Oregon Scientific RMR202 Manual de usuario

Indoor and Outdoor Thermometer with Atomic Time

Model:RMR202 / RMR202A

USER MANUAL

Indoor and Outdoor Thermometer

with Atomic Time

Model:RMR202 / RMR202A

USER MANUAL

CONTENTS

Overview .....................................................................2

Front View ..............................................................2

Back View ..............................................................2

Remote Sensor .......................................................3

Getting Started ...........................................................3

Insert Batteries ........................................................3

Remote Sensor...........................................................3

Sensor Data Transmission...................................... 4

Clock ...........................................................................4

Clock Reception ......................................................4

Manually Set Clock .................................................4

Temperature and Humidity........................................ 5

Ice Warning .............................................................5

Reset...........................................................................5

Precautions................................................................5

Speciﬁcations ............................................................6

About Oregon Scientiﬁc ...........................................6

EU-Declaration of Conformity ..................................6

FCC Statement...........................................................6

Declaration of Conformity........................................7

OVERVIEW

FRONT VIEW

510

1. Remote sensor reception indicator

2. Clock signal reception indicator

3. Indoor temperature

4. MODE:Change settings / display

5. / :Increase / decrease setting; activate /

deactivate clock reception signal

6. Outdoor temperature

7. Time zone (RMR202A only)

8. Clock with weekday

9. MEM:View current, maximum and minimum

temperature / humidity

10. Ice alert LED indicator

BACK VIEW

1. °C / °F:Select temperature unit

2. RESET:Reset unit to default settings

3. EU / UK:Select the nearest radio signal (RMR202

only)



REMOTE SENSOR

1. LED status indicator

2. Wall mount hole

3. Battery compartment

4. RESET hole

5. CHANNEL switch

GETTING STARTED

INSERT BATTERIES

1. Remove the battery compartment.

2. Insert the batteries, matching the polarities.

3. Press RESET after each battery change.

LOCATION MEANING

Clock / alarm Main unit batteries low

Outdoor temperature Sensor batteries low

and humidity area

REMOTE SENSOR

The main unit can collect data from up to 3 sensors.

To set up the sensor:

1. Open the battery compartment.

2. Select a channel then press RESET.

3. Close the battery door.

4. Place the sensor within 30 m (98 ft) of the main unit

using the table stand or wall mount.

TIP Ideal placements for the sensor would be in any

location on the exterior of the home at a height of not

more than 1.5 m (5 ft) and which can shield it from direct

sunlight or wet conditions for an accurate reading.

1.5 m (5 ft)

NOTE Use alkaline batteries for longer usage and

consumer grade lithium batteries in temperatures below

freezing.

SENSOR DATA TRANSMISSION

To search for a sensor:

Press and hold + MODE.

The sensor reception icon in the remote sensor area

shows the status:

ICON DESCRIPTION

Main unit is searching for

sensor(s).

A channel has been found.

The sensor cannot be

found.

TIP The transmission range may vary depending on

many factors. You may need to experiment with various

locations to get the best results.

CLOCK

CLOCK RECEPTION

This product is designed to synchronize its clock

automatically with a clock signal.

RMR202:

Slide EU / UK to select the signal received.

• EU: DCF-77 signal: within 1500 km (932 miles) of

Frankfurt, Germany.

• UK: MSF-60 signal: within 1500 km (932 miles) of

Anthorn, England.

RMR202A:

• WWVB-60 signal: within 3200km (2000 miles) of

Fort Collins Colorado.

To enable / disable signal reception:

Press and hold to enable or to disable signal

reception.

NOTE Reception takes 2-10 minutes. If the signal is

weak, it can take up to 24 hours to get a valid signal.

If signal reception is unsuccessful, place your unit next

to a window, press and hold to force another signal

search.

Clock signal reception indicator:

STRONG

SIGNAL

WEAK

SIGNAL NO SIGNAL

MANUALLY SET CLOCK

To set the clock manually, disable the signal reception ﬁrst.

1. Press and hold MODE.

2. Press or to change the settings.

3. Press MODE to conﬁrm.

4. The settings order is: time zone, 12/24 hr format,

hour, minute, year, calendar mode (day – month /

month – day), month, day and language.

RMR202: Time zone offset sets the clock +/- 23 hours

from the received clock signal time.

RMR202A: Select the time zone: (P) Paciﬁc, (E) Eastern,

NOTE The language options are English (E), German

(D), French (F), Italian (I), and Spanish (S).

To select display mode:

Press MODE to choose between clock with seconds /

weekday / calendar.

TEMPERATURE AND HUMIDITY

To toggle temperature unit:

Press °C / °F.

To auto-scan between sensors:

Press and hold + MEM to display each sensor’s data

for 3 seconds.

To end press .

