ONV ONV-IoT9000 Manual de usuario
ONV-IoT9000 IoT Intelligent Box Product
Manual
Packing List
IoT Intelligent control box (1 set)
Installation accessories (1 set)
Sheet metal (hanging ears) / box door key /warranty card
First, safety precautions
To ensure the safety of people and equipment, when installing, operating, and maintaining the equipment,
follow the signs on the equipment and the safety precautions described in the manual. “Warnings” and
“notes” in this manual do not represent all safety precautions that should be followed, and are only
supplementary to safety precautions.
When carrying out various operations of our equipment, we must strictly observe the relevant equipment
precautions and special safety instructions provided by ONV company. The "safety warnings" listed in the
manual only reflect the requirements of ONV company. The safety requirements have not been
reflected, and ONV company will not bear any responsibility for the loss caused by the violation of the
general safety operation requirements or the violation of the design production and use equipment safety
standards.
Note
This intelligent box is a Class A product. In the living environment, this product may cause radio interference.
In this case, users need to take practical measures for their interference.
Class A products are EMC class A certified products.
During transportation, handling, and installation, avoid collisions between the device and objects such as
doors, walls, and shelves.
■ Description
The figures in this document are for reference only. The appearance of the device is subject to actual delivery.
Second, the installation environment requirements
The intelligent box support outdoor pole mounting.
The temperature and humidity of the installation site must be kept within the temperature and humidity
range in which the smart box can work normally. For the normal temperature range and relative humidity
range of the smart box, refer to the intelligent box product datasheet.
The grounding cable of the intelligent box is an important step in the installation process. The correct
connection of the grounding cable of the intelligent box is an important guarantee for lightning protection,
interference prevention, and anti-static damage of the intelligent box.
Third, lightning protection requirements
Do not use outdoor overhead wiring. The equipment may be damaged by lightning. Please use buried or
steel pipe wiring.
Before turning on the power, the machine must be grounded to ensure that the grounding resistance of
the installation environment does not exceed 10Ω, otherwise the equipment or the docking equipment
may be damaged.
Fourth, pre-commissioning
The ONV IoT intelligent box is modular in design, which can be flexibly configured according to the actual
needs of the project, and the optimal matching function module is selected by adding/reducing. If the
intelligent box needs to be commissioned, it is recommended to complete it before the smart box is
installed on the pole.
The following is a diagram of the internal wiring of the intelligent box for participation
ONV IoT intelligent box equipment support managed PoE switch module for network transmission. You
can pre-configure the PoE switch network management function according to the following operations.
(This item is ignored for intelligent boxes without PoE switch)
4.1 Log in to the device for the first time through the web system
Know before you log in
If the web page is displayed abnormally, the browser version may be too low. Please upgrade your browser
and recommend Google chrome first. For detailed requirements, please refer to the configuration guide (Web
Network Management) of the corresponding product.
Login steps
1. Power on the intelligent box and confirm that the network module is working normally.
2. Use a network cable to connect the computer to any Ethernet port on the Ethernet switch.
3. Configure the computer's IP address to be on the same network segment as the default IP address of the
Ethernet switch.
4. Open a browser on your computer, enter 192.168.2.1 in the address bar, and press Enter to display the
web network management login interface. Enter the default user name “admin”and password“system”.
click“OK” or press “Enter” to enter the web network management configuration interface.
5. Configure the Ethernet switch. The web network management configuration interface provides basic and
optional configurations of the device. After the user has configured the basic configuration, he can log in
to the device through the web network management. After the optional configuration is configured, he can
log in to the device through Telnet. Only the content of basic configuration is introduced here. For the
content of optional configuration and more product information, please refer to the configuration guide of
the corresponding product.
4.2 Log in to the device for the first time through the console port
Know before you log in
The console cable is not shipped with the device and must be purchased separately.
Please prepare third-party terminal emulation software (Secure CRT software). For usage, please refer to
the software's instruction or online help.
Login steps
1. Power on the intelligent box and confirm that the working indicator of the Ethernet switch module is on
normally.
2. Connect a computer (PC) to the console port of the Ethernet switch using a console cable.
3. Open the terminal emulation software on the computer, create a new connection, set the connection port
and communication parameters. The communication parameter configuration of the computer terminal
must be consistent with the default configuration of the console port of the Ethernet switch.
Transmission rate: 115200
Data bits: 8
Calibration method: None
Stop bit: 1
Flow control mode: None
4. Press“Enter”until the following terminal appears on the emulation terminal, prompting the user to enter
a username and password. When logging in for the first time, the default user name is“admin”and the
password is“system”.
Passwords entered interactively are not displayed on the terminal screen. you can now type commands
to configure the device. For more information, refer to the configuration guide for the corresponding
product.
