Oregon Scientific Glaze JW208 Manual de usuario

GLAZE Digital Wall Clock

Model: JW208

USER MANUAL

JW208_COVER R1.indd 1 15-6-30 下午3:35

JW208_COVER R11.indd 2 15-6-30 下午4:50

GLAZE Digital Wall Clock

Model: JW208

USER MANUAL

INDEX

Overview ................................................................... 2

Front View .............................................................. 2

Rear View .............................................................. 3

Getting Started ......................................................... 3

Insert Batteries ....................................................... 3

Placement Of Unit .................................................. 3

Clock .......................................................................... 3

Radio-Controlled Clock (RCC) Reception .............. 3

Set The Clock Manually ......................................... 4

Weather Forecast ..................................................... 4

Temperature .............................................................. 5

Precautions ............................................................... 5

Specifications ........................................................... 6

Main Unit ................................................................ 6

About Oregon Scientific .......................................... 6

EU-Declaration Of Conformity ................................ 6

FCC Statement .......................................................... 7

Information For Users .............................................. 8

JW208-OSEU_IM_EN_R5.indd 1 15-9-9 下午2:53

OVERVIEW

FRONT VIEW

1. Current time and weather display

2. : Low battery display

3. Daylight Saving Time (DST) indication

4. Current weekday display

5. : RCC signal reception indication

6. Current indoor temperature reading

7. Current date display

REAR VIEW

1. Wall mounting hole

2. SET CLOCK: Manually adjust current time and

date.

3. RCC: Enable/disable radio-controlled clock (RCC)

function.

4. EU UK US: Slide to select desired region for RCC

clock function.

5. Battery compartment

6. Battery compartment door

7. +/- Increase/decrease settings

8. °C/°F : Toggle to select desired temperature unit.

JW208-OSEU_IM_EN_R5.indd 2 15-9-9 下午2:54

9. RESET : Reset the unit to default settings.

10. Grooves for inserting the table stand

GETTING STARTED

INSERT BATTERIES

1. Remove the battery compartment door.

2. Insert the batteries, matching the polarities (+/-).

3. Press RESET after each battery replacement.

NOTE Replace the batteries when displays.

PLACEMENT OF UNIT

The clock can be mounted on a wall or stand on a flat

surface.

Method Instruction

Table Stand

Fit the table stand into the

grooves at the bottom back of

the unit.

Wall Mount

Hook the unit to the wall using

the wall mounting hole at the

back.

CLOCK

RADIO-CONTROLLED CLOCK (RCC)

RECEPTION

This clock synchronizes automatically with a RCC signal.

Slide to select the desired region (EU UK US).

Region Signal

EU DCF

UK MSF

US WWVB

RCC signal reception indicator:

Screen display Description

Searching for RCC

signal reception

Excellent signal

JW208-OSEU_IM_EN_R5.indd 3 15-9-9 下午2:54

Weak signal

No RCC signal reception

NOTE MAIN UNIT INSTALLATION

• The default time zone setting is Central (C) for the

US and +/- 0 for the EU/UK. Check your time zone

setting before receiving the RCC signal.

• It takes 2-10 minutes to receive the RCC signal. If

the signal is weak, it could take up to 24 hours to

receive a valid signal.

To enable/disable signal reception:

• Press RCC to turn on/ search the signal.

• Press and hold RCC to turn off.

SET THE CLOCK MANUALLY

1. Press and hold SET CLOCK. The screen displays

ZONE and the number flashes.

2. Press once or press and hold +/- to adjust the

setting. For EU/UK, the time-zone offset sets the

clock up to +/- 23 hours from the received clock

signal time. For US, the time-zone setting is Central

(C); Eastern (E); Atlantic (A); Newfoundland (N);

Pacific (P); Mountain (M).

3. Press SET CLOCK to confirm.

4. The settings order is: 12/24 hour format, hour,

minute, year, calendar format (day-month / month-

day), month, day, daylight saving time (DST) (auto/

off), weekday language. Press once or press and

hold +/- to adjust the setting.

NOTE

• The language options are English (ENG), French

(FRE), German (GER), Italian (ITA) and Spanish

(SPA).

• The RCC signal reception is on after each reset or

battery replacement.

• The DST auto/off setting is available for the United

States only.

• The RCC and daylight saving time (DST) are

disabled when the time/year, month or date is

changed in the setting. The DST is also disabled

when the RCC is turned off.

WEATHER FORECAST

This product forecasts the next 6 hours of weather.

Screen display Description

Sunny

JW208-OSEU_IM_EN_R5.indd 4 15-9-9 下午2:54

Cloudy

Rainy

Snowy

TEMPERATURE

To select temperature unit:

• Press °C/°F to toggle the temperature reading in the

battery compartment of the main unit.