To toggle between current, minimum and maximum

records for the selected sensor:

Press MEM repeatedly.

To clear the records:

Press and hold MEM.

ICE WARNING

If the channel 1 sensor falls between 3°C to -2 °C (37°F

to 28°F), LED indicator will ﬂash, and will stop ﬂashing

once the temperature is out of this range.

RESET

Press RESET to return to the default settings.

PRECAUTIONS

• Do not subject the unit to excessive force, shock,

dust, temperature or humidity.

• Do not cover the ventilation holes with any items such

as newspapers, curtains etc.

• Do not immerse the unit in water. If you spill liquid

over it, dry it immediately with a soft, lint-free cloth.

• Do not clean the unit with abrasive or corrosive

materials.

• Do not tamper with the unit’s internal components.

This invalidates the warranty.

• Only use fresh batteries. Do not mix new and old

batteries.

• Images shown in this manual may differ from the

actual display.

• When disposing of this product, ensure it is collected

separately for special treatment.

• Placement of this product on certain types of wood

may result in damage to its ﬁnish for which Oregon

Scientiﬁc will not be responsible. Consult the furniture

manufacturer's care instructions for information.

• The contents of this manual may not be reproduced

without the permission of the manufacturer.

• Do not dispose old batteries as unsorted municipal

waste. Collection of such waste separately for special

treatment is necessary.

• Please note that some units are equipped with a

battery safety strip. Remove the strip from the battery

compartment before ﬁrst use.

NOTE The technical speciﬁcations for this product and

the contents of the user manual are subject to change

without notice.

SPECIFICATIONS

TYPE DESCRIPTION

MAIN UNIT

L x W x H 77 x 41.5 x 116.5mm

(3.03 x 1.63 x 4.59 in)

Weight 241g(8.5 oz)

without battery

Temperature range -5°C to 50°C

(23°F to 122°F)

Resolution 0.1°C (0.2°F)

Signal frequency 433 MHz

Power 2 x UM-4 (AAA) 1.5 V

batteries

REMOTE UNIT (THN132N)

L x W x H 96 x 50 x 22 mm

(3.78 x 1.97 x 0.87 in)

Weight 62g (2.22 ounces)

Transmission range 30m (98 ft) unobstructed

Temperature range -20°C to 60°C

(-4°F to 140°F)

Power 1 x UM-3 (AA) 1.5 V

batteries

ABOUT OREGON SCIENTIFIC

Visit our website (www.oregonscientiﬁc.com) to learn

more about Oregon Scientiﬁc products. If you’re in

the US and would like to contact our Customer Care

department directly, please visit: www2.oregonscientiﬁc.

com/service/support

Call 1-800-853-8883.

For international inquiries, please visit: www2.

oregonscientiﬁc.com/about/international

EU-DECLARATION OF CONFORMITY

Hereby, Oregon Scientific, declares that this Indoor

and Outdoor Thermometer with Atomic Time (Model:

RMR202 / RMR202A) is in compliance with the essential

requirements and other relevant provisions of Directive

1999/5/EC. A copy of the signed and dated Declaration of

Conformity is available on request via our Oregon Scientiﬁc

Customer Service.

COUNTRIES RTTE APPROVAL COMPLIED

All EC countries,Switzerland CH

and Norway N

FCC STATEMENT

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions: (1)

This device may not cause harmful interference, and

(2) This device must accept any interference received,

including interference that may cause undesired

operation.

WARNING Changes or modiﬁcations not expressly

approved by the party responsible for compliance could

void the user’s authority to operate the equipment.

NOTE This equipment has been tested and found

to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against

harmful interference in a residential installation.

This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful

interference to radio communications. However, there

is no guarantee that interference will not occur in a

particular installation. If this equipment does cause

harmful interference to radio or television reception,

which can be determined by turning the equipment

off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment

and receiver.

• Connect the equipment into an outlet on a

circuit different from that to which the receiver is

connected.

• Consult the dealer or an experienced radio / TV

technician for help.

DECLARATION OF CONFORMITY

The following information is not to be used as contact

for support or sales. Please call our customer service

number (listed on our website at www.oregonscientiﬁc.

com, or on the warranty card for this product) for all

inquiries instead.

Name: Oregon Scientiﬁc, Inc.

Address: 19861 SW 95th Ave.,Tualatin,

Oregon 97062 USA

Telephone No.: 1-800-853-8883

declare that the product

Product No.: RMR202 / RMR202A

Product Name: Indoor and Outdoor Thermometer with

Atomic Time

Manufacturer: IDT Technology Limited

Address: Block C, 9/F, Kaiser Estate,Phase 1,41

Man Yue St., Hung Hom, Kowloon,

Hong Kong

is in conformity with Part 15 of the FCC Rules. Operation

is subject to the following two conditions: 1) This device

may not cause harmful interference. 2) This device must

accept any interference received, including interference

that may cause undesired operation.

