Oracle® Talari D2000
Hardware Guide
F29960-01
March 2020
Oracle Talari D2000 Hardware Guide,
F29960-01
Copyright © 2014, 2020, Oracle and/or its affiliates. All rights reserved.
This software and related documentation are provided under a license agreement containing restrictions on use and
disclosure and are protected by intellectual property laws. Except as expressly permitted in your license agreement or
allowed by law, you may not use, copy, reproduce, translate, broadcast, modify, license, transmit, distribute, exhibit,
perform, publish, or display any part, in any form, or by any means. Reverse engineering, disassembly, or decompilation
of this software, unless required by law for interoperability, is prohibited.
The information contained herein is subject to change without notice and is not warranted to be error-free. If you find
any errors, please report them to us in writing.
If this is software or related documentation that is delivered to the U.S. Government or anyone licensing it on behalf of
the U.S. Government, then the following notice is applicable:
U.S. GOVERNMENT END USERS: Oracle programs, including any operating system, integrated software, any
programs installed on the hardware, and/or documentation, delivered to U.S. Government end users are "commercial
computer software" pursuant to the applicable Federal Acquisition Regulation and agency-specific supplemental
regulations. As such, use, duplication, disclosure, modification, and adaptation of the programs, including any operating
system, integrated software, any programs installed on the hardware, and/or documentation, shall be subject to license
terms and license restrictions applicable to the programs. No other rights are granted to the U.S. Government.
This software or hardware is developed for general use in a variety of information management applications. It is not
developed or intended for use in any inherently dangerous applications, including applications that may create a risk of
personal injury. If you use this software or hardware in dangerous applications, then you shall be responsible to take all
appropriate fail-safe, backup, redundancy, and other measures to ensure its safe use. Oracle Corporation and its affiliates
disclaim any liability for any damages caused by use of this software or hardware in dangerous applications.
Oracle and Java are registered trademarks of Oracle and/or its affiliates. Other names may be trademarks of their
respective owners.
Intel and Intel Xeon are trademarks or registered trademarks of Intel Corporation. All SPARC trademarks are used under
license and are trademarks or registered trademarks of SPARC International, Inc. AMD, Opteron, the AMD logo, and
the AMD Opteron logo are trademarks or registered trademarks of Advanced Micro Devices. UNIX is a registered
trademark of The Open Group.
This software or hardware and documentation may provide access to or information about content, products, and
services from third parties. Oracle Corporation and its affiliates are not responsible for and expressly disclaim all
warranties of any kind with respect to third-party content, products, and services unless otherwise set forth in an
applicable agreement between you and Oracle. Oracle Corporation and its affiliates will not be responsible for any loss,
costs, or damages incurred due to your access to or use of third-party content, products, or services, except as set forth in
an applicable agreement between you and Oracle.
Contents
About this Guide
My Oracle Support iv
Emergency Response iv
Revision History
1 Oracle Talari D2000 Hardware Guide
Hardware and Software Requirements 1-1
Overview 1-1
Talari APN Overview 1-1
Front Panel Configuration 1-2
Rear Panel Configuration 1-2
NIC Indicator Codes 1-2
Hardware Specifications 1-3
Installing the Talari Appliance 1-4
Rack Mounting 1-4
LAN/WAN Connections 1-4
Cabling and Bypass Mode 1-5
Powering Up the Appliance 1-5
Network Deployment Options 1-5
Installation Option: Easy 1st Install 1-6
Installation Option: Manual Install 1-7
Collecting ILOM Diagnostics for D2000 and D6000 1-8
Booting with the USB Drive 1-10
Creating a Bootable USB Drive from on Linux 1-15
Creating a Bootable USB Drive from on Windows 1-16
iii
About this Guide
This guide describes the physical characteristics of the Oracle Talari D2000 Appliance. It
includes setting up the physical connections on front panel as well as how to mount this
appliance in a rack. The intended audience of this document is a Network Administrator or a
Network Operator.
