Oreck CC1605 Manual de usuario
OWNER’S
MANUAL
PORTABLE CANISTER
U414300 #961A00007 ID111867
Important: Read carefully before assembly and use.
THANK YOU
for purchasing an Oreck product
please register your product:
online at oreck.com or call 1.800.989.3535
to register by phone
If you need assistance: visit our website at oreck.com or email us at info@oreck.com
PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE.
TABLE of CONTENTS IMPORTANT SAFETY INSTRUCTIONS ................................................................................. 4
FEATURES ................................................................................................................................... 6
OPERATION ................................................................................................................................. 8
Attach the Tool Caddy ................................................................................................................... 8
Attach the Adjustable Shoulder Strap ........................................................................................ 10
Using the Vacuum ....................................................................................................................... 11
MAINTENANCE ........................................................................................................................ 12
Replacing Inner Bag .................................................................................................................... 12
Replacing the Micro Filter ........................................................................................................... 14
Replacing the HEPA Filter .....................................................................................................................................16
TROUBLESHOOTING GUIDE ................................................................................................. 17
WARRANTY .............................................................................................................................. 18
1
2
3
4
5
6
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
When using an electrical appliance, basic precautions should always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE.
WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY:
This canister vacuum is intended for household use only. If used commercially, warranty is VOID.
• Fully assemble before operating.
• Operate cleaner only at voltage specified on data plate on the bottom of the cleaner.
• Do not leave appliance unattended when plugged in. Unplug from outlet when not in use and before servicing.
• Do not use outdoors or on wet surfaces.
• Do not allow to be used as a toy. Close attention is necessary when used by or near children.
• Use only as described in this manual. Use only manufacturer’s recommended attachments.
• Do not use with damaged cord or plug. If appliance is not working as it should, has been dropped, damaged, left outdoors, or dropped into
water, return it to a service center or call customer service at 0845 603 0153
• Do not pull or carry by cord, use cord as a handle, close door on cord, or pull cord around sharp edges or corners. Do not place product on
cord. Do not run appliance over cord. Keep cord away from heated surfaces.
• Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
• This appliance can be used by children aged from 8 years and above and persons with reduced physical sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction concering use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.
• Do not handle plug or appliance with wet hands.
• Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint, hair and anything that may reduce air flow.
• Do not use to pick up flammable or combustible liquids, such as gasoline or lighter fluid, or use in areas where they may be present.
• Keep hair, loose clothing, fingers and all parts of body away from openings and moving parts.
• Do not use to pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
• Do not use without dust bag and filter in place.
• Turn off all controls before unplugging.
• Use extra care when cleaning on stairs.
• Do not use sharp objects to clean out hose as they can cause damage.
PLEASE KEEP INSTRUCTIONS FOR FURTHER USE.
THIS PRODUCT CONTAINS CHEMICALS KNOWN TO
THE STATE OF CALIFORNIA TO CAUSE CANCER AND
BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM.
WASH HANDS AFTER HANDLING.
TO REDUCE THE RISK OF DAMAGE:
AVOID PICKING UP HARD, SHARP
OBJECTS WITH THIS PRODUCT, AS
THEY MAY CAUSE DAMAGE.
TO REDUCE THE RISK OF DAMAGE:
STORE APPROPRIATELY INDOORS IN A
DRY PLACE. DO NOT EXPOSE MACHINE
TO FREEZING TEMPERATURES.
5
CAUTION!
!
!
CAUTION!
!
!
WARNING!
!
!
The wires in this mains lead are coloured
in accordance with the following code:
Blue: Neutral Brown: Live
Plug:
As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying
the terminals in your plug, proceed as follows;
The wire which is coloured Blue must be connected to the terminal which is marked with the letter N or coloured Black.
The wire which is coloured Brown must be connected to the terminal which is marked with the letter L or coloured Red.
Neither wire is to be connected to the earth pin of the 3 pin plug.
Replace fuse with same size fuse.
Adjustable shoulder strap
Upholstery tool
Large floor tool
Dusting brush
Crevice tool
Power cord
The Ultimate Handheld Canister weighs about 2.3 kg/5 lbs.
CARTON CONTENTS
A
B
C
D
E
F
G
H
Tool caddy
On/Off Switch
Carry handle with strap hooks
Slinky hose
Hose inlet
Extension wand
I
J
K
L
2. FEATURES
7
3. OPERATION
Align the middle slot and two pronged
tabs with the vacuum tab and slots.
Snap the tool caddy down into place. Load the tools onto the tool caddy.
ATTACH THE TOOL CADDY
Align the J-shaped slot at the end of
the hose with the tab inside the hose
inlet. Turn clockwise to lock into place.
Attach the tool you would like to use.
Twist and push to lock in. Twist and
pull to remove.
9
3. OPERATION
ATTACH THE ADJUSTABLE SHOULDER STRAP
Loosen the straps, and slide the clip
up or down to adjust.
To carry in a vertical position: clip each
end of the shoulder strap into the two
carry handle side slots.
To carry in a horizontal position: clip
one end of the shoulder strap into carry
handle slot. Clip the opposite end into
the bottom of the vacuum slot.
The shoulder strap can be attached in a horizontal or vertical position.
