CA 92865 | 626.969.6140 | www.organiclighting.com 10
Depending on the area where the liniLED® LED strip is installed we off er a range of solutions to cope with
external factors. The product portfolio for the liniLED® PCB LED strip includes a IP20 connector.
Indoor environment | (IP00) Solder
Indoor environment | (IP20)
User Manual | liniLED® PCB Deco, Power, High Power, Photon
Open the PCB connector.
Push the liniLED® PCB LED strip into the connector.
Make sure the + is above.
Close the PCB connector.
Este manual sirve para los siguientes modelos
3
Tabla de contenidos
Otros manuales de Equipo de iluminación de Organic Lighting Systems
Manuales populares de Equipo de iluminación de otras marcas
Qazqa
Qazqa Suplux SL 3 Black 103062 Manual de usuario
Commercial Electric
Commercial Electric 54568141 Manual de usuario
CREE LIGHTING
CREE LIGHTING 304 Series Manual de usuario
Goobay
Goobay 49867 Manual de usuario
ECOMAN ITALIA
ECOMAN ITALIA LED T8 Manual de usuario
Alkalite
Alkalite Krypton KT-81 Manual de usuario