My Oracle Support
My Oracle Support (https://support.oracle.com) is your initial point of contact for all product
support and training needs. A representative at Customer Access Support can assist you with
My Oracle Support registration.
Call the Customer Access Support main number at 1-800-223-1711 (toll-free in the US), or call
the Oracle Support hotline for your local country from the list at http://www.oracle.com/us/
support/contact/index.html. When calling, make the selections in the sequence shown below on
the Support telephone menu:
1. Select 2 for New Service Request.
2. Select 3 for Hardware, Networking and Solaris Operating System Support.
3. Select one of the following options:
•For Technical issues such as creating a new Service Request (SR), select 1.
•For Non-technical issues such as registration or assistance with My Oracle Support,
select 2.
You are connected to a live agent who can assist you with My Oracle Support registration and
opening a support ticket.
My Oracle Support is available 24 hours a day, 7 days a week, 365 days a year.
Emergency Response
If a critical service situation occurs, the Tekelec Customer Care Center offers emergency
response twenty-four hours a day, seven days a week. The emergency response provides
immediate coverage, automatic escalation, and other features to ensure a rapid resolution to the
problem.
A critical situation is defined as a problem that severely affects service, traffic, or maintenance
capabilities, and requires immediate corrective action. Critical problems affect service or
system operation, resulting in:
•Failure in the system that prevents transaction processing
•Reduction in system capacity or in system traffic-handling capability
•Inability to restart the system
•Corruption of the database
About this Guide
iv
•Inability to perform maintenance or recovery operations
•Inability to provide any required critical or major trouble notification
•Any other problem severely affecting service, capacity, traffic, and billing. Maintenance
capabilities may be defined as critical by prior discussion and agreement with the Tekelec
Customer Care Center.
About this Guide
v
Revision History
Table 1 Revision history table
Date Change
June 2019 •Initial Release
October 2019 •Oracle Branding change
March 2020 •Adds ILOM Snapshot setup
and capture procedure
•Adds Creating bootable
USB drive (on Windows and
Linux) procedure
•Adds Booting with USB
drive procedure
Revision History
vi
1
Oracle Talari D2000 Hardware Guide
The following sections explain how to use your Oracle Talari D2000
Hardware and Software Requirements
Oracle Talari D2000 appliances have the following hardware and software requirements.
Hardware
D2000 appliances require a standard 19 inch (480mm) 4-post rack for mounting.
Software
The Talari Web Console is supported in latest versions of the following web browsers:
•Microsoft IE9 - IE11
•Mozilla Firefox
•Google Chrome
Supported browsers must have cookies enabled.
Supported browsers must have JavaScript installed and enabled.
Display
A minimum screen resolution of 1024 x 960 or greater is recommended.
Overview
The Oracle Talari D2000 is part of the D-series of Talari Appliances and intended for use in
data centers that demand high performance and physical resiliency. The Oracle Talari D2000
supports WAN Optimization and Easy 1st Install.
Figure 1-1 Oracle Talari D2000
Talari APN Overview
Talari Networks is redefining WAN reliability and application performance with its family of
APN Appliances by aggregating and transforming affordable broadband links to deliver
business-class performance and reliability at consumer prices. Talari APN Appliances (APNAs)
are seamlessly added to existing networks to deliver more bandwidth, reduced WAN operating
expenses, and greater reliability than any existing single-provider WAN.
1-1
Using our patented Adaptive Private Network technology, Talari’s solution combines diverse,
abundant, affordable IP bandwidth sources, and provides reliable, resilient and high-quality
connectivity between sites, insuring application continuity. Talari APNAs deployed in the main
office and remote offices provide a network of Conduits between sites. Each Conduit is made
of multiple WAN links and data transmitted across the Conduits is controlled and optimized to
use network resources available across all WAN Links.
Front Panel Configuration
For more information on the front panel status indicators, please see the Oracle Server X7-2
Service Manual.