Termómetro interior y exterior con

hora atómica

Modelo: RMR202 / RMR202A

MANUAL DE USUARIO

CONTENIDOS

Resumen.....................................................................2

Vista Frontal ............................................................2

Vista Trasera........................................................... 2

Sensor Remoto .......................................................3

Para Empezar .............................................................3

Cómo Introducir Las Pilas .......................................3

Sensor Remoto ..........................................................3

Transmisión de datos del sensor ............................4

Reloj ............................................................................4

Recepción del reloj.................................................. 4

Ajuste Manual Del Reloj.......................................... 5

Temperatura y humedad ........................................... 5

Aviso De Hielo......................................................... 5

Reinicio....................................................................... 6

Precaucion..................................................................6

Ficha Técnica .............................................................6

Sobre Oregon Scientiﬁc............................................ 7

EU-Declaración De Conformidad ............................. 7

RESUMEN

VISTA FRONTAL

510

1. Indicador de recepción del sensor remoto

2. Indicador de recepción de la señal del reloj

3. Temperatura interior

4. MODE: Cambiar conﬁguración / pantalla

5. / :Subir o bajar ajuste ; activar o desactivar la

señal de recepción del reloj

6. Temperatura exterior

7. Zona horaria (sólo RMR202A)

8. Reloj con día de la semana

9. MEM: Visualizar temperatura / humedad máxima,

mínima y actuales

10. Indicador de alerta de hielo LED

VISTA TRASERA

1. °C / °F:Selección de unidad de temperatura

2. RESET:La unidad vuelve a los ajustes

predeterminados

3. EU / UK:Seleccionar la señal de radio más cercana

(sólo RMR202)



Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Termómetro de Oregon Scientific

Oregon Scientific

Oregon Scientific RAR232 Manual de usuario

Oregon Scientific

Oregon Scientific BHGR618 Manual de usuario

Oregon Scientific

Oregon Scientific EMS100 Manual de usuario

Oregon Scientific

Oregon Scientific MTR101 Manual de usuario

Oregon Scientific

Oregon Scientific RMR183 Manual de usuario

Oregon Scientific

Oregon Scientific RAR213HG Manual de usuario

Oregon Scientific

Oregon Scientific RAR188A Manual de usuario

Oregon Scientific

Oregon Scientific RMR686P Manual de usuario

Oregon Scientific

Oregon Scientific RAR188A Manual de usuario

Oregon Scientific

Oregon Scientific RMR683HGA Manual de usuario

Oregon Scientific

Oregon Scientific RMR683HG Manual de usuario

Oregon Scientific

Oregon Scientific SL101 Manual de usuario

Oregon Scientific

Oregon Scientific EMR812HGN Manual de usuario

Oregon Scientific

Oregon Scientific RMR803A Manual de usuario

Oregon Scientific

Oregon Scientific THN122N Manual de usuario

Oregon Scientific

Oregon Scientific EM-913 R Manual de usuario

Oregon Scientific

Oregon Scientific SL101 Manual de usuario

Oregon Scientific

Oregon Scientific EMR963HG Manual de usuario

Oregon Scientific

Oregon Scientific RMR182 Manual de usuario

Oregon Scientific

Oregon Scientific RGR126 Manual de usuario

Oregon Scientific

Oregon Scientific AW133 Manual de usuario

Oregon Scientific

Oregon Scientific AW133 Manual de usuario

Oregon Scientific

Oregon Scientific THT328 Manual de usuario

Oregon Scientific

Oregon Scientific NTS-912 Manual de usuario

Manuales populares de Termómetro de otras marcas

Delton

Delton 981A Manual de usuario

Baker

Baker MM2P Manual de usuario

Tarmo

Tarmo 320281 Manual de usuario

Citizen

Citizen CTD 504 Manual de usuario

TFA

TFA 14.1500 Manual de usuario

Vive

Vive DMD1010 Manual de usuario

Gotemp

Gotemp THB4002 Manual de usuario

GREISINGER

GREISINGER G 1202 Manual de usuario

Amprobe

Amprobe TMD-53W Manual de usuario

Trotec

Trotec BP10 Manual de usuario

Radiance instruments

Radiance instruments RT616 Series Manual de usuario

Eurolec

Eurolec IR151 Manual de usuario

Scaneo

Scaneo TS42B Manual de usuario

Sper scientific

Sper scientific 800043 Manual de usuario

Microlife

Microlife NC 200 Manual de instrucciones

Motorola

Motorola MBP69SN Guía de configuración

The MeatStick

The MeatStick The MeatStick Manual de usuario

Hama

Hama TH35-A Manual de usuario