PRECAUTIONS

• Do not subject the unit to excessive force, shock,

dust, temperature or humidity.

• Do not immerse the unit in water. If you spill liquid

on it, dry it immediately with a soft, lint-free cloth.

• Do not clean the unit with abrasive or corrosive

materials.

• Do not tamper with the unit’s internal components.

This invalidates the warranty.

• Only use fresh batteries. Do not mix new and old

batteries.

• Images shown in this manual may differ from the

actual display.

• When disposing this product, ensure it is collected

separately for special treatment and not as

household waste.

• Placement of this product on certain types of

wood may result in damage to its finish for which

Oregon Scientific will not be responsible. Consult

the furniture manufacturer’s care instructions for

information.

• The contents of this manual may not be reproduced

without the permission of the manufacturer.

• Do not dispose old batteries as unsorted municipal

waste. Collection of such waste separately for

special treatment is necessary.

• Please note that some units are equipped with a

battery safety strip. Remove the strip from the

battery compartment before first use.

NOTE The technical specifications for this product and

the contents of the user manual are subject to change

without notice. To download an electronic version of the

user manual, please visit http://global.oregonscientific.

com/customerSupport.php.

NOTE Features and accessories will not be available

in all countries. For more information, please contact

your local retailer.

JW208-OSEU_IM_EN_R5.indd 5 15-9-9 下午2:54

SPECIFICATIONS

MAIN UNIT

TYPE DESCRIPTION

L x W x H 9.69x 6.81x 1.18 in

246 x 173 x 30 mm

Weight 500 g (17.6 ounces) without

battery

Operation range -5°C to 50°C (23°F to 122°F)

Temperature

accuracy

0°C to 40°C: ±1°C (± 2.0°F)

T<0°C : ±2°C (± 4.0°F)

T>40°C : ±2°C (± 4.0°F)

Time format 24/12 Hour with AM/PM

Temperature unit °C/°F

Date format MM:DD/DD:MM

Language option English/French/German/

Italian/Spanish

Power 3 x UM-3 (AA) 1.5V batteries

(included)

ABOUT OREGON SCIENTIFIC

Visit our website www.oregonscientific.com to learn more

about Oregon Scientific products.

For any inquiry, please contact our Customer Services at

http://global.oregonscientific.com/customerSupport.php.

Oregon Scientific Global Distribution Limited reserves

the right to interpret and construe any contents, terms

and provisions in this user manual and to amend it, at

its sole discretion, at any time without prior notice.

To the extent that there is any inconsistency between

the English version and any other language versions,

the English version shall prevail.

EU-DECLARATION OF CONFORMITY

Hereby, Oregon Scientific, declares that GLAZE Digital

Wall Clock (model: JW208) is in compliance with the

essential requirements and other relevant provisions

of Directive 1999/5/EC. A copy of the signed and dated

Declaration of Conformity is available on request via our

Oregon Scientific Customer Service.

JW208-OSEU_IM_EN_R5.indd 6 15-9-9 下午2:54

COUNTRIES RTTE APPROVED COMPLIED

All EU countries, Switzerland

and Norway

FCC STATEMENT

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions: (1)

This device may not cause harmful interference, and

(2) This device must accept any interference received,

including interference that may cause undesired

operation.

WARNING Changes or modications not expressly

approved by the party responsible for compliance could

void the user’s authority to operate the equipment.

NOTE This equipment has been tested and found

to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against

harmful interference in a residential installation.

This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful

interference to radio communications. However, there

is no guarantee that interference will not occur in a

particular installation. If this equipment does cause

harmful interference to radio or television reception,

which can be determined by turning the equipment

off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and

receiver.

• Connect the equipment into an outlet on a circuit

different from that to which the receiver is connected.

• Consult the dealer or an experienced radio / TV

technician for help.

DECLARATION OF CONFORMITY

The following information is not to be used as contact

for support or sales. Please call our customer service

number (listed on our website at www.oregonscientic.

com), or on the warranty card for this product) for all

inquiries instead.

Name: Oregon Scientic, Inc.

Address: 10778 SW Manhasset Drive.

Tualatin, Oregon 97062 USA

Telephone No.: 1-800-853-8883

declare that the product

Product No.: JW208

Product Name: GLAZE Digital Wall Clock

Manufacturer: IDT Technology Limited

Address: Block C, 9/F, Kaiser Estate,

Phase 1,41 Man Yue St.,

Hung Hom, Kowloon,

Hong Kong

JW208-OSEU_IM_EN_R5.indd 7 15-9-9 下午2:54

is in conformity with Part 15 of the FCC Rules.