Rear Panel Configuration
Table 1-1 Ports
1 Gigabit Ethernet (Bypass pair with Port 2)
2 Gigabit Ethernet (Bypass pair with Port 1)
3 Gigabit Ethernet (Bypass pair with Port 4)
4 Gigabit Ethernet (Bypass pair with Port 3)
5 Gigabit Ethernet (Bypass pair with Port 6)
6 Gigabit Ethernet (Bypass pair with Port 5)
7 Gigabit Ethernet (Bypass pair with Port 8)
8 Gigabit Ethernet (Bypass pair with Port 7)
MGT Dedicated network management port
9 1/10 Gigabit SFP+ (non-bypass)
10 1/10 Gigabit SFP+ (non-bypass)
Console RJ45 console port (9600/8-N-1). Used for service
and maintenance.
NIC Indicator Codes
All Ethernet ports on the D2000 have indicator lights for information on network activity and
link status.
Chapter 1
Front Panel Configuration
1-2
Table 1-2 MGT
Indicator Location Color Meaning
Activity Left Green On: Link up
Off: No activity
Blinking: Packet
Activity
Link Speed Right Green Off: 10/100 Mbps
On: 1Gbps
Table 1-3 Ports 1 - 8
Indicator Location Color Meaning
Activity Left Green Off: No activity
Blinking: Packet
Activity
Link Speed Right Amber/Green Off: No activity/10
Mbps
Green: 100 Mbps
Amber: 1 Gbps
Table 1-4 Ports 9 - 10
Indicator Location Color Meaning
Activity Top Green Off: No activity
Blinking: Packet
Activity
Link Speed Bottom Amber Off: No activity
Amber: 10 Gbps
Hardware Specifications
The D2000 has the following hardware specifications.
Power Redundant 1200 watt power supply
100-240V
50-60 Hz
Estimated BTU Per Hour Active idle: 416 BTU/hr
50% Workload: 549 BTU/hr
90% Workload: 659 BTU/hr
Physical Dimensions Height 1.68” (42.6mm)
Width 18.9” (482mm)
Depth 29.02” (737mm)
Gross Weight 40 lbs (18.1kg)
Mounting Options Rack mount, rail kit (included)
Chapter 1
Hardware Specifications
1-3
System LEDs See Oracle Server X7-2 Service Manual
Link LEDs Link activity
Link speed
Operating Temperature 41°F to 95°F (5° to 35°C)
Storage Temperature -40°F to 154°F (-40°C to 68°C)
Humidity Range 10% to 90% (non-condensing) operating
environment
Network Data Interfaces 8 Gigabit Ethernet Fail-To-Wire Ports
2 1/10-Gigabit Ethernet SFP+ Ports
Other interfaces 1 Gigabit Ethernet Management Port
1 USB 3.0 port
1 RJ-45 Console Port
Installing the Talari Appliance
Rack Mounting
Prior to installing the device, adhere to the following installation guidelines:
•Ensure that there is adequate airflow in the rack. Restricted airflow can damage the
equipment.
•Leave at least 1U of vertical space between each device installed in the rack.
•The rack width and depth should allow for proper serviceability and cable management.
•Ensure the rack is properly secured to the floor or ceiling.
•Ensure the rack is properly grounded.
•Ensure the installer is properly grounded and wearing appropriate safety equipment.
•Always load the rack from the bottom up.
•Load the heaviest devices in the rack first.
•Make sure the rack is level and stable before pulling a device out of the rack.
•Do not move racks by yourself; at least two people are recommended to move a rack.
•Cables should be easily identifiable.
Please refer to the Oracle® Servers X7-2 and X7-2L Installation Guide for additional appliance
specifications and detailed rackmounting instructions: https://docs.oracle.com/cd/E72435_01/
html/E72440/index.html.
LAN/WAN Connections
When connecting each Ethernet cable (LAN, WAN) to the appropriate connector on the D2000.
•Position the cables carefully, so that they do not put strain on the connectors.
•Organize cables in bundles such that cables do not intertwine.
•Inspect the cables to make sure that the routing and bend radii are satisfactory. Reposition
cables, if necessary.
Chapter 1
Installing the Talari Appliance
1-4
