Optimus SCP-104 Manual de usuario
Cat. No. 14-1256
OWNER’S MANUAL
Please read before using this equipment.
SCP-104
Stereo Cassette Player
with Headphones
14-1256.fm Page 1 Thursday, July 8, 1999 2:22 PM
2
FEATURES
Your Optimus SCP-104 Stereo Cassette Player delivers ex-
cellent sound from your favorite cassette tapes. You can use
the supplied stereo headphones for private listening or con-
nect amplified speakers (not supplied) to share the sound
with others.
Its features include:
Auto Stop Cassette Deck — turns off the power at the end
of a tape side during normal playback, to conserve power and
protect the motor.
Bass Boost (E-Bass) — lets you emphasize the bass
sounds to suit your listening preferences.
Jack — lets you connect headphones for private listen-
ing, or speakers to share the sound with others.
Removable Belt Clip — lets you attach the SCP-104 to your
belt for hands-free carrying when you are on the go.
©1999 Tandy Corporation.
All Rights Reserved.
Optimus and RadioShack are registered trademarks used by Tandy Corporation.
14-1256.fm Page 2 Thursday, July 8, 1999 2:22 PM
3
CONTENTS
Features .............................................................................. 2
Preparation ......................................................................... 4
Using the Belt Clip ........................................................ 4
Installing Batteries ........................................................ 4
Connecting the Headphones or Amplified Speakers .... 6
Listening Safely ..................................................... 6
Traffic Safety .......................................................... 7
Operation ............................................................................ 8
Care ................................................................................... 10
Cleaning the Tape-Handling Parts .............................. 11
Restoring Tape Tension and Sound Quality ............... 12
Specifications .................................................................. 13
14-1256.fm Page 3 Thursday, July 8, 1999 2:22 PM
4
PREPARATION
USING THE BELT CLIP
To attach the belt clip, align it with the slots on the back of the
SCP-104, then slide the clip in the opposite direction of the
arrow until it snaps into place.
To remove the belt clip, lift the tab and slide it off in the direc-
tion of the arrow.
INSTALLING BATTERIES
Your cassette player requires two AA batteries (not supplied)
for power. For the best performance and longest life, we rec-
ommend RadioShack alkaline batteries.
Cautions:
• Use only fresh batteries of the required size and recom-
mended type.
• Do not mix old and new batteries, different types of bat-
teries (standard, alkaline, or rechargeable), or recharge-
able batteries of different capacities.
Lift Up
14-1256.fm Page 4 Thursday, July 8, 1999 2:22 PM
5
Follow these steps to install batteries.
1. Slide the battery compartment cover in the direction of
the arrow to remove it.
2. Place the batteries in the compartment and on top of the
attached ribbon, as indicated by the polarity symbols (+
and –) marked on the back of the SCP-104.
3. Replace the cover.
When the sound becomes distorted or weak, or the cassette
player stops operating properly, replace the batteries.
Warning: Dispose of old batteries promptly and properly. Do
not burn or bury them.
Caution: If you do not plan to use the cassette player for a
week or more, remove the batteries. Batteries can leak chem-
icals that can destroy electronic parts.
Battery Compartment
Cover
14-1256.fm Page 5 Thursday, July 8, 1999 2:22 PM
6
CONNECTING THE HEADPHONES OR
AMPLIFIED SPEAKERS
For private listening, connect the supplied stereo head-
phones’
1/8-inch plug to the SCP-104’s jack. To share the
music with others, you can connect amplified speakers
(not supplied) with a 1/8-inch (3.5-mm) plug. Your local
RadioShack store carries a wide selection of headphones
and amplified speakers.
Listening Safely
To protect your hearing, follow these guidelines when you
use headphones.
• Set the volume to the lowest setting before you begin lis-
tening. After you begin listening, adjust the volume to a
comfortable level.
• Do not listen at extremely high volume levels. Extended
high-volume listening can lead to permanent hearing
loss.
E-Bass
E-Bass
14-1256.fm Page 6 Thursday, July 8, 1999 2:22 PM
7
• Once you set the volume, do not increase it. Over time,
your ears adapt to the volume level, so a volume level
that does not cause discomfort might still damage your
hearing.
Traffic Safety
Do not wear headphones while operating a motor vehicle or
riding a bicycle. This can create a traffic hazard and can be il-
legal in some areas.
Even though some headphones let you hear some outside
sounds when listening at normal volume levels, they still can
present a traffic hazard.
14-1256.fm Page 7 Thursday, July 8, 1999 2:22 PM
8
OPERATION
Make sure that you have connected headphones or speakers
to the SCP-104 before playing a cassette tape. See “Con-
necting the Headphones or Amplified Speakers” on Page 6.
Caution: We do not recommend using C-120 cassette tapes.
They are very thin and can easily become tangled in the
tape-handling parts.
1. Take up any slack in the cassette tape by turning its hub
with your finger or a pencil. If you do not remove excess
slack, the tape might become tangled in the play mecha-
nism. Avoid touching the tape.
2. Pull open the cassette compartment door.
3. Slide the cassette tape into the guides in the cassette
compartment door with the tape's open edge facing up,
the side you want to hear facing out, and the full reel to
the right. Then close the door.
14-1256.fm Page 8 Thursday, July 8, 1999 2:22 PM
9
4. Press PLAY to play the tape.
5. Adjust VOLUME to a comfortable listening level.
6. Set E-BASS ON/OFF to ON to emphasize the bass sound,
or to OFF to leave the bass sound unchanged.
7. To stop the tape before it automatically stops, press
STOP
.
To fast-forward the cassette tape, press F.FWD. The button
locks down and the tape advances rapidly. When you reach
the desired section of tape, press STOP then PLAY to resume
play.
To rewind the tape, turn the tape over and press F.FWD.
14-1256.fm Page 9 Thursday, July 8, 1999 2:22 PM
10
CARE
To enjoy your Optimus SCP-104 Stereo Cassette Player for a
long time:
• Keep the cassette player dry. If it gets wet, wipe it dry
immediately.
• Use and store the cassette player only in normal temper-
ature environments.
• Handle the cassette player gently and carefully. Don’t
drop it.
• Keep the cassette player away from dust and dirt.
• Wipe the cassette player with a damp cloth occasionally
to keep it looking new.
Modifying or tampering with the cassette player’s internal
components can cause a malfunction and invalidate its war-
ranty. If your cassette player is not performing as it should,
take it to your local RadioShack store for assistance.
14-1256.fm Page 10 Thursday, July 8, 1999 2:22 PM