Operation is subject to the following two conditions: 1)

This device may not cause harmful interference. 2) This

device must accept any interference received, including

interference that may cause undesired operation.

INFORMATION FOR USERS

Pursuant to and in accordance with Article 14 of

the Directive 2012/19/EU of the European

Parliament on waste electrical and electronic

equipment (WEEE), and pursuant to and in

accordance with Article 20 of the Directive 2006/66/EC

of the European Parliament on batteries and accumulators

and waste batteries.

The barred symbol of the rubbish bin shown on the

equipment indicates that, at the end of its useful life, the

product must be collected separately from other waste.

Please note that the batteries/rechargeable batteries

must be removed from the equipment before it is given

as waste.

To remove the batteries/accumulators refer to the speci-

cations in the user manual. Therefore, any products

that have reached the end of their useful life must be

given to waste disposal centers specializing in sepa-

rate collection of waste electrical and electronic equip-

ment, or given back to the dealer when purchasing a new

WEEE, pursuant to and in accordance with Article 14 as

implemented in the country.

The adequate separate collection for the subsequent

start-up of the equipment sent to be recycled, treated

and disposal of in an environmentally compatible way

contributes to preventing possible negative effects on

the environment and health and optimizes the recycling

and reuse of components making up the apparatus.

Abusive disposal of the product by the user involves ap-

plication of the administrative sanctions according to the

laws in force.

JW208-OSEU_IM_EN_R5.indd 8 15-9-9 下午2:54

Otros manuales para Glaze JW208

Tabla de contenidos

Idiomas:

Otros manuales de Reloj de Oregon Scientific

Oregon Scientific

Oregon Scientific RM813P Manual de usuario

Oregon Scientific

Oregon Scientific NR868A-01 Manual de usuario

Oregon Scientific

Oregon Scientific JMR868 Manual de usuario

Oregon Scientific

Oregon Scientific RAR186 Manual de usuario

Oregon Scientific

Oregon Scientific WL388 Manual de usuario

Oregon Scientific

Oregon Scientific RM368P Manual de usuario

Oregon Scientific

Oregon Scientific RM802 Manual de usuario

Oregon Scientific

Oregon Scientific RM822 Manual de usuario

Oregon Scientific

Oregon Scientific PRYSMA G RRM222P Instrucciones de instalación

Oregon Scientific

Oregon Scientific RMR939P Manual de usuario

Oregon Scientific

Oregon Scientific BAR332ES Manual de usuario

Oregon Scientific

Oregon Scientific RM308P Manual de usuario

Oregon Scientific

Oregon Scientific JW108 Manual de usuario

Oregon Scientific

Oregon Scientific BARM839 Manual de usuario

Oregon Scientific

Oregon Scientific BAR223P Manual de usuario

Oregon Scientific

Oregon Scientific IWA-80055 Manual de usuario

Oregon Scientific

Oregon Scientific BAR339P Manual de usuario

Oregon Scientific

Oregon Scientific RMR939P Manual de usuario

Oregon Scientific

Oregon Scientific RM912TH Manual de usuario

Oregon Scientific

Oregon Scientific RM383PA - MANUAL 2 Manual de usuario

Oregon Scientific

Oregon Scientific BAR332ES Manual de usuario

Oregon Scientific

Oregon Scientific RMB899P Manual de usuario

Oregon Scientific

Oregon Scientific JM889NA Manual de usuario

Oregon Scientific

Oregon Scientific Imola FST-301 Manual de usuario

Manuales populares de Reloj de otras marcas

Silicon Laboratories

Silicon Laboratories SI5324 Manual de usuario

Heathkit

Heathkit GC-1005 Manual de usuario

Andrew O'Malley

Andrew O'Malley DOTKLOK Manual de usuario

ALGE-Timing

ALGE-Timing ASC3 Manual de usuario

Bodet

Bodet Profil 960 Manual de usuario

Nixie Clock

Nixie Clock Divergence Meter Manual de usuario

La Crosse Technology

La Crosse Technology WS-8256-AL Manual de usuario

Mini Gadgets

Mini Gadgets MCPro Manual de usuario

Casio

Casio TMR-200 Manual de usuario

Progetti

Progetti ILTEMPOSTRINGE Manual

BVItech

BVItech BV-101 Manual de usuario

Progetti

Progetti KALIMERO Manual

La Crosse Technology

La Crosse Technology WT-3141b Manual

La Crosse Technology

La Crosse Technology W86531 Manual de usuario

Sharp

Sharp SPC900 Manual de usuario

La Crosse Technology

La Crosse Technology 404-50447 Manual de usuario

Datexx

Datexx DF0063 Manual de usuario

LG LEC-005 Manual de usuario
